DES-1012
10/100 Fast Ethernet Switch
User's Guide
Rev. 01 (January, 1998)
6DES1012..01
Printed In Taiwan
RECYCLABLE

Advertisement

Table of Contents
loading

Summary of Contents for D-Link DES-1012

  • Page 1 DES-1012 10/100 Fast Ethernet Switch User’s Guide Rev. 01 (January, 1998) 6DES1012..01 Printed In Taiwan RECYCLABLE...
  • Page 2: Wichtige Sicherheitshinweise

    Wichtige Sicherheitshinweise Bitte lesen Sie sich diese Hinweise sorgfältig durch. Heben Sie diese Anleitung für den spätern Gebrauch auf. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Vervenden Sie keine Flüssig- oder Aerosolreiniger. Am besten dient ein angefeuchtetes Tuch zur Reinigung. Um eine Beschädigung des Gerätes zu vermeiden sollten Sie nur Zubehörteile verwenden, die vom Hersteller zugelassen sind.
  • Page 3 Return Material Authorization (RMA) number. If a Registration Card for the product in question has not been returned to D-Link, then a proof of purchase (such as a copy of the dated purchase invoice) must be provided. If Purchaser's circumstances require special handling of warranty correction, then at the time of requesting RMA number, Purchaser may also propose special procedure as may be suitable to the case.
  • Page 4 D-Link Offices for Registration and Warranty Service The product's Registration Card, provided at the back of this manual, must be sent to a D-Link office. To obtain an RMA number for warranty service as to a hardware product, or to obtain warranty service as to a software product, contact the D-Link office nearest you.
  • Page 5: Fcc Warning

    Trademarks All rights reserved, contents subject to change without prior notice. Ethernet is a trademark of Xerox Corporation. Microsoft Windows is a trademark of Microsoft Corporation. All other trademarks belong to their respective proprietors. FCC Warning This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
  • Page 7: Table Of Contents

    Power Failure ... 8 IDENTIFYING EXTERNAL COMPONENTS... 9 ... 9 RONT ANEL ... 10 ANEL LED I ... 11 NDICATORS CONNECTING THE SWITCH... 13 ... 13 WITCH ... 14 UB TO WITCH 10Base-T Hub ... 15 100Base-TX Hub... 15 (MDI-II) UB WITHOUT PLINK Using a Straight Cable...
  • Page 8 10/100 Fast Ethernet Switch User’s Guide Using a Crossover Cable ... 16 ONFIGURING THE WITCH TO WITCH THER Using a Straight Cable... 18 Using a Crossover Cable ... 18 ONSOLE ANAGEMENT Overview ... 19 Setting Up a Console Device ... 19 Navigating the Console Program Screens ...
  • Page 9: About This Guide

    Terms/Usage For simplicity, this documentation uses the terms “Switch” (first letter upper case) to refer to your DES-1012 Fast Ethernet Switch, and “switch” (first letter lower case) to refer to all Ethernet switches, including your DES-1012. Overview of this User’s Guide Chapter 1, Introduction .
  • Page 10 10/100 Fast Ethernet Switch User’s Guide Chapter 4, Connecting the Switch . Tells how you can connect the your Switch to your Ethernet network. Appendix A, Technical Specifications. Lists the technical (general, physical and environmental, and performance) specifications of the Switch.
  • Page 11: Introduction

    10/100 Fast Ethernet Switch User’s Guide NTRODUCTION This section describes the features of the DES-1012, as well as giving some background information about Ethernet and Fast Ethernet switching technology. Fast Ethernet Technology The growing importance of LANs and the increasing complexity of desktop computing applications are fueling the need for high performance networks.
  • Page 12: Switching Technology

    Ethernet or Fast Ethernet LAN segments. Switching is a cost-effective way of increasing the total network capacity available to users on a local area network. A switch increases capacity and decreases network loading by making it possible for a local area network to be divided into different segments which don’t compete with each other for...
  • Page 13: Features

    200Mbps full duplex, the Switch can be cascaded from any port and to any number of switches. The Switch is a perfect choice for site planning to upgrade to Fast Ethernet in the future. Ethernet workgroups can connect to the Switch now, and change adapters and hubs anytime later without needing to change the Switch or reconfigure the network.
  • Page 14: Performance Features

    Ports Parallel Store-and-forward Architecture Provides High-Speed Switching scheme LEDs for Easy Recognition of the Switch Operating Status Optional DMA Port for a 100BASE-FX SC type module (paired with Port Console Port for easy Troubleshooting and Management Complete Frame Checking & Error Filtering...
  • Page 15: Unpacking And Setup

    This chapter provides unpacking and setup information for the Switches. Unpacking Open the shipping carton of the Switch and carefully unpack its contents. The carton should contain the following items: One DES-1012 Fast Ethernet Switch One AC power cord This User’s Guide...
  • Page 16: Setup

    Switch. Rack Installation The Switch can be mounted in an EIA standard size, 19-inch rack, which can be placed in a wiring closet with other equipment. To install, attach the mounting brackets on the switch’s front panel (one on each side) and secure them with the screws provided.
  • Page 17: Power On

    Figure 1B, Installing the Switch in an equipment rack Power On The Switch can be used with AC power sources 100 to 240 VAC, 50 to 60 Hz. The power switch is located at the rear of the unit adjacent to the AC power connector and the system fan.
  • Page 18: Power Failure

    10/100 Fast Ethernet Switch User’s Guide Power Failure As a precaution, the Switch should be turned OFF in case of a power failure. Press the power switch to the off or “0” position. When power is resumed, turn the Switch ON . At all times, avoid leaving the Switch ON after the occurrence of a power failure.
  • Page 19: Identifying External Components

    This chapter describes the front panel, rear panel and LED indicators of the Switch. Front Panel The front panel of the Switch consists of 12 (10/100 Mbps MDI-X) ports, one Uplink (MDI-II) port and LED indicators. Descriptions of the ports appear in the Introduction of this User’s Guide.
  • Page 20: Rear Panel

    Dip Switch. Use this Dip switch to set the duplex mode. Each port in the DES-1012 can be set for half duplex or full duplex mode. To set a port in full duplex mode, slide the corresponding switch up . To set it in half duplex mode, slide the corresponding switch down .
  • Page 21: Led Indicators

    Supported input voltages range from 100 ~ 240 VAC at 50 ~ 60 Hz. Power Switch. This turns the Switch on and off. To turn on the system, press the switch to the “1” position; to turn off, press the switch to the “0”...
  • Page 22 10/100 Fast Ethernet Switch User’s Guide indicators blink green whenever there is reception or transmission (i.e. Activity act) of data occurring at a port. FDX/Col . This LED indicator is green when a respective port is in full duplex (FDX) mode. Otherwise, it is OFF for half duplex (HDX) operations.
  • Page 23: Connecting The Switch

    10/100 Fast Ethernet Switch User’s Guide ONNECTING WITCH This chapter describes how to connect the DES-1012 to your Fast Ethernet network. PC to Switch A PC can be connected to the Switch via a two-pair Category 3, 4, 5 UTP /STP straight cable.
  • Page 24: Hub To Switch

    3. The FDX/Col LED indicator depends upon LAN card capabilities. Hub to Switch A hub (10 or 100Base-TX) can be connected to the Switch via a two-pair Category 3, 4, 5 UTP/STP straight cable. The connection is accomplished from the hub uplink (MDI-II) port to any of the Switch (MDI-X) ports.
  • Page 25: 100Base-Tx Hub

    (see Appendix A , Technical Specifications for cable requirements). Figure 7, The Switch connected to a Hub without an uplink (MDI- II) port using the Straight or crossover cable option Connecting the Switch 10/100 Fast Ethernet Switch User’s Guide...
  • Page 26: Using A Straight Cable

    Using a Straight Cable When using straight cable, the connection can be made from the uplink (MDI-II) port of the Switch to any port of the Hub (see figure 7 ) . Using a Crossover Cable When using crossover cable, the connection can be made from any port of the Switch to any port of the Hub (see figure 7).
  • Page 27: Switch To Switch (Other Devices)

    NOTE : The default communication mode of the Switch is: auto- negotiation (On), and HDX (Dip switch down) . Switch to Switch (Other Devices) DES-1012 can be connected to another switch or other devices (routers, bridges, etc.) via a two-pair Category 3, 4, 5 UTP/STP straight or crossover cable.
  • Page 28: Using A Crossover Cable

    Overview The console program allows you to manage the DES-1012 and monitor its performance. You have to access this program through a direct connection between a management console and the console port of the DES-1012. The management console used for the connection can be a VT-100 terminal or a PC running terminal emulation software.
  • Page 29: Navigating The Console Program Screens

    Data Bits—8 Stop Bit—1 Turn on the DES-1012. When you enter the main screen of the terminal, press the <Enter> or <Esc> key once to start communication. If the connection is successful, the console program Main Menu will appear on the screen.
  • Page 30 10/100 Fast Ethernet Switch User’s Guide Disable a function or select 10Mbps Enable a function or select 100Mbps Go back to the main menu While following steps in these sections, you may find the screen map below S : goto system sub menu V : D isplay H /W &...
  • Page 31: Configuring The Console

    With the System Submenu, you can perform the following: V: Display the Hardware and Firmware version numbers . This is a view- only screen showing the hardware and software version of the switch. Figure 11, Version Number Screen Connecting the Switch...
  • Page 32 10/100 Fast Ethernet Switch User’s Guide S: Display slide-in module status . This indicates the status of the slide-in module. If there is no module installed, the field will read, slide-in module is Absent.” If there is a module installed, this field will display the type of slide-in module.
  • Page 33 Each port in the 12-port NWay switch can be set for half duplex or full duplex mode. You need to set the Duplex mode through the Dip switch at the rear of the device. To set a port in full- duplex mode, slide the corresponding switch up. To set it in half- duplex mode, slide the corresponding switch down.
  • Page 34 10/100 Fast Ethernet Switch User’s Guide Figure 13, Set port ENABLE/DISABLE Because the following four functions have the similar screens that let you specify. Displayed here is the screen for E: set port ENABLE/DISABLE. E: Set port ENABLE/DISABLE . This is the operating status of the port.
  • Page 35: Port Counter

    Figure 14, Counters for Port 2 NOTE : Any changes you make to a specific port will clear the counters of that port and return that port counter to the default settings. Connecting the Switch 10/100 Fast Ethernet Switch User’s Guide...
  • Page 36 10/100 Fast Ethernet Switch User’s Guide Parameters in this screen are described in the following table. Field Description TX Packet Count The number of packets that have been transmitted successfully by the selected port. Packets are from 64-1518 bytes, including the CRC.
  • Page 37 1,518 bytes long and had either a CRC error or an alignment error. Collision PKT The number of collisions that occurred on the Count segment connected to the selected port. Connecting the Switch 10/100 Fast Ethernet Switch User’s Guide...
  • Page 38: Technical Specifications

    10/100 Fast Ethernet Switch User’s Guide General Standards: IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100 Base-TX/FX Fast Ethernet ANSI/IEEE Std 802.3 NWay auto-negotiation IEEE 802.3 Frame types: Transparent IEEE 802.3 MAC layer frame size: 64 - 1518 Bytes Protocol: CSMA/CD...
  • Page 39 40 watts maximum Consumption: DC fans: 1 built-in 40x40 mm fan Operating 32° ~ 122° F (0° ~ 50° C) Temperature: Storage -22° ~ 140° F (-30° ~ 60° C) Temperature: RJ-45 Pin Specification 10/100 Fast Ethernet Switch User’s Guide...
  • Page 40 10/100 Fast Ethernet Switch User’s Guide Humidity: 5% ~ 95% non-condensing Dimensions: 442x258x44 mm (1U) Weight: 2.5 Kg EMI: FCC Class A, CE Mark Class A, VCCI Class A Safety: UL (UL 1950), CSA (CSA950), TUV/GS (EN60950) Transmission Method: RAM Buffer:...
  • Page 41 10/100 Fast Ethernet Switch User’s Guide RJ-45 P PECIFICATION When connecting your 10/100 Fast Ethernet Switch to another switch, a bridge or a hub, a modified crossover cable is necessary. Please review these products for matching cable pin assignment. following...
  • Page 42: Rj-45 Pin Specification

    The standard Category 3 cable, RJ-45 pin assignments The following shows straight cable and crossover cable connection: Straight cable for Switch (uplink MDI-II port) to switch/Hub or Crossover cable for Switch (MDI-X port) to switch/hub or other network devices (MDI-X port) connection Media Direct Interface Signal...
  • Page 43 How to Install the DES-112FX 100BASE-FX module Unplug power code. Unscrew and remove the cover slot from the real panel of the DES-1012. Slide-in and securely screw the 100BASE-FX module into the open slot of the DES-1012. Attach the Fiber Optic cable to the 100BASE-FX module.
  • Page 44 2180 Dunwin Drive, Unit # 6, Mississauga Ontario, L5L 5M8, Canada TEL: 1-905-828-0260 FAX: 1-905-828-5669 U.K. D-LINK (EUROPE) LTD. D-Link House, 6 Garland Road, Stanmore, London HA7 1DP U.K. TEL: 44-181-235-5555 FAX: 44-181-235-5500 GERMANY D-LINK (DEUTSCHLAND) GMBH I.G. Bachstraße 2265812 65830 Kriftel, Germany...
  • Page 45: Registration Card

    3. What network protocol(s) does your organization use ? †XNS/IPX †TCP/IP †DECnet †Others_____________________________ 4. What network operating system(s) does your organization use ? †D-Link LANsmart †Novell NetWare †NetWare Lite †SCO Unix/Xenix †PC NFS †3Com 3+Open †Banyan Vines †DECnet Pathwork †Windows NT †Windows NTAS †Windows '95 †Others__________________________________________ 5.
