Standard
+ IEEE 802.3z compliance
High Performance Architecture
+ Supports Full-Duplex operation only
Transceivers Supported
+ SFP compliant
Technical Specifications
Product specifications
Standard
LEDs
Physical and Environmental
Dimension
Weight
Heat Dissipation
Power Consumption
Operating Temperature
Storage Temperature
Operating Humidity
Storage Humidity
Certifications
Warranty
Ordering Information
DES-6509
DES-6500
Supported SFPs
DEM-310GT
DEM-311GT
DES-6509
12-Port 1000BASE-X SFP Module
Overview
The DES-6509 is a 12-port SFP Module for the D-Link
6500 chassis. It uses standards-based 802.3z Gigabit SFP
transceivers to meet the demands of today's enterprise and
service provider networking infrastructure. The DES-6509
is the perfect solution for uplinking to servers, storage, or
department level switches such as D-Link xStack
DXS-3200. Fiber media is a great solution because it allows
IEEE 802.3z
+ Power
+ System
+ Link/Activity
13 in x 11.07in x 1.08in
2.51lbs
68.24BTU/hr
20 Watts Max.
0° – 104° F (0° - 40°C)
-14° – 131°F (-10° - 55°C)
5% - 95% non-condensing
5% to 95%, non-condensing
+ FCC Class A
+ CE mark
+ CSA International
1-Year Limited
1
12-Port 1000BASE-X SFP Module For DES-6500 Chassis
9-Slot Layer 2/3/4 Chassis Switch
1000BASE-LX Mini Gigabit Interface Converter
1000BASE-SX Mini Gigabit Interface Converter
1-Year Limited Warranty available only in the USA and Canada.
1
Latest documentation is available at http://support.dlink.com
for increased distances over copper cabling. When used with
D-Link DEM-310GT SFP fiber transceiver, a total distance of
DES-
®
up to 6.2 mi (10km) can be reached, which is often necessary
when running across larger distances such as campuses
or multi-building environments. If your situation consists of
shorter distances, the DEM-311GT transceiver from D-Link
provides Gigabit Multimode connection at distances of up to
1800 ft (550 m).
D-Link Systems, Inc. 17595 Mt. Herrmann Street Fountain Valley CA 92708 www.dlink.com
©2005-2006 D-Link Corporation/D-Link Systems, Inc. All rights reserved. D-Link and the
D-Link logo are registered trademarks of D-Link Corporation or its subsidiaries in the
United States and other countries. Other trademarks or registered trademarks are the
property of their respective owners. Visit www.dlink.com for more details.
Hardware version B1/B2
