Page 17
产品设置 微波炉安装 (如果设备与本手册中的图片有任何差异,以产品为准。) 微波炉零件和配件名称 从纸箱和炉腔中取出微波炉和所有材料。 转盘装置 玻璃转盘 使用说明书 A. 控制面板 E. 炉门装置 B. 玻璃转盘 F. 观察窗 C. 转盘轴 G. 安全联锁系统 D. 转盘装置 H. 波导盖 CN-14...
Page 19
台面安装 移除所有包装材料和附件。检查微波炉是否有任何损坏,如凹痕或炉门破裂。如果微波炉损 坏,请勿安装。 柜体:清除微波炉柜体表面所有的保护膜。连接在微波炉腔体上的波导盖用以保护磁控管, 请勿拆卸。 安装 1. 选择一个水平表面,为进气和/或排气口提供足够的开放空间。 a. 最小安装高度为85cm。 b. 设备的后表面应靠墙放置。在微波炉上方留出至少30cm的空间。微波炉和任何相邻 墙壁之间至少需要20cm的空间。 c. 不要从微波炉底部取下支腿。 d. 堵塞进气口和/或出气口会造成微波炉损坏。 e. 将微波炉放置在尽可能远离收音机和电视机的地方。 微波炉工作时可能对会干扰收音机或电视机的信号接收。 30 cm 0 cm 20 cm 20 cm > 85 cm 将微波炉插到标准家用插座上。确保其电压和频率与额定值标签上的电压和频率相同。 • 请勿将微波炉安装在炉灶或其他发热电 器上。如果安装在热源附近或上方,微 波炉可能会被损坏,此损坏不在保修范 注意 围内。 操作过程中, 可触及的表面会发烫 CN-16...
Page 35
INSTRUCTION MANUAL MICROWAVE OVEN MW3-EM20PE(BK) Please review this instruction manual before operating.
Page 36
CONTENTS PRODUCT SAFETY Precautions to avoid possible exposure to excessive microwave energy ........EN-01 Speci cations ............................EN-02 Important safety instructions ........................EN-03 To reduce the risk of injury to persons grounding installation ............EN-07 Cleaning ................................EN-09 Utensils .................................. EN-10 Materials you can use in microwave oven ....................
Page 37
11. Lock function ........................... EN-26 12. Eco function ........................... EN-26 13. Mute function ............................EN-26 14. Auto menu ............................EN-27 CLEANING AND MAINTENANCE Cleaning ................................EN-28 Trouble shooting ............................... EN-30 BEFORE OPERATING THIS PRODUCT, READ, UNDERSTAND, AND FOLLOW THESE INSTRUCTIONS. BE SURE TO SAVE THIS BOOKLIST FOR FUTURE NOTE REFERENCE.
PRODUCT SAFETY PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a). Do not attempt to operate this oven with the door open since this can result in harmful exposure to microwave energy. It is important not to break or tamper with the safety interlocks. (b).
IMPORTANT SAFETY INSTRUCTIONS persons or exposure to excessive microwave oven energy when using your appliance, follow basic WARNING precautions, including the following: Read and follow the Children should be PRECAUTIONS supervised to ensure that TO AVOID POSSIBLE they do not play with the EXPOSURE TO EXCESSIVE appliance.
Page 41
IMPORTANT SAFETY INSTRUCTIONS WARNING: It is hazardous If smoke is emitted, switch for anyone other than a competent person to carry and keep the door closed out any service or repair operation that involves the removal of a cover which Microwave heating of gives protection against beverages can result in...
Page 42
IMPORTANT SAFETY INSTRUCTIONS The microwave oven must The oven should be be operated with the cleaned regularly and any decorative door open. (for food deposits removed. ovens with a decorative Please keep the waveguide door.) area clean. Use soft damp cloth to clean it up when This appliance is intended there is food splash residue...
Page 43
IMPORTANT SAFETY INSTRUCTIONS The appliance is intended decorative door in order to be used freestanding. to avoid overheating. (This is not applicable for appliances with decorative The rear surface of door.) appliances shall be placed against a wall. The microwave oven shall not be placed in a cabinet Eggs in their shell and unless it has been tested in...
TO REDUCE THE RISK OF INJURY TO PERSONS GROUNDING INSTALLATION This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a grounding wire with a grounding plug.
Page 45
TO REDUCE THE RISK OF INJURY TO PERSONS GROUNDING INSTALLATION Electric Shock Hazard: Improper use of the grounding can result in electric shock. Do not plug into an outlet until appliance is properly installed and grounded. 1. A short power-supply cord is provided to reduce the risks resulting from becoming entangled in or tripping over a longer cord.
CLEANING Be sure to unplug the appliance from the power supply. 1. Clean the cavity of the oven after using with a slightly damp cloth. 2. Clean the accessories in the usual way in soapy water. 3. The door frame and seal and neighbouring parts must be cleaned carefully with a damp cloth when they are dirty.
UTENSILS Personal Injury Hazard: It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy. See the instructions on " Materials you can use in microwave oven "...
MATERIALS YOU CAN USE IN MICROWAVE OVEN UTENSILS REMARKS Follow manufacturer’s instructions. The bottom of browning dish must be at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause Browning dish the turntable to break. Microwave-safe only. Follow manufacturer’s instructions.
Page 49
MATERIALS YOU CAN USE IN MICROWAVE OVEN UTENSILS REMARKS Microwave-safe only. Follow the manufacturer’s instructions. Should be labeled “Microwave Safe”. Some plastic containers soften, as the food inside gets hot. “Boiling bags” and tightly closed plastic bags should be Plastic slit, pierced or vented as directed by package.
MATERIALS CAN NOT BE USED IN MICROWAVE OVEN UTENSILS REMARKS May cause arcing. Transfer food into microwave-safe dish. Aluminum tray May cause arcing. Transfer food into microwave-safe dish. Food carton with metal handle Metal shields the food from microwave energy. Metal trim may cause arcing.
PRODUCT SETTING SETTING UP YOUR OVEN (In case of any di erences between the appliance and the pictures in this manual, the product shall prevail.) NAMES OF MICROWAVE OVEN PARTS AND ACCESSORIES Remove the oven and all materials from the carton and oven cavity. Turntable Ring Assembly Glass turntable Instruction Manual...
SETTING UP YOUR OVEN TURNTABLE INSTALLATION Cleaning the cooking compartment and putting the turntable in place. For new installations, make sure all packaging and shipping tape has been removed from the turntable shaft. Before using the appliance to prepare food for the first time, you will need to put the turntable in place correctly.
Page 53
COUNTERTOP INSTALLATION Remove all packing material and accessories. Examine the oven for any damage such as dents or broken door. Do not install if oven is damaged. Cabinet: Remove any protective film found on the microwave oven cabinet surface. Do not remove the waveguide cover that is attached to the oven cavity to protect the magnetron.
INSTRUCTION FOR USE BEFORE USING FOR THE FIRST TIME It is normal that the oven may produce unpleasant odors when it is used for the first time. This section tells you what you need to do before using your microwave to prepare food for the first time.
1. POWER LEVELS power levels are available PRESS NUMBER KEY POWER DISPLAY 100% PL10 2. SETTING THE CLOCK When the microwave oven is plugged into an outlet , "0:00" will display. Press Clock once, 00:00 will appear on the display. Clock 时钟...
3. KITCHEN TIMER When the microwave oven is plugged into an outlet, "0:00" will display. Press Kitchen Timer once, 00:00 will appear on the display. Kitchen Timer 计时器 Press number keys to set the time, the maximum value is 99:99. 分钟...
Press number keys to set the power level. 分钟 分钟 分钟 START 开始 Press to start cooking. +30Sec. +30秒 5.WEIGHT DEFROST Press Weight Defrost once, “dEF1” will display Weight Defrost 按重量解冻 Press number keys to set the defrost weight. It should be within 100~2000 g. 分钟...
6. TIME DEFROST Press Time Defrost once, “dEF2” will display. Time Defrost 按时间解冻 Press number keys to set the defrost time. The maximum value is 99:99. 分钟 分钟 分钟 START 开始 Press to start defrosting. +30Sec. +30秒 • The default power level is PL3, it cannot be changed. NOTE 7.
Page 60
Press Time Cook once, “00:00” will appear on the display. Time Cook 烹饪时间 Press number keys to set the cooking time. 分钟 分钟 分钟 Press Power once, PL10 will appear on the display. Power 火力调节 Press number keys to set the power level. 分钟...
8. MEMORY FUNCTION Press M EMORY to program and choose up to three cooking procedures. Each procedure will be indicated by 1, 2 or 3 in MEMORY the display. 记忆模式 Press to start cooking.Two cooking stages can be START 开始 +30Sec.
• Press to save the procedure. START 开始 +30Sec. +30秒 Oven beeps once, screen will display "2". START 开始 • Press again to start the procedure. +30Sec. +30秒 • Auto Menu can’t be set in memory function. • If the power is not cut o , the procedure will be saved all the time. NOTE 9.SPEEDY COOKING In standby mode, press number keys “1-6”...
11. LOCK FUNCTION To lock the microwave so that it can’t be operated by children or other unintended users. STOP press for 3 seconds, there will To lock, in stanby mode, STOP 停止 CANCEL CANCEL 取消 be a long beep, will display denoting enter the locked state.
14. AUTO MENU Press the desired menu key repeatedly to set the weight of it. POPCORN For example, press POPCORN twice to 爆米花 cook the popcorn for 100 g. START 开始 Press to start cooking. +30Sec. +30秒 AUTO MENU CHART WEIGHT/ MENU DISPLAY...
CLEANING AND MAINTENANCE CLEANING With good care and cleaning, your appliance will retain its appearance and remain fully functioning for a long time to come. We will explain here how you should correctly care for and clean your appliance. • Scratched glass in the appliance door may develop into a crack. Do not use a glass scraper, sharp or abrasive cleaning aids or detergents.
Page 66
APPLIANCE FRONT WITH STAINLESS STEEL Hot soapy water: Clean using a dish cloth and then dry with a soft cloth. Remove splashes and patches of limescale, grease, starch and albumin immediately. Corrosion can form under these patches or splashes. Do not use glass cleaners or metal or glass scrapers for cleaning.
TROUBLE SHOOTING Normal Radio and TV reception may be interfered when microwave oven operating. It is similar to the Microwave oven interfering interference of small electrical appliances, like TV reception mixer, vacuum cleaner, and electric fan. It is normal. In low power microwave cooking, oven light may Dim oven light become dim.
