Scan to see the online manual.
OWNER'S MANUAL
DRYER
Read this owner's manual thoroughly before operating the appliance
and keep it handy for reference at all times. This abridged owner's
manual addresses user safety, precautions, and installation
information.
To view the complete owner's manual, you may:
1. Online manual: Visit the LG website at: http://gscs-manual.lge.com/
Total/HQ/GatewayPage/main.html or scan the QR code above; or
2. Printable PDF manual: Visit lg.com and search for your model
number; or
3. Call or write to customer service as provided in your Limited
Warranty.
ENGLISH
DLEX7**0*E / DLGX7**1*E / DLE7**0* / DLG7**1* / DLE7*00*E / DLG7*01*E
www.lg.com
MFL71950801
Rev.0 _0
2
Copyright © 2022-202 LG Electronics Inc. All Rights Reserved.
Advertisement
Table of Contents
Related Manuals for LG DLGX7 1 E Series
Summary of Contents for LG DLGX7 1 E Series
- Page 1 1. Online manual: Visit the LG website at: http://gscs-manual.lge.com/ Total/HQ/GatewayPage/main.html or scan the QR code above; or 2. Printable PDF manual: Visit lg.com and search for your model number; or 3. Call or write to customer service as provided in your Limited Warranty.
-
Page 2: Table Of Contents
Connecting the Water Inlet Hose (Steam models) Final Installation Check 35 OPERATION Before Use Loading the Dryer Options and Extra Functions 38 SMART FUNCTIONS LG ThinQ Application Smart Diagnosis Function 42 MAINTENANCE Regular Cleaning 44 TROUBLESHOOTING FAQs Before Calling for Service... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE Safety for a Dryer WARNING Fire Hazard Failure to follow safety warnings exactly could result in serious injury, death or property damage. Do not install a booster fan in the exhaust duct. •... -
Page 4: Warning Statements
IMPORTANT SAFETY INSTRUCTIONS WARNING Risk of Fire Install the clothes dryer according to the manufacturer’s instructions and local codes. Clothes dryer installation must be performed by a qualified installer. • Do not install a clothes dryer with flexible plastic venting materials. If •... - Page 5 IMPORTANT SAFETY INSTRUCTIONS • The appliance must be installed and electrically grounded by qualified service personnel in accordance with local codes. • Disconnect the power cord, house fuse or circuit breaker before installing or servicing the appliance. • When moving or installing the appliance in a different location, call qualified service personnel for installation and service.
- Page 6 • Do not grasp the power cord or touch the appliance controls with wet hands. • Do not modify or extend the power cord. • If the appliance has been submerged, contact an LG Electronics customer information center for instructions before resuming use.
- Page 7 IMPORTANT SAFETY INSTRUCTIONS • Do not put living animals such as pets inside the appliance. • Do not put any part of your body, such as your hands or feet, or metal objects under the appliance. • Do not let your hand get pinched when opening or closing the dryer door. •...
-
Page 8: Product Overview
PRODUCT OVERVIEW PRODUCT OVERVIEW Product Features The images in this guide may be different from the actual components and accessories, which are subject to change by the manufacturer without prior notice for product improvement purposes. Front View Control Panel Lint filters Leveling feet Reversible door Rear View... - Page 9 Water Inlet Hose Connection (for Steam Models) Exhaust Duct Oulet Product Specifications...
- Page 10 10 PRODUCT OVERVIEW Accessories Included Accessories Inlet Hose-Short (on some models) Inlet Hose-Long (on some models) Safety Tether Kit (on some models) Drying Rack (No. 3750EL001C) Side vent kit (Kit No. 383EEL9001B)
-
Page 12: 12 Installation
12 INSTALLATION Choosing the Proper • For garage installation, you will need to place the appliance at least 18 inches (45.7 cm) above the Location floor. The standard pedestal height is 15 inches (38 cm). You will need 18 inches (45.7 cm) from the garage floor to the bottom of the appliance. - Page 13 INSTALLATION Dimensions and Clearances The following clearances are recommended for the appliance. • Additional clearances should be considered for ease of installation and servicing. • Additional clearances should be considered on all sides of the dryer to reduce noise transfer. Installation Spacing for Recessed Area or Closet Installation Description Dimension/Clearance...
- Page 14 14 INSTALLATION NOTE • There should be at least a little space around the dryer (or any other appliance) to eliminate the transfer of vibration from one appliance to another. If there is enough vibration, it could cause appliances to make noise or come into contact, causing paint damage and further increasing noise.
-
Page 15: Leveling The Appliance
INSTALLATION Leveling the Appliance NOTE • If you are installing the appliance on the optional WARNING pedestal, you must use the leveling feet on the • Use long-sleeved gloves and safety glasses. pedestal to level the appliance. The appliance leveling feet should be fully retracted. •... - Page 16 16 INSTALLATION door aside face down on a protected Remove the 4 screws securing the hinges to surface to prevent damage to the door or the door frame. Remove the two plastic cover the work surface. caps . Reinstall the hinges and cover caps on the opposite sides from which they were removed.
- Page 17 INSTALLATION Open the door from the side so that the hinge Do NOT remove the upper screw behind screws are accessible. the hinge bracket. Set the parts aside. CAUTION • Do NOT remove any of the eight screws on the face of the cabinet (marked below).
- Page 18 18 INSTALLATION Reverse the components inside the door. • You will now be removing and reversing various components inside the door. See a few page later for a detailed diagram and identification of the inner structure and parts of the door. (The diagram shows the “before view”...
- Page 19 INSTALLATION 2) While sliding the lock rod right, lift the • Now rotate the hinge filler 180 degrees right end up and out of the guides. and install it on the upper left side of the door. Reinstall the top lock rod. CAUTION •...
- Page 20 20 INSTALLATION assembly on the bottom left and lift the Install the side lock rod. hinge assembly out. • Flip the side lock rod over and install it on the opposite side. Insert the lower end into the left hinge and lower the rod into the guides on the door while compressing the spring inside the recess.
- Page 21 INSTALLATION different screws on the bottom edge, in the Now, pick up the upper hinge pivot removed locations marked below. earlier and rotate it 180 degrees. Install the hinge on the top left side of the cabinet. A detailed diagram and identification of the inner structure and parts of the door Interlock buttons Lower hinge filler Side lock rod...
-
Page 22: Installing The Vent Kit
• An adapter kit, part number 383EEL9001B, may back easily and lock the pivot in place. The be purchased from your LG retailer. This kit door is now ready to remount on the contains duct components necessary to change opposite side of the dryer. - Page 23 INSTALLATION duct onto the blower housing and secure Insert the 4" (10.2 cm) elbow through the to the base of the dryer as shown. rear opening and press it onto the adapter duct. Be sure that the male end of the elbow faces down through the hole in the bottom of the dryer.
-
Page 25: Connecting Gas Dryers
INSTALLATION Ductwork • Incorrect or inadequate exhaust systems are not covered by the dryer warranty. Dryer failures or service required because of such exhaust Maximum length No. of systems will not be covered by the dryer of 4-inch Wall Cap Type 90°... - Page 26 26 INSTALLATION Connecting the Gas Supply • This dryer must be plugged into a 120-VAC, 60- Hz. grounded outlet protected by a 15-ampere fuse or circuit breaker. NOTE • Where a standard 2-prong wall outlet is • In the Commonwealth of Massachusetts: This encountered, it is your personal responsibility product must be installed by a licensed plumber and obligation to have it replaced with a...
-
Page 27: Connecting Electric Dryers
INSTALLATION Check all pipe connections (both internal and equipment-grounding conductor must be run external) for gas leaks with a noncorrosive with the circuit conductors and connected to the leak-detection fluid. equipment-grounding terminal or lead on the appliance. • The appliance has its own terminal block that Proceed to Venting the Dryer. - Page 28 28 INSTALLATION Four-Wire Power Cord Reinstall the terminal block access cover. • A UL-listed strain relief is required. • Use a 30-amp, 240-volt, 4-wire, UL-listed power cord with #10 AWG-minimum copper conductor and closed loop or forked terminals with upturned ends. White Wire moved from Ground Screw Remove the terminal block access cover on Hot Leads of Power Cord (Black and Red)
- Page 29 INSTALLATION Install UL-listed strain relief into the power Power Cord Ground Wire cord through-hole. Ground Screw Thread the 4-wire #10 AWG minimum copper power cable prepared in step 1 through the Three-Wire Power Cord strain relief. • A 3-wire connection is NOT permitted on new construction after January 1, 1996.
-
Page 30: Connecting The Water Inlet Hose (Steam Models)
30 INSTALLATION Reinstall the terminal block access cover. Terminal block UL-listed strain relief White Wire from Dryer Harness UL-listed 3-wire power cord Hot Leads of Power Cord (Black and Red) Attach the two hot leads (black and red) of the Neutral Wire (White) power cord to the outer terminal block External Ground Wire (if required by local... - Page 31 Old hoses could leak or burst causing flooding and property 1) Connect the straight end of the long damage. Contact an LG Customer Information hose to the cold water faucet. Center for assistance in buying hoses.
-
Page 32: Final Installation Check
32 INSTALLATION Final Installation Check NOTE Once you have completed the installation of the • Before connecting the water line to the dryer, dryer and it is in its final location, confirm proper flush several gallons of water into a drain or operation with the following tests. - Page 33 INSTALLATION performed to alert you to any serious problems in the exhaust system of your home. • Your appliance features Flow Sense , an innovative sensing system that automatically detects blockages and restrictions in dryer ductwork. Keeping ductwork clean of lint buildup and free of restrictions allows clothes to dry faster and reduces energy use.
- Page 34 34 INSTALLATION NOTE Excess or crushed Too many elbows or transition duct exhaust too long • Do not interrupt the test cycle, as this could result in inaccurate results. • Even if no bars are displayed during the test cycle, some restrictions may still be present in the exhaust system.
-
Page 35: Operation
OPERATION OPERATION Before Use WARNING • To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT SAFETY INSTRUCTIONS before operating this appliance. Operation Overview Adjust Settings Default settings for the selected cycle can now be changed, if desired, using the cycle Clean the Lint Filter modifier and option buttons. -
Page 36: Loading The Dryer
• Damp clothes will expand as they dry. Do not overload the dryer; clothes require room to tumble and dry properly. Additional Operation Information The complete owner’s manual can be found on the LG website at: http://gscs-manual.lge.com/ Total/DFZ/NA/DR/TD/main.html or by scanning the QR code. -
Page 37: Options And Extra Functions
OPERATION Options and Extra Functions Your dryer includes several additional cycle options to customize cycles to meet your individual needs. Select the desired option after selecting the desired cycle and settings. NOTE • The LED for the option will light up when the option is selected. -
Page 38: Smart Functions
• Remote Control - Control the appliance remotely or check to see how much time is left in the cycle from the LG ThinQ application. NOTE • Once the remote control feature is enabled, you can start a cycle from the LG ThinQ application. - Page 39 • The appliance supports 2.4 GHz Wi-Fi networks only. To check your network frequency, contact your Internet service provider or refer to your Start a cycle from the LG ThinQ application on wireless router manual. your smartphone. • LG ThinQ is not responsible for any network...
-
Page 40: Smart Diagnosis Tm Function
If this equipment does opensource.lge.com. cause harmful interference to radio or television LG Electronics will also provide open source code reception, which can be determined by turning the to you on CD-ROM for a charge covering the cost... - Page 41 SMART FUNCTIONS • Launch the LG ThinQ application and select the Smart Diagnosis feature in the menu. Follow the instructions provided in the LG ThinQ application. Using Audible Diagnosis to Diagnose Issues Follow the instructions below to use the audible diagnosis method.
-
Page 42: Maintenance
42 MAINTENANCE MAINTENANCE WARNING • Unplug the appliance before cleaning. • Never use harsh chemicals, abrasive cleaners, or solvents to clean the appliance. They will damage the finish. Regular Cleaning Cleaning the Lint Filter Always clean the lint from the filter after every Cleaning the Exterior cycle. - Page 43 MAINTENANCE filter in warm, soapy water and allow it to dry thoroughly before reinstalling. NOTE • NEVER operate the appliance without the lint filter in place.
-
Page 44: Troubleshooting
Scan this QR code to quickly access the video search page on the offical LG website. On the lg.com/us home page, click on the Support menu tab to bring up the menu selections. Select Video Tutorials. Type Dryer in the search box on the new page and click the Search button. -
Page 45: Before Calling For Service
TROUBLESHOOTING Before Calling for Service The dryer is equipped with an automatic error-monitoring system to detect and diagnose problems at an early stage. If the dryer does not function properly or does not function at all, check the following before you call for service. - Page 46 46 TROUBLESHOOTING Problem Possible Cause & Solution The Flow Sense ( After clearing the restrictions, the Flow Sense ( ) system requires multiple, indicator remains consecutive cycles to determine that the performance value has improved before the active after clearing Flow Sense ( ) indicator is reset.
- Page 47 TROUBLESHOOTING Problem Possible Cause & Solution Appliance runs and This is how the Wrinkle Care option works. pauses by itself after • Make sure that the Wrinkle Care option has been set. The option is designed to prevent the drying cycle creases that are formed when the clothes are not unloaded promptly after the drying finishes.
- Page 48 48 TROUBLESHOOTING Problem Possible Cause & Solution Excess static in Fabric softener is not used or is used incorrectly. clothes after drying. • Use a fabric softener or the Reduce Static option, if available, to reduce static electricity. Be sure to follow the manufacturer’s instructions. Clothes dried too long (overdried).
- Page 49 TROUBLESHOOTING Problem Possible Cause & Solution Drum does not turn This is normal. during Steam Cycle. • The drum is turned off so that the steam vapor remains in the drum. The drum will normally turn for about 2 seconds once a minute. Cannot see steam This is normal.
- Page 50 During Wi-Fi setup, the app is requesting a password to connect to the product (on appliance and certain phones). smartphone to Wi-Fi • Locate the network name which starts with "LG" under Settings > Networks. Note the last network. part of the network name. - If the network name looks like LGE_Appliance_XX-XX-XX, enter lge12345.
-
Page 51: Warranty
Should your LG Dryer (“Product”) fail due to a defect in materials or workmanship under normal and proper use, during the warranty period set forth below, LG will, at its option, repair or replace the Product. This limited warranty is valid only to the original retail purchaser of the Product (“You”) and applies only when purchased lawfully and used within the United States including U.S. - Page 52 Notice of Dispute. In the event you intend to commence an arbitration proceeding, you must first notify LG in writing at least 30 days in advance of initiating the arbitration by sending a letter to LG at LG Electronics, USA, Inc. Attn: Legal Department-Arbitration 111 Sylvan Avenue, Englewood Cliffs, NJ 07632.
- Page 53 If you and LG are unable to resolve the dispute within 30 days, either party may proceed to file a claim for arbitration.
- Page 54 54 WARRANTY www.lg.com/us/support/repair-service/schedule-repair-continued and clicking on “Find My Model & Serial Number”). You may only opt out of the dispute resolution procedure in the manner described above (that is, by e-mail or telephone); no other form of notice will be effective to opt out of this dispute resolution procedure.
- Page 55 LG Customer Information Center For inquiries or comments, visit www.lg.com or call: 1-800-243-0000 U.S.A. 1-888-542-2623 CANADA Register your product Online! www.lg.com...
