- Page 1 User Manual GETTING STARTED? EASY. ZWF824B3PW EN User Manual Washing Machine...
-
Page 2: Safety Information
VISIT OUR WEBSITE TO: Get usage advice, brochures, trouble shooter, service and repair information: www.zanussi.com/support SAFETY INFORMATION Before beginning the installation and use of this appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. -
Page 3: Safety Instructions
This appliance is designed for single household domestic use • in an indoor environment. This appliance may be used in, offices, hotel guest rooms, bed • & breakfast guest rooms, farm guest houses and other similar accommodation where such use does not exceed (average) domestic usage levels. -
Page 4: Electrical Connection
• Do not install or use the appliance where the • Before connection to new pipes, pipes not used temperature can be less than 0°C or where it is for a long time, where repair work has been exposed to the weather. carried out or new devices fitted (water meters, •... -
Page 5: Product Description
seals, door locking assembly, plastic peripherals DISPOSAL such as detergent dispensers. Please note that WARNING! Risk of injury or some of these spare parts are only available to suffocation. professional repairers, and that not all spare parts are relevant for all models. •... -
Page 6: Technical Data
The rating plate reports the model name (A), product number (B),electrical ratings (C) and se- rial number (D). Mod. xxxxxxxxx Prod.No. 910000000 00 000V ~ 00Hz 0000 W 00000000 TECHNICAL DATA Dimension Width/ Height/ Total depth 59,6 cm /84,7 cm /57,7 cm Electrical connection Voltage 230-240 V... -
Page 7: Information For Installation
INFORMATION FOR INSTALLATION CAUTION! Do not lay washing machine on its front. Positioning and levelling Adjust the appliance correctly to prevent vibration, 3. Put the appliance back into an upright position. noise and movement of the appliance when it Remove the power supply cable and the drain operates. - Page 8 The drain hose should stay at a height of no less 4. To a stand pipe with vent hole - Insert the drain than 60 cm and not more than 100 cm. hose directly into a drain pipe. Refer to the illustration.
-
Page 9: Installation On Suspended Flooring
FIXING PLATE KIT If you install the appliance on a plinth that is not an accessory supplied by ZANUSSI, secure the appliance in the fixing plates. Read carefully the instructions supplied with the accessory. -
Page 10: Special Features
CONTROL PANEL SPECIAL FEATURES off the clothes to be drained out with the water, in such a way that there is no need to access this Your new washing machine meets all modern area for regular maintenance and cleaning. Refer to requirements for an effective treatment of laundry chapter 'Care and Cleaning' for best maintenance with low water, energy and detergent consumption... -
Page 11: Programme Chart
DISPLAY A. The time area: • Programme time. • The alarm codes. Refer to the chapter “Troubleshooting” for their description. • The level of the FlexiTime B. The Delay Start indicator. C. The Child Lock indicator. D. The Door Lock indicator: •... - Page 12 Reference spin Programme speed Maximum Programme description Default temperature Spin speed load (Type of load and level of soiling) Temperature range range Sportswear 1200 rpm 3 kg Synthetic and delicate items. Lightly soiled 30 °C (1200- 400 items or items to refresh. 40°C - Cold rpm) Spin/Drain...
- Page 13 Programme options compatibility Programme ■ ■ ■ ■ ■ ■ ■ Eco 40-60 ■ ■ ■ ■ ■ ■ ■ ■ ■ Cottons ■ ■ ■ ■ ■ ■ ■ ■ ■ Synthetics ■ ■ ■ ■ ■ ■ ■ Delicates ■...
-
Page 14: Extra Rinse
Universal pow- Liquid for col- Delicates Programme Liquid Universal Special oureds woollens ▲ ▲ ▲ Dark Colours ▲ ▲ ▲ CleanBoost ▲ ▲ 14min Refresh ▲ ▲ 30min Rapid ▲ ▲ ▲ 60min EasyWash 1) At temperature higher than 60 °C the use of powder detergent is recommended. ▲... - Page 15 NIGHT Touch FlexiTime button to reduce the programme duration according to your needs. The display The intermediate and the final spinning phases are shows the new programme duration and a number suppressed and the programme ends with water in of dashes will decrease accordingly: the drum.
-
Page 16: Before First Use
BEFORE FIRST USE 1. Connect the mains plug to the mains socket. During installation or before first use 2. Open the water tap. you may observe some water in the 3. Put a small quantity of detergent in the appliance. This is residual water left in compartment for washing phase. -
Page 17: Filling The Detergent And Additives
FILLING THE DETERGENT AND ADDITIVES Compartment for washing phase. If you use liquid detergent, put it immediately before you start the programme. Compartment for liquid additives (fabric conditioner, starch). Maximum level for quantity of liquid additives. Flap for powder or liquid deter- gent. -
Page 18: Starting A Programme Without The Delay Start
• The display shows the level of the Time Manager, the programme duration and the indicators of the phases of the programme. 2. If necessary, change the temperature and the spin speed or add available options. When you activate an option, the indicator of the set option comes on. -
Page 19: Interrupting A Programme And Changing The Options
You can cancel or change the set of Before starting the new programme the delay start before you press the the appliance could drain the water. In . To cancel the delay start: this case, make sure that the detergent is still in the detergent compartment, if •... -
Page 20: Hints And Tips
STAND-BY The washing programme is completed, but there is water in the drum: Some minutes after the end of the washing • The drum turns regularly to prevent the creases programme, if you do not deactivate the appliance, in the laundry. the energy saving status activates. -
Page 21: Stubborn Stains
STUBBORN STAINS • the wash load to turn grey, • greasy clothes, For some stains, water and detergent is not • mould in the appliance. sufficient. Excessive detergent may cause: We recommend that you pre-treat these stains • sudsing, before you put the items in the appliance. •... - Page 22 After each cycle, keep the door and the detergent Regularly examine the drum to check for limescale. dispenser slightly ajar to get air circulation and dry Regular detergents already contain water softening the humidity inside the appliance: this will prevent agents, but we recommend to run a cycle with an mildew and odours.
-
Page 23: Cleaning The Detergent Dispenser
Clean it when needed, using ammonia cream cleanser agent without scratching the seal surface. Always obey the instructions that you find on the packaging of the product. CLEANING THE DETERGENT DISPENSER CLEANING THE INLET HOSE AND THE VALVE FILTER... -
Page 24: Frost Precautions
45° 20° FROST PRECAUTIONS 5. When the drain pump is empty, install the inlet hose again. If the appliance is installed in an area where the temperature can be less than 0° C, remove the WARNING! Make sure that the remaining water from the inlet hose and the drain temperature is higher than 0 °C before pump. - Page 25 Values and programme duration may differ depending on different conditions (e.g. room tem- perature, water temperature and pressure, load size and type of laundry, supply voltage) and also if you change the default setting of a programme. ACCORDING TO UK ECODESIGN FOR ENERGY-RELATED PRODUCTS AND ENERGY INFORMATION REGULATIONS Eco 40-60 pro-...
-
Page 26: Troubleshooting
Programme Litres hh:mm °C Wool 0.300 65.0 1:05 30.00 30.0 1200 30°C 1) Reference indicator of the spin speed. 2) Suitable for washing heavily soiled textiles. 3) Suitable for washing lightly soiled cottons, synthetic and mixed fabrics. 4) It also performs as quick washing cycle for lightly soiled laundry. TROUBLESHOOTING WARNING! Refer to Safety chapters. - Page 27 • The programme was not finished properly or the appliance stopped too early. Switch the appliance off and on again. Internal fail. No commu- • If the alarm code appears again, contact the Authorised Service Cen- nication between elec- tre. tronic elements of the appliance.
-
Page 28: Environmental Concerns
Problem Possible solution The programme dura- • The AutoSense System is able to adjust the programme duration ac- tion increases or de- cording to the type and the laundry load size. Refer to "The AutoSense creases during pro- System load detection" in "Daily Use" chapter. gramme execution. - Page 32 WWW.ZANUSSI.COM/SHOP...
