Toshiba Satellite A75-S2292 Specifications

TOSHIBA
Satellite A75 Series
Model Name Description
Satellite A75- Intel® Pentium® 4 Processor 538, 15.4" WXGA, 512MB, 60GB (4200 RPM), DVD-SuperMulti,
S2292 802.11g, TV-Out, CD play/Instant play button, Microsoft® Windows® XP Home, 1-year Limited
Warranty
System Characteristics
Operating System
•
Microsoft® Windows® XP Home
2
Processor and Chipset
•
Mobile Intel® Pentium® 4 Processor 538 supporting HT
Technology [3.20GHz, 1MB L2 cache, 533MHz Front Side Bus
•
ATI MOBILITY™ RADEON™ 9000 IGP
Memory
•
512MB (Min)/1536MB (Max). PC2700 DDR333 SDRAM 2.5V
SODIMM Memory modules; configurable from 512MB to 1536MB
3
Mass Storage
Hard Disk Drive:
•
60GB (4200 RPM), Enhanced IDE (ATA-6) hard disk drive; 9.5mm
height; user removable
Optical Disk Drive:
•
Fixed Bay DVD Super Multi Drive, 5.25" EIDE, 12.7mm height.
Capability: CD-ROM (24x read), CD-R (16x write), CD-RW (8x
write), DVD-ROM (8x read), DVD-R (4x write), DVD-RW (2x
write), DVD+R (2x write), DVD+RW (2.4x write), DVD-RAM (2x
write)
Optional Floppy Disk Drive
•
External USB Floppy Drive, 3.5", 1.44MB
4
Display
•
15.4" diagonal WXGA TFT active-matrix TruBrite™ LCD; internal
display supports up to 16M colors at 1280 x 800 (WXGA)
•
Maximum brightness 232 Cd/m
•
Brightness Control
Graphics
•
ATI MOBILITY™ RADEON™ 9000 IGP (integrated video); 64MB
of shared memory, user adjustable to 128MB
Input Devices
•
Keyboard: Full sized 85 keys with 12 function keys, 2.7mm key
stroke, 6mm height; Dedicated Windows® & Application keys
support; HotKey function
•
Mouse: Touch Pad
Expandability
•
1 expansion memory slots
•
1 PC Card slots support 1 Type II, PCMCIA R2.01, PC Card16,
CardBus
5
Communications
•
Integrated V.92 modem
•
Integrated 10/100Base-TX
•
Integrated Wi-Fi® compliant 802.11g Atheros wireless LAN
Ports
•
RGB (monitor) port
•
TV-Out port (S-video)
•
Parallel port
•
3 Universal Serial Bus (USB) ports (v2.0)
•
External Microphone jack
•
Headphone jack
•
RJ-45 LAN port
•
RJ-11 modem port
•
CD play/Instant play button
Physical Description
•
Dimensions (WxDxH Front/H Rear): 14.4" x 10.8" x 1.54"/1.81"
• 6
Weight : Starting at 7.97lbs depending upon configuration
•
LED Indicators: DC-In, Power, Primary Battery, Hard Drive, CD-
DVD ROM Access, Wireless indicator, Caps Lock, Arrow Lock,
Numeric Lock, Main Battery Charging Status, Sleep Suspend
Mode, SD Card
Sound
•
Realtek ALC259 Software Sound
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
1
2
© Copyright 2004 Toshiba America Information Systems Inc. ("TAIS"). All Rights reserved.
Satellite A75-Series Revision 1.00 09-15-2004 CBB CB v_1.10
•
16-bit stereo; Built-in stereo speakers, Built-in microphone
•
3D Sound Support, Direct 3D Sound; DirectSound, Direct Music,
MIDI (playback) Support
•
Sound Volume Control Dial
Power Supply
•
120W (19V 6.3A) Auto-sensing external AC Adapter, 100-240V /
50-60Hz input.
7
Battery
•
12-cell (6450mAh), rechargeable, removable Lithium Ion (Li-Ion)
battery pack
•
Battery Life (Normal Mode): Up to 2 hours (12-cell battery)
(measured by Winstone™)
Security
•
Slot for cable lock; HDD, memory (by screw only); User Power-on
password, Supervisor Password (Set-up Security), Screen Blank
(by HotKey), Screen Saver (by software).
BIOS
•
ACPI v1.0b, PNP v1.0a, VESA v2.0, DPMS, DDC, SM BIOS v2. 1,
PC BIOS v2.2 support
Software
Toshiba Software and Utilities
•
Toshiba Notebook Maximizer
•
Toshiba Speech System
•
Toshiba ConfigFree™
•
Toshiba Custom Utilities
•
Toshiba Touch and Launch
•
Toshiba MyConnect™ - 45 day free trial offer
MYCONNECT OFFER DETAILS: 1 Valid in the US only! You must cancel your Access
Plan before the end of the trial period to avoid being charged the $39.95 monthly
Access Service fee for the six month plan commitment period. Monthly automatic
renewal feature after end of commitment period. Available to new members in the U.S.,
age 18 or older, and a major credit card for billing is required. Offer is for unlimited dial-
up, wired broadband, or Wi-Fi remote access connection time in the 50 United States
and the District of Columbia within the MyConnect service area for 30 day continuous
service periods. Use of optional 800 telephone number dial-up usage will incur
additional fees even during the trial period. Other terms and conditions apply. Offer
expires December 31, 2004. Information, prices, and availability subject to change
without notice.
Third-party Software
•
Microsoft® Works
•
Microsoft® Office Trial Version Student/Teacher
•
Microsoft® Office OneNote™ 2003
•
Software Decoder: InterVideo® (Win-DVD™ 5) -w/SRS
TruSurround XT® Technology (SRS TruSurround XT® Technology
features: TruSurround, SRS Dialog Clarity Enhancement, &
TruBass)
•
Sonic® Solutions Drive Letter Access (DLA)
•
Sonic® Solutions RecordNow!™ Basic
•
ArcSoft ShowBiz® DVD Version 1.3
•
Intuit® Quicken® New User Edition 2004
•
Norton AntiVirus™ 2004 – w/3-Month Subscription
•
AOL® (3 –Month offer)
AOL OFFER DETAILS: Availability may be limited, especially during peak times. TO
AVOID BEING CHARGED A MONTHLY MEMBERSHIP FEE, SIMPLY CANCEL
BEFORE THE THREE-MONTH PROMOTIONAL PERIOD ENDS. Premium services
carry surcharges and communication surcharges may apply, including AK, even during
promotional period. Members may incur telephone charges on their phone bill,
depending on their location and calling plan, even during promotional period. Available
to new AOL members in the United States, age 18 or older; a major credit card or
checking account is required.
•
Adobe® Acrobat® Reader
•
AT&T® Worldnet® Service – 1 Month FREE
Telephone access and other charges and other terms and conditions may apply. Offer
available to new customers only.
•
QuickTime™ Player
•
RealOne™ Player 8 Basic
•
Microsoft® Internet Explorer
•
Napster™ digital music service (30-day trial)
Part Number UPC Code
PSA70U-09K00G 032017280632
Page 1 of 8
