- Page 1 MM-EM25PE(BM) โปรดอ‹ า นคู ‹ ม ื อ คำแนะนำการใชŒ ง านนี ้ ก ‹ อ นใชŒ ง านผลิ ต ภั ณ ฑ...
- Page 4 อุ ป กรณ น ี ้ ไ ม‹ ไ ดŒ ม ี ไ วŒ ส ำหรั บ การ หากสายไฟชำรุ ด จะตŒ อ งเปลี ่ ย นโดย ใชŒ ง านโดยบุ ค คล (รวมถึ ง เด็ ก ) ที ่ ม ี ผู...
- Page 6 คำเตื อ น : อนุ ญ าติ ใ หŒ เ ด็ ก ใชŒ ง าน เตาไมโครเวฟ โดยลำพั ง ไม‹ ม ี ก าร ควบค ุ ม ด ู แ ลเฉพาะเม ื ่ อ ได Œ ใ ห Œ ค ำแนะนำ การใชŒ...
- Page 35 Details Matter...
- Page 37 MICROWAVE OVEN MM-EM25PE(BM)
-
Page 38: Table Of Contents
CONTENTS PRODUCT SAFETY Precautions to avoid possible exposure to excessive microwave energy ........EN-01 Important safety instructions ........................EN-03 To reduce the risk of injury to persons grounding installation ............EN-07 Cleaning ................................EN-09 Utensils .................................. EN-10 Materials you can use in microwave oven ....................EN-11 Materials can not be used in microwave oven .................. - Page 39 9. Auto menu function - potato ........................EN-25 10. Auto menu function - frozen vegetable ................... EN-25 11. Auto menu function - beverage ......................EN-25 12. Auto menu function - dinner plate..................... EN-25 13. Auto menu function - pizza ........................EN-26 14.
-
Page 40: Product Safety
PRODUCT SAFETY PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a). Do not attempt to operate this oven with the door open since open door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. - Page 41 SPECIFICATIONS Model MM-EM25PE(BM) Voltage Frequency 220V~ 50Hz Microwave Input Power 1250W Microwave Output Power 800W All pictures in this manual are for illustrative purposes only; these may be slightly different from the purchased equipment, please refer to the NOTE actual product. EN-2...
-
Page 42: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of fire, electric shock, injury to persons or exposure to excessive microwave oven energy when using your appliance, follow basic WARNING precautions, including the following: Read and follow the Children should be specific: "PRECAUTIONS supervised to ensure that TO AVOID POSSIBLE they do not play with the... - Page 43 IMPORTANT SAFETY INSTRUCTIONS If the supply cord is When heating food in damaged, it must plastic or paper containers, be replaced by the keep an eye on the oven manufacturer, its service due to the possibility of agent or similarly qualified ignition.
- Page 44 IMPORTANT SAFETY INSTRUCTIONS checked before The microwave oven must consumption, in order to be operated with the avoid burns. decorative door open. (for ovens with a decorative door.) The oven should be cleaned regularly and any This appliance is intended food deposits removed.
- Page 45 IMPORTANT SAFETY INSTRUCTIONS The appliance is intended decorative door in order to be used freestanding. to avoid overheating. (This is not applicable for appliances with decorative The rear surface of door.) appliances shall be placed against a wall. The microwave oven shall not be placed in a cabinet Eggs in their shell and unless it has been tested in...
-
Page 46: To Reduce The Risk Of Injury To Persons Grounding Installation
TO REDUCE THE RISK OF INJURY TO PERSONS GROUNDING INSTALLATION This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a grounding wire with a grounding plug. - Page 47 TO REDUCE THE RISK OF INJURY TO PERSONS GROUNDING INSTALLATION Electric Shock Hazard: Improper use of the grounding can result in electric shock. Do not plug into an outlet until appliance is properly installed and grounded. 1. A short power-supply cord is provided to reduce the risks resulting from becoming entangled in or tripping over a longer cord.
-
Page 48: Cleaning
CLEANING Be sure to unplug the appliance from the power supply. 1. Clean the cavity of the oven after using with a slightly damp cloth. 2. Clean the accessories in the usual way in soapy water. 3. The door frame and seal and neighbouring parts must be cleaned carefully with a damp cloth when they are dirty. -
Page 49: Utensils
UTENSILS Personal Injury Hazard: It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy. See the instructions on " Materials you can use in microwave oven "... -
Page 50: Materials You Can Use In Microwave Oven
MATERIALS YOU CAN USE IN MICROWAVE OVEN UTENSILS REMARKS Follow manufacturer’s instructions. The bottom of browning dish must be at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause Browning dish the turntable to break. Microwave-safe only. Follow manufacturer’s instructions. - Page 51 MATERIALS YOU CAN USE IN MICROWAVE OVEN UTENSILS REMARKS Microwave-safe only. Follow the manufacturer’s instructions. Should be labeled “Microwave Safe”. Some plastic containers soften, as the food inside gets hot. “Boiling bags” and tightly closed plastic bags should be Plastic slit, pierced or vented as directed by package.
-
Page 52: Materials Can Not Be Used In Microwave Oven
MATERIALS CAN NOT BE USED IN MICROWAVE OVEN UTENSILS REMARKS May cause arcing. Transfer food into microwave-safe dish. Aluminum tray May cause arcing. Transfer food into microwave-safe dish. Food carton with metal handle Metal shields the food from microwave energy. Metal trim may cause arcing. -
Page 53: Product Setting
PRODUCT SETTING SETTING UP YOUR OVEN NAMES OF MICROWAVE OVEN PARTS AND ACCESSORIES Remove the oven and all materials from the carton and oven cavity. Glass Tray (Can be used under all functions) Instruction Manual A. Control panel E. Door assembly B. -
Page 54: Setting Up Your Oven
SETTING UP YOUR OVEN TURNTABLE INSTALLATION Cleaning the cooking compartment and putting the turntable in place. For new installations, make sure all packaging and shipping tape has been removed from the turntable shaft. Before using the appliance to prepare food for the first time, you will need to put the turntable in place correctly. - Page 55 SETTING UP YOUR OVEN COUNTERTOP INSTALLATION Remove all packing material and accessories. Examine the oven for any damage such as dents or broken door. Do not install if oven is damaged. Cabinet: Remove any protective film found on the microwave oven cabinet surface. Do not remove the light brown waveguide cover that is attached to the oven cavity to protect the magnetron.
- Page 56 SETTING UP YOUR OVEN 2. Plug your oven into a standard household outlet. Be sure the voltage and the frequency is the same as the voltage and the frequency on the rating label. • Do not install oven over a range cooktop or other heat-producing appliance.
-
Page 57: Instruction For Use
INSTRUCTION FOR USE BEFORE USING FOR THE FIRST TIME The appliance may produce unpleasant odors when it is used for the first time. This section tells you what you need to do before using your microwave to prepare food for the first time. -
Page 58: Operation
OPERATION CONTROL PANEL AND FEATURES 1. DIGITAL DISPLAY 2. TIME COOK Press to set Cooking time. 3. TIME DEFROST 4. WEIGHT DEFROST 5. POWER Press to select Microwave power level. 6. CLOCK Press to set Clock. 7. KITCHEN TIMER 8. Auto Menu •... -
Page 59: Microwave Power Level
1. MICROWAVE POWER LEVEL* 11 power levels are available. Press “POWER” to select Level 10. Press the digit on the Control Panel to select Level 9 to 0. When you select “PL0”, there is no power, only FAN will work to remove odor in the cabinet. -
Page 60: Kitchen Timer
• In the process of clock setting, if the “STOP/CANCEL” button is pressed or if there is no operation within 1 minute, the oven will go back to the former setting automatically. NOTE • If the clock need to be reset, please repeat step b to step . d 3. - Page 61 Press “START/+30SEC.” to start cooking. Example: To cook the food with 50% microwave power for 15 minutes. • Press “TIME COOK” once. “00:00” displays. • Press “1”, “5”, “0”, “0” in order. • Press “POWER” once, then press “5” to select 50% microwave power.
-
Page 62: Express Cook
5. EXPRESS COOK In waiting state, instant cooking at 100% power level can be started by select a cooking time from 1 to 6 minutes by pressing number pads 1 to 6. Press " START/+30SEC. " to increase the cooking time. The maximum cooking time is 99 minutes and 99 seconds. -
Page 63: Time Defrost Function
7. TIME DEFROST FUNCTION Press “TIME DEFROST”, screen will display “dEF2”. Press number pads to input defrosting time. The effective time range is 0:01~99:99 Press “START/+30SEC.” to start defrosting. The remained cooking time will be displayed. The default microwave power is power level 3. •... -
Page 64: Auto Menu Function - Potato
9. AUTO MENU FUNCTION - POTATO Press “POTATO” repeatedly until the number you wish appears in the display, “1”, “2”, “3” will display in order. “1” SET : 1 potato (approximate 230 gram) “2” SETS: 2 potatoes (approximate 460 gram) “3”... -
Page 65: Auto Menu Function - Pizza
Press “START/+30SEC.” to cook, buzzer sounds once. When cooking finishes, buzzer sounds five times and then turn back to waiting state. 13. AUTO MENU FUNCTION - PIZZA Press “PIZZA” repeatedly until the number you wish appears in the display, “100”, “200”, “400” grams will display in order. For example, press “PIZZA”... -
Page 66: Lock Function For Children
• Press “START/+30SEC.” to start cooking. 15. LOCK FUNCTION FOR CHILDREN Lock: In waiting state, press “STOP/CANCEL” for 3 seconds, there will be a long “beep” denoting the entering into the children-lock state; meanwhile, screen will display “ “. Lock quitting: In locked state, press “STOP/CANCEL”... -
Page 67: Inquiring Function
• Press “POWER” once, “PL10” displays, then press “8” and “PL8” displays. • Press “START/+30SEC.” to save the setting. Buzzer sounds once and “2” displays. If you press “START/+30SEC.” again, the procedure will be saved as the memory 2 and operated. •... -
Page 68: Cleaning
CLEANING With good care and cleaning, your appliance will retain its appearance and remain fully functioning for a long time to come. We will explain here how you should correctly care for and clean your appliance. • Scratched glass in the appliance door may develop into a crack. Do not use a glass scraper, sharp or abrasive cleaning aids or detergents. - Page 69 CLEANING APPLIANCE FRONT PLATE Hot soapy water: Clean using a dish cloth and then dry with a soft cloth. Remove splashes and patches of limescale, grease, starch and albumin immediately. Corrosion can form under these patches or splashes. Do not use glass cleaners or metal or glass scrapers for cleaning.
-
Page 70: Maintenance
MAINTENANCE TROUBLE SHOOTING NORMAL Radio and TV reception may be interfered when microwave oven operating. It is Microwave oven interfering TV reception similar to the interference of small electrical appliance, like mixer, vacuum cleaner, and electric fan. It is normal. In low power microwave cooking, oven light Dim oven light may become dim. - Page 72 Details Matter...
