OWNER'S MANUAL
DRYER
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
RV09VHP2W / RV09VHP4W1
MFL71712129
Rev.00_062322
Copyright © 2022 LG Electronics Inc. All Rights Reserved.
www.lg.com

Advertisement

Table of Contents
loading

Related Manuals for LG RV09VHP4W1

Summary of Contents for LG RV09VHP4W1

  • Page 1 This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. ENGLISH RV09VHP2W / RV09VHP4W1 www.lg.com MFL71712129 Rev.00_062322 Copyright © 2022 LG Electronics Inc. All Rights Reserved.

  • Page 2: Table Of Contents

    Operation Overview..................17 Preparing the Clothes..................18 Control Panel ....................20 Programme Table ....................22 Extra Options and Functions ................26 SMART FUNCTIONS LG ThinQ Application ..................29 Smart Diagnosis ....................31 MAINTENANCE Cleaning after Every Dry .................33 Cleaning the Appliance Periodically ..............35 TROUBLESHOOTING Before Calling for Service................38...

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. Safety Messages This symbol is displayed to indicate matters and operations that can cause risks.
  • Page 4 SAFETY INSTRUCTIONS • Children should be supervised to ensure that they do not play with the appliance. • Do not dry unwashed items in the appliance. • Fabric softeners, or similar products, should be used as specified by the fabric softener instructions. •...
  • Page 5 SAFETY INSTRUCTIONS could result in fire. Clothes not removed from the appliance after drying could result in fire. Remove clothes immediately after drying, and then hang or lay the clothes flat to cool. • This appliance is intended to be used in household only. Maximum Capacity •...
  • Page 6 SAFETY INSTRUCTIONS • This appliance must not be installed behind a lockable door, a sliding door or a door with a hinge on the opposite side to that of the appliance, in such a way that a full opening of the appliance door is restricted.
  • Page 7 Improper use can cause fire or explosion. • In case of flood, disconnect the power plug and contact the LG Electronics customer information centre. • Do not push down on the appliance door when it is open.
  • Page 8 SAFETY INSTRUCTIONS • Dispose of all packaging materials (such as plastic bags and styrofoam) away from children. The packaging materials can cause suffocation. • Remove the door before disposing of or discarding this appliance to avoid the danger of children or small animals getting trapped inside.

  • Page 9: Installation Parts And Specifications

    Front View Water Container Control Panel Door Drain Tube Available Accessories Please contact LG Electronics Customer Information Centre or visit the LG Website at http://www.lg.com for purchase. Condensing Drain Hose Drain Hose Holder Elbow Bracket for Securing Drain Hose Dry Rack...
  • Page 10 • The included accessories vary depending on the model you purchased. Specifications Asterisk(s) means model variant and can be varied (0-9) or (A-Z). Model RV09VHP2W / RV09VHP4W1 Power supply 220 V~, 50 Hz Dimension (Width X Depth X Height) 600 mm X 690 mm X 850 mm...

  • Page 11: Installation Location Requirements

    INSTALLATION Installation Location • With the appliance installed, adjust all four feet using a spanner to ensure the appliance is Requirements stable, and a clearance of approximately 20 mm is left between the top of the appliance and the Before installing the appliance, check the following underside of any work-top.

  • Page 12: Leveling The Appliance

    INSTALLATION Adjusting and Leveling the NOTE Appliance • The appliance performs best at a room When the appliance is not perfectly level, turn the temperature of 23 ℃. adjustable feet until the appliance no longer wobbles. • Turn the adjustable feet clockwise to raise or Electrical Connection turn the adjustable feet counterclockwise to lower from front-to-back, side-to-side and...
  • Page 13 INSTALLATION the door down carefully from the cabinet Swap the position of the hinge assembly with the front side facing down to the floor. the door latch assembly and then tighten the screws in reverse order. • Tighten the screw in their proper position referring from steps 2 to 4.

  • Page 14: Stacking Instructions

    INSTALLATION Stacking Kit Install the door with the screws removed in step 1 and then check the door closes properly. In order to stack the appliance, an LG stacking kit is required. NOTE Dryer • If you reversed the door, attach the...
  • Page 15 600L on upper part. The procedure for the opposite side will be the same. *1 The depth of the washing machine Place the appliance on the top of an LG front Installing the Optional Drain load washing machine. Hose Remove the 2 screws from the bottom of the Normally, condensed water is pumped up to the rear cover on each side.
  • Page 16 INSTALLATION Separate the anti-backflow lid and the water container hose from the connecting elbow or T piece. Attach the anti-backflow lid to the head of the connecting elbow or T piece and then connect the optional drain hose to the opposite side of the connecting elbow or T piece.

  • Page 17: Operation Operation Overview

    OPERATION OPERATION Operation Overview • All strings and attached belts of clothes should be well tied and fixed before being put into the drum. Using the Appliance Before the first cycle, set the appliance to dry for 5 Press the Power button to turn the appliance minutes to warm up the drum.

  • Page 18: Preparing The Clothes

    OPERATION Preparing the Clothes NOTE • The frequency of cleaning condenser may vary NOTE depending on the size and the initial moisture amount of the clothes. • For the best drying performance and most efficient energy usage, do not overload the appliance.
  • Page 19 OPERATION Woollens Symbol Description • Dry woollens on the Wool programme. Be sure to follow fabric care label symbols first. Wool Gentle / Delicate may not be completely dried from the cycle, so do not repeat drying. Pull woollens to their Do not Tumble Dry original shape and dry them flat.

  • Page 20: Control Panel

    • To use the extra functions, press and hold the corresponding button for 3 seconds. The corresponding symbol lights up in the display. Remote Start • With the LG ThinQ app, you can use a smartphone to control your appliance remotely. • In order to use the Remote Start function, refer to SMART FUNCTIONS. Wi-Fi •...
  • Page 21 OPERATION Description Time and Status Display • The display shows the settings, estimated remaining time, options, and status messages. When the appliance is turned on, the default settings in the display will illuminate. Time and Status Display Description Drying progress indicator •...

  • Page 22: Programme Table

    OPERATION Programme Table Sensor Drying Programme Guide Programme Cotton Max. Load Capacity 9 kg Dry Level Extra • Clothing Type • Towels, dressing gowns and bed linen • Detail • For thick and quilted fabrics Cupboard • Bath towels, tea towels, underwear and cotton socks •...
  • Page 23 OPERATION Programme Wool Max. Load Capacity 1 kg Detail For wool fabrics that are suitable for tumble drying Programme Sportswear Max. Load Capacity 2 kg Clothing Type Soccer kit and training wear Detail For polyester material Programme Allergy Care Max. Load Capacity 4.5 kg Clothing Type Cotton, underwear, bed sheets and baby clothes...
  • Page 24 OPERATION Programme Warm Air Max. Load Capacity – Clothing Type Bath towels, bath robes, dishcloths and acrylic quilted fabrics Detail Small Items & damp clothing, Everyday items suitable for heat drying CAUTION • If the load is less than 1 kg, please use the Warm Air programme in Timed Drying programmes. Wool items should be dried using the Wool programme and heat-sensitive fabrics including silk, underwear and lingerie should be dried using the Rack Dry programme.
  • Page 25 OPERATION Programme Dry Mode Programme Dry Level Energy Normal Speed Bedding – Refresh Down Jacket – Refresh Rack Dry – Cool Air – Warm Air –...

  • Page 26: Extra Options And Functions

    OPERATION Extra Options and Dry Level Functions It allows you to select a dryness level for the drying programme. Delay End Turn the appliance on. It allows you to delay the finishing time of the drying cycle from 3 hours to 19 hours. Select a programme.
  • Page 27 5 minutes. available accessories, you may need to purchase the dryer rack first if it was not provided with your model. Please contact LG Electronics Customer Information Centre or visit the LG Website at http://www.lg.com for purchase.
  • Page 28 OPERATION Open the door. NOTE • Check the lint filter and remove any lint Insert the hook of dryer rack to the drum accumulated from items dried on the rack. centre. • The More Time / Less Time keys can be used to finely adjust the drying time.

  • Page 29: Smart Functions

    LG ThinQ application. • If the distance between the appliance and • If you enable this function in the LG ThinQ the wireless router is too far, the signal application and turn on the dryer after using the strength becomes weak.
  • Page 30 Use a smartphone to control your appliance wireless router manual. remotely. You can also monitor your cycle • LG ThinQ is not responsible for any network operation so you know how much time is left in the connection problems or any faults, cycle.

  • Page 31: Smart Diagnosis

    If you experience a problem with your Wi-Fi equipped appliance, it can transmit troubleshooting data to a smartphone using the LG ThinQ application. • Launch the LG ThinQ application and select the Smart Diagnosis feature in the menu. Follow the instructions provided in the LG ThinQ application.
  • Page 32 SMART FUNCTIONS Place the mouthpiece of your smartphone close to the Power button. Press and hold the More Time button for 3 seconds or longer while holding the smartphone mouthpiece to the Power button until the data transfer is complete. •...

  • Page 33: Maintenance

    MAINTENANCE MAINTENANCE WARNING • Remove the power plug when you clean the appliance. Not removing the plug may result in electric shock. Cleaning after Every Dry Clean the inner filter Pull out the inner filter from the outer filter and Cleaning the Lint Filter then open the inner filter.
  • Page 34 MAINTENANCE Clean the outer filter Close the outer filter while pushing the side of the filter. Remove the dust or lint around the filter inlet. CAUTION • When the lint drops into the filter inlet, it may NOTE cause degradation of drying performance and increase in drying time.

  • Page 35: Cleaning The Appliance Periodically

    MAINTENANCE Empty the water container after every use. Not Press the Start/Pause button. doing so will affect the drying performance. Cleaning the Appliance NOTE Periodically • If the water container is full, the icon glows and a chime will sound while the appliance is operating.
  • Page 36 MAINTENANCE NOTE NOTE • Adequate room ventilation should be provided • Use the water container if the optional drain to avoid the back flow of gases into the room hose is installed or the appliance is stacked on from units burning other fuels, such as open the washing machine.
  • Page 37 MAINTENANCE • This function operates for about 3 hours. • Do not pour the water quickly as it will spill out. • Pouring more that 1.5 liters of water into the compartment will cause water to leak back out. Empty the water container after the function has finished.

  • Page 38: Troubleshooting

    Operation of your appliance can lead to errors and malfunctions. The following tables contain possible causes and notes for resolving an error message or malfunction. It is recommended to read the tables carefully below in order to save your time and money that may cost for calling to LG Electronics service centre.
  • Page 39 The door is closed while clothes or foreign substance is caught in the door. • Check if clothes or foreign substance is caught in the door before using the appliance. If water leaks continuously, contact the LG Electronics Customer Information Centre. Appliance runs and This is how the anti crease option works.
  • Page 40 TROUBLESHOOTING Symptoms Possible Cause & Solution Clothes take too long Appliance controls are not set properly. to dry. • Use the appropriate control settings for the type of load you are drying. Some loads may require an adjustment of the dry level setting for proper drying.
  • Page 41 TROUBLESHOOTING Symptoms Possible Cause & Solution Clothes are wrinkled. Clothes have dried too long (overdried). • Over drying a load of clothes can lead to wrinkled clothes. Try a shorter drying time. Clothes have been left in the appliance for too long after cycle ends. •...
  • Page 42 TROUBLESHOOTING Symptoms Possible Cause & Solution Clothes have damp Very large load or very small load. Single large item such as a blanket or spots after a Sensor comforter. Dry programme. • If items are too tightly packed or too sparse the sensor may have trouble reading the dryness level of the load.
  • Page 43 • Find the Wi-Fi network connected to your smartphone and remove it, then connected to the Wi-Fi register your appliance on LG ThinQ. network. Mobile data for your smartphone is turned on. • Turn off the Mobile data of your smartphone and register the appliance using the Wi-Fi network.
