Technical information
-Voltage
- Frequency rated
-Motor Power rated
-Heating Power rated : 900 - 990W
-Product dimensions( LxDxH) mm
-Capacity
-Net Weight
Material
- Jug
- Blade
- Motor housing
Published by Philips Consumer Lifestyle
1
SHW-01-001-14012R02
: 220 -230V
: 50Hz
: 120W
205x153x310mm
:1200ml
(for2~4 people)
: 2.0kg
: Stainless steel
: stainless steel
: PP (food contact)
Printed in China
SOUP MAKER
Power Cord:
HR2201/81
India
Copy Right Reserved
HR2201/81
Subject to modification
Advertisement
Related Manuals for Philips HR2201/81
Summary of Contents for Philips HR2201/81
- Page 1 :1200ml (for2~4 people) -Net Weight : 2.0kg Material - Jug : Stainless steel - Blade : stainless steel - Motor housing : PP (food contact) Published by Philips Consumer Lifestyle Printed in China Copy Right Reserved Subject to modification SHW-01-001-14012R02...
- Page 2 Product introduction Control panel A: Smooth soup program with light. Smooth soup program to make a smooth soup in 23 minutes. B: Chunky soup program with light. Chunky soup program to make a chunky soup in 20 minutes. C: Compote program with light. Compote program to make a compote in 13 minutes. D: Smoothie program with light....
- Page 3 Main feathers DC motor，light weight and small noise Unique blade design, perfect blading performance. Cageless design, easier clean Streamlined raised surface, ensure perfect blading performance...
-
Page 4: Motor Unit
Technical information - Electrical diagram: Motor Unit Control board Overflow sensor Main PCBA Thermostat Upper coupler motor Low coupler Motor thermostat Heating element Power socket Thermal fuse... - Page 5 Technical information - Function Flow Chart _ Cream Soup...
- Page 6 Technical information - Function Flow Chart _Chunky Soup - Function Flow Chart _Compote...
- Page 7 Technical information - Function Flow Chart _Smoothie - Function Flow Chart _Manual Blending...
- Page 8 Trouble shooting Plug in the appliance, no power. Is coupler Upper coupler and lower Assemble motor unit into jug connection coupler disconnect properly Lower coupler fault Replace lower coupler assy Thermostat or Thermal fuse Is jug ok? Replace socket assy fault Is PCB assy PCB assy fault...
- Page 9 Trouble shooting Power on, program complete but ingredients are not blended well. Proper Select the proper program In-proper program selected program? ( refer to recipe) Ingredients not prepared Prepare ingredient properly Ingredients? properly (refer to DFU & provided ( Quantity, Size, etc.) recipebook) Is motor Motor failed by rust...
- Page 10 Trouble shooting Overflow Proper Select the proper program In-proper program was selected program? ( refer to recipe) Ingredients Remove some ingredients to touched Too much ensure its level in somewhere overflow ingredients( including liquid) between MIN and MAX sensor? Is Overflow sensor Overflow sensor dirty Clean overflow sensor...
- Page 11 DISASSEMBLY ADVISE Step 3：Remove 9 fixing screws. You can get main PCBA, Key PCB. Before you start dismantling! For your safety be sure the plug is disconnected from the mains! Step 1：Remove the upper handle. Main PCBA EMC PCB Main PCBA Assy Key PCBA Step 2：...
- Page 12 How to replace DC motor. Step 1: Remove main PCBA and EMC PCB. Step 2: Remove blade with spanner. Step 3: Remove dust-protect cover. Easy-to- click design, easy to remove main PCBA. Step 4: Remove 4 fixing screws, then you can get out the motor.
-
Page 13: Exploded Drawing
Exploded drawing... -
Page 14: Spare Parts
Spare parts Position 12NC Part name Remark 996510060071 COVER OF LIB HANDLE Q828K20AY80 996510070897 LID HANDLE Q828K360E47R 996510070863 SCREW COVER J0010000033R 996510070862 CONTROL PANEL Y7769700008 996510070898 LID COVER Q8286141Y80R 996510070896 Q828365AE47 996510071898 PCB ASSY A7761000008R 996510054782 MOTOR COVER Q7769420B55R 996510070864 MOTOR ASSY WITH THERMOSTAT B776077S201R 996510070866... - Page 15 This chapter summarises the most common problems you could encounter with the appliance. If you are unable to solve the problem with the information below, visit www.philips.com/support for a list of frequently asked questions or contact the Consumer Care Centre in your country.
