- Page 1 Order Number : GETEC-C1-10-202 FCC Part 15 subpart B 1 / 1 Test Report Number : GETEC-E3-10-104 Page APPENDIX G : USER’S MANUAL EUT Type: LED LCD Monitor FCC ID.: BEJE2370VV...
- Page 2 OWNER’S MANUAL LED LCD MONITOR Please read this manual carefully before operating your set and retain it for future reference. LED LCD MONITOR MODELS E2370V E2770V www.lg.com...
-
Page 3: Important Precautions
Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential electrical shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing. - Page 4 Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.
- Page 5 Important Precautions On Cleaning Unplug the display before cleaning the face of the display screen. Use a slightly damp (not wet) cloth. Do not use an aerosol directly on the display screen because over-spraying may cause electrical shock. When cleaning the product, unplug the power cord and scrub gently with a soft cloth to prevent scratching.
- Page 6 Accessories !!! Thank you for selecting LGE products !!! Please make sure the following items are included with your monitor. If any items are missing, contact your dealer. Owner's Manual/Cards Power Cord (Depending on the country) DVI-D Signal Cable 15-pin D-Sub Signal Cable (This feature is not available in all countries.) Remote control...
-
Page 7: Connecting The Display
Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connecting the stand Place the monitor face down on the cushion or soft cloth. Assemble the Stand Base into the Stand Body in the correct direction as shown in the picture. Stand Body Stand Base Use a Coin on the bottom of the stand base and turn screw clockwise to tighten. -
Page 8: Positioning Your Display
Connecting the Display Detach the monitor to the Stand Base by turning the screw to the left. IMPORTANT This illustration depicts the general model of connection. Your monitor may differ from the items shown in the picture. Do not carry the product upside down holding only the stand base. The product may fall and get damaged or injure your foot. -
Page 9: Connecting With The Pc
Connecting the Display Connecting with the PC Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connect signal input cable and power cord in order, then tighten the screw of the signal cable. - Page 10 Connecting the Display Press the power button on the bottom right of the monitor to turn the power on. When monitor power is turned on, the 'Self Image Setting Function' is executed automatically. (Only Analog Mode) Power Button NOTE ‘ Self Image Setting Function’? This function provides the user with optimal display settings.When the user connects the monitor for the first time, this function automatically adjusts the display to optimal settings for individual input signals.
-
Page 11: Remote Control Functions
Remote Control Functions Remote Control Controls Button Use this button to turn the display on or off. Input Button Use this button to select the input signal. (D-SUB/DVI-D/HDMI1/HDMI2) User Mode Use this button to select the User Mode. Button Aspect Ratio Use Aspect Ratio control. -
Page 12: Control Panel Functions
Control Panel Functions Front Panel Controls G-MODE Button Use this button to enter USER MODE, THRU MODE, SUPER+ RESOLUTION, ASPECT RATIO or AUTO BRIGHT menus. For more information, refer to page 15 to 20. INPUT Button When two input signals at least are connected, you can (SOURCE Hot key) select the input signal (D-SUB/DVI-D/HDMI1/HDMI2) you want. -
Page 13: Auto Image Adjustment
Control Panel Functions MENU Button Use this button to enter or exit from the On Screen Display. OSD LOCKED/UNLOCKED This function allows you to lock the current control settings, so that they cannot be inadvertently changed. Press and hold the MENU button for several seconds. The message "OSD LOCKED"... -
Page 14: On Screen Display (Osd) Control Adjustment
On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls. -
Page 15: On Screen Display(Osd) Selection And Adjustment
On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. D-SUB : D-SUB(Analog signal) input DVI-D : DVI-D(Digital signal) input HDMI : HDMI signal Main menu Sub-menu Supported input Description G-MODE USER MODE Use this menu to select the User Mode. - Page 16 On Screen Display(OSD) Selection and Adjustment HORIZONTAL DISPLAY To adjust the position of the D-SUB VERTICAL screen To improve the clarity and CLOCK D-SUB PHASE stability of the screen Use this menu to allow the picture OVERSCAN HDMI to completely fill the screen, removing noise around the edges of HDMI input video signal.
- Page 17 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. Press the G-MODE Button, then the main menu of the OSD appears.
- Page 18 On Screen Display(OSD) Selection and Adjustment This menu allows you to easily customize the settings to your preferences, such as Brightness, SUPER+ RESOLUTION, and screen Aspect Ratio. Once set, you can select the optimized mode depending on your preferences. Main menu Sub menu Description USER MODE...
- Page 19 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description THRU MODE SUPER+ RESOLUTION THRU MODE SUPER+ RESOLUTION Not use the Frame-Buffer memory G-MODE G-MODE THRU MODE THRU MODE G-MODE SUPER+ RESOLUTION G-MODE THRU MODE G-MODE SUPER+ RESOLUTION to prevent the picture delay. It can use in GAME MODE to prevent picture delay.
- Page 20 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description SUPER+ RESOLUTION ASPECT RATIO SUPER+ RESOLUTION ASPECT RATIO Select this when you want to use the NORMAL G-MODE G-MODE SUPER+ RESOLUTION SUPER+ RESOLUTION G-MODE ASPECT RATIO product in the most general using G-MODE SUPER+ RESOLUTION G-MODE...
- Page 21 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description ASPECT RATIO ASPECT RATIO The picture will be displayed with FULL G-MODE G-MODE ASPECT ASPECT RA RATIO G-MODE ASPECT RATIO Full size. FULL ORIGINAL ORIGINAL FULL ORIGINAL The picture will be displayed with ORIGINAL G-MODE G-MODE...
- Page 22 On Screen Display(OSD) Selection and Adjustment G-MODE SUPER+ RESOLUTION G-MODE SUPER+ RESOLUTION G-MODE SUPER+ RESOLUTION Main menu Sub menu Description AUTO BRIGHT AUTO BRIGHT AUTO BRIGHT Select this to adjust the brightness G-MODE G-MODE AUTO BRIGHT O BRIGHT G-MODE AUTO BRIGHT automatically.
- Page 23 On Screen Display(OSD) Selection and Adjustment The OSD screen will appear when you press the INPUT button on the front of the monitor. Menu Name INPUT INPUT : Move to the upper menu Sub-menu Name : Move OK : Select the menu DVI-D DVI-D D-SUB...
- Page 24 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. Press the MENU Button, then the main menu of the OSD appears.
-
Page 25: Black Level
On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description D-SUB/DVI-D input To adjust the brightness of the BRIGHTNESS screen. To adjust the contrast of the screen. CONTRAST To adjust the clearness of the screen. SHARPNESS BLACK LEVEL You can set the offset level. If you select 'HIGH', the screen will be bright and if HDMI input you select ‘LOW’, the screen will be... -
Page 26: Color Temp
On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description PRESET Mode PIP ON / OFF COLOR TEMP Select either PRESET or USER to PIP ON / OFF PIP INPUT PIP INPUT adjust the screen color. PIP POSITION PIP POSITION PIP SWAP PIP SWAP PIP SWAP... - Page 27 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description D-SUB input To move image left and right. HORIZONTAL To move image up and down. VERTICAL To minimize any vertical bars or stripes CLOCK visible on the screen background. The horizontal screen size will also change.
- Page 28 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description D-SUB input To choose the language in which the LANGUAGE control names are displayed. WHITE If the output of the video card is BALANCE different the required specifications, the color level may deteriorate due to video signal distortion.
- Page 29 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description D-SUB/DVI-D input PIP ON/OFF To select PIP on or off. * It supports only for HDMI input in RGB PIP ON / OFF (D-sub analog signal) mode. PIP ON / OFF PIP INPUT PIP INPUT PIP INPUT...
- Page 30 On Screen Display(OSD) Selection and Adjustment The OSD screen will appear when you press the VOLUME button on the front of the monitor. Menu Name : Move to the upper menu : Decrease Sub-menu Name : Increase : Mute Button Tip EXIT : Exit Main menu Sub menu...
-
Page 31: Troubleshooting
Troubleshooting Check the following before calling for service. No image appears No image appears Is the power cord of the • Check and see if the power cord is connected display connected? properly to the power outlet. Is the power indicator •... -
Page 32: Display Image Is Incorrect
Troubleshooting Display image is incorrect Display Position is • Press the AUTO button to automatically adjust incorrect. your display image to the ideal setting. • Press the AUTO button to automatically adjust On the screen your display image to the ideal setting. background, vertical bars or stripes are visible. - Page 33 CD (or diskette) that comes with your display. Or, you can also download the driver from our web site: http://www.lg.com. • Make sure to check if the video card supports Plug&Play function. The Audio function is not working Picture OK &...
-
Page 34: Specifications
Specifications E2370V Display 58.42 cm (23 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 58.42 cm 0.265 mm x 0.265 mm (Pixel pitch) Horizontal Freq. Analog,Digital: 30 kHz to 83 kHz Sync Input HDMI : 30 kHz to 83 kHz Vertical Freq. - Page 35 Specifications E2770V Display 68.6 cm (27 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 68.6 cm 0.311 mm x 0.311 mm (Pixel pitch) Horizontal Freq. Analog,Digital: 30 kHz to 83 kHz Sync Input HDMI : 30 kHz to 83 kHz Vertical Freq.
-
Page 36: Preset Modes (Resolution)
Specifications Preset Modes (Resolution) DSUB/DVI Timing Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) 640 x 350 31.469 720 x 400 31.468 640 x 480 31.469 640 x 480 37.500 800 x 600 37.879 800 x 600 46.875 1024 x 768 48.363 1024 x 768 60.123... -
Page 37: Installing The Wall Mount Plate
Installing the Wall mount plate This monitor satisfies the specifications of the Wall mount plate or the interchange device. Place the monitor face down on the cushion or soft cloth. To remove the Stand Base from the Stand Body, turn the screw counterclockwise using a coin. - Page 38 Installing the Wall mount plate Install the Wall mount plate. Wall mount plate(Separate purchase) This is stand-type or wall mount type and is connectable with Wall mount plate. Please refer to the installation guide for more details, which is provided when Wall mount plate is purchased.
- Page 39 Make sure to read the Important Precautions before using the product. Ke e p t h e O w n e r ’ s M a n u a l (C D ) i n a n accessible place for future reference. The model and serial number of the SET is ENERGY STAR is a set of power-saving located on the back and one side of the SET.
-
Page 40: Fcc Compliance Statement
Regulatory Information cont. respecte toutes les exigences du Règlement sur le FCC Compliance Statement matériel brouilleur du Canada. This equipment has been tested and found to comply NOTICE within the limits of a Class B digital device pursuant to Part The regulations are applied only to the products with the 15 of the FCC Rules. - Page 41 Regulatory Information cont. Why do we have environmentally labelled computers? visual ergonomics. In many countries, environmental labelling has become an established method for encouraging the adaptation of Below you will find a brief summary of the ecological goods and services to the environment. With the growing requirements met by this product.
- Page 42 Congratulations! Information for Environmental Preservation The display you have just purchased carries the TCO’03 LGE. announced the 'LG Declaration for a Cleaner Displays label. Environment' in 1994, and this ideal has served as a This means that your display is designed,manufactured guiding managerial principle ever since.
- Page 43 à la fois les aspects Informationen zur Erhaltung der Umwelt économiques et sociaux de nos activités, tout en Im Jahr 1994 verkündete LGE die 'LG Declaration for a respectant l’environnement. Cleaner Environment' (LG Erklärung für eine sauberere Umwelt).
- Page 44 La LGE. ha annunciato nel 1994 la cosiddetta 'LG Declaration for a Cleaner Environment' (Dichiarazione di Promocionamos actividades orientadas a la conservación LG a favore di un ambiente più pulito), un ideale che da del medio ambiente y desarrollamos nuestros productos allora funge da principio ispiratore della gestione específicamente para que se ajusten a la filosofía que...
- Page 45 'ƒÂÍ·‡ˆË˛ LG ÔÓ Óı‡Ì ÓÍÛʇ˛˘ÂÈ Ò‰˚', het milieu ÍÓÚÓ‡ˇ Ò ÚÂı ÔÓ ÒÎÛÊËÚ ÓÒÌÓ‚Ì˚Ï ÔË̈ËÔÓÏ LGE. publiceerde in 1994 de 'LG Declaration for a Cleaner ÛÔ‡‚ÎÂÌˡ. Õ‡ ÓÒÌÓ‚Â ˝ÚÓÈ ‰ÂÍ·‡ˆËË Ï˚ ÒÏÓ„ÎË Environment' (de LG-verklaring met betrekking tot een Ô‰ÔËÌˇÚ¸ ‰ÂÈÒڂˡ, Ó·ÂÒÔ˜˂‡˛˘ËÂ...
- Page 46 ÔËÂÏÎÂÏÓ„Ó ÏÂÚÓ‰‡. «‡ ·ÓΠÔÓ‰Ó·ÌÓÈ ËÌÙÓχˆËÂÈ ÔÓ Ì‡¯ÂÈ ÔÓ„‡ÏÏ ÛÚËÎËÁ‡ˆËË ÓÚıÓ‰Ó‚ Ó·‡˘‡ÈÚÂÒ¸ Í (EPA applied model only) ÏÂÒÚÌÓÏÛ ÔÓÒÚ‡‚˘ËÍÛ ËÎË Ô‰ÒÚ‡‚ËÚÂβ ÍÓÔÓ‡ˆËË LG. is a set of power-saving guidelines NERGY issued by the U.S. Environmental Protection Ã˚ ÓËÂÌÚËÛÂÏÒˇ ̇ Ó·ÂÒÔ˜ÂÌË ˝ÍÓÎӄ˘ÂÒÍÓÈ...
- Page 47 Regulatory Information cont. WEEE un bidone della spazzatura barrato da una croce (for Europe ) significa che il prodotto è coperto dalla direttiva europea 2002/96/EC. 2.Tutti i prodotti elettrici ed elettronici dovrebbero essere smaltiti separatamente rispetto alla raccolta differenziata municipale, mediante impianti di raccolta specifici designati dal governo o dalle autorità...
- Page 48 Regulatory Information cont. 4.Wilt u meer informatie over de verwijdering van eller de lokale myndigheder. uw oude toestel? Neem dan contact op met uw 3.Korrekt bortskaffelse af dit gamle apparat er med gemeente, de afvalophaaldienst of de winkel til at forhindre mulige skadevirkninger på miljøet waar u het product hebt gekocht.
- Page 49 Regulatory Information cont. Portuguese Hungarian Slovak Polish Czech Croatian...
- Page 50 Regulatory Information cont. Estonian Latvian Lithuanian...
