- Page 1 Dryer User Manual DSX 93460 W 2960311307_KM/130117.2102...
- Page 2 Please read this user manual first! Dear Customer, Thank you for prefering a Beko product. We hope that your product which has been manufactured with high quality and technology will give you the best results. We advise you to read through this manual and the other accompanying documentation carefully before using your product and keep it for future reference.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1 Important safety and 6 Operating the product environmental instructions 6.1 Control panel ........20 1.1 General safety ........4 6.2 Screen symbols ........20 1.1.1 Electrical safety .......5 6.3 Preparing the machine .....21 1.1.2 Product safety .........6 6.4 Program selection ......21 1.2 Mounting over a washing machine 8 6.5 Main programs ........21... -
Page 4: Important Safety And Environmental Instructions
Important safety and environmental instructions This section contains safety instructions that will help protect from risk of personal injury or property damage. Failure to follow these instructions shall void any warranty. 1.1 General safety • The dryer can be used by children at and above 8 years old and by persons whose physical, sensory or mental capabilities were not fully developed or who lack experience and knowledge provided that they are... -
Page 5: Electrical Safety
Important instructions for safety and environment 1.1.1 Electrical safety Electrical safety instructions should be followed while electrical connection is made during the installation. The appliance must not be supplied through an external switching device, such as a timer,or connected to a circuit that is regularly switched on and off by utility. -
Page 6: Product Safety
Important instructions for safety and environment 1.1.2 Product safety • Superheating of the clothes inside of the dryer can occur if you cancel the programme or in the event of a power failure whilst the dryer is running, this concentration of heat can cause self-combustion and fire so always activate the ventilation programme to cool down or quickly remove all laundry from the dryer in order to hang them up... - Page 7 Important instructions for safety and environment Clothes that are washed inadequately may ignite on their own and even may ignite after drying ends. • You must provide enough ventilation in order to prevent gases exiting from devices operating with other types of fuels including the naked flame from accumulating in the room due to the back fire effect.
-
Page 8: Mounting Over A Washing Machine
Important instructions for safety and environment • The lint must not be allowed to accumulate around the tumble dryer. 1.2 Mounting over a washing machine • A fixing device should be used between the two machines when installing the dryer above a washing machine. The fitting device can be obtained through spare part suppliers. -
Page 9: Intended Use
Important instructions for safety and environment 1.3 Intended use • Dryer has been designed for domestic use. It is not suitable for commercial use and it must not be used out of its intended use. • Use the dryer only for drying laundry that are marked accordingly. -
Page 10: Compliance With The Weee Regulation And Disposing Of The Waste Product
Important instructions for safety and environment 1.5 Compliance with the WEEE regulation and disposing of the waste product This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waste electrical and electronic equipment (WEEE). This product has been manufactured with high quality parts and materials which can be reused and are suitable for recycling. -
Page 11: Technical Specifications
Important instructions for safety and environment 1.8 Technical Specifications Height (Min. / Max.) 84,6 cm / 86,6 cm* Width 59,5 cm Depth 60,9 cm Capacity (max.) 9 kg** Net weight (plastic front door 49,5 kg usage) Net weight (glass front door 52 kg usage) Voltage... -
Page 12: Your Dryer
Your Dryer 2.1 Overview 1. Top panel 2. Control panel 3. Loading door 4. Kick plate opening button 5. Ventilation grids 6. Adjustable legs 7. Kick plate 8. Type label 9. Lint filter 10. Water tank drawer 11. Power cord Dryer / User Manual 12 / EN... -
Page 13: Package Contents
Your Dryer 2.2 Package Contents 1. Water drain hose * 2. Filter drawer spare sponge* 3. User Manual 4. Drying basket* 5. Drying basket user manual* *It can be supplied with your machine depending on its model. Dryer / User Manual 13 / EN... -
Page 14: Installation
Installation Before the calling the nearest Authorized • The rear surface of the tumble dryer Service for the installation of the dryer, shall be placed against a wall. ensure that electrical installation and on the Do not place the dryer water drain is appropriate referring to the power cable. -
Page 15: Adjusting The Feet
Installation 3.4 Adjusting the feet Connecting the water drain hose 1-2 Pull hose at the behind of the dryer • In order to ensure that the dryer by hand in order to disconnect it from operates more silently and vibration- where it is connected. -
Page 16: Warnings About Sounds
Installation 3.7 Warnings about sounds It is normal to hear a metallic noise from the compressor sometimes during operation. Water collected during operation is pumped to water tank. It is normal to hear pumping noise during this process. 3.8 Changing the illumination lamp In case an illumination lamp is used in your laundry dryer.To change the Bulb/LED used... -
Page 17: Electrical Connection
Electrical Connection Installation Make sure that you have an earthed power Do not operate without the top outlet socket rated at 13 amps (minimum). cover fitted. Risk of injury. 4.1 Attention! When installed, the socket must be reachable Important after installation, or a separate switch (which can disconnect the two poles) must be used 4.3 Fitting a different plug in the installation. -
Page 18: Preparation
Preparation 5.1 Laundry suitable for drying in the dryer Always obey the instructions given on the garment tags. Dry only the laundry having a label stating that they are suitable for drying in a dryer and make sure that you select the appropriate programme. -
Page 19: Correct Load Capacity
Preparation • Do not add wet laundry while the dryer is Following weights are given as examples. in operation Approximate • Clean the lint filter before or after each Laundry weights (g)* drying cycle. (See 7.1 Cleaning Lint Cotton quit covers Filter / Loading Door Inner Surface) 1500 (double) -
Page 20: Operating The Product
Operating the product 6.1 Control panel Program selection knob Remaining duration indicator On/Off button 4. Start/pause button End duration button Sound warning button 6.2 Screen symbols Child-proof Filter Tank Volume up Anti Mute full lock cleaning Creasing Dryer / User Manual 20 / EN... -
Page 21: Preparing The Machine
Operating the product 6.3 Preparing the machine 6.5 Main programs Plug in the machine The main programs are given below based on Place laundry inside the machine. fabric type. • Cotton Press the On/Off button. 4. When your machine turns on for the first Dry durable laundry with this program. - Page 22 Operating the product • Babyprotect Program used for baby clothing with can be dried approval on the label. Very little dampness might remain on the shirts after the program. It is recommended that you do not leave the shirts in the drying machine.
-
Page 23: Programme Selection And Consumption Table
Operating the product 6.7 Programme selection and consumption table Capacity Spin speed in washing Approximate amount Drying time Programmes (kg) machine (rpm) of remaining humidity (minutes) Cottons / Coloreds Extra dry 1000 % 60 Cupboard dry 9 / 4,5 1000 % 60 185 / 108 Iron dry... -
Page 24: Auxiliary Functions
Operating the product 6.8 Auxiliary functions Loading door open Start/Pause led blinks when the loading door Sound warning cancel of the drying machine is open. Drying machine makes sound warnings 6.10 End duration when the program is completed. If you don’t want sound notifications, press the “Sound You can delay the end duration of the Notification”... -
Page 25: Starting The Programme
Operating the product 6.13 Changing the programme Canceling the end duration function If you want to cancel the end duration after it is started setting countdown and start the program After the machine starts running, you can right away: change the program you selected to dry your 1. -
Page 26: Canceling The Programme
Operating the product Do not contact the inner surface of the drum when adding or removing laundry during a continuing program. The drum surface is hot. 6.14 Canceling the programme If you want to cancel the program and end the drying operation for any reason after the machine starts running, press the On/Off button. -
Page 27: Maintenance And Cleaning
Maintenance and cleaning Service life of product extends and • A layer can build up on the filter pores frequently experienced problems will be that can cause clogging of the filter after reduced if it is cleaned at regular intervals. using the dryer for a while. -
Page 28: Cleaning The Sensor
Maintenance and cleaning 7.2 Cleaning the sensor 7.3 Draining the water tank There are dampness sensors in the dryer Dampness of the laundry is removed and that detect whether the laundry is dry or not. condensed during drying process and the To clean the sensors: water that arise accumulates in the water •... -
Page 29: Cleaning The Filter Drawer
Maintenance and cleaning • Open the filter drawer by pressing the If the direct water draining is used red button. as an option, there is no need to empty the water tank. 7.4 Cleaning the filter drawer Lint and fiber that could not be captured by the lint filter are blocked in the filter drawer behind the kick plate. -
Page 30: Cleaning The Evaporator
Maintenance and cleaning 7.5 Cleaning the evaporator • Close the filter drawer as to lock the red button. Clean the lint accumulated on the fins of the evaporator located behind the filter drawer with a vacuum cleaner. • Place the filter drawer back into its place, turn the filter drawer cover in the arrow direction and close it securely. -
Page 31: Troubleshooting
Troubleshooting Drying process takes too much time. • Pores of the lint filter are clogged. >>> Wash the lint filter with warm water. • Filter drawer may be blocked>>>clean the foam inside the filter drawer. • Ventilation grids on the front side of the machine are blocked. >>> Remove the objects (if any) that block ventilation in front of the ventilation grids. - Page 32 Troubleshooting Drum lighting does not turn on. (On models with lamp) • Dryer is not switched on with the On / Off button. >>> Make sure that the dryer is switched on. • Lamp is defective. >>> Call Authorized Service Agent to have the lamp replaced. End/Anti-creasing symbol is on.
-
Page 33: Service
Service Service once the Please keep your purchase receipt or other proof of purchase in a safe place; you will manufacturers guarantee has need to have it should the product require expired. attention under guarantee. If you have purchased an extended You should also complete the details below;... - Page 36 • Disclaims any liability for incidental or consequential damages. • The guarantee does not in anyway diminish your statutory or legal rights. Beko plc, Beko House, 1 Greenhill Crescent, Watford, WD18 8QU Tel: 0845 6004911 Email: service@beko.co.uk Fax: 0845 6004922...
