Page 1
TopPage LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U SERVICE MANUAL No. S14A1LC60EQ1P LCD COLOR TELEVISION LC-60/70EQ10U PWB Unit Edition LC-60/70SQ10U LC-60/70SQ15U LC-60/70SQ17U LC-60/70TQ15U LC-60/70UQ17U MODELS In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its orig- inal condition and only parts identical to those specified should be used. CONTENTS OUTLINE CHAPTER 2.
Page 2
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U LC-60EQ10U Service Manual OUTLINE OUTLINE MODEL NAME PARTS CODE DESCRIPTION LC-60/70EQ10U DKEYMG381FM01 MAIN Unit LC-60/70SQ15U/17U,TQ15U,SQ10U,UQ17U DKEYMG382FM01 MAIN Unit LC-60EQ10U,SQ10U/15U/17U DUNTKG400FM01 LCD CONTROL (T-CON) Unit LC-70EQ10U,SQ10U/15U/17U DUNTKG400FM02 LCD CONTROL (T-CON) Unit LC-60TQ15U,UQ17U DUNTKG400FM10 LCD CONTROL (T-CON) Unit LC-70TQ15U,UQ17U DUNTKG400FM11 LCD CONTROL (T-CON) Unit •...
Page 3
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U Service Manual LC-60EQ10U CHAPTER 1. PRINTED WIRING BOARD ASSEMBLIES [1] MAIN Unit (DUNTKG381FM01) MAIN Unit (Side-A) (DUNTKG381FM01) 1 – 1...
Page 4
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U MAIN Unit (Chip Side-A) (DUNTKG381FM01) P 9 5 0 P 9 5 0 P 9 5 0 P 2 0 0 P 2 7 0 S C 3 8 I C 2 0 0 P 1 9 0 F B 2 0 C 9 5 1 F B 9 5 R 9 5 5...
Page 5
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [2] MAIN Unit (DUNTKG382FM01) MAIN Unit (Side-A) (DUNTKG382FM01) 1 – 3...
Page 9
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U LCD CONTROL Unit (Side B) 1 – 7...
Page 10
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U LCD CONTROL Unit (Chip Side B) C5904 C5885 C5905 FL5807 C5888 C5886 C5814 FL5806 C5892 C5890 FB5834 FB5832 C5887 C5819 FL5804 1 – 8...
Page 11
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U Service Manual LC-60EQ10U CHAPTER 2. SCHEMATIC DIAGRAM [1] DESCRIPTION OF SCHEMATIC DIAGRAM 1. VOLTAGE MEASUREMENT CONDITION: 1) The voltages at test points are measured on exclusive AC adaptor and the stable supply voltage of AC 120V. Signals are fed by a color bar signal gener- ator for servicing purpose and the above voltages are measured with a 20k ohm/V tester.
Page 12
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [2] SCHEMATIC DIAGRAM • MAIN Unit (DKEYMG381FM01) MAIN Unit-1(DUNTKG381FM01) 2 – 2...
Page 13
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U MAIN Unit-2(DUNTKG381FM01) 2 – 3...
Page 14
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U MAIN Unit-3(DUNTKG381FM01) 2 – 4...
Page 15
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U MAIN Unit-4(DUNTKG381FM01) 2 – 5...
Page 16
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U MAIN Unit-5(DUNTKG381FM01) 2 – 6...
Page 17
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U MAIN Unit-6(DUNTKG381FM01) 2 – 7...
Page 18
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U MAIN Unit-7(DUNTKG381FM01) 2 – 8...
Page 19
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U MAIN Unit-8(DUNTKG381FM01) 2 – 9...
Page 20
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U MAIN Unit-9(DUNTKG381FM01) 2 – 10...
Page 21
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U MAIN Unit-10(DUNTKG381FM01) 2 – 11...
Page 22
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U MAIN Unit-11(DUNTKG381FM01) 2 – 12...
Page 23
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U • MAIN Unit (DKEYMG382FM01) MAIN Unit-1(DUNTKG382FM01) MAIN1(T UN ER ) T U1104 AA083WJ QZ ATS C-HN IM T O MAIN 4(CP U) R 1151 R 1104 IF_ _ AG C IF_ _ _ AG C C PU _IF_ AG C F B1106 0241TA D _ _ I F +...
Page 24
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U MAIN Unit-2(DUNTKG382FM01) MAIN2(T ER MINAL) DUN TK G382WE 01 T O MAIN10(P OW ER ) D+3.3V D+5V B U+3. 3V T L570 C 578 0.1u T O MAIN 7(UC OM) R 608 C 577 R 620 T L575 4. 7u 1/10W F B527 U AR T_ CP UT O232C...
Page 25
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U MAIN Unit-3(DUNTKG382FM01) MAIN3(H DMI) DUN TK G382WE 01 T O_PO WE R ( 0 10) M+2.3V D +5V D +3.3V B U+3.3V R 1519 B U+5V D1521 D B2S 311 C 1515 T L2601 H DMIS W_ 1.0V R 1545 0.1u V CC IC1501...
Page 26
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U MAIN Unit-4(DUNTKG382FM01) MAIN4 (CP U) T O MAIN10(P OW ER ) S TB +3.3V R 3397 D +5V T O MAIN11(L AN _U SB ) H DMI0_R X_S D A D +3.3V U SB _ D 0P U SB _ D 0P H DMI0_R X_S C L IC3303 C 3333...
Page 27
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U MAIN Unit-5(DUNTKG382FM01) MAIN5 (DDR) DUN TK G 382WE 01 T O MAIN10(P OW ER S UP P LY ) D +1.5V T O MAIN 4(CP U) B _D DR _D Q8 B _D DR _D Q8 B _D DR _D Q9 B _D DR_DQ 9 B _ DD R_ DQ 10 B _D DR _D Q10...
Page 28
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U MAIN Unit-6(DUNTKG382FM01) MAIN6 (FL AS H) DUN TK G382WE 01 T O MAIN10(P OW ER S UP P LY ) D +3.3V C 3112 B U+3. 3V 0.1u T O_MAIN07(U CO M) R 3102 4.7K V CC E XT _B O O T_ BU T O MAIN 4(CP U) E E PR OM_W P R 3101...
Page 29
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U MAIN Unit-7(DUNTKG382FM01) MAIN7 (UC OM) T O MAIN10(P OW ER ) DUN TK G382WE 01 D +5V B U+5V B U+3. 3V R 2021 R 2082 R 2015 O PC *P 2001 N B265WJ T O MAIN10(P OW ER ) T L2051 D +3.3V B U+5V...
Page 30
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U MAIN Unit-8(DUNTKG382FM01) MAIN8 (PANE L) DUN TK G382WE 01 T O_MAIN10(P OW ) D +3.3V B U+3. 3V B U+5V U R+13V S C3801 W A671WJ QZ F B3840 R 3808 A373WJ QZ G ND T O_MAIN 4(CP U) V BO _H TP DN H TP DN F B3821...
Page 31
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U MAIN Unit-9(DUNTKG382FM01) MAIN9(AUDIO ) DUN TK G382WE 01 T O MAIN 2(TE RMINAL ) MON I_ HP _R MON I_ HP _L MON I_ HP _L R 1904 R 1903 C 1907 390P C 1908 C 1904 H P_ MO NITO R_ L 2.2u C 1910 C 1905...
Page 32
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U MAIN Unit-10(DUNTKG382FM01) MAIN10(P OW ER ) DUN TK G382WE 01 T o MA IN 1(TU NE R) 3411A33N T L9602 M+2.3V IC9602 C 9629 IC9605 D +3.3V 2200P V in V out 3464A33N T L9607 Q9602 G ND R N4982 V in V out T o MA IN 2(TE RMIN AL )
Page 33
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U MAIN Unit-11(DUNTKG382FM01) MAIN11(L AN _U SB ) DUN TK G382WE 01 T O MAIN10(P OW ER S UP P LY ) U +5V D +3.3V C 9402 T O MAIN 4(CP U) C 9403 T O MAIN 4(CP U) U SB _ D 1P C P U_ D AT MD I_ R J 45_T P U SB _ D 1N...
Page 34
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U • LCD CONTROL Unit (DUNTKG400FM01/02) LCD CONTROL Unit-1 (DUNTKG400FM01/02) 2 – 24...
Page 35
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U LCD CONTROL Unit-2 (DUNTKG400FM01/02) 2 – 25...
Page 36
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U LCD CONTROL Unit-3 (DUNTKG400FM01/02) 2 – 26...
Page 37
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U LCD CONTROL Unit-4 (DUNTKG400FM01/02) 2 – 27...
Page 38
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U LCD CONTROL Unit-5 (DUNTKG400FM01/02) 2 – 28...
Page 39
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U LCD CONTROL Unit-6 (DUNTKG400FM01/02) 2 – 29...
Page 40
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U • LCD CONTROL Unit (DUNTKG400FM04/05) LCD CONTROL Unit-1 (DUNTKG400FM04/05) V byOne_Connector(001) L CDCO NT U NIT 1/6 F B4801 T O PO WE R ( 0 04) A561WJ QZ VC C _ 13V F RE D _ 3D _ EN C 4823 C 4824 C 4825...
Page 41
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U LCD CONTROL Unit-2 (DUNTKG400FM04/05) DDR (002) (MAST ER ) R 5050 T O PO WE R ( 0 04) A_ D QL 7 A_ DD R_ D QL 7_ 1 VC C _ 3.3V VC C _ 3.3V R 5046 R 5002 VC C _ 1.5V VC C _ 1.5V...
Page 42
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U LCD CONTROL Unit-3 (DUNTKG400FM04/05) F961_MP T CO N Apricot(003) L CDCO NT U NIT 3/6 T O PO WE R ( 0 04) T O DDR(002) VC C _ 3.3V VC C _ 3.3V A_D D R_ D QL 6_ 2 C5823 C5826 A_D D R_ D QL 3_ 2...
Page 43
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U LCD CONTROL Unit-4 (DUNTKG400FM04/05) P OW ER (004) L CDCO NT U NIT 4/6 *R 6268 *R 6269 *R 6275 2.2K V LS _15.6V C 6212 D6206 C 6269 C 6256 C 6252 C 6248 E XA722WJ QZ 0.1u 0.1u 0.1u 0.1u...
Page 44
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U LCD CONTROL Unit-5 (DUNTKG400FM04/05) C S(005) L CDCO NT U NIT 5/6 V S2 *Q6803 2S D1664Q V S2 *Q6807 I_V CS +2 2S D1664Q *R 6852 C 6811 *R 6816 *R 6843 0.1u *R 6813 *R 6854 *R 6820 *R 6826 0.51 0.51...
Page 45
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U LCD CONTROL Unit-6 (DUNTKG400FM04/05) miniL VDS_Conn(006) L CDCO NT U NIT 6/6 T O PO WE R ( 0 04) VC C _ 3.3V E MC parts s elect R CILF A157WJ ZZY V RK -S B1F F000J# @ COMME S C5301 C N5301 C N5302...
Page 47
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U PartsGuide PARTS GUIDE No. S14A1LC60EQ1P LCD COLOR TELEVISION LC-60/70EQ10U Note: The reference numbers on the PWB are LC-60/70SQ10U arranged in alphabetical order. LC-60/70SQ15U LC-60/70SQ17U LC-60/70TQ15U LC-60/70UQ17U MODELS CONTENTS PRINTED WIRING BOARD PRINTED WIRING BOARD ASSEMBLIES (LC-60/70EQ10U) ASSEMBLIES (LC-60/70UQ17U) PRINTED WIRING BOARD DUNTKG381FM01 (MAIN Unit) ASSEMBLIES (LC-60/70SQ10U) DUNTKG382FM01 (MAIN Unit)
Page 48
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [1] PRINTED WIRING BOARD ASSEMBLIES (LC-60/70EQ10U) DKEYMG381FM01 MAIN Unit DUNTKG400FM01 LCD CONTROL (T-CON) Unit (LC-60EQ10U) DUNTKG400FM02 LCD CONTROL (T-CON) Unit (LC-70EQ10U) [2] PRINTED WIRING BOARD ASSEMBLIES (LC-60/70SQ10U) DKEYMG382FM01 MAIN Unit DUNTKG400FM01 LCD CONTROL (T-CON) Unit (LC-60SQ10U) DUNTKG400FM02 LCD CONTROL (T-CON) Unit (LC-70SQ10U)
Page 91
TopPage LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U SERVICE MANUAL No. S14A1LC60EQ10 LCD COLOR TELEVISION LC-60/70EQ10U LC-60/70SQ10U LC-60/70SQ15U LC-60/70SQ17U LC-60/70TQ15U LC-60/70UQ17U MODELS In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its orig- inal condition and only parts identical to those specified should be used. CONTENTS SAFETY PRECAUTION CHAPTER 6.
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U CONTENTS SAFETY PRECAUTION LED flashing specification at the time of IMPORTANT SERVICE SAFETY PRE- an error (Center icon LED used) ....6-1 CAUTION............i TROUBLESHOOTING TABLE PRECAUTIONS A PRENDRE LORS DE (LC-60/70EQ10U) ........6-4 LA REPARATION........
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U LC-60EQ10U SAFETY PRECAUTION Service Manual IMPORTANT SERVICE SAFETY PRECAUTION Service work should be performed only by qualified service technicians who are thoroughly familiar with all safety checks and the servicing guidelines which follow: WARNING • Using two clip leads, connect a 1.5k ohm, 10 watt resistor paral- leled by a 0.15µF capacitor in series with all exposed metal cabinet 1.
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U PRECAUTIONS A PRENDRE LORS DE LA REPARATION Ne peut effectuer la réparation qu' un technicien spécialisé qui s'est parfaitement accoutumé à toute vérification de sécurité et aux conseils suivants. • A l'aide de deux fils à pinces, brancher une résistance de 1.5 kΩ AVERTISSEMENT 10 watts en parallèle avec un condensateur de 0.15µF en série N'entreprendre aucune modification de tout circuit.
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U PRECAUTIONS FOR USING LEAD-FREE SOLDER Employing lead-free solder • “PWBs” of this model employs lead-free solder. The LF symbol indicates lead-free solder, and is attached on the PWBs and service manuals. The alphabetical character following LF shows the type of lead-free solder. Example: Indicates lead-free solder of tin, silver and copper.
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U LC-60EQ10U Service Manual OUTLINE MAJOR SERVICE PARTS PWB Unit • LC-60/70EQ10U PARTS CODE DESCRIPTION DKEYMG381FM01 MAIN Unit DUNTKG400FM01 LCD CONTROL (T-CON) Unit (LC-60EQ10U) DUNTKG400FM02 LCD CONTROL (T-CON) Unit (LC-70EQ10U) DUNTKF800FM53 KEY Unit DUNTKG369FM02 RC/ICON Unit RUNTKB222WJQZ WiFi+BT Unit RUNTKB109WJQZ POWER/DRIVE Unit (LC-60EQ10U) RUNTKB131WJQZ POWER/DRIVE Unit (LC-70EQ10U)
Page 97
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U • LC-60/70UQ17U PARTS CODE DESCRIPTION DKEYMG382FM01 MAIN Unit DUNTKG400FM10 LCD CONTROL (T-CON) Unit (LC-60UQ17U) DUNTKG400FM11 LCD CONTROL (T-CON) Unit (LC-70UQ17U) DUNTKF800FM54 KEY Unit DUNTKG369FM01 RC/ICON Unit RUNTKB222WJN1 WiFi+BT Unit RUNTKB116WJQZ POWER/DRIVE Unit (LC-60UQ17U) RUNTKB118WJQZ POWER/DRIVE Unit (LC-70UQ17U) RUNTKB075WJZZ LED Unit (LC-60UQ17U) RUNTKB077WJZZ LED Unit (LC-70UQ17U) NOTE: *1 Replace MAIN PWB Units (DKEYMG381FM01) in case of IC3103 failure.
Page 99
*1 Emergency alert messages via Cable are unreceivable. As part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from these values in individual units.
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U LC-60EQ10U Service Manual CHAPTER 3. DIMENSIONS [1] DIMENSIONS LC-60SQ17U/LC-60SQ15U/LC-60SQ10U/LC-60EQ10U Unit: inch (mm) Unité: pouce (mm) Unidad: pulgada (mm) *1 Active area/Área activa/Zone active *2 Thinnest part/Parte más delgada/Partie la plus mince *3 Including projecting parts/Incluyendo partes salientes/Parties saillantes incluses 3 –...
Page 107
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U LC-60TQ15U Unit: inch (mm) Unité: pouce (mm) Unidad: pulgada (mm) *1 Active area/Área activa/Zone active *2 Thinnest part/Parte más delgada/Partie la plus mince *3 Including projecting parts/Incluyendo partes salientes/Parties saillantes incluses 3 – 2...
Page 108
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U LC-70SQ17U/LC-70SQ15U/LC-70SQ10U/LC-70EQ10U Unit: inch (mm) Unité: pouce (mm) Unidad: pulgada (mm) *1 Active area/Área activa/Zone active *2 Thinnest part/Parte más delgada/Partie la plus mince *3 Including projecting parts/Incluyendo partes salientes/Parties saillantes incluses 3 – 3...
Page 109
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U LC-70TQ15U Unit: inch (mm) Unité: pouce (mm) Unidad: pulgada (mm) *1 Active area/Área activa/Zone active *2 Thinnest part/Parte más delgada/Partie la plus mince *3 Including projecting parts/Incluyendo partes salientes/Parties saillantes incluses 3 – 4...
Page 110
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U LC-60UQ17U Unit: inch (mm) Unité: pouce (mm) Unidad: pulgada (mm) *1 Active area/Área activa/Zone active *2 Thinnest part/Parte más delgada/Partie la plus mince *3 Including projecting parts/Incluyendo partes salientes/Parties saillantes incluses 3 – 5...
Page 111
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U LC-70UQ17U Unit: inch (mm) Unité: pouce (mm) Unidad: pulgada (mm) *1 Active area/Área activa/Zone active *2 Thinnest part/Parte más delgada/Partie la plus mince *3 Including projecting parts/Incluyendo partes salientes/Parties saillantes incluses 3 – 6...
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U LC-60EQ10U Service Manual CHAPTER 4. REMOVING OF MAJOR PARTS [1] REMOVING OF MAJOR PARTS (LC-60EQ10U/SQ10U,15U,17U) 1. Removing of Stand Unit and Rear Cabinet Ass’y. 1. Remove the 4 lock screws (1) and detach the Stand Unit (2). 2. Remove the 1 lock screw (3) and detach the AC Cord Cover (4). 3.
Page 113
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [Precautions when fixing the Rear Cabinet] When fixing the Rear Cabinet, be careful not to catch the backlight LED harness, speaker harness and other harnesses in it. • The hooks on the external wall of the Rear Cabinet are fitted in the Front Cabinet Ass’y. After putting the Rear Cabinet in place, fit the hooks securely;...
Page 114
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 2. Removing of Speaker (L/R), KEY Unit Ass’y and Bottom Cover (L/R). 1. Remove the 2 lock screws (1) and detach the Speaker Unit (R) (2), Speaker Unit (L) (3). 2. Disconnect the SP1 Wire. 3. Detach the KEY Unit Ass'y (4). 4.
Page 115
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 3. Removing of Connectors 1. Disconnect the following connectors from the MAIN Unit. (PD, LW, UB, BT,RA) 2. Disconnect the following connectors from the POWER/DRIVE Unit. (PD, LA) 3. Disconnect the following connectors from the LCD CONTROL Unit. (PL, LW) [LA] [PD] [PL]...
Page 116
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 4. Removing of 60" LCD Panel Module Unit, LCD CONTROL Unit, MAIN Unit, POWER/DRIVE Unit. 1. Remove the 21 Hooks and Detach the 60" LCD Panel Module Unit (1). 2. Remove the 2 Connecting Cords(FFC80P) (2), 2 Connecting Cords(FFC64P) (17), 4 Ferrite Cores (18). 3.
Page 117
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 5. Removing of RC/ICON Unit. 1. Detach the RC/ICON Unit (1). 2. Disconnect the RA Wire. 4 – 6...
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [2] REMOVING OF MAJOR PARTS (LC-70EQ10U/SQ10U,15U,17U) 1. Removing of Stand Unit and Rear Cabinet Ass’y. 1. Remove the 4 lock screws (1) and detach the Stand Unit (2). 2. Remove the 1 lock screw (3) and detach the AC Cord Cover (4). 3.
Page 119
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [Precautions for assembly] Push Push Push CAUTION Set it so that there may not be a clearance between Front Cabinet Ass'y and Rear Cabinet Ass'y. Push Push The fingernail is surely fixed when Rear cabinet Ass'y is There is a gap without the fingernail fitting firmly pushed, and the gap disappears.
Page 120
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 2. Removing of Speaker (L/R), KEY Unit and Bottom Cover (L/R). 1. Remove the 2 lock screws (1) and detach the Speaker Unit (R) (2), Speaker Unit (L) (3). 2. Disconnect the SP1 Wire. 3. Detach the KEY Unit Ass'y (4). 4.
Page 121
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 3. Removing of Connectors 1. Disconnect the following connectors from the MAIN Unit. (PD, LW, UB, BT,RA) 2. Disconnect the following connectors from the POWER/DRIVE Unit. (PD, LA) 3. Disconnect the following connectors from the LCD CONTROL Unit. (PL, LW) [PD] [LW] [RA]...
Page 122
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 4. Removing of 70" LCD Panel Module Unit, LCD CONTROL Unit, MAIN Unit, POWER/DRIVE Unit. 1. Remove the 24 Hooks and Detach the 70" LCD Panel Module Unit (1). 2. Remove the 2 Connecting Cords(FFC80P) (2), 2 Connecting Cords(FFC64P) (17), 4 Ferrite Cores (18). 3.
Page 123
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 5. Removing of RC/ICON Unit. 1. Detach the RC/ICON Unit (1). 2. Disconnect the RA Wire. 4 – 12...
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [3] The location putting on the heat measure sheet (LC-60/70EQ10U/SQ10U,15U,17U) 1. MAIN PWB Unit • LC-60EQ10U/SQ10U,15U,17U PSPAZC805WJKZ • LC-70EQ10U/SQ10U,15U,17U 27mm from center of screw hole. 20mm (3) Stick ***** x1 from center (4) Stick ***** x1 of screw hole. PSPAZC805WJKZ x2 (M&C PWB COOLER) 30mm...
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [4] Precautions for assembly (LC-60/70EQ10U/SQ10U,15U,17U) 1. Points to be checked and precautions when servicing the unit Mount the main PWB Ass’y on the backlight chassis and check that the EMI-prevention parts are not peeled and twisted from the access holes. (The EMI-prevention parts, conductive nonwoven fabric gaskets, must be seen from the access holes.) [Countermeasure] Attach the conductive nonwoven fabric gaskets on the shielded case on the main PWB.
Page 126
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U • LC-70EQ10U/SQ10U,15U,17U Base line (Punch mark of BL chassis) Base line (Punch mark of ANG) (2) Stick ***** PSPAZC690WJZZ (COND:8X255 ) (1) Prepare***** Caution LANGKD825WJ3W Base line : of TERMINAL ANG P unch mark (TERM ANG SIDE ) Stick it on the inside of the protruding portion. Do not stick it on protruding portion.
Page 127
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U The following is a drawing mounting the main PWB Ass’y on the backlight chassis. (The parts indicated by -> are the access holes for confirmation.) (Main PWB Ass’y => State where the shielded case and RF terminal angle are mounted on the main PWB) 4 –...
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [5] REMOVING OF MAJOR PARTS (LC-60TQ15U) 1. Removing of Stand Unit and Rear Cabinet Ass'y. 1. Remove the 1 lock screw (1) and detach the Stand Support Ass'y (2). 2. Remove the 4 lock screws (3) and detach the Stand Unit (4). 3.
Page 129
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 2. Removing of Speaker (L/R), KEY Unit and Bottom Cover Ass'y. 1. Remove the 1 lock screw (1) and the 4 Hooks and detach the Bottom Cover Ass'y (2). 2. Detach the Speaker Unit (L) (3), Speaker Unit (R) (4). 3.
Page 130
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 3. 3. Removeing of connectors and Decoration Cover (Rear), Front Cover Ass'y and BL Support Angle Ass'y (Bottom). 1. Disconnect the following connectors from MAIN Unit. (SP2,PD, LW, RA, UB, BT). 2. Disconnect the following connectors from POWER/DRIVE Unit. (PD, L1). 3.
Page 131
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 4. Removing of 60" LCD Panel Module Unit, LCD CONTROL Unit, MAIN Unit, POWER/DRIVE Unit. 1. Remove the 17 lock screws (1) and detach the Aluminum Frame Ass'y (2) 2. Remove the 2 Connecting Cords(FFC80P) (4), 2 Connecting Cords(FFC64P) (5), 4 Ferrite Cores (3). 3.
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [6] REMOVING OF MAJOR PARTS (LC-70TQ15U) 1. Removing of Stand Unit and Rear Cabinet Ass'y. 1. Remove the 1 lock screw (1) and detach the Stand Support Ass'y (2). 2. Remove the 4 lock screws (3) and detach the Stand Unit (4). 3.
Page 133
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 2. Removing of Speaker Unit (L/R), KEY Unit and Bottom Cover Ass'y. 1. Remove the 1 lock screw (1) and the 4 Hooks and detach the Bottom Cover Ass'y (2). 2. Detach the KEY Unit Ass'y (3). 3. Remove the 2 Hooks and detach the KEY Button (4) from the KEY Button Cover (5). 4.
Page 134
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 3. Removeing of connectors and Decoration Cover (Rear) and Front Cover Ass'y. 1. Disconnect the following connectors from MAIN Unit. (PD, SP2, LW, RA, UB, BT). 2. Disconnect the following connectors from POWER/DRIVE Unit. (PD, L1, L2). 3. Disconnect the following connectors from LCD CONTROL Unit. (PL, LW). 4.
Page 135
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 4. Removing of Aluminum Frame Ass'y, LCD CONTROL Unit, MAIN Unit, POWER/DRIVE Unit, VESA Angle Ass'y and Stand fix Angle. 1. Remove the 18 lock screws (1) and detach the Aluminum Frame Ass'y (2) 2. Remove the 2 Connecting Cords(FFC 80p) (3), 2 Connecting Cords(FFC 64p) (4), 4 Ferrite Cores (5). 3.
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [7] The location putting on the heat measure sheet (LC-60/70TQ15U) 1. MAIN PWB Unit BL chassis (Under the Main unit) 27mm from center of screw hole. 20mm from center of screw hole. 30mm (1) Stick*** Punch mark PSPAZC805WJKZ COOLER:25x25x8t Stick standard for CPU Cooler is Punch Mark(right under) 27mm &...
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [8] Precautions for assembly (LC-60/70TQ15U) 1. Points to be checked and precautions when servicing the unit Mount the main PWB Ass’y on the backlight chassis and check that the EMI-prevention parts are not peeled and twisted from the access holes. (The EMI-prevention parts, conductive nonwoven fabric gaskets, must be seen from the access holes.) [Countermeasure] Attach the conductive nonwoven fabric gaskets on the shielded case on the main PWB.
Page 138
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U • LC-70TQ15U (2) Stick*** (1) Prepare*** PSPAZC691WJZZ LANGKD146WJFW CONDUCTR:8x180 TERM ANG WIDTH (4) Prepare*** LANGKD145WJFW SIDETERMINALANG (5) Stick*** (3) Stick ***** PSPAZC690WJZZ HDECPA090WJZZ T-LABEL SIDE CONDUCTR:8x255 (3) Stick*** HDECPA091WJZZ DEC SHEET BTM The following is a drawing mounting the main PWB Ass’y on the backlight chassis. (The parts indicated by ->...
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [9] REMOVING OF MAJOR PARTS (LC-60UQ17U) 1. Removing of Stand Unit and Rear Cabinet Ass'y. 1. Remove the 1 lock screw (1) and detach the Stand Support Ass'y (2). 2. Remove the 4 lock screws (3) and detach the Stand Unit (4). 3.
Page 140
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 2. Removing of Speaker (L/R), KEY Unit and Bottom Cover Ass'y. 1. Remove the 1 lock screw (1) and the 4 Hooks and detach the Bottom Cover Ass'y (2). 2. Detach the Speaker Unit (L) (3), Speaker Unit (R) (4). 3.
Page 141
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 3. 3. Removeing of connectors and Decoration Cover (Rear), Front Cover Ass'y and BL Support Angle Ass'y (Bottom). 1. Disconnect the following connectors from MAIN Unit. (SP2,PD, LW, RA, UB, BT). 2. Disconnect the following connectors from POWER/DRIVE Unit. (PD, L1). 3.
Page 142
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 4. Removing of 60" LCD Panel Module Unit, LCD CONTROL Unit, MAIN Unit, POWER/DRIVE Unit. 1. Remove the 17 lock screws (1) and detach the Aluminum Frame Ass'y (2) 2. Remove the 2 Connecting Cords(FFC80P) (4), 2 Connecting Cords(FFC64P) (5), 4 Ferrite Cores (3). 3.
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [10] REMOVING OF MAJOR PARTS (LC-70UQ17U) 1. Removing of Stand Unit and Rear Cabinet Ass'y. 1. Remove the 1 lock screw (1) and detach the Stand Support Ass'y (2). 2. Remove the 4 lock screws (3) and detach the Stand Unit (4). 3.
Page 144
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 2. Removing of Speaker Unit (L/R), KEY Unit and Bottom Cover Ass'y. 1. Remove the 1 lock screw (1) and the 4 Hooks and detach the Bottom Cover Ass'y (2). 2. Detach the KEY Unit Ass'y (3). 3. Remove the 2 Hooks and detach the KEY Button (4) from the KEY Button Cover (5). 4.
Page 145
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 3. Removeing of connectors and Decoration Cover (Rear) and Front Cover Ass'y. 1. Disconnect the following connectors from MAIN Unit. (PD, SP2, LW, RA, UB, BT). 2. Disconnect the following connectors from POWER/DRIVE Unit. (PD, L1, L2). 3. Disconnect the following connectors from LCD CONTROL Unit. (PL, LW). 4.
Page 146
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 4. Removing of Aluminum Frame Ass'y, LCD CONTROL Unit, MAIN Unit, POWER/DRIVE Unit, VESA Angle Ass'y and Stand fix Angle. 1. Remove the 18 lock screws (1) and detach the Aluminum Frame Ass'y (2) 2. Remove the 2 Connecting Cords(FFC 80p) (3), 2 Connecting Cords(FFC 64p) (4), 4 Ferrite Cores (5). 3.
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [11] The location putting on the heat measure sheet (LC-60/70UQ17U) 1. MAIN PWB Unit BL chassis (Under the Main unit) 27mm from center of screw hole. 20mm from center of screw hole. 30mm (1) Stick*** Punch mark PSPAZC805WJKZ COOLER:25x25x8t Stick standard for CPU Cooler is Punch Mark(right under) 27mm &...
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [12] Precautions for assembly (LC-60/70UQ17U) 1. Points to be checked and precautions when servicing the unit Mount the main PWB Ass’y on the backlight chassis and check that the EMI-prevention parts are not peeled and twisted from the access holes. (The EMI-prevention parts, conductive nonwoven fabric gaskets, must be seen from the access holes.) [Countermeasure] Attach the conductive nonwoven fabric gaskets on the shielded case on the main PWB.
Page 149
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U • LC-70TQ15U (2) Stick*** (1) Prepare*** PSPAZC691WJZZ LANGKD146WJFW CONDUCTR:8x180 TERM ANG WIDTH (4) Prepare*** LANGKD145WJFW SIDETERMINALANG (5) Stick*** (3) Stick ***** PSPAZC690WJZZ HDECPA090WJZZ CONDUCTR:8x255 T-LABEL SIDE (3) Stick*** HDECPA091WJZZ DEC SHEET BTM The following is a drawing mounting the main PWB Ass’y on the backlight chassis. (The parts indicated by ->...
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U LC-60EQ10U Service Manual CHAPTER 5. ADJUSTMENT [1] ADJUSTMENT PROCEDURE The adjustment values are set to the optimum conditions at the factory before shipping. If a value should become improper or an adjustment is required due to part replacement, make an adjustment according to the following procedure. 1.
Page 151
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 2.2.3 How to upgrade the software 1. Unplug the AC cord. 2. Insert the USB Memory for version upgrade into the service socket. 3. Plug in the AC cord with power button pressed down. 4. After 5 seconds, unpress the power button. 5.
Page 152
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 2.3. Monitor microprocessor software version upgrade Create the USB memory for monitor microprocessor software version upgrade in the same manner as explained in the “Main software version upgrade”. Copy the file ASTN_UQ17U_xxx.USB and ASTNMxxx.SMB. (named temporarily) for monitor microprocessor software version upgrade to the USB memory.
Page 153
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 3. Entering and exiting the adjustment process mode 1) Before entering the adjustment process mode, the AV position RESET in the video adjustment menu. 2) While holding down the “VOL (–)” and “INPUT” keys at a time, plug in the AC cord of the main unit to turn on the power. The letter “<K>”...
Page 154
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 5. List of adjustment process mode menu The character string in brackets [ ] will appear as a page title in the adjustment process menu header. Page Line Item Description Remarks (adjustment detail, etc.) MAIN / BOOT Version Main software version Monitor / Monitor BOOT Version Monitor and monitor boot software version T-CON Version...
Page 155
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U Page Line Item Description Remarks (adjustment detail, etc.) ANALOG RGB ADJ Analog RGB picture level adjustment R A_GAIN G A_GAIN B A_GAIN R OFFSET G OFFSET B OFFSET RGB_A_CLAMP VCOM ADJ VCOM adjustment value LEV1 Standard value 1 Adjustment gradation setting. LEV2 Standard value 2 LEV3...
Page 156
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U Page Line Item Description Remarks (adjustment detail, etc.) CALC RESET VAL1 VAL2 VAL3 VAL4 VAL5 VAL6 VAL7 GAMMA ADJ TEMP MONITOR TIME OUT MONITOR MAX TEMP MONITOR ERROR CAUSE RESET LCD TEST PATTERN1 LCD TEST PATTERN2 LCD TEST PATTERN3 LCD TEST PATTERN4 LCD TEST PATTERN5 TV TEST PATTERN 1...
Page 157
Writing setting values to EEPROM EEP RECOVER Reading setting values from EEPROM MODEL NAME PANEL SIZE SETTING FOR ADJ VERUP FLAG ENABLE SHARP RC ENABLE PANEL LIMIT PANEL RANGE LIMIT SHORT CHECK MODE SHORT CHECK CURRENT CURRENT SW TEST NETWORK UPDATE SERIAL NO CHECK 5 –...
Page 158
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U *1 Details of P1.12 (NORMAL STANDBY CAUSE) When TV set is powered off due to normal use or product specification, the last cause will be recorded. The code, character string and description for the standby cause are below. If you power off by remote, the cause will not be recorded. Code Character string Description...
Page 159
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 6. Special features * STANDBY CAUSE (Page 1/28) Display of a cause (code) of the last standby The cause of the last standby is recorded in EEPROM whenever possible. Checking this code will be useful in finding a problem when you repair the troubled set. * EEP SAVE (Page 28/28) Storage of EEP adjustment value * EEP RECOVER (Page 28/28)
Page 160
LC-60/70EQ10U/SQ10U,15U,17U/TQ15U/UQ17U 8.2. Image adjustment 8.2.1 Device check Before adjustment, check that the adjustment jig and signal source are set for Sharp LCD US. Signal generator level adjustment check (Adjust to the standard value level.) • Composite signal: 0.714Vp-p ± 0.02Vp-p (Pedestal to white) •...
Page 161
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 8.2.4 Component 33K signal adjustment Adjustment point Adjustment conditions Adjustment procedure Setting 1080i signal • Send the 100% color bar signal to the component input. Color saturation: 100% 1080i 100% color bar 100% white 0% black Automatic adjustment exe- Point the cursor to [ COMP33K ADJ(INPUT1)] and press the [Enter] key.
Page 162
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 9. White balance adjustment 9.1. White balance adjustment (For details about the adjustment procedure, refer to “Kameyama Model Integrated Monitor WB Adjustment Specification V1.92”.) • LC-60/70EQ10U/SQ10U,15U,17U/TQ15U Adjustment Adjustment conditions Adjustment procedure point Setting 1) Set the unit to the following conditions. AV MODE: [DYNAMIC] Backlight: +16 Active Backlight: OFF...
Page 163
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U Adjustment Adjustment conditions Adjustment procedure point [Adjustment standard value] Measuring instrument: [TOPCON SR-UL2] Technical measuring instrument. Level Reference value Adjustment spec Inspection spec X=0.272 ±0.0010 ±0.0020 Point 7 y=0.277 X=0.2755 ±0.0015 ±0.0030 Point 6 y=0.2720 X=0.2755 ±0.0020 ±0.0040 Point 5 y=0.2720 X=0.2755 ±0.0030...
Page 164
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U • LC-60/70UQ17U Adjustment Adjustment conditions Adjustment procedure point Setting 1) Set the unit to the following conditions. AV MODE: [DYNAMIC] Backlight: +16 Active Contrast: OFF Aging Time: Min. 30 minutes Resolution Enhanced:Mode1 2) Connect the unit with the white balance adjustment jig. 3) Display the adjustment screen in RS-232C command.
Page 165
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U Adjustment Adjustment conditions Adjustment procedure point Point 2 [Adjustment standard value] LEV20048 Measuring instrument: [TOPCON SR-UL2] Technical measuring instrument. MG2R0192 MG2G0192 Level Reference value Adjustment spec Inspection spec MG2B0192 X=0.3127 MG2Y0192 ±0.0010 ±0.0020 Point 7 1G2G**** y=0.329 1G2B**** 1G2R**** X=0.3127 ±0.0015 ±0.0030...
Page 166
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 9.2. Gamma2.2 Adjustment (LC-60/70UQ17U) Adjustment Adjustment con- Adjustment procedure point ditions Setteing AV MODE: For details on the adjustment procedure, refer to the latest version of "Gamma Adjustment DYNAMIC Specification". Backlight:+16 1. Confirm the set condition. Active Contrast: 2. Execute aging for 30 minutes or more. 3.
Page 167
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 10. Key writing 10.1. EDID writing (Main PWB: QPWBXG381WJ**/QPWBXG382WJ**) 1. Write the EDID key data on IC3103 mounted on the main PWB. 2. Carry out thorough data management to avoid redundant writing of data. If the IC where data is written is damaged, replace the PWB since only the IC cannot be changed. Adjustmeent Point Adjustment conditions Adjustment procedure...
Page 168
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 12. Software version 1. Main microprocessor ASTN_UQ17U_xxx.USB ASTN_UQ17U_xxx.DAT ASTN_UQ17U_xxx_CHK.USB ASTN_UQ17U_xxxxxxxx.PCC 2. Monitor microprocessor ASTNMxxx.SMB 3. T-CON ROM APRICOT_****************.ROM 13. Writing the inch and model name onto EEPROM 1. Enter the adjustment process mode. 2. Point the cursor to [MODEL NAME] (Page 28/28). 3.
Page 169
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 14. Check MIRACAST HDCP (EQ/SQ/TQ/UQ models) After changing to New Main board , change "Model and Panel Size" and write "Serial Number", then please check if MIRACAST HDCP is written or not. 1) Models which MIRACAST HDCP is needed EQ/SQ/TQ/UQ models should have MIRACAST HDCP written because they are models which have miracast feature.
Page 170
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 15. How to White Balance Data Copy NOTE: This is only available when it's possible to enter the adjust process mode. Get ready before you start • USB Memory of 128MB or higher capacity. • PC running on Windows 98/98SE/ME/2000/XP operating system. •...
Page 171
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U After change Main Board Entering the adjustment process mode Enter the adjustment process mode and go to page where it has "USB RESTORE". (Same page as where "USB BACKUP" was.) Insert the USB Memory written AQUOS_DATA.dat into the service socket. Press Enter After about 7 second , return "Restore OK"...
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [2] PUBLIC MODE SETTING PROCEDURE 1. How to start Public Mode • There are the following two ways to get the public mode setup screen displayed. In the adjustment process mode, turn on “PUBLIC MODE”. Also press the “CH ( )”...
Page 173
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 4. Public Mode Menu The guidance is not displayed on screen. Setup procedure • To move the cursor up and down, use the “cursor UP/DOWN” key (remote controller) and “CH ( )” key (remote controller and set). • To change the settings, use the “cursor RIGHT/LEFT” key (remote controller) and “VOL (+)/(–)” key (remote controller and set). •...
Page 174
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [How to use USB clone] This is the function that copying the one TV's user setting to other TVs or copying previous user setting to itself.(Only same series.) 1. Insert the USB memory to TV. 2. Insert AC code of TV with pushing the “INPUT” and “Vol+” keys which are on the tact key. 3.
Page 175
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 10.The following guide is dispalyed.Then select the “USB→TV [Start]”. 11.Follow guide is displayed when it is finished , then select "Reset" . TV will restart. 12.Comfirm the user setting is copied. 5 – 26...
Page 176
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 5. On Setting Items * “EZ-SETUP” discussed below indicates “EZ-SETUP after the first power-on”. 1) POWER ON FIXED Selection Selection between “Variable” and “Fixed” (loop provided) Default – (Variable) Explanation In “Fixed” setting, the power-off by the power key of the unit is invalidated and the image is kept being received. The power can be turned off by stopping the power supply from AC.
Page 177
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 6) PANEL BUTTON Selection Selection between “Respond” and “No respond” (loop provided) Default Respond Explanation All the operations by keys (except the power key) of the unit can be invalidated. Limit in Setting • Adjustment process, inspection mode and hotel menu mode can be started irrespective of setting. Exception •...
Page 178
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 10)INPUT MODE FIXED Selection Selection between “Variable”, “Fixed”, “ACON (AC CTRL)” and “AC/RCON (AC/RC CTRL)” (loop provided) Default – (Variable) • At the “Fixed” setting, the TV set gets started with the settings of “Input mode start”, and then any other channels and inputs Explanation are not accepted.
Page 179
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 15)PUBLIC MODE (ON/OFF) Selection Selection between “ON” and “OFF” (loop provided) Default Explanation In case of “ON”, public mode settings are effected. Limit in Setting None Exception None Remarks The public-mode settings are operable only when this item is set at ON. 5 –...
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U LC-60EQ10U Service Manual CHAPTER 6. TROUBLESHOOTING TABLE [1] Failure diagnosis by LED in front of cabinet START Is the Center Icon flashing? Check "[2] LED flashing specification at the time of an error (Center icon LED used)". Is the Center Icon lighting Check Power-Unit and AC-cable.
Page 181
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 3. New method LED flashing timing chart at the time of an error 100ms 400ms 1.6sec 1) Inverter/Lamp failure details (Flashes slowly once and flashes fast) Note Pins are monitor microcomputer pins unless other- Error type Center icon LED operation wise specified.
Page 182
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 3) Communication failure details (Flashes slowly 3 times and flashes fast) Note Basically, debug print logs are analyzed or commu- Error type Center icon LED operation nication logs are analyzed by a bus monitor. Initial communica- H: On Initial communication from the main CPU is not tion reception failure received.
Page 183
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [3] TROUBLESHOOTING TABLE (LC-60/70EQ10U) • LED Backlight does not turn on. If it is not an error of power supply/LED driver, It is start-up in the lamp error disregard mode. Do you start? When main unit is replaced, does it start normally? Replace main unit.
Page 184
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U Trouble Shooting Panel Module When C-S FPC is replaced, does screen display normally? Replace C-S FPC. When C-PWB is replaced, does screen display normally? Replace C-PWB. (Adjust “VCOM ADJ” after replace C-PWB) Replace Panel HIRAKI. (Adjust “VCOM ADJ” after replace Panel HIRAKI) 6 –...
Page 185
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U <HDMI input> No video (1)-1 HDMI: No external input video [HDMI1] IsHDMI1 selected on the input select menu screen? Select HDMI1 on the input select menu screen for the right input signal. Does the HOT PLUG detection function? Check the line between the pin(18) of SC1501 and the pin(30) of IC2601.
Page 186
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U <HDMI input> No video (1)-2 HDMI: No external input video [HDMI2] Is HDMI2 selected on the input select menu screen? Select HDMI2 on the input select menu screen for the right input signal. Does the HOT PLUG detection function? Check the line between the pin(18) of SC1502 and the pin(34) of IC2601.
Page 187
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U <HDMI input> No video (1)-3 HDMI: No external input video [HDMI3] Is HDMI3 selected on the input select menu screen? Select HDMI3 on the input select menu screen for the right input signal. Does the HOT PLUG detection function? Check the line between the pin(18) of SC1503 and the pin(38) of IC2601.
Page 188
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U <HDMI input> No video (1)-4 HDMI: No external input video [HDMI4] Is HDMI4 selected on the input select menu screen? Select HDMI4 on the input select menu screen for the right input signal. Does the HOT PLUG detection function? Check the line between the pin(18) of SC1504 and the pin(43) of IC2601.
Page 189
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U No video (2) COMPONENT: No external input video [INPUT-5] Is INPUT-5 selected on the input select menu screen? Is the INPUT-SELECT for the input signal? Select INPUT-5 on the input select menu screen for the right input signal. Does the INPUT-5 COMP1_PLUG detection function? Check the line between pin (17) of input terminal (J510) and pin (B29) of IC3301 (CPU).
Page 190
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U No video (3) COMPOSITE: No external input video [INPUT-6] COMPOSITE: No external input video [INPUT-7] Is INPUT-6 selected on the input select menu screen? Is INPUT-7 selected on the input select menu screen? Select INPUT-6 on the input select menu Select INPUT-7 on the input select menu screen for the right input signal.
Page 191
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U No video (4) PC: No external input video [PC-IN] Is PC-IN selected on the input select menu screen? Select PC-IN on the input select menu screen for the right input signal. Is IC2601 (HDMI-SW) accessed by I2C, with PC connected, to read the VGA_SCL/SDA data? Check the DDC-12C line and its peripheral circuits.
Page 192
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U No video (5) No video at UHF/VHF broadcast signal reception No video at digital broadcast signal reception Is the specified TV signal selected on the input select menu screen? Are there the IF signal at input pins(AT32/AU32)(TUN_IFN/P) Are there the IF signal at input pins(AT32/AU32)(TUN_IFN/P) of of IC3301(CPU)? IC3301(CPU)? Is there IF-AGC signal at input pin(12) of TU1104?
Page 193
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U • Does not sound. No audio (1) INPUT-6 No audio. INPUT-7 No audio. INPUT-5 No audio. Is INPUT-6 selected on the input select Is INPUT-7 selected on the input select Is INPUT-5 selected on the input select menu screen? menu screen? menu screen? Refer to “: No external input...
Page 194
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U No audio (2) [PC analog audio input] PC-IN No audio. [HDMI analog audio input] HDMI2 No audio. Is PC-IN selected on the input select menu screen? Is HDMI2 selected on the input select menu screen? Refer to “: No external input video [PC-IN]”. Refer to “: No external input video [HDMI2]”.
Page 195
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U No audio (3) No audio at UHF/VHF broadcast signal reception. No audio at digital broadcast signal reception. Is TV selected on the input select menu screen? Is TV selected on the input select menu screen? Refer to “No video at UHF/VHF broadcast signal Refer to “No video at digital broadcast signal reception”.
Page 196
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U No audio (4) HDMI1 No audio (HDMI connected) HDMI2 No audio (HDMI connected) HDMI3 No audio (HDMI connected) HDMI4 No audio (HDMI connected) [HDMI1 input] Is INPUT-1 selected on the input select menu screen? [HDMI2 input] Is INPUT-2 selected on the input select menu screen? [HDMI3 input] Is INPUT-3 selected on the input select menu screen? [HDMI4 input]...
Page 197
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U No audio signal at Digital Audio Output terminal (Analog sound heard) No INPUT-1/2/3/4 (HDMI) audio. No audio at digital broadcast signal reception. If no video appears, refer to “No external input video (HDMI) If no video appears, refer to “No video at digital broadcast signal [HDMI1/2/3/4]”.
Page 198
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U No monitor audio output Is the audio output from the monitor set at “VARIABLE” or “FIXED” on the menu screen? Check IC3301 (CPU) and its peripheral circuits. Are there the audio signal outputs at pins (AN34) (HP_MONITOR_L) and (AN35) (HP_MONITOR_R) of IC3301 (CPU)? Check IC3301 (CPU) and its peripheral circuits.
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [4] TROUBLESHOOTING TABLE (LC-60/70SQ10U/15U/17U,TQ15U,UQ17U) • LED Backlight does not turn on. If it is not an error of power supply/LED driver, It is start-up in the lamp error disregard mode. Do you start? When main unit is replaced, does it start normally? Replace main unit.
Page 200
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U Trouble Shooting Panel Module When C-S FPC is replaced, does screen display normally? Replace C-S FPC. When C-PWB is replaced, does screen display normally? Replace C-PWB. (Adjust “VCOM ADJ” after replace C-PWB) Replace Panel HIRAKI. (Adjust “VCOM ADJ” after replace Panel HIRAKI) 6 –...
Page 201
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U <HDMI input> No video (1)-1 HDMI: No external input video [HDMI1] Is HDMI1 selected on the input select menu screen? NO Select HDMI1 on the input select menu screen for the right input signal. Does the HOT PLUG detection function? Check the line between the pin(18) of SC1501 and the pin(3) of IC2501.
Page 202
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U <HDMI input> No video (1)-2 HDMI: No external input video [HDMI2] Is HDMI2 selected on the input select menu screen? Select HDMI2 on the input select menu screen for the right input signal. Does the HOT PLUG detection function? Check the line between the pin(18) of SC1502 and the pin(34) of IC2601.
Page 203
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U <HDMI input> No video (1)-3 HDMI: No external input video [HDMI3] Is HDMI3 selected on the input select menu screen? Select HDMI3 on the input select menu screen for the right input signal. Does the HOT PLUG detection function? Check the line between the pin(18) of SC1503 and the pin(38) of IC2601.
Page 204
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U <HDMI input> No video (1)-4 HDMI: No external input video [HDMI4] Is HDMI4 selected on the input select menu screen? Select HDMI4 on the input select menu screen for the right input signal. Does the HOT PLUG detection function? Check the line between the pin(18) of SC1504 and the pin(43) of IC2601.
Page 205
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U No video (2) COMPONENT: No external input video [INPUT-5] Is INPUT-5 selected on the input select menu screen? Is the INPUT-SELECT for the input signal? Select INPUT-5 on the input select menu screen for the right input signal. Does the INPUT-5 COMP1_PLUG detection function? Check the line between pin (17) of input terminal (J510) and pin (B29) of IC3301 (CPU).
Page 206
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U No video (3) COMPOSITE: No external input video [INPUT-6] COMPOSITE: No external input video [INPUT-7] Is INPUT-6 selected on the input select menu screen? Is INPUT-7 selected on the input select menu screen? Select INPUT-6 on the input select menu Select INPUT-7 on the input select menu screen for the right input signal.
Page 207
L C - 6 0 / 7 0 E Q 1 0 U , S Q 1 0 U / 1 5 U / 1 7 U , T Q 1 5 U ,U Q 1 7 U No video (4) PC: No external input video [PC-IN] Is PC-IN selected on the input select menu screen? Select PC-IN on the input select menu screen for the right input signal.
Page 208
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U No video (5) No video at UHF/VHF broadcast signal reception No video at digital broadcast signal reception Is the specified TV signal selected on the input select menu screen? Are there the IF signal at input pins(AT32/AU32)(TUN_IFN/P) Are there the IF signal at input pins(AT32/AU32)(TUN_IFN/P) of of IC3301(CPU)? IC3301(CPU)? Is there IF-AGC signal at input pin(12) of TU1104?
Page 209
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U • Does not sound. No audio (1) INPUT-6 No audio. INPUT-7 No audio. INPUT-5 No audio. Is INPUT-6 selected on the input select Is INPUT-7 selected on the input select Is INPUT-5 selected on the input select menu screen? menu screen? menu screen? Refer to “: No external input...
Page 210
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U No audio (2) [PC analog audio input]PC-IN No audio. [HDMI analog audio input] HDMI2 No audio. Is PC-IN selected on the input select menu screen? Is HDMI2 selected on the input select menu screen? Refer to “: No external input video [PC-IN]”. Refer to “: No external input video [HDMI2]”.
Page 211
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U No audio (3) No audio at UHF/VHF broadcast signal reception. No audio at digital broadcast signal reception. Is TV selected on the input select menu screen? Is TV selected on the input select menu screen? Refer to “No video at UHF/VHF broadcast signal Refer to “No video at digital broadcast signal reception”.
Page 212
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U No audio (4) HDMI1 No audio (HDMI connected) HDMI2 No audio (HDMI connected) HDMI3 No audio (HDMI connected) HDMI4 No audio (HDMI connected) [HDMI1 input] Is HDMI1 selected on the input select menu screen? [HDMI2 input] Is HDMI2 selected on the input select menu screen? [HDMI3 input] Is HDMI3 selected on the input select menu screen? [HDMI4 input]...
Page 213
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U No audio signal at Digital Audio Output terminal (Analog sound heard) No HDMI1/2/3/4 audio. No audio at digital broadcast signal reception. If no video appears, refer to “No external input video (HDMI) If no video appears, refer to “No video at digital broadcast signal [HDMI1/2/3/4]”.
Page 214
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U No monitor audio output Is the audio output from the monitor set at “VARIABLE” or “FIXED” on the menu screen? Check IC3301 (CPU) and its peripheral circuits. Are there the audio signal outputs at pins (AN34) (HP_MONITOR_L) and (AN35) (HP_MONITOR_R) of IC3301 (CPU)? Check IC3301 (CPU) and its peripheral circuits.
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U LC-60EQ10U Service Manual CHAPTER 7. MAJOR IC INFORMATIONS [1] MAJOR IC INFORMATIONS (DKEYMG381FM01) 1. MAJOR IC INFORMATIONS 1.1. IC2601 (VHiSii9687A-1Q) This IC is 4 input and 1 output HDMI port processor. The TMDS cores run at 3.0Gbps. (Supports video resolutions up to 4Kx2K@30Hz, 1080p@120Hz, and 1080p 3D@60Hz.) The adaptive equalizer provides long cable support.
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [2] MAJOR IC INFORMATIONS (DKEYMG382FM01) 1. MAJOR IC INFORMATIONS 1.1. IC2601 (VHiSii9687A-1Q) This IC is 4 input and 1 output HDMI port processor. The TMDS cores run at 3.0Gbps. (Supports video resolutions up to 4Kx2K@30Hz, 1080p@120Hz, and 1080p 3D@60Hz.) The adaptive equalizer provides long cable support.
Page 217
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U 1.12. IC2501 (VHiSii9679+-1Q) The Sii9679 HDMI receiver supports HDMI input with HDCP1.4 or HDCP2.2 encryption. This device supports up to 4K x 2K Ultra HD video format. 1.13. IC2503 (RH-iXD741WJZZS) This is 8M-bit SPI Flash device stores the F/W of IC2501. 7 –...
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U PartsGuide PARTS GUIDE No. S14A1LC60EQ10 LCD COLOR TELEVISION LC-60/70EQ10U LC-60/70SQ10U LC-60/70SQ15U LC-60/70SQ17U LC-60/70TQ15U LC-60/70UQ17U MODELS CONTENTS PRINTED WIRING BOARD PRINTED WIRING BOARD ASSEMBLIES (LC-60/70EQ10U) ASSEMBLIES (LC-60/70UQ17U) PRINTED WIRING BOARD LCD PANEL MODULE UNIT ASSEMBLIES (LC-60/70SQ10U) CABINET AND MECHANICAL PRINTED WIRING BOARD PARTS (LC-60EQ10U) ASSEMBLIES (LC-60/70SQ15U) CABINET AND MECHANICAL...
Page 226
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [11] CABINET AND MECHANICAL [23] CABINET AND MECHANICAL PARTS (LC-70SQ10U) PARTS-2 (LC-70UQ17U) [12] CABINET AND MECHANICAL [24] SUPPLIED ACCESSORIES/ PARTS (LC-60SQ15U) PACKING PARTS (LC-60EQ10U,SQ10U/15U/17U) (NOT REPLACEMENT ITEM) [13] CABINET AND MECHANICAL PARTS (LC-70SQ15U) [25] SUPPLIED ACCESSORIES/ PACKING PARTS [14] CABINET AND MECHANICAL (LC-70EQ10U,SQ10U/15U/17U) PARTS (LC-60SQ17U) (NOT REPLACEMENT ITEM)
Page 227
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [1] PRINTED WIRING BOARD ASSEMBLIES (LC-60/70EQ10U) DKEYMG381FM01 MAIN Unit DUNTKG400FM01 LCD CONTROL (T-CON) Unit (LC-60EQ10U) DUNTKG400FM02 LCD CONTROL (T-CON) Unit (LC-70EQ10U) DUNTKF800FM53 KEY Unit DUNTKG369FM02 RC/ICON Unit RUNTKB222WJQZ WiFi+BT Unit RUNTKB109WJQZ POWER/DRIVE Unit (LC-60EQ10U) RUNTKB131WJQZ POWER/DRIVE Unit (LC-70EQ10U)
Page 228
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [8] CABINET AND MECHANICAL PARTS (LC-60EQ10U) RC/ICON Unit WiFi+BT Unit POWER/ DRIVE MAIN Unit Unit 60"LCD PANEL MODULE Unit CONTROL Unit Unit...
Page 229
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [8] CABINET AND MECHANICAL PARTS (LC-60EQ10U) CCABAD080WJ34 Front Cabinet Ass'y Not Available Front Cabinet Not Available R/C LED Decoration HDECSA115WJ3A Shine Trim TLABZE300WJSA QUATTRON Label LHLDWA175WJUZ Wire Holder LHLDWA289WJKZ Wire Holder TLABZD496WJZZ Licence Label CCABBC175WJ31...
Page 230
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [9] CABINET AND MECHANICAL PARTS (LC-70EQ10U) RC/ICON Unit WiFi+BT Unit POWER/ DRIVE Unit 70"LCD PANEL MAIN MODULE Unit Unit CONTROL Unit Unit...
Page 231
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [9] CABINET AND MECHANICAL PARTS (LC-70EQ10U) CCABAD081WJ34 Front Cabinet Ass'y Not Available Fronr Cabinet Not Available R/C LED Decoration HDECSA116WJ3A Shine Trim TLABZE300WJSA QUATTRON Label LHLDWA175WJUZ Wire Holder, x2 TLABZD496WJZZ Licence Label CCABBC177WJ31 Rear Cabinet Ass'y Not Available...
Page 232
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [10] CABINET AND MECHANICAL PARTS (LC-60SQ10U) RC/ICON Unit WiFi+BT Unit POWER/ DRIVE MAIN Unit Unit 60"LCD PANEL MODULE Unit CONTROL Unit Unit...
Page 233
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [10] CABINET AND MECHANICAL PARTS (LC-60SQ10U) CCABAD080WJ31 Front Cabinet Ass'y Not Available Fronr Cabinet Not Available R/C LED Decoration HDECSA115WJ3A Shine Trim LHLDWA175WJUZ Wire Holder LHLDWA289WJKZ Wire Holder TLABZD612WJ3C Licence Label TLABZE228WJSC QUATTRON Label CCABBC175WJ33...
Page 234
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [11] CABINET AND MECHANICAL PARTS (LC-70SQ10U) RC/ICON Unit WiFi+BT Unit POWER/ DRIVE Unit 70"LCD PANEL MAIN MODULE Unit Unit CONTROL Unit Unit...
Page 235
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [11] CABINET AND MECHANICAL PARTS (LC-70SQ10U) CCABAD081WJ31 Front Cabinet Ass'y Not Available Fronr Cabinet Not Available R/C LED Decoration HDECSA116WJ3A Shine Trim LHLDWA175WJUZ Wire Holder, x2 TLABZD612WJ3C Licence Label TLABZE228WJSC QUATTRON Label PSPAHB013WJZZ Himeron, x2 CCABBC177WJ33...
Page 236
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [12] CABINET AND MECHANICAL PARTS (LC-60SQ15U) RC/ICON Unit WiFi+BT Unit POWER/ DRIVE MAIN Unit Unit 60"LCD PANEL MODULE Unit CONTROL Unit Unit...
Page 237
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [12] CABINET AND MECHANICAL PARTS (LC-60SQ15U) CCABAD080WJ31 Front Cabinet Ass'y Not Available Fronr Cabinet Not Available R/C LED Decoration HDECSA115WJ3A Shine Trim LHLDWA175WJUZ Wire Holder LHLDWA289WJKZ Wire Holder TLABZD612WJ3C Licence Label TLABZE228WJSC QUATTRON Label CCABBC175WJ33...
Page 238
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [13] CABINET AND MECHANICAL PARTS (LC-70SQ15U) RC/ICON Unit WiFi+BT Unit POWER/ DRIVE Unit 70"LCD PANEL MAIN MODULE Unit Unit CONTROL Unit Unit...
Page 239
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [13] CABINET AND MECHANICAL PARTS (LC-70SQ15U) CCABAD081WJ31 Front Cabinet Ass'y Not Available Fronr Cabinet Not Available R/C LED Decoration HDECSA116WJ3A Shine Trim LHLDWA175WJUZ Wire Holder, x2 TLABZD612WJ3C Licence Label TLABZE228WJSC QUATTRON Label PSPAHB013WJZZ Himeron, x2 CCABBC177WJ33...
Page 240
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [14] CABINET AND MECHANICAL PARTS (LC-60SQ17U) RC/ICON Unit WiFi+BT Unit POWER/ DRIVE MAIN Unit Unit 60"LCD PANEL MODULE Unit CONTROL Unit Unit...
Page 241
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [14] CABINET AND MECHANICAL PARTS (LC-60SQ17U) CCABAD080WJ31 Front Cabinet Ass'y Not Available Front Cabinet Not Available R/C LED Decoration HDECSA115WJ3A Shine Trim LHLDWA175WJUZ Wire Holder LHLDWA289WJKZ Wire Holder TLABZD612WJ3C Licence Label TLABZE228WJSC QUATTRON Label CCABBC175WJ33...
Page 242
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [15] CABINET AND MECHANICAL PARTS (LC-70SQ17U) RC/ICON Unit WiFi+BT Unit POWER/ DRIVE Unit 70"LCD PANEL MAIN MODULE Unit Unit CONTROL Unit Unit...
Page 243
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [15] CABINET AND MECHANICAL PARTS (LC-70SQ17U) CCABAD081WJ31 Front Cabinet Ass'y Not Available Fronr Cabinet Not Available R/C LED Decoration HDECSA116WJ3A Shine Trim LHLDWA175WJUZ Wire Holder, x2 TLABZD612WJ3C Licence Label TLABZE228WJSC QUATTRON Label PSPAHB013WJZZ Himeron, x2 CCABBC177WJ33...
Page 244
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [16] CABINET AND MECHANICAL PARTS-1 (LC-60TQ15U) WiFi+BT Unit RC/ICON Unit Unit...
Page 245
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [16] CABINET AND MECHANICAL PARTS-1 (LC-60TQ15U) CCOVAE786WJ31 Front Cover Ass'y Not Available Front Cover Not Available LED Decoration HDECSA105WJSA Shine Trim CCABBC194WJ33 Rear Cabinet Ass'y Not Available Rear Cabinet Not Available Terminal Label (Back) Not Available Terminal Label (Bottom)
Page 246
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [17] CABINET AND MECHANICAL PARTS-2 (LC-60TQ15U) MAIN Unit POWER/ DRIVE Unit CONTROL Unit...
Page 247
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [17] CABINET AND MECHANICAL PARTS-2 (LC-60TQ15U) CANGKD790WJ31 BL Support Angle Ass'y (Bottom) CHLDZB965WJ33 P-Chassis Unit (Top) CHLDZB966WJ33 P-Chassis Unit (Bottom) CHLDZB967WJ33 P-Chassis Unit (Left) CHLDZB968WJ33 P-Chassis Unit (Right) CANGKD506WJ31 VESA Angle Ass'y, x4 CANGKD933WJ31 BL Support Angle Ass'y (Top) CCHSMA706WJ34...
Page 248
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [18] CABINET AND MECHANICAL PARTS-1 (LC-70TQ15U) WiFi+BT Unit RC/ICON Unit 2-10 Unit...
Page 249
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [18] CABINET AND MECHANICAL PARTS-1 (LC-70TQ15U) CCOVAE787WJ31 Front Cover Ass'y Not Available Front Cover Not Available LED Decoration HDECSA106WJSA Shine Trim CCABBC195WJ33 Rear Cabinet Ass'y Not Available Rear Cabinet Not Available Terminal Label (Back) Not Available Terminal Label (Bottom)
Page 250
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [19] CABINET AND MECHANICAL PARTS-2 (LC-70TQ15U) MAIN Unit POWER/ DRIVE Unit CONTROL Unit...
Page 251
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [19] CABINET AND MECHANICAL PARTS-2 (LC-70TQ15U) CANGKD762WJ31 Suppot Angle Ass'y (Bottom) CHLDZB969WJ33 P-Chassis Unit (Top-Left) CHLDZB970WJ33 P-Chassis Unit (Top-Right) CHLDZB971WJ33 P-Chassis Unit (Bottom-Left) CHLDZB972WJ33 P-Chassis Unit (Bottom-Right) CHLDZB973WJ33 P-Chassis Unit (Left) CHLDZB974WJ33 P-Chassis Unit (Right) CANGKD506WJ31...
Page 252
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [20] CABINET AND MECHANICAL PARTS-1 (LC-60UQ17U) WiFi+BT Unit RC/ICON Unit Unit...
Page 253
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [20] CABINET AND MECHANICAL PARTS-1 (LC-60UQ17U) CCOVAE786WJ31 Front Cover Ass'y Not Available Front Cover Not Available LED Decration HDECSA105WJSA ShineTrim CCABBC194WJ33 Rear Cabinet Ass'y Not Available Rear Cabinet Not Available Terminal Label (Back) Not Available Terminal Label (Bottom) Not Available...
Page 254
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [21] CABINET AND MECHANICAL PARTS-2 (LC-60UQ17U) MAIN Unit CONTROL Unit POWER/ DRIVE Unit...
Page 255
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [21] CABINET AND MECHANICAL PARTS-2 (LC-60UQ17U) CANGKD790WJ31 BL Support Angle (Bottom) CHLDZB965WJ33 P-Chassis Unit (Top) CHLDZB966WJ33 P-Chassis Unit (Bottom) CHLDZB967WJ33 P-Chassis Unit (Left) CHLDZB968WJ33 P-Chassis Unit (Right) CANGKD506WJ31 VESA Angle Ass'y, x4 CANGKD933WJ31 BL Support Angle (Top) CCHSMA706WJ34...
Page 256
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [22] CABINET AND MECHANICAL PARTS-1 (LC-70UQ17U) WiFi+BT Unit RC/ICON Unit 2-10 2-10 Unit...
Page 257
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [22] CABINET AND MECHANICAL PARTS-1 (LC-70UQ17U) CCOVAE787WJ31 Front Cover Ass'y Not Available Front Cover Not Available LED Decration Not Available ShineTrim CCABBC195WJ33 Rear Cabinet Ass'y Not Available Rear Cabinet Not Available Terminal Label (Back) Not Available Terminal Label (Bottom)
Page 258
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U [23] CABINET AND MECHANICAL PARTS-2 (LC-70UQ17U) CONTROL Unit MAIN POWER/ Unit DRIVE Unit...
Page 259
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [23] CABINET AND MECHANICAL PARTS-2 (LC-70UQ17U) CANGKD762WJ31 Suppot Angle Ass'y (Bottom) CHLDZB969WJ33 P-Chassis Unit (Top-Left) CHLDZB970WJ33 P-Chassis Unit (Top-Right) CHLDZB971WJ33 P-Chassis Unit (Bottom-Left) CHLDZB972WJ33 P-Chassis Unit (Bottom-Right) CHLDZB973WJ33 P-Chassis Unit (Left) CHLDZB974WJ33 P-Chassis Unit (Right) CANGKD506WJ31...
Page 261
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [24] SUPPLIED ACCESSORIES/PACKING PARTS (LC-60EQ10U,SQ10U/15U/17U) (NOT REPLACEMENT ITEM) CDAi-A930WJ31 Stand Base Ass'y CANGKE160WJ01 Stand Support Ass'y, x2 CSAKKA011WJ01 Stand Screw Ass'y TCADEA290WJZZ Enquete Card TiNS-G058WJZZ SET UP Guide RRMCGB118WJSA Remote Control Unit Not Available AAA Size Battery, x2 KOPTLA006WJN1...
Page 263
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [25] SUPPLIED ACCESSORIES/PACKING PARTS (LC-70EQ10U,SQ10U/15U/17U) (NOT REPLACEMENT ITEM) CDAi-A930WJ31 Stand Base Ass'y CANGKE160WJ01 Stand Support Ass'y, x2 CSAKKA011WJ01 Stand Screw Ass'y TCADEA290WJZZ Enquete Card TiNS-G058WJZZ SET UP Guide RRMCGB118WJSA Remote Control Unit Not Available AAA Size Battery, x2 KOPTLA006WJN1...
Page 265
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [26] SUPPLIED ACCESSORIES/PACKING PARTS (LC-60TQ15U) (NOT REPLACEMENT ITEM) CDAi-A857WJ32 Stand Base Ass'y CANGKD781WJ02 Stand Support Ass'y CSAKKA016WJ02 Stand Screw Ass'y TCADEA290WJZZ Enquete Card TiNS-G058WJZZ SET UP Guide RRMCGB118WJSA Remote Control Unit Not Available AAA Size Battery, x2 TGAN-B767WJZZ...
Page 267
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [27] SUPPLIED ACCESSORIES/PACKING PARTS (LC-70TQ15U) (NOT REPLACEMENT ITEM) CDAi-A857WJ32 Stand Base Ass'y CANGKD781WJ02 Stand Support Ass'y CSAKKA016WJ02 Stand Screw Ass'y TCADEA290WJZZ Enquete Card TiNS-G058WJZZ SET UP Guide RRMCGB118WJSA Remote Control Unit Not Available AAA Size Battery, x2 TGAN-B767WJZZ...
Page 269
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [28] SUPPLIED ACCESSORIES/PACKING PARTS (LC-60UQ17U) (NOT REPLACEMENT ITEM) CDAi-A919WJ03 Stand Base Ass'y CANGKE168WJ31 Stand Support Ass'y CSAKKA023WJ31 Stand Screw Ass'y TCADEA290WJZZ Enquete Card TiNS-G058WJZZ SET UP Guide RRMCGB118WJSA Remote Control Unit Not Available AAA Size Battery, x2 KOPTLA006WJN1...
Page 271
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [29] SUPPLIED ACCESSORIES/PACKING PARTS (LC-70UQ17U) (NOT REPLACEMENT ITEM) CDAi-A919WJ03 Stand Base Ass'y CANGKE168WJ31 Stand Support Ass'y CSAKKA023WJ31 Stand Screw Ass'y TCADEA290WJZZ Enquete Card TiNS-G058WJZZ SET UP Guide RRMCGB118WJSA Remote Control Unit Not Available AAA Size Battery, x2 KOPTLA006WJN1...
