- Page 1 CPE Product Description Issue V2.3 Date 2017-02-06 HUAWEI TECHNOLOGIES CO., LTD.
- Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...
-
Page 3: Table Of Contents
4 Services and Applications ......................15 5 Adopted Standards ........................16 6 Packing List ..........................17 7 Acronyms and Abbreviations ..............错误！未定义书签。 Issue Draft B(2016-03-2206) Huawei Proprietary and Confidential Page 3 of 21 Copyright © Huawei Technologies Co., Ltd. -
Page 4: Product Overview
Product Description Product Overview Introduction The Huawei eA380-135 V1R1 CPE is the Long Term Evolution (LTE) customer premises equipments (CPE). As a wireless gateway, the eA380-135 can be deployed outdoors to provide services such as data collection and video surveillance. - Page 5 User-friendly design of LED indicator shows the status of equipment. Supports Windows XP,Windows Vista,Windows 7,Linux,MAC.Compatible with Browser include Internet Explorer, Firefox,Chrome,Safari. Appearance Figure 1-1 Appearance of eA380-135 Issue Draft B(2016-03-2206) Huawei Proprietary and Confidential Page 5 of 21 Copyright © Huawei Technologies Co., Ltd.
-
Page 6: Application Scenarios
IP route protocol and NAT:High-speed routing capability. With the built-in NAT,the eA380-135,together with LTE terminals,can provide flexible broadband access solutions and networking schemes. Issue Draft B(2016-03-2206) Huawei Proprietary and Confidential Page 6 of 21 Copyright © Huawei Technologies Co., Ltd. - Page 7 Series CPEs Product Description Figure 2-1 The eA380-135 deployed in wISP network Figure 2-2 The eA380-135 deployed in industrial network Issue Draft B(2016-03-2206) Huawei Proprietary and Confidential Page 7 of 21 Copyright © Huawei Technologies Co., Ltd.
- Page 8 Series CPEs Product Description Figure 2-3 The eA380-135 connected to a video camera. Figure 2-4 The eA380-135 connected to multiple devices Issue Draft B(2016-03-2206) Huawei Proprietary and Confidential Page 8 of 21 Copyright © Huawei Technologies Co., Ltd.
-
Page 9: Technical Specifications
EIRP 37 dBm Receiving eA380-135 sensitivity B43: < -99 dBm/5 MHz < -96 dBm/10 MHz < -93 dBm/20 MHz Issue Draft B(2016-03-2206) Huawei Proprietary and Confidential Page 9 of 21 Copyright © Huawei Technologies Co., Ltd. -
Page 10: Antenna Specifications
3.1.2 Antenna Specifications Table 3-2 eA380-135 LTE antenna specifications Item eA380–135 Band 3600 to 3800 MHz (Band 43) Gain 13±1 dBi Input 50 ohm Issue Draft B(2016-03-2206) Huawei Proprietary and Confidential Page 10 of 21 Copyright © Huawei Technologies Co., Ltd. -
Page 11: Software
Supports Network Address Translation (NAT) and Network Address Port Translation (NAPT). Supports fragment message identification for normal NAT Supports NAT traverse DHCP server Issue Draft B(2016-03-2206) Huawei Proprietary and Confidential Page 11 of 21 Copyright © Huawei Technologies Co., Ltd. - Page 12 Up to 16 MAC address items. Ratio adjustment: Automatically Manually STA management: Supports limit of access users (up to 32 users) Issue Draft B(2016-03-2206) Huawei Proprietary and Confidential Page 12 of 21 Copyright © Huawei Technologies Co., Ltd.
-
Page 13: User Interfaces
Security (WEP and WPA and WPA2) Access list (MAC) Firewall: Firewall switch LAN MAC address filtering IP address filtering Issue Draft B(2016-03-2206) Huawei Proprietary and Confidential Page 13 of 21 Copyright © Huawei Technologies Co., Ltd. - Page 14 SIM card state Operator name and system mode Others Network connection settings: Automatic network registration Manual network registration Select network connection type: LTE Issue Draft B(2016-03-2206) Huawei Proprietary and Confidential Page 14 of 21 Copyright © Huawei Technologies Co., Ltd.
-
Page 15: Services And Applications
Remote Management and Maintenance The eA380-135 supports remote configuration to manage devices,configure network parameters, and query the status by TR069. Issue Draft B(2016-03-2206) Huawei Proprietary and Confidential Page 15 of 21 Copyright © Huawei Technologies Co., Ltd. -
Page 16: Adopted Standards
RFC894 RFC826 RFC791,RFC1122,RFC1071,RFC1141, RFC1624, RFC792,RFC950,RFC1256 ICMP RFC792,RFC950,RFC1256 RFC793 RFC768 DHCP RFC1531,RFC1533 RFC1631 Wireless Port The eA380-135's wireless Uu port complies with LTE R11/12. Issue Draft B(2016-03-2206) Huawei Proprietary and Confidential Page 16 of 21 Copyright © Huawei Technologies Co., Ltd. - Page 17 (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Issue Draft B(2016-03-2206) Huawei Proprietary and Confidential Page 17 of 21 Copyright © Huawei Technologies Co., Ltd.
- Page 18 Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Issue Draft B (2016-03-22) Huawei Proprietary and Confidential Page 18 of 21 Copyright © Huawei Technologies Co., Ltd.
-
Page 19: Packing List
Table 6-1 describes the eA380-135' packing list. Table 7-1 eA380-135' packing list Item Quantity Description eA380-135 Standard Quick installation guide Standard Installation accessory Standard Issue Draft B(2016-03-2206) Huawei Proprietary and Confidential Page 19 of 21 Copyright © Huawei Technologies Co., Ltd. -
Page 20: Acronyms And Abbreviations
PDCP Packet Data Convergence Protocol Radio Link Control Radio Resource Control Remote Terminal Unit Security Parameter Index SSID Service Set Identifier User Equipment Issue Draft B(2016-03-2206) Huawei Proprietary and Confidential Page 20 of 21 Copyright © Huawei Technologies Co., Ltd. - Page 21 Series CPEs Product Description Acronym/Abbreviation Full Name USIM Universal Subscriber Identity Module Issue Draft B(2016-03-2206) Huawei Proprietary and Confidential Page 21 of 21 Copyright © Huawei Technologies Co., Ltd.
