- Page 1 VL-MV72AZ User Guide...
- Page 2 VL-MV72AZ User Guide 1.1 Main Monitor / Extension Monitor 5 6 7 8 9 Display Button INFORMATION Speaker Button MENU Play Lamp (blue) Button MONITOR Button Microphone TALK Button Button PLAY Button Button PAGE RESET Press to page extension monitor...
- Page 3 VL-MV72AZ User Guide 1.2 Soft Keys Soft Key Status Icons Soft Key Icons Icons indicate the functions that can be operated by the soft keys Status Icons (Main monitor) Indicates which doorphone is calling, monitor, or on a call. Indicates there is call from the doorphone when monitoring or on a call with another device.
- Page 4 VL-MV72AZ User Guide 2.0 Basic Operations Answering doorphone calls and to Unlock the doors. ANSWER the call Press “TALK” button. - Speak within about 50 cm of the microphone. - Speak alternatively with the visitor. If you and the visitor speak at the same time, you will not hear each other.
