Page 1: User Manual
Refrigerator user manual English This manual is made with 100% recycled paper. imagine the possibilities Thank you for purchasing a Samsung product. To receive a more complete service, please register your product at www.samsung.com/register Free Standing Appliance... -
Page 2: Safety Information
Important safety symbols and precautions : Hazards or unsafe practices that may result in severe personal WARNING injury or death. -
Page 3: Severe Warning Signs
SEvERE WARNING SIGNS FOR INSTAllATION WARNING • Do not install the refrigerator in a damp place or place where it may come in contact with water. - Deteriorated insulation of electrical parts may cause an electric shock or fire. • D o not place this refrigerator in direct sunlight or expose to the heat from stoves, room heaters or other appliance. - Page 4 • I f the products equipped with LED Lamp, do not disassemble Lamp Cover and LED Lamp by yourself. - Please contact your service agents. • I f any dust or water is in refrigerator, pull out power plug and contact your Samsung Electronics service center. - There is a risk of fire. cAuTION SIGNS FOR uSING cAuTION • To get best performance of product,...
-
Page 5: Additional Tips For Proper Usage
cAuTION SIGNS FOR clEANING ANd MAINTENANcE cAuTION • D o not directly spray water inside or outside the refrigerator. - There is a risk of fire or electric shock. • D o not spray inflammable gas near the refrigerator. - There is a risk of explosion or fire. • D o not spray cleaning products directly on the display. - Printed letters on the display may come off. -
Page 6: Saving Energy Tips
- Allow clearance to the right, left, back and top when installing. This will help reduce power consumption and keep your energy bills lower. contents SETING up YOuR SIdE-bY-SIdE REFRIGERATOR OpERATING ThE SAMSuNG SIdE-bY-SIdE REFRIGERATOR TROublEShOOTING safety information ·····················································································22 ·····································7 ····················16... -
Page 7: Getting Ready To Install The Refrigerator
GETTING REAdY TO INSTAll ThE REFRIGERATOR Congratulations on the purchase of your Samsung Side-By-Side Refrigerator. We hope you will enjoy the many state-of-the-art features and efficiencies that this new appliance has to offer. Selecting the best location for the refrigerator • Select a location with easy access to the water supply. -
Page 8: Removing The Front Leg Cover
REMOvING ThE REFRIGERATOR dOORS If your entrance won’t allow the refrigerator to pass easily through it, you can remove the doors. 1. Removing the Front Leg Cover First, open both the freezer and refrigerator doors, and then take off the front leg cover by removing the three screws counter-clockwise. Separating the Water Supply Line from the Refrigerator 1. -
Page 9: Removing The Fridge Door
Removing the Fridge Door 1. W ith the door closed, remove the upper hinge cover using a screwdriver. 2. Remove hinge screws and the ground screw by turning counter-clockwise, and take off the upper hinge . Be careful that the door does not fall on you as you are removing it 3. Remove the door from the lower hinge lifting the door straight up 4. -
Page 10: Reattaching The Front Leg Cover
Reattaching the Fridge Door 1. I nsert the lower hinge back into the lower hinge bracket 2. Fit the hole in the corner of the fridge door over the lower hinge 3. I nsert the upper hinge shaft on the hinge . Make sure the hinge is level between the upper hinge hole the top of the cabinet . -
Page 11: Levelling The Refrigerator
lEvEllING ThE REFRIGERATOR Now that the doors are back on the refrigerator, you will want to make sure the refrigerator is level so you can then make final adjustments. If the refrigerator is not level, it will not be possible to get the doors perfectly even. The front of the refrigerator is also adjustable. When the Freezer door is lower than the fridge Insert a flat-blade screwdriver into a notch on the... -
Page 12: Installing The Water Dispenser Line
ThE WATER dISpENSER lINE (OpTIONAl) A water dispenser is just one of the helpful features on your new Samsung refrigerator. To help promote better health, the Samsung water filter removes unwanted particles from your water. However, it does not sterilize or destroy microorganisms. You will need to purchase a water purifying system to do that. In order for the icemaker to operate properly,... -
Page 13: Installing Water Dispenser Line
• S amsung Warranty does not cover WATER LINE INSTALLATION. • T he cost of connection to a water supply is at the customer expense, unless included in the delivery charge (refer to the delivery agreement with the seller) • P lease contact Plumber or Authorised Installer for the installation if needed. • I f Water leakage occurs due to improper installation, Please contact installer. INSTAllING ThE WATER dISpENSER lINE For Exterior model Parts for water line Installation... -
Page 14: Replacement Instructions
COUPLER “A” LINE OUTLET 90 degree SIDE OF PURIFIER Insert Locking Clip After PURIFIER WATER tube seated COUPLER WATER INLET Locking Clip SIDE OF PURIFIER Replacement Instructions 1. Shut off water supply. 2. Note the Flow direction on the filter. 3. I nsert water supply tube into the inlet side of the filter until the tube stop. FLOW DIRECTION WATER SUPPLY INLET SIDE... - Page 15 Connect the water line to the refrigerator. - Remove the compressor cover of the refrigerator. - Connect the water line to the valve, as shown in the figure. - When connected, check if there is any leakage. I f any, repeat the connection. - Reattach the compressor cover of the refrigerator. WATER LINE CONNECTION NUT INSTRUCTIONS COMPRESSOR COVER OF...
-
Page 16: Operating The Samsung Side-By-Side Refrigerator
SAMSUNG side-by-side refrigerator OpERATING ThE REFRIGERATOR USING ThE CONTROL PANEL / DIGITAL DISPLAY cOOlSElEcT MOdEl dISpENSER MOdEl NORMAl MOdEl Speeds up the time needed to freeze products in the freezer. This can be helpful POWER if you need to quickly freeze FREEZE items that spoil easily or if the... -
Page 17: Using The Ice And Cold Water Dispenser
cONTROllING ThE TEMpERATuRE ConTRoLLIng ThE FREEzER TEMPERATuRE The freezer temperature can be set between -14°C (8°F) and -25ºC (-14°F) to suit your particular needs. Press the Freezer button repeatedly until the desired temperature is shown in the temperature display. Keep in mind that foods like ice cream may melt at -16ºC (4°F). -
Page 18: Using The Coolselect Zone™ Drawer (Optional)
• D o not put your fingers, hands or any other unsuitable objects in the chute or WARNING ice-maker bucket. - I t may result in personal injury or material damage. • N ever put finger or any other objects in the dispenser opening. - It may cause injury. • U se only the ice maker provided with the refrigerator. • T he water supply to this refrigerator must only be installed/connected by a suitably qualified person and connect to a potable water supply only. -
Page 19: Removing The Freezer Accessories
zero zone (0ºC) • W hen “Zero Zone” is chosen, the temperature of the CoolSelect Zone Drawer is kept at 0 ºC regardless of the set refrigerator temperature. • “ Zero Zone” temperature helps keep meat or fish fresh longer. Cool • W hen “Cool” is chosen, the temperature will be the same as the set temperature of the refrigerator. The digital panel shows the same temperature as that of the display panel. -
Page 20: Removing The Fridge Accessories
REMOvING ThE FRIdGE AccESSORIES 1. Remove the spill Proof glass Shelf by pulling the shelf out as far as it will go. Then, gently lift it up and gently remove it. 2. Remove the Vegetable & Fruit Drawer by pressing on the indentations found on the inside left and right sides of the Veggie Box/Dry Box cover and remove by pulling forward. -
Page 21: Changing The Water Filter
This is due to air getting into the line. It should pose no problem to operation. ordering replacement filters To order more water filter cartridges, contact your authorised Samsung dealer. uSING ThE dOORS The refrigerator doors are equipped with a door opening and closing feature that ensures that the doors close all the way and are securely sealed. -
Page 22: 22_ Troubleshooting
troubleshooting PROBLEM SOLUTION The refrigerator • Check that the power plug is properly connected. • Is the temperature control on the display panel set to the correct does not work at all or it does not chill • Is the refrigerator in direct sunlight or located too near a heat source? sufficiently. • Is the back of the refrigerator too close to the wall and therefore keeping air The food in the fridge is • Is the temperature control on the display panel set to the correct frozen. • Is the temperature in the room very low? • Did you store the food with a high water content in the coldest part of the You hear unusual • Check that the refrigerator is level and stable. - Page 23 memo...
-
Page 24: Ambient Room Temperature Limits
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic accessories should not be mixed with other commercial wastes for disposal. Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. COUNTRY...
