Installation Outline Drawing

Checking the Content
[1] PS Unit X 1 [2] Mounting Plate X 1
[4] Power Cord [5] Cross Ethernet
Cable 0.5m X1
Europe x 2
USA x 1
[7] Interface Cable X 1 [8] Open I/F PCB X 1
[10] Screw with Toothed [11] Stepped Screw (M4)
Washer X 4
(Binding small; M4x8) X 8
Installation Outline Drawing
• [4] Power Cord
The connector has a different shape depending on locations.
2 are packaged in the products for EUR/1 is packaged in the products for USA
[3] Support Plate X 2
Use the correct power code to mach the location/area of installation.
Make sure not to leave unused power code at the site.
< CD/GUIDES >
• Media Pack US
Installation Outline Drawing
[6] Shield Ethernet
Cable 3.0m X1
[9] Screw (TP; M3x6) X 4
[12] Wire Saddle X 3
F-1-4
3
F-1-5
3
