- Page 1 Additional Operating Instructions SITRANS F Vortex flowmeters SITRANS FX330 Ex-i Edition 09/2018 www.siemens.com/flow...
-
Page 2: Table Of Contents
4.4 Grounding and equipotential bonding................20 4.5 Flow sensor circuits (remote version only) ..............22 5 Operation 5.1 Start-up........................... 23 5.2 Operation ........................23 5.3 Electrostatic charge ....................... 23 6 Service 6.1 Maintenance ........................24 6.2 Dismantling ........................24 7 Notes www.siemens.com/flow 09/2018 - A5E39673922-AB... -
Page 3: Safety Instructions
IECEx KIWA 16.0021X The "X" after the certificate number refers to special conditions for safe use of the device, which have been listed in these instructions. If needed, the IEC certificate can be downloaded from the manufacturer's website. 09/2018 - A5E39673922-AB www.siemens.com/flow... -
Page 4: Safety Instructions
The operator or his agent is responsible for observing any additional standards, directives or laws if required due to operating conditions or place of installation. This applies in particular to the use of easily detachable process connections when measuring flammable media. www.siemens.com/flow 09/2018 - A5E39673922-AB... -
Page 5: Device Description
5 Ex data according to KIWA 16 ATEX 0044X or IECEx KIWA 16.0021X 6 Permissible ambient temperature range 7 Maximum values intrinsically safe circuits 8 Safety instructions, disposal and data matrix 9 Internet address of the manufacturer 09/2018 - A5E39673922-AB www.siemens.com/flow... - Page 6 5 Ex data according to KIWA 16 ATEX 0044X or IECEx KIWA 16.0021X 6 Permissible ambient temperature range 7 Maximum values intrinsically safe circuits 8 Safety instructions, disposal and data matrix 9 Internet address of the manufacturer www.siemens.com/flow 09/2018 - A5E39673922-AB...
-
Page 7: Flammable Products
Definition of zone 1 according to EN 1127-1, Appendix B: An area in which an explosive atmosphere, as a result of the mixture of flammable substances in the form of gas, steam or mist with air, under normal operation may occasionally occur. 09/2018 - A5E39673922-AB www.siemens.com/flow... -
Page 8: Types Of Protection
The classification is outlined in the following tables. The tables take into account the following parameters: • Ambient temperature T • Product temperature T • Nominal size DN • Heat resistance of the connecting cable www.siemens.com/flow 09/2018 - A5E39673922-AB... - Page 9 Insulation must be limited to the piping. Unobstructed ventilation of the signal converter • must be ensured. The permitted ambient temperature range is indicated on the nameplate; depending on the device version it is T = -40...+65°C / -40...+149°F. The minimum product temperature is -40°C / -40°F. 09/2018 - A5E39673922-AB www.siemens.com/flow...
- Page 10 1 Permanent service temperature of connecting cable and cable entry min. 80°C Temperature class in °F Temperature class in °F Nominal size DN15…25 392 392 DN40…50 392 383 DN80…100 392 329 DN150...300 392 392 1 Permanent service temperature of connecting cable and cable entry min. 176°F www.siemens.com/flow 09/2018 - A5E39673922-AB...
- Page 11 1 Permanent service temperature of connecting cable and cable entry min. 80°C Temperature class in °F Temperature class in °F Nominal size DN15…25 392 392 DN40…50 392 392 DN80…100 392 392 DN150...300 392 392 1 Permanent service temperature of connecting cable and cable entry min. 176°F 09/2018 - A5E39673922-AB www.siemens.com/flow...
- Page 12 1 Permanent service temperature of connecting cable and cable entry min. 80°C Temperature class in °F Temperature class in °F Nominal size DN15…25 DN40…50 DN80…100 DN150...300 1 Permanent service temperature of connecting cable and cable entry min. 176°F www.siemens.com/flow 09/2018 - A5E39673922-AB...
- Page 13 1 Permanent service temperature of connecting cable and cable entry min. 80°C Temperature class in °F Temperature class in °F Nominal size DN15…25 248 248 DN40…50 248 248 DN80…100 248 248 DN150...300 248 248 1 Permanent service temperature of connecting cable and cable entry min. 176°F 09/2018 - A5E39673922-AB www.siemens.com/flow...
- Page 14 1 Permanent service temperature of connecting cable and cable entry min. 80°C Temperature class in °F Temperature class in °F Nominal size DN15…25 392 356 DN40…50 392 320 DN80…100 392 284 DN150...300 392 329 1 Permanent service temperature of connecting cable and cable entry min. 176°F www.siemens.com/flow 09/2018 - A5E39673922-AB...
- Page 15 1 Permanent service temperature of connecting cable and cable entry min. 80°C Temperature class in °F Temperature class in °F Nominal size DN15…25 392 392 DN40…50 392 392 DN80…100 392 392 DN150...300 392 392 1 Permanent service temperature of connecting cable and cable entry min. 176°F 09/2018 - A5E39673922-AB www.siemens.com/flow...
-
Page 16: Electrical Data
The verification of intrinsic safety for the interconnection between the flow sensor an the signal converter is not necessary, if the cable length does not exceed 50 m / 164 ft and the supplied cable is used. www.siemens.com/flow 09/2018 - A5E39673922-AB... -
Page 17: Installation
1 M4 hexagon socket screw on connection housing • De-energise the signal converter. • Loosen the hexagon socket screw 1. • Turn the signal converter or the connection box. • Screw signal converter or connection box back to the base again. 09/2018 - A5E39673922-AB www.siemens.com/flow... -
Page 18: Special Conditions
23. Thermal and electrical data Observe the maximum ambient and product temperatures and electrical data. For further Ambient temperature / temperature classes information refer to on page 8 and refer to Electrical data on page 16. www.siemens.com/flow 09/2018 - A5E39673922-AB... -
Page 19: Electrical Connections
Ensure that the gaskets and incised gasket ring are tight. 4.2 Power supply Vortex flowmeters do not require a separate power supply. The required supply for the built-in electronics is provided via the 4...20 mA current output or the bus connection. 09/2018 - A5E39673922-AB www.siemens.com/flow... -
Page 20: Inputs / Outputs
PA terminal must be provided to connect to the equipotential bonding. Figure 4-1: Ground connection of the compact version 1 Electrical grounding connection on connection piece between the flow sensor and the signal converter 2 Electrical grounding terminal in the housing www.siemens.com/flow 09/2018 - A5E39673922-AB... - Page 21 PA connection in the signal converter terminal compartment or via the external PA connection. Figure 4-2: Ground connection of the remote version 1 Electrical grounding connection on the flow sensor 2 Electrical grounding connection on the housing of the signal converter 09/2018 - A5E39673922-AB www.siemens.com/flow...
-
Page 22: Flow Sensor Circuits (Remote Version Only)
2 Connection terminal signal converter 3 Connection shielding flow sensor 4 Shielding (drain wire and overall shield) 5 Connection shielding signal converter 6 Heat shrink tubing The flow sensor circuit is designed in protection type "intrinsic safety Ex ia IIC". www.siemens.com/flow 09/2018 - A5E39673922-AB... -
Page 23: Operation
• spraying of electrons (e.g. in the vicinity of electrostatic painting systems) or • pneumatically conveyed dust is exposed. CAUTION! Electrostatic charging of the housing surface by friction must be avoided. The devices must not be dry cleaned. 09/2018 - A5E39673922-AB www.siemens.com/flow... -
Page 24: Service
The display can be rotated in 90° increments. It is connected to the connector as shown in the following figure. Exchanging the converter insert It is permitted to replace the entire SITRANS FXT030 converter insert with a brand-new version identical in construction. www.siemens.com/flow 09/2018 - A5E39673922-AB... - Page 25 In the case of environmentally critical or hazardous products, appropriate safety precautions • must be taken with regard to residual liquids in the measuring unit. New gaskets have to be used when re-installing the device in the piping. • 09/2018 - A5E39673922-AB www.siemens.com/flow...
-
Page 26: Notes
NOTES SITRANS FX330 www.siemens.com/flow 09/2018 - A5E39673922-AB... - Page 27 NOTES SITRANS FX330 09/2018 - A5E39673922-AB www.siemens.com/flow...
- Page 28 For more information www.siemens.com/flow www.siemens.com/processautomation Siemens AG Process Industries and Drives Process Automation 76181 Karlsruhe Germany Product Information...
