- Page 1 Equipment Additional Information Lea este manual antes de usar el producto Centro de Asistencia de Sony http://esupport.sony.com/ES/LA/ Llame al número telefónico que aparece en su póliza de garantía. Por favor no devuelva el producto a la tienda donde adquirió el producto.
-
Page 2: Table Of Contents
Table of Contents IMPORTANT NOTICE ....3 Viewing Pictures from Safety Information ....3 Connected Equipment Connection Diagram . -
Page 3: Important Notice
Introduction Safety Information Thank you for choosing this Sony product. Before operating the TV, please read this manual thoroughly and retain it for Note future reference. This television includes a QAM demodulator which Note should allow you to receive unscrambled digital •... - Page 4 NOTE ON AC ADAPTER Warning To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. To prevent fire or shock hazard, do not place objects filled with liquids, such as vases, on the apparatus.
- Page 5 Please take a moment to register your TV Discover the wealth of entertainment now available on super-high resolution http://esupport.sony.com/LA/perl/ Blu-ray Disc™ player and other Sony HD registration.pl equipment. Four Steps to a Stunning HD Sound Experience Complete the high-definition experience Set, Source, Sound, and Setup.
-
Page 6: Getting Started
Securing the TV Getting Started Sony strongly recommends taking Setting Up Your TV measures to prevent the TV from toppling over. Unsecured TVs may Some TV models are packaged with a topple and result in property damage, detached Table-Top Stand so you can serious bodily injury or even death. -
Page 7: Recommended Measures To Secure
The length of the M4 machine screw Recommended Measures to Secure differs depending on the rope or chain the TV diameter. Please refer to below illustration. Consider the following measures when 8 - 12 mm securing your TV to a Stand (not supplied). Secure the Stand for the TV. -
Page 8: Precautions
Precautions How to care for your BRAVIA TV Safety is very important. Please read and follow the safety documentation (Safety Booklet) separately provided. Unplug the TV and other connected equipment from the wall outlet before you begin cleaning your Wipe the LCD screen gently with a soft cloth. -
Page 9: Parts And Controls
+ / – / • Increases/decreases the volume, or Parts and Controls selects the next (+) or previous (–) channel when the CH Up/Down notification is displayed by pressing the CH/INPUT button. • Moves the selected input source up/ down when the input select menu is displayed by pressing the CH/INPUT button. -
Page 10: Remote Control
TV Control: Use the [TV Control] menu to operate Remote Control the TV from the [Home (Menu)] or [Options] menu. Return to TV: Select this option to return to TV program. PIC OFF Press to turn picture off, and sound remains on. -
Page 11: Guidelines For Remote Control
POWER Turns the TV on or switches to standby Guidelines for Remote mode. Control WIDE Point your remote control directly at the IR Adjusts the screen display. Press sensor located on your TV. repeatedly to select the desired wide ... -
Page 12: Watching Tv
The boxy 4:3 aspect ratio (common to most SD signals) must be adjusted to fill the Watching TV screen. Press / on the TV or POWER on the remote control to turn on the TV. Press PIC OFF to turn picture off, and sound remains on. -
Page 13: Changing The Viewing Style
Changing the Viewing Style Changing the Wide Mode Press WIDE repeatedly to select the wide mode. [Wide Zoom]* [Normal] [Full] [Zoom]* * Parts of the top and bottom of the picture may be cut off. For HDMI PC Input (PC timing) [Normal] [Full 1] [Full 2]... -
Page 14: Navigating Through Home Menu
Applications Navigating through Home Menu Using the TV as a Photo Frame The HOME button allows you to access a variety of TV settings and features. Photo Frame displays the clock and calendar at the same time as displaying a Press HOME. -
Page 15: Media
You can enjoy photo/music/video files You can change the setting of the [Duration] stored in a Sony digital still camera or in the [Photo Frame Settings] (page 21). camcorder through a USB cable or USB storage device on your TV. - Page 16 Audio Codec: MPEG1 Layer1/2, MP3, The data on the USB device may be damaged. • Sony will not be held liable for any damage to, or Dolby Digital (2ch), DTS, loss of, data on the recording media due to a DTS 2.0...
-
Page 17: Settings
CineMotion Settings Provides improved picture movement when playing BD (Blu-ray Disc), DVD Preferences or VCR images taken on film, reducing picture blur and graininess. Select [Auto] to represent original film-based Note content as it is. • The options you can adjust vary depending on the situation. - Page 18 Sound Alternate Audio Digital channels only. Sound Mode Select among the available Select according to content you want options to switch among the to enjoy. alternate audio streams. The program you are tuned to may be Reset broadcasted in a different Reset [Equalizer], [Clear Voice], language in the alternate audio [Steady Sound], [Balance] and...
- Page 19 Horizontal Center Edit Channel Labels Adjusts the horizontal position of the Allows you to assign labels (such as picture. station call letters) to channel numbers. Vertical Center Press F/f to scroll through the channel numbers. Then press Adjusts the vertical position of the select the channel number that you picture.
- Page 20 Parental Lock Unrated (Available only when Country is set to Password U.S.A.) Sets a PIN code to block channels and Allow: Allows programs and external inputs. Use 0-9 on the movies that are broadcasted remote to enter a four-digit password. without a rating.
- Page 21 Duration: Select the time period Custom: Allows you to customize ([1 h], [2 h], [4 h] or [24 h]) after the following settings: which the TV automatically Character Size switches to standby mode. Small, Standard, Large Character Style First day of the week: Sets Style 1-7 [Sunday] or [Monday] as the first Character Color...
- Page 22 Clock/Timers AV Setup Sets the timer and clock. Manage Inputs: Assigns name to Sleep Timer: Sets the time in external equipment input. minutes that you would like the Select [Auto] to display names TV to remain on before shutting when the equipment is off automatically.
- Page 23 [On], the following HOME/OPTIONS button. functions are available. Note If the specific Sony equipment • Some equipment with [BRAVIA Sync that is compatible with BRAVIA Control] does not support the [Device Sync Control is connected, this Control Keys] feature.
-
Page 24: Customer Support
Auto Shut Off broadcasters. Select [On] to automatically power off the TV when no input signal is Contact Sony detected for a certain period of time. Displays your TV’s product information. Select [Off] to disable this function. -
Page 25: Viewing Pictures From Connected Equipment
Viewing Pictures from Connected Equipment Connection Diagram You can connect a wide range of optional equipment to your TV. Note • Depending on TV model, connecting a large USB device may interfere with other connected devices beside Home Audio System with ARC/HDMI HDMI Device... -
Page 26: Connecting The Tv
Showing a Set Top Box with HDMI Connecting the TV connection Note • Use an antenna cable connector no greater than 14 mm thick. • When connecting the cable to the Cable/ Antenna, input finger tighten only, over tightening the connection can damage the TV. •... -
Page 27: Component Connection
Showing a Set Top Box with Cable System or VHF/UHF Antenna COMPONENT connection System Rear of TV Cable or Antenna Set Top Box... - Page 28 Showing HD BRAVIA® Sync™ Basic Connection Optical Connection Rear panel A/V Receiver Blu-ray Disc HD Cable Box or HD Satellite Receiver Side Panel SAT (Dish) Cable/ Antenna *1 Signifies a BRAVIA Sync capable device. *2 The optical connection is only needed for A/V receivers that do not support ARC (Audio Return Channel).
-
Page 29: Home Theater System
Showing HD Basic Connection with Home Theater System *Optical Rear panel Connection Side Panel Home Theater System Blu-ray Disc/DVD Rear of TV SD Cable Box or Cable/Antenna SD Satellite Receiver Cable/ VIDEO SAT (Dish) * The optical connection is only needed for home theater system that do not support ARC (Audio Return Channel) when connecting with HDMI. -
Page 30: Vcr/Dvd
Showing PC Connection with SD VCR/DVD Rear panel *DVI Notebook PC Side Panel Rear of TV VCR/DVD Combo Splitter Cable/Antenna * DVI does not support audio signals. Connect the audio output of the PC to the PC speakers or an A/V receiver to listen to sound from the PC. -
Page 31: Using Audio And Video Equipment
AUDIO OUT (OPTICAL) to output digital sound. • When connecting with an HDMI cable, be sure to use HighSpeed HDMI Cable with Cable Type Logo (Recommended SONY Cable). • When connecting mono equipment, connect the audio cable to the L (mono) jack. -
Page 32: Additional Information
For product protection and safety • When removing the Table-Top Stand from the TV, lay the display face down on a stable work reasons, Sony strongly recommends that surface that is larger than the TV. installation of your TV on the wall be •... -
Page 33: Installing The Tv Against A Wall Or Enclosed Area
LED indicator flashes red (interval time is three seconds). Press / on the TV to turn it off, disconnect the AC power cord, and contact Sony Leave at least this much space around the set. Customer Support. Installed on the wall When the LED indicator is not flashing, check the items as follows. -
Page 34: Sound
Picture or sound noise when viewing a TV Sound channel Make sure that the antenna is connected No sound, but good picture using a 75-ohm coaxial cable (not supplied). Press VOL +/- or MUTING. Keep the antenna cable away from other ... -
Page 35: Specifications
The Parental Lock password has been forgotten Specifications Press HOME and select [Settings] t [Preferences] t [Parental Lock] t System [Password] then enter 4357 for the password. Television system Store Display Mode or Promoting Feature NTSC: American TV standard Logo appears on the screen ATSC (8VSB terrestrial): ATSC compliant 8VSB ... - Page 36 1,080 lines (vertical) • “Blu-ray Disc”, “Blu-ray” and “Blu-ray KDL-32R320C: 1,366 dots (horizontal) × Disc” logo are trademarks of Blu-ray 768 lines (vertical) Disc Association. • “PlayStation” is a registered trademark and “PS3” is a trademark of Sony Computer Entertainment Inc.
- Page 37 • For DTS patents, see http://patents.dts.com. Manufactured under license from DTS, Inc. DTS, the Symbol, & DTS and the Symbol together are registered trademarks, and DTS 2.0+Digital Out is a trademark of DTS, Inc. © DTS, Inc. All Rights Reserved. •...
- Page 40 TV, visit: http://esupport.sony.com/LA/ Software Updates: NOTE: If your TV is connected to the Internet, you can check for software updates by pressing HOME, then select [Settings] t [Customer Support] t [Software Update]. © 2015 Sony Corporation Printed in U.S.A. 4-574-477-E3(1)
