S5U1C33001H

COMPONENTS INCLUDED WITH PACKAGE

The following shows the components included with the package:
(1) S5U1C33001H (main unit) ......................................................... 1
(2) USB cable ................................................................................... 1
(3) Target system interface cable (10-pin) ...................................... 1
(4) Target system interface cable (4-pin) ........................................ 1
(5) Target system interface cable (30-pin) ...................................... 1
(6) Target system interface connectors (10-pin) ............................. 4 (straight × 2, low-angle × 2)
(7) Target system interface connectors (4-pin) ............................... 4 (straight × 2, low-angle × 2)
(8) Target system interface connectors (30-pin) ............................. 2 (low-angle × 2)
(9) AC cable ..................................................................................... 1
(10)Target system power supply cable (6-pin) ................................. 1
(11)Target system power supply connector (6-pin) ......................... 1 (low-angle)
(12)User registration card ................................................................. English/Japanese, 1 each
(13)Warranty card ............................................................................. English/Japanese, 1 each
(14)Usage precautions ..................................................................... English/Japanese, 1 each
(15)Manual download guide ............................................................. English/Japanese, 1 each
The items specified below are not included with the package. These items must be prepared separately.
(16)S5U1C33001H
(Ver. 4)
(17)Debugger (gdb.exe) for the S1C33 Family
(18)Debugger manual for the S1C33 Family
4
(Ver. 4)
Manual (S1C33 Family In-Circuit Debugger)
(included in the S1C33 Family C Compiler Package)
(included in the S1C33 Family C Compiler Package)
Figure 2 Package Components
(this PDF, downloadable from the SEIKO EPSON HP)
• S5U1C33001H (main unit)
EMU/ERASE
TRC FULL/WRITE
POWER
OK
BUSY 1 2 3 4 5 6 7 8
ERROR
1 2 3 4 5 6 7 8
UVCC VCC OUT
• AC cable
• Target system interface
cables
10 pins–10 pins
10 pins–4 pins
30 pins–30 pins
• Target system power supply
cable
6 pins–6 pins
• User registration card
• Warranty card
• Usage precautions
• Manual download guide
Registration
..............
..........
............
........
English Japanese
• USB cable
• Target system connectors
10 pins (straight) × 2
• • • • •
• • • • •
10 pins (low angle) × 2
• • • • •
• • • • •
4 pins (straight) × 2
• • • •
4 pins (low angle) × 2
• • • •
30 pins (low angle) × 2
• Target system power supply
connector
6 pins (low angle)
• • • • • •
