Hitachi GCR-8480B User Manual page 22

Pin No. Siganl
115 IOPORT9
116 DSLB
117 AV
118 SLCIST1
119 SLCIST2
120 SLCO0
121 SLCO1
122 SLCO2
123 SLCO3
124 EFMIN
125 EFMIN2
126
127
128 PWM0
129
130 PCKISTF
131 PCKISTP
132 PLL2V
133 PLL2Vss
134
135
136
137
138
139
140
141
142
143 RREC
144
145
146
147 VREF
148
149
150 FBAL
151 TBAL
152
153 TOFST
20
Type
DD
AVss
JITC
FR
DD
PDO
PDS1
PDS2
PDS3
RPO
SVss
AD1
PH
BH
FE
TE
TES
PHC
BHC
SGC
COMMENT
B General input/output port
O SLC PWM output
P Slice Level VDD 3.3V
I EFM Slice Level Control port
I
O EFM Slice level output
O
O
O
I EFM input pin
I
P Slice Level GND
O Jitter output
I VCO PWM output
I VCO frequency control port
I Frequency comparater charge pump control port
I Phase comparater charge pump control port
P VCEC PLL VDD 3.3V
P VCEC PLL GND
O Charge Pump Filter
O Charge Pump select port
O
O
O P/N Balance Adjust port
P Servo GND
I AD input1
I Peak HOLD
I Bottom HOLD
I Optical judge input port
I FE input port
I TE input port
I TES compartor input
I VREF input port
O PH Slice condensor input port
O BH Slice condensor input port
O Focus Balance port
O Tracking Balance Port
O Servo gain control port
O Tracking offset Adjust port
