Summary of Contents for Sony Vaio PCG-C1MV
- Page 2 Sony and VAIO are trademarks of Sony. Microsoft, MS-DOS, Windows, the Windows 95, Windows 98, Windows 2000, Windows CAUTION: Danger of explosion if battery is incorrectly replaced.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Section Title Page CHAPTER 1. REMOVAL ..........1-1 Please confirm disassembly method by “Repair Manual” which has been informed you separately. CHAPTER 2. SELF DIAGNOSTICS ......2-1 Please confirm “Self Diagnostics” method which will be informed you with distribution of “Self Diagnostics” software. CHAPTER 3. -
Page 4: Chapter 1. Removal
CHAPTER 1. REMOVAL < ATTENTION > Please confirm disassembly method by “Repair Manual” which has been informed you separately. Confidential PCG-C1MV/C1MVP (AM) (END) -
Page 5: Chapter 2. Self Diagnostics
CHAPTER 2. SELF DIAGNOSTICS < ATTENTION > Please confirm “Self Diagnostics” method which will be informed you with distribution of “Self Diagnostics” software. Confidential PCG-C1MV/C1MVP (AM) (END) -
Page 6: Chapter 3. Block Diagram
IMIC9716IBTD Port80 bq3285LD MBM29F016A H8Crisis Module 4MB Flash LPC I/F (3.3V) USB2 SD23 0110 000x Magic Gate MS,NUM,CAPS,SCRL LED SUMIRE Sony CXD3451GA PWR,CAM,BT SW CAM CN F731791C Sometaro PBK-TEB I/O Exp CXD401 JOG SW CAM CN Analog O2micro Devices MS CN... -
Page 7: Chapter 4. Frame Harness Diagram
CHAPTER 4. FRAME HARNESS DIAGRAM LCD HOUSING ASSY IFX-166 BOARD FROM board connector (direct connection) Harness (connector at both end) Harness (soldered at one end) LITHIUM ION BATTERY PACK CN2602 Rear UNIT CN2102 POWER CAMERA BUTTON DIAL SHUTTER MODEM SWX-83 BOARD CARD SIDE A Side R... -
Page 8: Main Section
CHAPTER 5. EXPLODED VIEWS AND PARTS LIST Ref.No. Part No. Description Ref.No. Part No. Description 4-655-327-01 RETAINER, SPEAKER 1-823-465-11 FFC 12P 1-544-951-11 SPEAKER (WITH HARNESS) A-8067-126-A PWB SWX-83 NON-BT ASSY (S) NOTE: 4-643-073-11 SHEET (SPEAKER), ADHESIVE 1-823-466-11 CABLE, FLEXIBLE FLAT 16P •... -
Page 9: Lcd Section
5-2. LCD Section Ref.No. Part No. Description X-4623-818-2 COVER SUB ASSY, HINGE X-4623-812-2 BEZEL SUB ASSY (B), LCD 4-646-976-11 CUSHION (LATCH) 4-643-078-11 RUBBER (UNDER), BLIND A-8067-128-A LCD 8.9WSXGA ASSY (S) 1-476-913-11 INVERTER UNIT 1-961-294-11 HARNESS (INVERTER 6P) 1-961-422-12 HARNESS (LCD) 4-655-335-01 HINGE (L) 4-655-343-01... -
Page 10: Port Assy Section
5-3. Port Assy Section Ref.No. Part No. Description 4-655-763-01 FOOT, RUBBER 4-655-758-02 CABINET (LOWER) * 203 4-655-760-01 PLATE, CONNECTOR A-8066-914-A COMPLETE PWB CNX-147 1-794-548-11 CONNECTOR, USB (A) * 206 4-656-128-01 BRACKET 1-823-344-11 CABLE, I/F 4-655-761-01 HOLDER, CONNECTOR 4-656-127-02 ESCUTCHEON (CONNECTOR) X-4624-077-2 CABINET (UPPER) SUB ASSY 4-655-762-01... -
Page 11: Accessories
5-4. Accessories Ref.No. Part No. Description ACCESSORIES *********** 0301 1-757-562-31 CORD, POWER 1-757-673-11 CORD, CONNECTION 4-655-329-01 CAP (IN BAG), SENSOR 0307 1-476-942-11 ADAPTOR, AC 1-756-074-41 BATTERY PACK, LITHIUM ION PORT ASSY 4-659-022-01 QUICK START, C1MVP, MV AV Connecting Cable The components identified by mark 0 or dotted line with mark 0 are critical for safety. - Page 12 : Additional Model American Area : North, Central and South Americas This manual and the constituent data may not be replicated, copied nor reprinted in whole or in part without prior written authorization of Sony Corporation. English Sony Corporation 2002A0500-1 ©...
-
Page 13: Revision History
Revision History Suffix Ver. Date Contents QM No. Ver. 1 2002.01.23 First Edition <Remarks> [Confidential] PCG-C1MV/C1MVP (AM)
