- Page 1 Quick Reference Guide Field IM/AMG/QRG_1 Electronic Commercial Water Meter with Integral Logger AquaMaster...
- Page 2 Cert. No. Q5907 As a part of ABB, a world leader in process automation technology, we offer customers application expertise, service and support worldwide. We are committed to teamwork, high quality manufacturing, advanced EN 29001 (ISO 9001) technology and unrivalled service and support.
-
Page 3: Controls And Display
CONTROLS AND DISPLAY This Quick Reference Guide is applicable to product firmware version 2.20 or Upper Display Lower Display Date Time greater. Features applicable to the GSM Forward Flow Total Flow Velocity option are only present on version 2.30 or Reverse Flow Total Pressure greater. -
Page 4: Security Access
Further key operations access the menus as follows: = Menu Displayed Text; = User entered data ; = Function Key 2.0 Measurements 1.0 Information AquaMaster 12:31:00 ABB Limited 25/12/1998 Stonehouse Test Mode Flow etc. Note. Pressing within a menu displays all the remaining parameters immediately. -
Page 5: Parameter Changes
PARAMETER CHANGES Space Flow Units : l/s (Repeat space function key until Flow Units? Space required units are displayed) Flow Units? Flow Units : l/m Note. Use to escape or cancel in input mode, or to exit a menu. FSD(100% or URV) 200 l/m Changing Selections Note. - Page 6 PARAMETER CHANGES Go To Menu To quickly traverse the AquaMaster menu structure, assuming that the menu system has been activated (by pressing 3 or 4 times) and that a suitable login level has been obtained, go to a given Menu by typing its number followed by Tab :- eg to go to menu 12 type: and AquaMaster menu 12 will now be accessible:...
-
Page 7: Menu Layout
MENU LAYOUT CLI Value r a l Function y t i Security Access Level f f i r f f i r . t t e t i / t t . t t . t t l e t o l f t i x o i t... - Page 8 MENU LAYOUT... s t i r i f l a i s t i l a i t i x t i x l a i s t i z i l s t i s t i t i n t i x l a i s t i...
- Page 9 ...MENU LAYOUT e l i o i t – > ) d l l a t . l a t i a ) s ( . t r t i x o i t . ) e o i t f f i t i x y l i...
-
Page 10: Wireless Communications
WIRELESS COMMUNICATIONS Access via GSM Mains Powered Meters Commissioning test for signal strength When the meter is mains powered, the GSM radio This provides a means of carrying out a radio module is continuously powered and is able to signal test for selecting the optimum location for handle remote communications (SMS Requests, the antenna. - Page 11 ...WIRELESS COMMUNICATIONS Status SMS Request Message SMS Request messages must have the following GSM Module Status format: GSM Module Status [>368] shows the current GSM radio module status as one of: +password;command;command;...;command; Not Configured +password is the character + followed by the AquaMaster login password [>248] and the Off (SIM not fitted) command can be:-...
- Page 12 WIRELESS COMMUNICATIONS... SMS Tel. No AR Schedule AutoReport SMS text messages will be sent to the Use AR Schedule [>361] to set the AutoReport SMS telephone number programmed into SMS schedule to one of the following options:- Tel. No [>362]. Telephone numbers should be Daily entered as they would normally be dialled, with no Weekly (every Sunday at WakeUp Base...
- Page 13 ...WIRELESS COMMUNICATIONS Access Lock Using AquaMaster to change SIM's Access When the SIM Access Lock is enabled, the PIN is Lock status required to be sent to the SIM each time the GSM This requires that the PIN has already been module is powered up.
-
Page 14: Tariff Control
TARIFF CONTROL Notes toTariff Control: The Tariff Control menu is used for defining Tariff A only. Tariff B is always the opposite of Tariff A. Daily Cycle Start Time defines the start of normal day time. Weekly Cycle Start Day defines the first day of the weekend (from 00:00). Weekly Cycle End Day defines the first day of the week (at 00:00). - Page 15 NOTES...
- Page 16 NOTES...
- Page 17 ...NOTES...
- Page 18 NOTES...
