Euroset 5040 Quick Guide
1 2
Keys
1 Name keys
2 Automatic call pick-up key*
3 Star key / Proximity sensor key*
4 Hash key / Telephone lock key*
5 Recall key / Set key*
6 Loudspeaker key (handsfree)
7 Mute key
8 Redial key
9 Calls list key / Visual display of incoming calls
10 Loud key / Up key
11 Quiet key / Down key
* Keys can have two functions. Hold down key for at
least 1 second to use the function marked with an
asterisk. If activated successfully you will hear the
positive confirmation tone. The corresponding sym-
bol is shown in the display (see "Display symbols").
Display
To get the optimum viewing angle you can adjust the
display to an angle of 0° - 60°.
Proximity
Display sensor
3 4 5 6 7
1
en
Display symbols œ
{
In setting mode
ƒ
Telephone locked
~
Baby Call (direct call) activated
}
Microphone off
›
Handsfree on
Number indicated in calls list called more
‰
than once
Œ
Power on
On: Proximity sensor activated
Flashing: Proximity sensor and automatic
call pick-up activated
8
0 – 9 Phone number
9
Call duration
00:00
10
Entry mark when setting (e.g. volume)
o
Recall key pressed
u
11
P Pause
--- Ready for use
No memory content
z
When trying to connect: telephone
zzzz
locked
With tone dialling:
Star key
n
- Hash key
Keypad and display illumination
The whole keypad and the display light up
when a call comes in,
◆
when you press a key,
◆
when you lift handset,
◆
when you approach the telephone and the prox-
◆
imity sensor is on (see page 5).
Proximity sensor
The proximity sensor detects when you approach the
telephone and lights up the keypad and display. A call
is automatically answered by speaking handsfree.
Prerequisite: the caller is stored under a Name key
and "Automatic call pick-up" is activated (see page 5).
*
