SPP-ID975/ID976
SERVICE MANUAL
Ver 1.0 1999. 11
General
Frequency band (SPP-ID975)
902 – 928 MHz
Frequency band (SPP-ID976)
923.1 – 927.75 MHz
Base phone : 18 µW
Handset
: 73 µW
Operating channel
30 channels
Dial signal
Tone, 10 PPS (pulse) selectable
Supplied accessories
AC power adaptor AC-T122 (1)
Telephone line cords (2)
Wall bracket for base phone (1)
Rechargeable battery pack BP-T23 (1)
Handset
Power source
Rechargeable battery pack BP-T23
Battery charging time
Approx. 12 hours
Battery life
Standby : Approx. 7 days
Talk
: Approx. 6 hours
Dimensions
Approx. 58 × 177 × 46 mm (w/h/d),
antenna excluded
× 7 × 1
(approx. 2
inches)
3/8
13/16
Antenna: Approx. 72 mm
(approx. 2
inches)
7/8
Mass
Approx. 270 g
(approx. 9.5 oz), battery included
MICROFILM
Photo: SPP-ID975
SPECIFICATIONS
Base phone
Power source
DC 9V from AC power adaptor
AC-T122
Battery charging time
Approx. 24 hours
Dimensions
Approx. 166 × 63 × 225 mm (w/h/d),
antenna excluded
× 2
(approx. 6
5/8
Antenna: Approx. 120 mm
(approx. 4
inches)
3/4
Mass
Approx. 595 g
(approx. 1 lb 9 oz), wall bracket excluded
Design and specifications are subject to
change without notice.
Notes on Chip Component Replacement
• Never reuse a disconnected chip component.
• Notice that the minus side of a tantalum capacitor may be dam-
aged by heat.
– 1 –
US Model
Canadian Model
× 8
inches)
1/2
7/8
CORDLESS TELEPHONE
SPP-ID975
SPP-ID976
