- Page 1 WAM7500/WAM7501/WAM6500/WAM6501 Wireless Audio - 360 R7/R6 Portable User Manual imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register...
-
Page 2: Table Of Contents
Contents GettinG StArted USinG the SAMSUnG MUltirooM App Accessories ........4 Switching the input source ..22 Standby Mode ......4 Playing Music ......23 Front Panel ........5 Playing a music file stored in the Rear Panel - WAM6500/WAM6501 .. 6 smart device ........23 ConneCtionS Listening to streaming music .....26... - Page 3 ConneCtinG MUltipleS Regulatory Compliance prodUCtS Statements ........50 Warning ..........50 Selecting the product ....39 IC Statement: (for Canada) ....50 Selecting another product for This Class B digital apparatus playback ..........39 complies with Canadian ICES-003 ..51 Setting Groups ......40 Important Safety Instructions .....51 Setting the Surround Sound Safety precautions .......
-
Page 4: Getting Started
Getting Started Accessories Confirm you have the supplied accessories shown below. • WAM7500/WAM7501 Quick Setup Guide • WAM6500/WAM6501 Power Adapter Quick Setup Guide Standby Mode in Wi-fi / Bluetooth / tV SoundConnect mode - The product switches to Standby mode if there is no operation (music playing, button operation, app use) for 15 minutes. -
Page 5: Front Panel
Be careful not to insert your hand or finger into the tweeter opening on top of the product. < WAM7500/WAM7501 > < WAM6500/WAM6501 > Touch this button to switch to TV SoundConnect or Bluetooth. Source button Touch and hold this button for more than 5 seconds to re-search TV SoundConnect. -
Page 6: Rear Panel - Wam6500/Wam6501
You can check product's battery status. Battery LED indicator when power Battery LED indicator when power adapter is connected adapter is not connected • Red LED : Charging • Green LED : 100% to 10% of charge remaining • LED OFF : Fully charged Battery Status • Slow red blinking : 10~0% remaining • Rapid red blinking : Not charging... -
Page 7: Connections
Connections preparing connection Internet Wireless Router Samsung Link Requirements: Wireless Router, Smart Device The wireless router should be connected to the Internet. The smart device should be connected to the router via a Wi-Fi connection. installing the Samsung Multiroom App ❚... -
Page 8: Connecting Wirelessly
Connecting wirelessly Connecting to your wireless network automatically (Android/ioS) ❚ Wireless Router Plug the product into an electrical outlet. On your Smart device, select the Samsung Multiroom app. Run the tutorial if you want, and then press done. Press Connect now. • It searches for the device available for pairing. - Page 9 Once an available device is found, it attempts to connect to the wireless network. In case of secure network, the password prompt appears on the smart device screen. Use the onscreen keyboard to enter the password. • Depending on the network environments, the product(s) may not be automatically connected.
-
Page 10: Connecting To The Wireless Network Manually (Android)
Connecting to the wireless network manually (Android) ❚ Depending on the network environments, the product(s) may not be automatically connected. In that case, you can set up the product manually to connect to the network. Wireless Router If the automatic setup fails, select the Manual. play/pause Standby Press and hold both... - Page 11 On your smart device, press next. • It searches for the device available for pairing. Once an available device is found, the product tries to connect to the newly found smart device first, then it attempts to connect to the wireless network. In case of secure network, the password prompt appears on the smart device screen.
-
Page 12: Connecting To The Wireless Network Manually (Ios)
Connecting to the wireless network manually (ioS) ❚ Wireless Router If the automatic setup fails, select the Manual. play/pause Standby Press and hold both buttons simultaneously for more than 5 seconds to configure the Wi-fi Setup. • The R7/R6 can wait for 2 minutes in its standby mode until the Wi-Fi connection is established. - Page 13 On your smart device, press next. • It searches for the device available for pairing. Go to Settings ; Wi-fi in iOS, and then select the Samsung Wireless Audio. To connect your smart device to the R7/R6, use the keyboard that appears to enter your password.
- Page 14 Go back to the Samsung Multiroom app. Select next. From the wireless network list, select the desired one for R7/R6 connection. In case of secure network, the password prompt appears on the smart device screen. Use the onscreen keyboard to enter the password. • Once you finish entering, the R7/R6 connects to the network.
-
Page 15: Connecting With A Hub (Not Included)
Go back to the Samsung Multiroom app. • All network connections are finished. Connecting with a hUB (not included) • If the product fails to connect to your network or its network connection operates abnormally, place the product closer to the HUB or your router and try again. • The product is a wireless network device. - Page 16 Attach the HUB's power cord to the power port on the rear of the HUB, and then plug the power cord into an electrical outlet. The power ( ) and the HUB ( ) indicators on the HUB's front turn on. When the pairing indicator ( ) begins to flash, plug the product(s) into an outlet.
- Page 17 Download the Samsung Multiroom app from Google Play or the App Store. On your smart device, select the Samsung Multiroom app. Setup starts. If the automatic setup fails, run the App again and follow the instructions in the app guide on your device to connect the product and the HUB.
-
Page 18: Adding A Hub
Adding a hUB ❚ An product and a HUB may not pair successfully if the product and HUB are too far apart or are on different floors. In such cases, you can link two HUBs together by setting the second HUB to Repeater mode. The additional HUB amplifies the signal and lets you pair the product to the closest HUB. -
Page 19: Adding Additional Speaker(S)
Adding additional speaker(s) To add additional speaker(s) to an existing speaker connection, use Add Speaker function. Run the Samsung Multiroom app on your smart device. Press to view the list of all speakers. Press Press the Add Speaker. Connect the power cable of the speaker to be added to a wall outlet. • If connecting the power cable of the speaker to a wall outlet, the Wi-Fi is automatically switched into standby mode. -
Page 20: Connecting To Bluetooth Devices
The additional new speaker is completely added. Connecting to Bluetooth devices You can connect the product to a Bluetooth device to enjoy the music stored in your Bluetooth device. Turn on the Bluetooth function of your smart device, and then select Search. Select the [Samsung] r7 or [Samsung] r6. - Page 21 9 This product may cause electric interference during its operation. 9 The product supports SBC data (44.1kHz, 48kHz). 9 The AVRCP feature is not supported. 9 Connect only to a Bluetooth device that supports the A2DP (AV) function. 9 You cannot connect to a Bluetooth device that supports only the HF (Hands Free) function. 9 Only one Bluetooth device can be paired at a time.
-
Page 22: Using The Samsung Multiroom App
Using the Samsung Multiroom App Switching the input source You can change the input source (Music Services, Nearby Devices or other external device) for the selected product. Press Source. Select a source from the list of sources that appears. 4444... -
Page 23: Playing Music
playing Music playing a music file stored in the smart device ❚ Press Source. Select the Songs on phone (files stored in the smart device). • If the source is set to music of mobile phone, press Select your desired category. • Songs : Lists all the music files by name. - Page 24 Using playback menu Press When a popup menu appears, select your desired function. • Shuffle : It randomly plays back music files from the standby list. • repeat : It repeats the current music file or all the music files from the standby list. • Add to playlist : Creates a new playlist or adds currently playing music into the current playlist.
- Page 25 Adjusting equalizer You can create your own settings by selecting product's factory-default settings or adjusting the frequencies manually at your preference. Press When a popup menu appears, press the equalizer. To adjust the bass or treble frequency ranges, drag the slider up or down. Press oK.
-
Page 26: Listening To Streaming Music
listening to streaming music ❚ Listening to streaming music Press Source. From the Music Services, select your desired service. noteS 9 Depending on your region or manufacturer, supported content services may differ. 9 You may not subscribe to a service using your smart device. To use a for-pay service, first subscribe to the service through your computer. -
Page 27: Listening To The Internet Radio
listening to the internet radio Press Source. Select tunein. Select your desired category. • following : Shows the list of stations added to the preset list or marked as you are following. By default, 3 radio stations are displayed in the preset list. • Browse : Lists all supported Internet radio stations. -
Page 28: Following A Station
following a station ❚ You can add a channel to the following list. Select the desired channel. to display a popup menu, and then select +following. Press Press Save. • The channel you are currently listening to is added to the following list. 4444... -
Page 29: Setting Presets
Setting presets ❚ You can add the internet radio channel you are following into the preset list, or rearrange the displaying order in the list. to display a popup menu, and then select +following in the menu. Press , and then press edit. Press Drag the desired channel from the following to the presets. -
Page 30: Using The Settings Menu
Using the Settings menu Press Add Speaker ❚ Add Speaker You can connect multiple products to the app. 4444... -
Page 31: Guide
Guide ❚ tutorial Select the tutorial to learn how to use the app. Services ❚ Displays a list of available services. noteS 9 Depending on your region or manufacturer, supported content services may differ. 9 You may not subscribe to a service using your smart device. To use a for-pay service, first subscribe to the service through your computer. -
Page 32: Device Settings
device Settings ❚ front led • off : Turns off the product's front led indicators. • on : Turns on the product's front led indicators. Sound feedback • off : Turns off the Sound feedback. • on : Turns on the Sound feedback. 4444... -
Page 33: Software Update
Software Update Shows the product's current software version, and lets you turn auto update on or off. • on : When on, automatically updates the software when new firmware is released. • off : Turns off the auto update function. noteS 9 Auto update is available when your product is connected to a network and the Software Auto Update function is set to On. - Page 34 Continuous play You can relay currently playing music to a selected product. hub : Wireless Band You can change the wireless band of your HUB depending on the wireless communication environments at home. 4444...
-
Page 35: Clock
Clock ❚ Alarm (WAM7500, WAM7501 only) Lets you set the Alarm. Sleep timer Lets you set the Sleep timer. 4444... -
Page 36: Support
Support ❚ device id Lets you check the Device ID. Contact Samsung Provides a link to the Samsung website. 4444... -
Page 37: Information
open Source licenses Lets you view the open Source licenses. information ❚ Samsung Multiroom Allows you to check the software version number of the speaker. 4444... - Page 38 App Version Allows you to check the Samsung Multiroom app version. 4444...
-
Page 39: Connecting Multiples Products
Connecting multiples products Selecting the product You can select the desired one from connected products and set the input source for playback. Press to go to the list of all products. Select the desired product. If no input source is assigned to the selected product, the music files stored in the smart device are listed up. -
Page 40: Setting Groups
Setting Groups You can group multiple speakers into one group that plays the same music. Grouping is available only when multiple speakers are connected to the same network. Press to go to the list of all speakers. Press Group. Select other products to add into the group, and then press done. noteS 9 Group playback is not available for Bluetooth and TV SoundConnect connections. -
Page 41: Setting The Surround Sound Mode
Setting the Surround Sound Mode You can configure multiple products for surround sound effect. Press to go to the list of all products. Press Surround. Press and hold a product, and drag it to the desired place and then select next. 4444... - Page 42 Test products and adjust product volume, and then press done. noteS 9 The Surround Mode may be cancelled automatically if the network connection is unstable. 9 When enabling the Surround Sound mode, we recommend that you set the same decibel levels for the speakers you assign to Front L and Front R.
-
Page 43: Using Miscellaneous Functions
Using miscellaneous functions Connecting with tV SoundConnect function This section explains how to connect the product to Bluetooth compatible SAMSUNG TVs. Connect Source Plug the product into an outlet, and then press the button on its top panel. Set Add new device to on in the TV's tV SoundConnect Settings menu. (Refer to the TV's user manual for details.) A message asking whether to proceed with Bluetooth pairing appears. -
Page 44: Playing Media Content Saved In A Pc
playing Media Content Saved in a pC Wireless Audio - Multiroom for desktop ❚ To play iTunes system and shared PC music files through product, install the Wireless Audio - Multiroom for desktop program. Visit www.samsung.com to download the Wireless Audio - Multiroom for desktop program and install it. - Page 45 Select the content type and add the selected folder to the shared folders list. After sharing folders, make sure to press the done button. On your Smart device, select the Samsung Multiroom app. Select desired PC on the Samsung Multiroom app, and shared folders and files stored in the PC will be displayed.
-
Page 46: Appendix
Appendix troubleshooting Before requesting service, please check the following. Symptom Check Remedy The unit will not turn on. • Is the power cord plugged into the • Connect the power cord to the outlet? outlet. Hub and product is not paired. •... - Page 47 Symptom Check Remedy HUB doesn't work properly • Is the HUB plugged in? • Plug in the HUB. • Is the LAN cable connected to • Connect the LAN cable to the ETHERNET SWITCH the wireless router and the HUB on the back properly? of the HUB and to your wireless...
-
Page 48: Open Source License Notice
Symptom Check Remedy I cannot group products. • Is the product connected to the • If the product is connected to network via Wi-Fi? the network via Bluetooth or TV SoundConnect, you cannot use the group products function. App doesn't work properly •... -
Page 49: Specifications
Specifications • WAM7500/WAM7501 Weight 7.5 Ibs Dimensions 7.1 (W) X 7.1 (D) X 16.6 (H) inches General Operating Temperature Range +41°F to +95°F Operating Humidity Range 10 % to 75 % Wireless LAN Built-in WEP (OPEN/SHARED) Network Security WPA-PSK (TKIP/AES) WPA2-PSK (TKIP/AES) • WAM6500/WAM6501... -
Page 50: Regulatory Compliance Statements
regulatory Compliance Statements CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF The lighting flash and arrowhead The explanation point within the within the triangle is a warning sign ELECTRIC SHOCK, DO NOT REMOVE triangle is a warning sign alerting alerting you to dangerous voltage THE COVER (OR BACK). -
Page 51: This Class B Digital Apparatus Complies With Canadian Ices-003
iMportAnt note: iC radiation exposure Statement: This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated so there is at least 8 inches (20cm) between the radiator and your body. this Class B digital apparatus complies with Canadian iCeS-003 ❚... -
Page 52: Safety Precautions
Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. Unplug this apparatus during lightning storms or when unused for long periods of time. -
Page 53: Usage Precautions
• When placing the product on a shelf, cabinet, or desk, make sure the top panel faces upwards. • Do not place the product on an unstable surface (e.g. a shaky shelf, a tilted desk, etc.). - Dropping the product can cause it to malfunction and poses a risk of injury. Severe vibration or impact can also cause the product to malfunction and lead to a fire hazard. -
Page 54: Cleaning Precautions
• If you smell gas, ventilate the room immediately. Do not touch the power plug of the product. Do not turn the product off or on. • Do not strike or subject the product to a sudden shock. Do not pierce the product with a sharp object. -
Page 55: Compatible Products
Compatible products ❚ • Mobile : Android 2.3.3 (Gingerbread) or above, iOS (6.0) or above noteS 9 Some devices may not be compatible with the product. 9 Note that older versions of compatible products may not be supported. Copyright © 2015 Samsung Electronics Co.,Ltd. All rights reserved;... - Page 56 LIMITED WARRANTY TO ORIGINAL PURCHASER Samsung Electronics Canada Inc.(SECA), warrants that this product is free from defective material and workmanship. SECA further warrants that if this product falls to operate properly within the specified warranty period and the failure is due to improper workmanship or defective materials, SECA will repair or replace the product at its option.
- Page 57 Contact SAMSUnG World Wide If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care certer. Country Contact Certer Web Site U.S.A 1-800-SAMSUNG (726-7864) www.samsung.com/us/support North America www.samsung.com/ca/support (English) CANADA 1-800-SAMSUNG (726-7864) www.samsung.com/ca_fr/support (French) MEXICO 01-800-SAMSUNG (726-7864) www.samsung.com/mx/support...
- Page 58 Country Contact Certer Web Site LUXEMBURG 261 03 710 www.samsung.com/support NETHERLANDS 0900-SAMSUNG (0900-7267864) (€ 0,10/Min) www.samsung.com/nl/support www.samsung.com/be/support (Dutch) BELGIUM 02-201-24-18 www.samsung.com/be_fr/support (French) NORWAY 815 56480 www.samsung.com/no/support DENMARK 70 70 19 70 www.samsung.com/dk/support FINLAND 030-6227 515 www.samsung.com/fi/support SWEDEN 0771 726 7864 (0771-SAMSUNG) www.samsung.com/se/support 801-172-678* lub +48 22 607-93-33 * POLAND...
- Page 59 Country Contact Certer Web Site SINGAPORE 1800-SAMSUNG(726-7864) www.samsung.com/sg/support AUSTRALIA 1300 362 603 www.samsung.com/au/support NEW ZEALAND 0800 726 786 www.samsung.com/nz/support VIETNAM 1800 588 889 www.samsung.com/vn/support 0-2689-3232, THAILAND www.samsung.com/th/support 1800-29-3232 MYANMAR +95-01-2399-888 www.samsung.com/support S.E.A 1800-88-9999 MALAYSIA www.samsung.com/my/support 603-77137477 (Overseas contact) 021-56997777 INDONESIA www.samsung.com/id/support 08001128888...
