- Page 1 XL-EFM-404 G.SHDSL.bis EFM Network Extender User’s Guide...
-
Page 2: Table Of Contents
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 TABLE OF CONTENTS INTRODUCTION ..........................3 ..........................3 ESCRIPTIONS ............................ 4 EATURES ..........................4 PECIFICATIONS ..........................6 PPLICATIONS GETTING TO KNOW ABOUT THE EFM MODEM .................. 7 ..........................7 RONT ANEL .......................... - Page 3 XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Security ............................35 SNMP............................... 38 ............................. 39 TILITY System Info ............................40 Config Tool ............................40 Upgrade ............................42 Logout ............................. 42 Restart ............................. 43 ...
-
Page 4: Introduction
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Introduction Descriptions The EFM Based Network Extender (or say EFM Modem) which provides a flexible and friendly solution for the Ethernet based services provision to subscribers by the service provider. Additionally, this family of products provides a simple way in a back-to-back deployment to provide point to point configuration. -
Page 5: Features
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Features Extending Ethernet Services to sites with existing copper infrastructure Increased Flexibility in Deployment Lower Investment and Quick Return on Investment EFM Bonding (PAF, PME Aggregation Function) up to 22.8Mbps (4 pairs) Support EFM OAM complying IEEE 802.3ah... - Page 6 XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 VLAN Support Port-bases & Tag-based(802.1Q) Up to 16 VLANs Priority Re-mapping VLAN Trunk mode QoS Support Ingress Rate control Egress Traffic shaping Classification based on Port/802.1p/DSCP 4 Priority Queues Strict Priority...
-
Page 7: Applications
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Products’ Information 1 pair 2BASE-TL EFM Network Extender 2 pair 2BASE-TL EFM Network Extender 4 pair 2BASE-TL EFM Network Extender Applications... -
Page 8: Getting To Know About The Efm Modem
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Getting to know about the EFM Modem This section will introduce hardware of the EFM modem. Front Panel The front panel contains LED which show status of the EFM Modem. LED status of EFM Modem... -
Page 9: Rear Panel
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Rear Panel The rear panel of G.SHDSL.bis EFM Modem is where all of the connections are made. Connector Description DC-IN Power adaptor inlet: Input voltage 9VDC CONSOLE RJ-45 for system configuration and maintenance... -
Page 10: Lan Ports And Mgmt Port
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 For pair (2-wire) model , Loop1 has been used For two pair (4-wire) model, Loop1 and 2 have been used For four pair (8-wire) model, Loop1, 2, 3 and 4 have been used LAN ports and MGMT port The EFM modem have four LAN ports and one MGMT Ethernet port. -
Page 11: Protective Earth (Frame Ground) Terminal
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 (2) Pressing the Reset Button for eight seconds will cause the product loading the factory default setting and losing all of yours configuration. When you want to change its configuration but forget the user name or password, or if the product is having... -
Page 12: Configuration Use Web Browser
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Configuration use Web Browser Configuration method There are three methods to configure the EFM modem: serial console, Telnet and Web Browser. Users have to choose one method to configure the EFM modem. -
Page 13: 3.2 Installation
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 3.2 Installation This following guide is designed to lead users through Web Configuration of G.shdsl.bis EFM Modem in the easiest and quickest way possible. Please follow the instructions carefully. Connect the power adapter to the port labeled DC 9V on the rear panel of the EFM modem. -
Page 14: 3.3 Setup Up On Web Browser
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 3.3 Setup up on Web Browser This section introduces the configuration and functions of the web configurator. The web configurator is an HTML-based management interface that allows easy EFM modem setup and management via Interface browser. -
Page 15: 3.4 Basic Setup
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Following is the first screen that displays when you access the web configurator. 3.4 Basic Setup The Basic Setup contains: Operation mode and MGMT port IP DHCP server User can use it to completely basic setup the EFM modem. -
Page 16: Dhcp Server
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Click CPE (Customer Premises Equipment) side or CO (Central Office) side to setup the operation mode. When connection with DSLAM, the SHDSL.bis EFM modem’s working mode is CPE. When “LAN to LAN” connection, one side must be CO and the other side must be CPE. - Page 17 XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Dynamic Host Configuration Protocol (DHCP) is a communication protocol that lets network administrators to manage centrally and automate the assignment of Internet Protocol (IP) addresses in an organization's network. Using the Internet Protocol, each machine that can connect to the Internet needs a unique IP address.
-
Page 18: Lan
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 For example: If the LAN IP address is 192.168.0.1, the IP range of LAN is 192.168.0.2 to 192.168.0.254. The DHCP server assigns the IP form Start IP Address to End IP Address. The legal IP address range is form 0 to 255, but 0 are reserved as network name and 255 are reserved for broadcast. -
Page 19: Review
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 IP Address: 192.168.2.1 Subnet Mask: 255.255.255.0 Gateway: 0.0.0.0 DNS Server 1: 168.95.1.1 DNS Server 2: 168.95.192.1 DNS Server 3: Review Press Next to set the next page : The screen will prompt the new configured parameters. Checking the parameters and Click Restart The EFM modem will reboot and working with new parameters or press or Continue to configure another parameters. -
Page 20: Advanced Setup
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Advanced Setup Note: The advanced functions are only for advanced users to setup advanced functions. The incorrect setting of advanced function will affect the performance or system error, even disconnection. Advanced setup contains SHDSL.bis EFM, VLAN and QoS parameters. - Page 21 XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Annex Type: There are four Annex types, Annex A (ANSI), Annex B (ETSI), Annex AF and Annex BG in SHDSL.bis . Check with your ISP about it. TCPAM Type: the default option is Auto. You may assign the different type manually by click the caption TPCAM-16 or TPCAM-32 .
-
Page 22: Vlan
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 4 wire model: Main Rate: When using Annex AF and BG TCPAM32 : main rate is 1536Kbps ~ 11392Kbps (Nx128kbps, N=12~89) TCPAM16 : main rate is 384Kbps ~ 7680Kbps (Nx128kbps, N=3~60) - Page 23 XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 VLAN (Virtual Local Area Network) allows a physical network to be partitioned into multiple logical networks. Devices on a logical network belong to one group. A device can belong to more than one group. With VLAN, a device cannot directly talk to or hear from devices that are not in the same group.
- Page 24 XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01...
-
Page 25: 802.1Q Tag-Based Vlan
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 802.1Q Tag-Based VLAN Click the 802.1Q Tag-Based VLAN to configure the EFM modem. VID: (Virtual LAN ID) It is an definite number of ID which number is from 1 to 4094. -
Page 26: Port-Based Vlan
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 The unit supports up to 8 active VLANs with shared VLAN learning (SVL) bridge out of 4096 possible VLAN specified in IEEE 802.1Q. Each port always belongs to a default VLAN with its port VID (PVID) as an untagged member. - Page 27 XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Port-Based VLANs are VLANs where the packet forwarding decision is based on the destination MAC address and its associated port. When using the port-based VLAN, the port is assigned to a specific VLAN independent of the user or system attached to the port.
-
Page 28: Qos
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 If you click the LAN1 to LAN4 only with DSL and Sniffing, there are port isolation means that each LANs port can only communicate with management port and cannot communicate with each other. -
Page 29: Port Based Priority
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Port Based Priority When you click Port Based Priority, it will show the following: Scheduling Configuration item can setup the queue type from type 1 to type 3. Each queue type can setup the queue weight form 1 to 15. -
Page 30: Vlan Tag Priority
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 VLAN Tag Priority When you click VLAN Tag Priority, it will show the following: Scheduling Configuration item can setup the queue from 0 to 3. Each queue can select three type: from type 1 to type 3. Queue Weight item can setup the queue with weight form 1 to 15. - Page 31 XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 When you click IP DSCP(Differentiated Services Code Point) Priority, it will show the following: Each IP DSCP value (from 0 to 63) is mapped to a Queue value (from 0 to 3). The number 0 represents the lowest priority and 3 represents the highest priority.
-
Page 32: Status
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 To let the configuration that you have changed take effect, click Restart to reboot system. If you want to continue the setup procedure, click Continue is O.K. Status When you click STATUS You can monitor the following : SHDSL.bis EFM, MGMT, LAN and... -
Page 33: Shdsl .Bis Efm
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 SHDSL .Bis EFM SHDSL.bis status including run-time device status : mode and Bitrate and Performance information: SNR margin, attenuation and CRC error count. 4-pairs model will be showed as following, you can know about their four channel run- time status. -
Page 34: Mgmt
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Below display screen is come from one pair model: If two EFM modem have been linking togetor, you can know about their run-time line rate status and performance information from this screen. -
Page 35: Lan
XtendLan XL-EFM404 XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 LAN status will prompt the MAC address, IP address, Subnet mask and DHCP client table. Interface INTERFACE status inculdes MGMT and LAN statistics information. -
Page 36: Administration
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Administration This session introduces Administration including SECURITY and SNMP (simple network management protocol). Security For system secutiry, suggest to change the default user name and password in the first setup otherwise unauthorized persons can access the EFM modem and change the parameters. - Page 37 XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 For better security, change the Supervisor ID and Supervisor password for the EFM modem. If you don’t set them, all users can be able to access the EFM modem using the default IP and Password is root.
- Page 38 XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Legal address pool will setup the legal IP addresses from which authorized person can configure the EFM modem. This is the more secure function for network administrator to setup the legal address of configuration.
-
Page 39: Snmp
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Press Restart to restart the EFM modem working with the new parameters and press Continue to setup other parameters. SNMP Simple Network Management Protocol (SNMP) provides for the exchange of messages between a network management client and a network management agent for remote management of network nodes. -
Page 40: Utility
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 In the table of current community pool, you can setup the access authority. Status: Set Enable for modify this item. Access Right: Deny for deny all access Read for access read only Write for access read and write. -
Page 41: System Info
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 The UTILITY menu including: SYSTEM INFO: system information, CONFIG TOOL: load the factory default configuration, UPGRADE: upgrade the firmware LOGOUT: logout the system RESTART: restart the EFM modem. System Info For review the information, click SYSTEM INFO to display the screen as shown below. - Page 42 XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Choose the function and then press Finish. Load Factory Default: It will load the factory default parameters to the EFM modem. Note: This action will change all of the settings to factory default. On the other hand, you will lose all the existing configured parameters.
-
Page 43: Upgrade
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Upgrade You can upgrade the firmware of EFM modem using the upgrade function. Press Upgrade in UTILITY menu. Type the path and file name of the firmware file you wish to upload to the EFM modem in text box or click Browse to locate it. -
Page 44: Restart
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Restart For restarting the EFM modem, press Restart to reboot the EFM modem. When you press Restart, display screen is as following:... - Page 45 XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 It show the configuration is success. When the system have rebooted later, you can re-open the browser.
-
Page 46: Configuration Use Serial Console And Telnet With Menu Driven Interface
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Configuration use Serial Console and Telnet with Menu Driven Interface Introduction Serial Console Check the connectivity of the supplied serial cable from your computer to the serial port of this EFM Modem. Start your terminal access program by terminal emulation program or... -
Page 47: Operation Interface
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Operation Interface For serial console and Telnet management, the EFM Modem implements the menu driven interface. It can show you all of available commands for you to select. You don’t need to remember the command syntax and save your time on typing the whole command line. -
Page 48: Menu Driven Interface Commands
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Menu Driven Interface Commands Before changing the configuration, familiarize yourself with the operations list in the following table. The operation list will be shown on the window. Menu Driven Interface Commands... - Page 49 XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 If you are the authorized user, the menu tree is the following:...
- Page 50 XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 If you are the unauthorized user, the menu tree is the following: If you are the authorized user, you can view the display screen as the following: If you are the unauthorized user, you can view the display screen as the following, only have...
-
Page 51: Enable
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Enable To setup the EFM modem, move the cursor “ >>” to enable and press enter key. While the screen appears, type the supervisor password. The default supervisor password is “root”. -
Page 52: Setup
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 ping Internet Ping command. admin You can setup management features in this command. utility Upgrade software and backup and restore configuration are working via “utility” command. exit Quit system Setup All of the setup parameters are located in the subdirectories of setup. Move the cursor “ >>... -
Page 53: Lan
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Main Rate: When using Annex AF and BG TCPAM32 : 768Kbps ~ 5696Kbps (Nx64kbps, N=12~89) TCPAM16 : 192Kbps ~ 3840Kbps (Nx64kbps, N=3~60) When using Annex A and B TCPAM16 : 192Kbps ~ 2304Kbps (Nx 64kbps, N=3~36) -
Page 54: Vlan
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Interface number <1~1>: 1 ----------------------------------------------------------------------------- The default interface number is 1, no matter what it the model. LAN interface parameters can be configured LAN IP address, subnet mask and NAT network type. -
Page 55: Mgmt
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 To active the VLAN function, move the cursor “ >> “ to mode and press enter. The products support two types of VLAN, 802.1Q and Port-Based. The 802.1Q defines the operation of VLAN bridges that permit the definition, operation, and administration of VLAN topologies within a bridged LAN infrastructure. -
Page 56: Dhcp
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 ---------------------------------------------------------------------- Command: setup mgmt 1 address <ip> <netmask> Message: Please input the following information. IP address (ENTER for default) <192.168.1.1>: Subnet mask (ENTER for default) <255.255.255.0>: ---------------------------------------------------------------------- DHCP Dynamic Host Configuration Protocol (DHCP) is a communication protocol that lets network administrators to manage centrally and automate the assignment of Internet Protocol (IP) addresses in an organization's network. -
Page 57: Dns Proxy
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 The dynamic IP maximum lease time is configured by lease_time command. You can setup 3 domain name servers via name_server commands. Fixed Host IP Address list is setup via fixed command. -
Page 58: Host Name
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Host name Enter local host name via hostname command. Move cursor “ >> “ to hostname and press enter. ---------------------------------------------------------------------- Command: setup hostname <name> Message: Please input the following information. Local hostname (ENTER for default) <SOHO>: test... -
Page 59: Show
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Move cursor “ >> “ to interface and press enter. Show You can view the system information, configuration, and configuration in command script by show command. Move cursor “ >> “ to show and press enter. -
Page 60: Write
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Command Description system The general information of the system will show in system command. config Config command can display detail configuration information. script Configuration information will prompt in command script. Move cursor “ >> “ to system and press enter. -
Page 61: Ping
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Ping Ping command will be used to test the connection of EFM modem. Please move cursor to ping and press enter. ---------------------------------------------------------------------- Command: ping <ip> [1~65534|-t] [1~1999] Message: Please input the following information. -
Page 62: Security
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 ---------------------------------------------------------------------- Command: admin user modify <1~5> <more...> Message: Please input the following information. Legal access user profile number <1~5> : 2 ---------------------------------------------------------------------- The screen will prompt as follow. >> Attrib UI mode... -
Page 63: Supervisor Password And Id
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 The screen will prompt as follow: >> edit Edit community entry list Show community configuration There have 5 entries of SNMP trap are allowed to be configured in this system. Move the cursor to trap and press enter. -
Page 64: Exit
XtendLan XL-EFM404 G.SHDSL .bis EFM Modem User Manual V0.01 Move the cursor “ >> “ to utility and press enter. >> upgrade Upgrade main software backup Backup system configuration Restore Restore system configuration 4.12 EXIT If you want to exit the system without saving, use exit command to quit system.
