Care, Cleaning, and Storage

1. Unplug unit and allow to cool completely before cleaning. never immerse waffle maker in
water or other liquid or wash in a dishwasher.
2. Brush any loose crumbs from the waffle grids. Then wipe the grids with a paper towel or
cloth.
3. Should any batter become baked onto the grids or the outside of the unit, pour a small amount
of cooking oil onto the batter. Allow it to sit for a few minutes to soften and wipe off with a
paper towel or cloth.
4. Wipe the outside of the waffle maker with a damp cloth. Do not use steel wool scouring pads
or abrasive kitchen cleaners on the unit.
5. For compact vertical storage, rotate waffle maker to upright position (Fig. G). While holding
the handles together, lock in position by flipping up
one of the red locking levers from the grooves in the
hinged base (Fig. h and Fig. I).
Before next use, remember to unlock from storage
position (Fig. I) by dropping the red locking levers
back in towards base (Fig. h).

Replacing the Timer Battery

The battery used in the waffle maker is a CR2032 3V lithium battery which will seldom need
to be replaced. If you ever need to replace the battery, follow the instructions below.
1. on the left and right side of the timer is an undercut. Use your fingernail or insert a thin
object (such as a butter knife) in the undercut on the left side of the timer (Fig. J) and lift
that side of the timer away from the waffle maker. hold that side of the timer with your
finger, to prevent it from slipping back in the waffle maker, and insert your fingernail (or
the knife) in the undercut on the right side of the timer and lift that side away from the
waffle maker. now pull the timer out completely from the opening in the waffle maker
(Fig. M).
2. Turn the timer over so the back side is facing up. Using your thumb, remove the battery
compartment cover by sliding it in the direction the arrow is pointing (Fig. K).
3. Using a small paring knife, or some other narrow object, carefully press near the top of the
interlock spring towards the wall of the timer to release the battery from under the hooks
(Fig. L). Use the tip of the knife to remove the battery and discard.
4. Position new CR2032 3V lithium battery, with writing facing up, in compartment fitting it
underneath the plastic edge (Fig. L). Push battery down on the side by the interlock spring
until the battery snaps into position under the hooks.
5. Replace battery cover. holding the cover with your thumb on the arrow, fit the sides of the
cover in the grooves on the timer and slide the door towards the interlock spring. Turn the
timer over and press the button to make sure it is operating.
6. Place the timer back in the waffle maker by aligning the rib on the timer with the notch
in the opening on the side of the waffle maker (Fig. M). Push the timer in so it is securely
positioned.
Fig. H
Red locking lever
in UnLoCKED
position
5
Fig. G
Red
locking
lever
Groove in
hinged base
Fig. I
Red locking lever in
LoCKED position
Fig. J
Undercut
Fig. K
Battery
compartment
cover
Fig. L
Interlock spring
Hooks
Plastic edge
Fig. M
Notch
Red
locking
lever
Timer
Rib
