Philips HDD1620 Service Manual
Micro audio jukebox
Hide thumbs
Also See for HDD1620:
- Manuel d'utilisation (54 pages) ,
- User manual (54 pages) ,
- Quick start manual (12 pages)
Advertisement
Quick Links
Micro Audio Jukebox
Service Manual
TABLE OF CONTENTS
Technical Specification and Service hints......................1
Safety Instructions......................................................2
Instructions for Use.................................................... 3
Mechanical Instructions.............................................. 4
Exploded view and Service parts list............................. 5
Troubleshooting flow.................................................. 6
Overall Block diagram................................................. 7
Overall Electrical diagram........................................... 8
IRIS CODE..................................................................9
Revision list............................................................... 10
©Copyright 2005 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may by reproduced, stored in a
retrieval system or transmitted, in any form or by any means, electronics,
mechanical, photocopying, or otherwise without the prior permission of Philips
Version 1.5
HDD1420/1620/1630/1635/1830/1835
All version
Chapter
3141 785 30705
Advertisement
Related Manuals for Philips HDD1620
Summary of Contents for Philips HDD1620
-
Page 1: Table Of Contents
All rights reserved. No part of this publication may by reproduced, stored in a retrieval system or transmitted, in any form or by any means, electronics, mechanical, photocopying, or otherwise without the prior permission of Philips 3141 785 30705 Version 1.5... -
Page 2: Technical Specification And Service Hints
3.6 – 3.7V to the power supply with the AC/DC adapter. 3-step to 2-step voltage 3.53 – 3.6V Make sure all other applications such as Philips Device 2-step to 1-step voltage 3.48 – 3.53V plug-in, Windows Media Player or Windows Explorer Force Power Off voltage <3.5V... - Page 3 Once the installation is complete, connect the GoGear to the power supply with the AC/DC adapter. Make sure all other applications such as Philips Device plug-in, Windows Media Player or Windows Explorer that accessing the device are closed or else Device Manager will not recognize the device.
-
Page 4: Service Hints
Volume + and the power on/off slider switch until the display turns off. While the device restart, press and hold the volume – key until the Philips splash screen disappear and showing the connection icon to put the device in USB Mass Storage Device mode. - Page 5 1.0 TECHNICAL SPECIFICATION and SERVICE HINTS IMPORTANT: All music & content of your micro jukebox will be erased once the device is formatted. Unzip and copy all the content of the shipment ui files of the corresponding model version into the root directory of the device.
- Page 6 2.0 SAFTETY INSTRUCTIONS WAARSCHUWING WARNING Alle IC’s en vele andere halfgeleiders zijn All ICs and many other semi-conductors are gevoelig voor electrostatische ontladingen susceptible to electrostatic discharges (ESD). (ESD). Careless handling during repair can reduce life Onzorgvuldig behandelen tijdens reparatie kan drastically.
-
Page 7: Safety Instructions
2.0 SAFETY INSTRUCTIONS Battery Handling Guideline Since the battery is packed in soft package, to ensure its better performance, it’s very important to carefully handle the battery 2.1 Soft Aluminium foil The soft aluminum packing foil is very easily damaged by sharp edge parts such as Ni-tabs, pins and needles. •... -
Page 8: Instructions For Use
3.0 INSTRUCTION FOR USE Power Connector... - Page 9 4.0 MECHANICAL INTRUCTIONS Set Disassembly 1. Add a tape over the knobs on two side before opening the set to prevent the knobs will fall out the set after open. 2. Remove the cosmetic screw on the back cover by Allen Key.
- Page 10 4.0 MECHANICAL INTRUCTIONS 5. Remove the 4 screws on four corners. See pointed arrows. 6. Carefully pull out the mainboard assy, which include the HDD drive, LCD, battery and PCBA board. 7. Disconnect the flex cable from the front touch screen module carefully, then free the top cover assy.
- Page 11 4.0 MECHANICAL INTRUCTIONS 9. Turn to the bottom side. 10. Open up the metal shielding and disconnect the cable connected to the battery. Carefully disassemble the mini mic as circled in the picture from the plastic audio jack holder. 11. Remove the battery part form PCBA. 12.
- Page 12 4.0 MECHANICAL INTRUCTIONS 13. After remove both battery and hard disk.
-
Page 13: Exploded View And Service Parts List
SHIELDING PHOENIX 994000003572 CRADLE HOLDER PHOENIX 994000003558 SCREW 1.7X5 PHOENIX 994000003557 BATTERY PACK PHOENIX 282206200084 HDD 4GB (HDD1420/00) 282206200079 HDD 6GB (HDD1620/00/05, HDD1630/17 & HDD1635/17) 994000003563 HDD DAMPER PHOENIX 994000003564 HDD HOLDER PHOENIX 994000003568 HD FPC PHOENIX 994000003565 FFC PHOENIX... - Page 14 SHIELDING PHOENIX 994000003572 CRADLE HOLDER PHOENIX 994000003558 SCREW 1.7X5 PHOENIX 994000003557 BATTERY PACK PHOENIX 282206200084 HDD 4GB (HDD1420/00) 282206200079 HDD 6GB (HDD1620/00/05, HDD1630/17 & HDD1635/17) 994000003563 HDD DAMPER PHOENIX 994000003564 HDD HOLDER PHOENIX 994000003568 HD FPC PHOENIX 994000003565 FFC PHOENIX...
-
Page 15: Troubleshooting Flow
6.0 TROUBLESHOOTING FLOW SYMPTOM 1: NO POWER... - Page 16 6.0 TROUBLESHOOTING FLOW SYMPTOM 2: JUKEBOX FREEZES / HANGS UP Open up the unit, unplug battery connector and reconnect again...
- Page 17 6.0 TROUBLESHOOTING FLOW SYMPTOM 3: ERROR MESSAGE SCROLLS ON THE DISPLAY...
- Page 18 6.0 TROUBLESHOOTING FLOW SYMPTOM 4: NO SOUND...
- Page 19 7.0 BLOCK DIAGRAM...
- Page 20 +1.2V R583 R583 +1.2V 100K 100K +3.3V +1.2V_AVDD R541 R541 0402 0402 +1.2V Place Close Each Power Pin +1.2V_USB_VDDP 0402 0402 I2S_SDIN 0402 0402 C562 C562 R568 R568 C566 C566 0.1U 0.1U C558 C558 C559 C559 100K 100K 0805 0805 0402 0402 0.1U...
- Page 21 Only For PP5022 Ver.B CKE reset issue Can be eliminate XM2_MD[0..15] VCC_MEM U512 U512 XM2_MA[1..15] RESET# XM2_CKE R578 R578 C567 C567 100K 100K SN74AUC1G126 SN74AUC1G126 0.1U 0.1U 0402 0402 SC70_5 SC70_5 Power Supply Voltage:1.65V~1.95V RAM TYPE/WIDTH (UPPER 2 BITS ARE FIRMWARE SELECT) VCC_MEM 0402 0402...
- Page 22 dI=Vo*(1-Vo/Vi)/(L*f) Imax=Iomax+(dI/2) 4/14 HD Power IC change from XC6366 to TPS62040 奇力新 SCDS3D16T-3R3T-B +3.3VP +3.3V 沛波 SPC-04702-6R8-GP (4.7*4.7*2) REGS_PWR IN_+3.3VP +3.3V_HDD1P +3.3V_HDD REGS_PWR IN_+3.3V_HDD1P 6.8UH 6.8UH SHORT-SMT3 SHORT-SMT3 SHORT-SMT3 SHORT-SMT3 3.3UH 3.3UH SPC-04702 SPC-04702 SHORT-SMT3 SHORT-SMT3 JO503 JO503 100K 100K 0402 0402 VIN_0...
- Page 23 +1.8V 120Z/100M/NA 120Z/100M/NA 0402 0402 No AGND=>Check +3.3V 0402 0402 L517 L517 120Z/100M 120Z/100M U507 U507 120Z/100M 120Z/100M L515 L515 120Z/100M 120Z/100M +3.3V AUDIO_LDO_IN AUDIO_LDO_OUT C554 C554 HPVDD DBVDD C546 C546 VOUT 0402 0402 C544 C544 C541 C541 0402 0402 R540 R540 0.1U...
- Page 24 Cradle POWER SWITCH +3.3V 0402 0402 Ext_ANT Ext_ANT OC_CRL_PWR# 0.1U 0.1U 0402 0402 0402 0402 +80-20% +80-20% U513 U513 SPARKGAP_6 SPARKGAP_6 +3.3V OC#_R Power_Out_C FLAG R589 R589 AT3_HD[0:15] Cradle_Power_Out_R Cradle_Power_Out 1" HDD FPC Connector C552 C552 FPF2006 FPF2006 0/NA 0/NA 0.1U 0.1U SC70_5...
- Page 25 GND 0402 0402 0402 0402 0402 0402 R597 R597 R596 R596 9360-304-XXXX 9360-304-XXXX BKLT_PWM_RC S/W request to Control enable LCD output PHILIPS PHILIPS BKLT_PWM FPC/FFC-1MM-2P/NA FPC/FFC-1MM-2P/NA LED1 LED2 Using on PA020 6.81K 6.81K 63.4K 63.4K 0402 0402 0.1U 0.1U...
-
Page 26: Revision List
9.0 REVISION LIST Version 1.0 (3141 785 30700) • Initial release HDD1420/HDD1620/HDD1630/DD1635 Version 1.1 (3141 785 30701) Chapter 5 – Service part list revised service 12NC as listed below • Added the new part cradle assy for HDD1635/17 (994000003791) Version 1.2 (3141 785 30702) Chapter 5 –...
