ECL-NVR64 User's Manual
Our units do not support PAL
V 5.0.0

Advertisement

Table of Contents
loading

Summary of Contents for Eclipse Security ECL-NVR64

  • Page 1 ECL-NVR64 User’s Manual Our units do not support PAL V 5.0.0...

  • Page 2: Table Of Contents

    Table of Contents Features and Specifications .......................1 Overview ............................1 Features ............................1 Specifications ..........................2 ECL-NVR64 Series ....................2 1.3.1 Front Panel and Rear Panel .......................9 Front Panel ............................9 ECL-NVR64 Series ....................9 2.1.1 Rear Panel ..........................15 ECL-NVR64 Series ....................15 2.2.1 Alarm Connection ........................18 2.3.1...
  • Page 3 USB Manager........................29 3.3.13 System Status ........................30 3.3.14 Remote Device ...........................31 Remote Device Connection ....................31 3.4.1 Short-Cut Menu ........................32 3.4.2 3.4.3 Image ............................32 Channel Name ........................34 3.4.4 Upgrade ..........................35 3.4.5 Preview ............................36 Preview ..........................36 3.5.1 Preview control interface ....................37 3.5.2 Right Click Menu .........................38 3.5.3 3.5.4 Preview Display Effect Setup ....................39...
  • Page 4 Picture Playback ........................69 3.8.6 Backup ............................70 3.9.1 File Backup ...........................70 Import/Export ........................71 3.9.2 Backup Log...........................72 3.9.3 3.9.4 USB Device Auto Pop-up ....................73 3.10 Alarm ............................73 Detect Alarm.........................74 3.10.1 3.10.1.1 Motion Detect ......................74 3.10.1.2 Video Loss ........................77 3.10.1.3 Tampering ........................77 3.10.1.4 Video diagnosis ......................78 3.10.2 Face Detect ..........................79...
  • Page 5 3.14 Device Maintenance and Manager ..................116 System Info......................... 116 3.14.1 3.14.1.1 Version ........................116 3.14.1.2 BPS ..........................117 3.14.1.3 Online User ....................... 118 3.14.1.4 Remote Device Information ..................118 3.14.1.5 Remote........................119 3.14.1.5.1 Device Status......................119 3.14.1.5.2 Firmware ......................... 119 3.14.2 Log ............................120 Account ..........................121...
  • Page 6 4.8.2.4 DDNS .........................148 4.8.2.5 IP filter ........................150 4.8.2.6 Email...........................150 4.8.2.7 FTP ..........................152 4.8.2.8 UPnP ..........................152 4.8.2.9 SNMP .........................153 4.8.2.10 Multicast ........................154 4.8.2.11 Register ........................154 4.8.2.12 Alarm Centre ......................155 4.8.2.13 HTTPS ........................156 4.8.2.13.1 Create Server Certificate ..................156 4.8.2.13.2 Download root certificate ..................157 4.8.2.13.3 View and set HTTPS port ..................159 4.8.2.13.4 Login ........................160 Event ...........................160...
  • Page 7 4.8.5.1.2 Date and time ......................184 4.8.5.1.3 Holiday Setup......................185 4.8.5.2 Display ........................186 4.8.5.2.1 Display ........................186 4.8.5.2.2 Tour ...........................187 4.8.5.3 RS232 ........................187 4.8.5.4 PTZ ..........................188 4.8.5.5 Account ........................189 4.8.5.5.1 User name .........................189 4.8.5.5.2 Group ........................191 4.8.5.6 Auto maintain ......................192 4.8.5.7 Import/Export......................193 4.8.5.8 Default ........................193 4.8.5.9 Upgrade ........................194...
  • Page 8 Welcome Thank you for purchasing our network video recorder! This user’s manual is designed to be a reference tool for your system. Please open the accessory bag to check the items one by one in accordance with the list below. Contact your local retailer ASAP if something is missing or damaged in the bag.

  • Page 9: Installation Environment

    Important Safeguards and Warnings 1．Electrical safety All installation and operation here should conform to your local electrical safety codes. The product must be grounded to reduce the risk of electric shock. We assume no liability or responsibility for all the fires or electric shock caused by improper handling or installation.
  • Page 10  Keep away from extreme hot places and sources；  Avoid direct sunlight；  Keep away from extreme humid places；  Avoid violent vibration；  Do not put other devices on the top of the NVR；  Be installed in well ventilated place; do not block the vent. ...

  • Page 11: Features And Specifications

    1 Features and Specifications 1.1 Overview This series NVR is a high performance network video recorder. This series product support local preview, multiple-window display, recorded file local storage, remote control and mouse shortcut menu operation, and remote management and control function. This series product supports centre storage, front-end storage and client-end storage.

  • Page 12: Specifications

    IR control function (For some series product only.). Shortcut menu operation via remote control.  Support IPC or NVS remote video preview and control. 1.3 Specifications 1.3.1 ECL-NVR64 ECL-NVR64 Series Main Processor Industrial X86 multiple-core processor Operation System Embedded LINUX system...
  • Page 13 Network Protocol RTP/RTCP, RTSP, UDP, HTTP, NTP, SNMP Audio/Video 192M connection Connection Audio/Video 192M transmission Transmission Audio/Video Based on 64-bit high-performance file system. Storage Video Resolution 1080P, 720P, D1, HD1, CIF, QCIF Audio/Video Audio/Video Based on data library and menu tree. Support various search Search engines.
  • Page 14 Figure 2-2 Please refer to the following sheet for detailed information. Name Function Power button Press it once to turn on the device. Press it for a long time to turn off the device (Usually we do not recommend). Press power button for a long time or pull out the power cable may result in device auto restart.

  • Page 15: Ecl-Nvr64 Series

    Figure 2-3 2.1.2 ECL-NVR64 Series The front panel is shown as in Figure 2-4. Figure 2-4 Please refer to the following sheet for detailed information. Name Icon Function Power button, press this button for three seconds to boot up or Power button shut down NVR.

  • Page 16: Front Panel

    Icon Name Function Front panel lock USB port Network The network indicator light is blue and it flashes when indicator light you connect the device to the network. Alarm indicator The alarm indicator light becomes on once an alarm light occurred.

  • Page 17: Rear Panel

    2.2 Rear Panel ECL-NVR64 Series 2.2.1 The general series rear panel is shown as in Figure 2-7. Function Function Power socket Ethernet port Alarm input, alarm HDMI port output, RS485 port. RS232 port USB 2.0 port Audio output USB 3.0 port...

  • Page 18: Alarm Connection

    3. Please make sure the front-end device has soundly earthed. Improper grounding may result in chip damage. 2.3.1 Alarm input and output details 2.3.1.1 ECL-NVR64 Series You can refer to the following sheet for alarm input and output information. See Figure 2-13.
  • Page 19 1，2，3，4，5，6， ALARM 1 to ALARM 16. The alarm becomes active in low voltage. 7，8，9，10，11， 12，13，14，15，16 1-ON C，2-ON C， Eight groups of normal open activation output (on/off button) 3-ON C，4-ON C， 5-ON C，6-ON C， 7-ON C，8-ON C GND cable. The A/B cable to control the RS485 devices. It is to connect to control decoder such as the recorder.

  • Page 20: Alarm Input And Output Port

    Figure 2-15 Icon Note 1～4 ALARM 1 to ALARM 4. The alarm becomes active in low voltage. NO1 C1， NO2 C2， NO3 C3， NO4 Four groups of normal open activation output (on/off button) 2.3.2 Alarm input and output port Please refer to the following sheet for more information. ...

  • Page 21: Alarm Relay Specifications

    2.3.4 Alarm relay specifications JRC-27F Model: Material of the Silver touch Rating Rated switch capacity 30VDC 2A, 125VAC 1A （Resistance Maximum switch power 125VA 160W Load） Maximum switch voltage 250VAC, 220VDC Maximum switch currency Insulation Between touches with same 1000VAC 1minute polarity Between touches with different 1000VAC 1minute...
  • Page 22 In input box, you can select input methods. Left click the corresponding button on the panel you can input numeral/English character (small/capitalized). Here ← stands for backspace button. ＿ stands for space button. In English input mode: _stands for input a backspace icon and ← stands for deleting the previous character.

  • Page 23: Local Basic Operation

    3 Local Basic Operation 3.1 Boot up and Shutdown 3.1.1 Boot up Before the boot up, please make sure:  The rated input voltage matches the device power on-off button. Please make sure the power wire connection is OK. Then click the power on-off button. ...
  • Page 24 Figure 3-1 Click Cancel button or Next Step button, system goes to login interface. See Figure 3-2. System consists of four accounts:  Username: admin. Password: admin. (administrator, local and network)  Username: 888888. Password: 888888. (administrator, local only)  Username: 666666.
  • Page 25 Figure 3-3 Click Next button, you can go to network interface. See Figure 3-4. For detailed information, please refer to chapter 3.11. Figure 3-4 Click Next button, you can go to remote device interface. See Figure 3-5. For detailed information, please refer to chapter 3.4.
  • Page 26 Figure 3-5 Click Next button, you can go to RAID interface. See Figure 3-6. For detailed information, please refer to chapter 3.12.4. Figure 3-6 Click Next button, you can go to Schedule interface. See Figure 3-7.

  • Page 27: Navigation Bar

    For detailed information, please refer to chapter 3.7.2. Figure 3-7 Click Finish button, system pops up a dialogue box. Click the OK button, the startup wizard is complete. See Figure 3-8. Figure 3-8 3.3 Navigation Bar You need to go to the Main menu->Setting->System->General to enable navigation bar function; otherwise you can not see the following interface.

  • Page 28: Main Menu

    3.3.1 Main Menu Click button to go to the main menu interface. 3.3.2 Dual-screen operation Important This function is for some series only. Click to select screen 2, you can view an interface shown as below. See Figure 3-10. It is a navigation bar for screen 2.

  • Page 29: Channel Info

    Click button , system goes to alarm status interface. It is to view device status and channel status. Please refer to chapter 3.14.1.4. 3.3.9 Channel Info Click button , system goes to the channel information setup interface. It is to view information of the corresponding channel.

  • Page 30: System Status

    ， system goes to the USB Manager interface. See Figure 3-13. It is to view USB information, Click backup and update. Please refer to chapter 3.9.1 file backup, chapter 3.9.3 backup log, chapter3.9.2 import/export, and chapter 3.14.4 upgrade for detailed information. Figure 3-13 3.3.14 System Status Click...

  • Page 31: Remote Device

    3.4 Remote Device 3.4.1 Remote Device Connection From Mani menu->Setting->Remote->Remote or right click mouse on the preview interface and then select remote device item, you can see the following interface. See Figure 3-15. Figure 3-15 Click Device search button, you can view the searched IP addresses at the top pane of the interface. Double click an IP address or check one IP address and then click Add button, you can add current device to the bottom pane of the interface.

  • Page 32: Short-Cut Menu

    Figure 3-16 3.4.2 Short-Cut Menu In the preview interface, for the channel of no IPC connection, you can click the icon “+” in the centre of the interface to quickly go to the Remote Device interface. See Figure 3-17. Figure 3-17 3.4.3 Image From main menu->Setting->Camera->Image, you can see the image interface is shown as below.
  • Page 33  Saturation: It is to adjust monitor window saturation. The value ranges from 0 to 100. The default value is 50. The larger the number, the strong the color is. This value has no effect on the general brightness of the whole video. The video color may become too strong if the value is too high. For the grey part of the video, the distortion may occur if the white balance is not accurate.

  • Page 34: Channel Name

     Auto: Device auto select to output the color or the B/W video according to the devic e feature (The general bright of the video or there is IR light or not.)  B/W: The device outputs the black and white video. ...

  • Page 35: Upgrade

    Figure 3-19 3.4.5 Upgrade Important System max supports to upgrade 8 network cameras at the same time. It is to update the network camera. From main menu->Setting->Camera->Remote->Upgrade, the interface is shown as below. See Figure 3-20. Click Browse button and then select the upgrade file. Then select a channel (or you can select device type filter to select several devices at the same time.) Click Begin button to upgrade.

  • Page 36: Preview

    Figure 3-20 3.5 Preview After device booted up, the system is in multiple-channel display mode. See Figure 3-21.Please note the displayed window amount may vary. The following figure is for reference only. Please refer to chapter 1.3 Specifications for the window-amount your product supported. Figure 3-21 3.5.1 Preview If you want to change system date and time, you can refer to general settings ( Main...

  • Page 37: Preview Control Interface

    Menu->Setting->System->General). If you want to modify the channel name, please refer to the display settings (Main Menu->Camera->CAM name) Please refer to the following sheet for detailed information. Current channel pops up Current channel pops up this icon this icon when it is when video loss alarm occurs.

  • Page 38: Right Click Menu

    Figure 3-23  Put the middle button at the centre of the zone you want to zoom in, and move the mouse, you can view an interface shown as in Figure 3-24. Figure 3-24 Right click mouse to cancel zoom and go back to the original interface. Manual record function It is to backup the video of current channel to the USB device.

  • Page 39: Preview Display Effect Setup

    After you logged in the device, right click mouse, you can see the short cut menu. Please see Figure 3-25.  Window split mode: You can select window amount and then select channels.  PTZ: Click it to go to PTZ interface. ...

  • Page 40: Preview Tour Parameters

    Figure 3-26 Now you can set corresponding information.  Time display: You can select to display time or not when system is playback.  Channel display: You can select to channel name or not when system is playback.  Image enhance: Check the box; you can optimize the margin of the preview video. ...

  • Page 41: Ptz

    steps listed below. From Main menu->Setting->System->Display->Tour, you can see an interface shown as in Figure 3-27. Here you can set tour parameter.  Screen No.: Please select screen from the dropdown list.  Video detect: It is to set video detect tour. System supports 1/8-window tour. ...
  • Page 42 In the main menu, from Setting->System->PTZ, you can see an interface is shown as in Figure 3-28. Here you can set the following items:  Channel: Select the current camera channel.  PTZ type: There are two types: local/remote. Please select local mode if you are connect RS485 cable to connect to the Speed dome (PTZ).

  • Page 43: Ptz Control

    Figure 3-29 3.6.2 PTZ Control After completing all the setting please click save button. Right click mouse (click “Fn” Button in the front panel or click “Fn” key in the remote control). The interface is shown as in Figure 3-30. Please note you can only go to the PTZ control interface when you are in 1-window display mode.
  • Page 44 and wiper, rotation and etc. Speed is to control PTZ movement speed. The value ranges from 1 to 8.The speed 8 is faster than speed 1. You can use the remote control to click the small keyboard to set. You can click of the zoom, focus and iris to zoom in/out, definition and brightness.

  • Page 45: Ptz Function Setup

    Figure 3-33 Please refer to the following sheet for detailed information. Please note the above interface may vary due to different protocols. The button is grey and can not be selected once the current function is null. Right click mouse or click the ESC button at the front panel to go back to the Figure 3-31. Icon Function Icon...
  • Page 46 Figure 3-35 Tour Setup In Figure 3-34, click tour button. Input tour value and preset No. Click Add preset button to add current preset to the tour. See Figure 3-36. Tips Repeat the above steps to add more presets to the tour. Click Del preset button to remove it from the tour. Please note some protocols do not support delete preset function.

  • Page 47: Call Ptz Function

    Figure 3-37 Scan Setup In Figure 3-34, click Scan button. Use direction buttons to set camera left limit and then click Left button. Use direction buttons to set camera right limit and then click Right button. Now the scan setup process is complete.

  • Page 48: Record And Snapshot

    Call Scan In Figure 3-33, input Scan value and then click to call a tour. Click again to stop call. Rotate In Figure 3-33, click to enable the camera to rotate. System supports preset, tour, pattern, scan, rotate, light and etc function. Note: ...

  • Page 49: Overlay

     Video/audio: You can enable or disable the video/audio. Please note, once you enable audio function for one channel, system may enable audio function of the rest channels by default.  Copy：After you complete the setup, you can click Copy button to copy current setup to other channel(s).

  • Page 50: Schedule

    Figure 3-41 3.7.2 Schedule The record type priority is: Alarm>Motion detect>Regular. 3.7.2.1 Schedule Record Set record time, record plan and etc. Please note system is in 24-hour record by default after its first boot up. In the main menu, from Main menu->Setting->Storage->Schedule, you can go to schedule menu. See Figure 3-45.
  • Page 51  Redundancy: System supports redundancy backup function. It allows you backup recorded file in two disks. You can highlight Redundancy button to activate this function. Please note, before enable this function, please set at least one HDD as redundant. (Main menu->Setting->Storage->HDD Manager).
  • Page 52 Figure 3-45 Figure 3-46 Quick Setup Copy function allows you to copy one channel setup to another. After setting in channel 1, click Copy button, you can go to interface Figure 3-47. You can see current channel name is grey such as channel 1. Now you can select the channel you wan to paste such as channel 5/6/7.

  • Page 53: Schedule Snapshot

    button becomes hidden. Figure 3-47 Click OK button to save current setup. 3.7.2.2 Schedule Snapshot From Main menu->Setting->Storage->Record or on the preview interface, right click mouse and then select record item, you can see Figure 3-48. Select snapshot channel and enable snapshot function. Click Save button. Figure 3-48 From Main menu->Setting->Camera->Encode->Snapshot, you can go to snapshot interface.
  • Page 54 Figure 3-49 In the main menu, from Main menu->Setting->Storage->Schedule, you can go to schedule menu. See Figure 3-45. Here you can set snapshot period. There are total six periods in one day. Please refer to chapter 3.7.2.1 for detailed setup information. The setup steps are general the same. Figure 3-50...

  • Page 55: Motion Detect Record/Snapshot

    Note  Please note the trigger snapshot has the higher priority than regular snapshot. If you have enabled these two types at the same time, system can activate the trigger snapshot when an alarm occurs, and otherwise system just operates the regular snapshot. ...
  • Page 56 Figure 3-52 Period: Click set button, you can see an interface is shown as in Figure 3-53. Here you can set motion detect period. System only enables motion detect operation in the specified periods. It is not for video loss or the tampering. There are two ways for you to set periods. Please note system only supports 6 periods in one day.

  • Page 57: Motion Detect Snapshot

    Figure 3-54 3.7.3.2 Motion Detect Snapshot From Main menu->Setting->Camera->Encode->Snapshot, you can go to snapshot interface. See Figure 3-55. In Figure 3-55, select trigger snapshot from the dropdown list and then set picture size, quality and snapshot frequency. Click OK button to save current setup. From Main menu->Setting->Event->Detect, here you can select motion detect type, motion detect channel and then check the enable box.

  • Page 58: Alarm Record/Snapshot

    3.7.4 Alarm Record/Snapshot 3.7.4.1 Alarm Record Before you set alarm setup information, please go to chapter 2.3 to connect alarm input and alarm output cable (such as light, siren and etc). The record priority is: Alarm>Motion detect>Regular. In the main menu, from Setting->Event-> Alarm, you can see alarm setup interface. See Figure 3-56. ...

  • Page 59: Alarm Snapshot

    3.7.4.2 Alarm Snapshot Please refer to Step a) to step c) of chapter 3.7.3.2 to enable timing snapshot. From Main menu->Setting->Storage->schedule, you can go to Figure 3-57 to enable snapshot function. From Main menu->Setting->Event->Alarm, you can go to Figure 3-56 to set alarm parameter and enable snapshot function.

  • Page 60: Manual Snapshot

    Figure 3-58 Check the box here to select manual record channel(s). You can see the corresponding indicator light on the front panel is on.  Channel: It is to display device all channels.  Manual: It has the highest priority. Enable corresponding channel to record no matter what period applied in the record setup.
  • Page 61 Figure 3-59 Click Add new holiday button, you can see an interface shown as in Figure 3-60. Here you can set holiday date name, repeat mode, start time/end time and etc. Figure 3-60 Click Add button to complete holiday setup. Now you can enable holiday setup and then click Apply button.

  • Page 62: Holiday Snapshot

    3-61. Now you can set period and record type of holiday time. Please refer to chapter 3.7.2.1 for detailed setup information. Figure 3-61 Click OK button to set holiday record setup. 3.7.6.2 Holiday Snapshot Set Holiday date first. Please refer to step a) to step c) of chapter 3.7.6.1. From Main menu->Setting->Storage->Schedule, you can go to schedule interface.
  • Page 63 Figure 3-62 Please refer to the following sheet for more information. Name Function  Display Here is to display the searched picture or file.  window Support 1/4/9/16-window playback.  Here you can select to search the picture or the recorded file. ...
  • Page 64 selection requirement.  pane. In 9-window playback mode, you can switch between 1-8, 9-16 and etc channels.  In 16-window playback mode, you can switch between1-16, 17-32 and etc channels.  The time bar will change once you modify the playback mode or the channel option.
  • Page 65 │ to begin frame by frame playback. In frame by frame playback mode, click ►/ to restore normal playback. ► Slow play In playback mode, click it to realize various slow play modes such as slow play 1, slow play 2, and etc. Fast forward ...
  • Page 66  After you clip on record file, click Backup button you can save it.  For one device, if there is a backup in process, you can not start a new backup operation.  It is to edit the file. ●Please play the file you want to edit and then click this button when you want to edit.

  • Page 67: Accurate Playback By Time

    when playback Note: All the operations here (such as playback speed, channel, time and progress) have relationship with hardware version. Some series NVRs do not support some functions or playback speeds. 3.8.3 Accurate playback by time Select records from one day, click the list, you can go to the file list interface. You can input time at the top right corner to search records by time.

  • Page 68: Mark Playback

    Figure 3-64 Click the , you can go to the smart search playback. Click it again, system stops smart search playback. Important  System does not support motion detect zone setup during the full-screen mode.  During the multiple-channel playback, system stops playback of rest channels if you implement one-channel smart search.

  • Page 69: Picture Playback

     Play before mark time Here you can set to begin playback from previous N seconds of the mark time. Note Usually, system can playbacks previous N seconds record if there is such kind of record file. Otherwise, system playbacks from the previous X seconds when there is such as kind of record. ...

  • Page 70: Backup

    3.9 Backup 3.9.1 File Backup In this interface, you can backup record file to the USB device. a) Connect USB burner, USB device or portable HDD and etc to the device. b) From Main menu->Backup, you can go to the Backup interface. See Figure 3-67. Figure 3-67 c) Select backup device and then set channel, file start time and end time.

  • Page 71: Import/Export

    Figure 3-68 h) Click backup button, system begins burning. At the same time, the backup button becomes stop button. You can view the remaining time and process bar at the left bottom. Note  During backup process, you can click ESC to exit current interface for other operation (For some series product only).

  • Page 72: Backup Log

    Figure 3-69  Export: Please connect the peripheral device first and then go to the following interface. Click Export button, you can see there is a corresponding “Config_Time” folder. Double click the folder, you can view some backup files.  Import: Here you can import the configuration files from the peripheral device to current device.

  • Page 73: Usb Device Auto Pop-Up

    Figure 3-70 b) Select log type and then set start time/end time, click Search button, you can see log time and event information. Click to view detailed log information. c) Select log items you want to save and then click backup button, you can select a folder to save them.

  • Page 74: Detect Alarm

    3.10.1 Detect Alarm In the main menu, from Setting to Detect, you can see motion detect interface. See Figure 3-72.There are three detection types: motion detection, video loss, tampering. 3.10.1.1 Motion Detect After analysis video, system can generate a motion detect alarm when the detected moving signal reached the sensitivity you set here.
  • Page 75  Alarm upload: System can upload the alarm signal to the network (including alarm centre) if you enabled current function.  Send email: System can send out email to alert you when an alarm occurs.  Record channel: System auto activates motion detection channel(s) to record once an alarm occurs. Please make sure you have set MD record in Schedule interface(Main Menu->Setting->Schedule) and schedule record in manual record interface(Main Menu->Advanced->Manual Record) ...
  • Page 76 Figure 3-73 Figure 3-74 Figure 3-75...

  • Page 77: Video Loss

    Figure 3-76 Motion detect here only has relationship with the sensitivity and region setup. It has no relationship with other setups. 3.10.1.2 Video Loss From main menu->Setting->Video detect->video loss, you can see the interface is shown as in Figure 3-77. This function allows you to be informed when video loss phenomenon occurred. You can enable alarm output channel and then enable show message function.

  • Page 78: Video Diagnosis

    When someone viciously masks the lens, or the output video is in one-color due to the environments light change, system alert guarantee video continuity. From main menu->Setting->Video detect->Tampering, you can see tampering interface is shown as in Figure 3-78. You can enable “Alarm output “or “Show message” function when tampering alarm occurs. ...

  • Page 79: Face Detect

    Figure 3-79 3.10.2 Face Detect When camera detects human face, system can generate an alarm. From main menu->Setting->Event->Face detect, the interface is shown as in Figure 3-80.  Human face ROI: Check the box here, system can enhance the human face display pane. ...

  • Page 80: Audio Detect

    Figure 3-80 3.10.3 Audio Detect System can generate an alarm once it detect the audio input is abnormal or audio volume changes. From main menu->Setting->Event->Audio detect, you can see an interface shown as in Figure 3-81.  Input abnormal: Check the box here, system can generate an alarm once the audio input is abnormal.

  • Page 81: Alarm Output

    Figure 3-81 3.10.4 Alarm output From Main menu->Setting->Event->Alarm output, you can see an interface shown as in Figure 3-82. Here is for you to set proper alarm output (Auto/manual/stop). Click OK button of the alarm reset, you can clear all alarm output status. Figure 3-82...

  • Page 82: Alarm Setup

    Please highlight icon to select the corresponding alarm output. After all the setups please click OK button, system goes back to the previous menu. 3.10.5 Alarm Setup In the main menu, from Setting->Event->Alarm, you can see alarm setup interface.  Alarm in: Here is for you to select channel number.
  • Page 83  Alarm output: The number here is the device alarm output port. You can select the corresponding ports(s) so that system can activate the corresponding alarm device(s) when an alarm occurred.  Latch: When the anti-dither time ended, the channel alarm you select in the alarm output may last the specified period.
  • Page 84 Figure 3-83 Figure 3-84...
  • Page 85 Figure 3-85 Figure 3-86...
  • Page 86 Figure 3-87 Figure 3-88...

  • Page 87: Abnormality

    Figure 3-89 Please highlight icon to select the corresponding function. After setting all the setups please click save button, system goes back to the previous menu. 3.10.6 Abnormality There are three types: Disk/Network/power fault.  Disk: Disk error, no disk, no space. See Figure 3-90. ...
  • Page 88 Figure 3-90 Figure 3-91...

  • Page 89: Network

    Figure 3-92 3.11 Network 3.11.1 TCP/IP From main menu->Setting->Network/TCP/IP, the interface is shown as in Figure 3-93.  MTU: It is to set MTU value of the network adapter. The value ranges from 1280-7200 bytes. The default setup is 1500 bytes. Please note MTU modification may result in network adapter reboot and network becomes off.
  • Page 90  Multiple-address mode: eth1/eth2/ eth3/eth4 operate separately. You can use the services such as HTTP, RTP service via eth1/eth2/ eth3/eth4. Usually you need to set one default card (default setup is eth1) to request the auto network service from the device-end such as DHCP, email, FTP and etc.

  • Page 91: Connection

    Figure 3-93 3.11.1.1 Connection The connection setup interface is shown as in Figure 3-94.  Max connection: system support maximal 128 users. 0 means there is no connection limit.  TCP port: Default value is 37777.  UDP port: Default value is 37778. ...

  • Page 92: Pppoe

    Figure 3-94 3.11.1.2 PPPoE PPPoE interface is shown as in Figure 3-95. Input “PPPoE name” and “PPPoE password” you get from your ISP (Internet service provider). Click save button, you need to restart to activate your configuration. After rebooting, NVR will connect to internet automatically. The IP in the PPPoE is the NVR dynamic value.

  • Page 93: Ddns Setup

    Figure 3-95 3.11.1.3 DDNS Setup DDNS setup interface is shown as in Figure 3-96. You need a PC of fixed IP in the internet and there is the DDNS software running in this PC. In other words, this PC is a DNS (domain name server). In network DDNS, please select DDNS type and highlight enable item.
  • Page 94 Figure 3-96 Please note DDNS type includes: CN99 DDNS, NO-IP DDNS, Quick DDNS, Dyndns DDNS and sysdns DDNS. All the DDNS can be valid at the same time, you can select as you requirement. Private DDNS function shall work with special DDNS server and special Professional Surveillance Software (PSS).

  • Page 95: Upnp

    Important  Do not register frequently. The interval between two registrations shall be more than 60 seconds. Too many registration requests may result in server attack.  System may take back the domain name that is idle for one year. You can get a notification email before the cancel operation if your email address setup is OK.

  • Page 96: Ip Filter

    Figure 3-97 Figure 3-98 3.11.1.5 IP Filter IP filter interface is shown as in Figure 3-99. You can add IP in the following list. The list supports max 64 IP addresses. System supports valid address of IPv4 and IPv6. Please note system needs to check the validity of all IPv6 addresses and implement optimization.
  • Page 97  Type: You can select trusted site and blacklist from the dropdown list. You can view the IP address on the following column.  Start address/end address: Select one type from the dropdown list, you can input IP address in the start address and end address.

  • Page 98: Email

    Figure 3-100 3.11.1.6 Email The email interface is shown as below. See Figure 3-101.  SMTP server: Please input your email SMTP server IP here.  Port: Please input corresponding port value here.  User name: Please input the user name to login the sender email box. ...

  • Page 99: Ftp

    Figure 3-101 3.11.1.7 FTP You need to download or buy FTP service tool (such as Ser-U FTP SERVER) to establish FTP service. Please install Ser-U FTP SERVER first. From “start” -> “program” -> Serv-U FTP Server -> Serv-U Administator. Now you can set user password and FTP folder. Please note you need to grant write right to FTP upload user.

  • Page 100: Snmp

    Figure 3-103 System also supports upload multiple NVRs to one FTP server. You can create multiple folders under this FTP. FTP interface is shown as in Figure 3-104. Please highlight the icon in front of Enable to activate FTP function. Here you can input FTP server address, port and remote directory.

  • Page 101: Multicast

    SNMP is an abbreviation of Simple Network Management Protocol. It provides the basic network management frame of the network management system. The SNMP widely used in many environments. It is used in many network device, software and system. You can set in the following interface. See Figure 3-105. Figure 3-105 Please enable the SNMP function.
  • Page 102 Figure 3-106 Here you can set a multiple cast group. Please refer to the following sheet for detailed information.  IP multiple cast group address -224.0.0.0-239.255.255.255 -“D” address space  The higher four-bit of the first byte=”1110”  Reserved local multiple cast group address -224.0.0.0-224.0.0.255 -TTL=1 When sending out telegraph -For example...

  • Page 103: Alarm Centre

    3.11.1.10 Alarm Centre This interface is reserved for you to develop. See Figure 3-107. Figure 3-107 3.11.1.11 Auto register This function allows the device to auto register to the proxy you specified. In this way, you can use the client-end to access the NVR and etc via the proxy. Here the proxy has a switch function. In the network service, device supports the server address of IPv4 or domain.

  • Page 104: Cluster Ip

    Figure 3-108 2) The proxy server software developed from the SDK. Please open the software and input the global setup. Please make sure the auto connection port here is the same as the port you set in the previous step. 3) Now you can add device.

  • Page 105: Network Test

    Figure 3-109 3.11.2 Network Test In this interface, you can see network test and network load information. 3.11.2.1 Network Test From main menu->Info-Network->Test, the network test interface is shown as in Figure 3-110.  Destination IP: Please input valid IPV4 address and domain name. ...

  • Page 106: Network Load

    Figure 3-110 3.11.2.2 Network Load From main menu->Info-Network->Load, network load is shown as in Figure 3-111. Here you can view the follow statistics of the device network adapter. Here you can view information of all connected network adapters. The connection status is shown as offline if connection is disconnected.

  • Page 107: Hdd Setup

    Figure 3-111 3.12 HDD Setup Here you can view HDD information such as type, status, total capacity, record time and etc. The operation includes format, resume from error, change HDD property (Read write, Read-only). Here you can also set alarm and HDD storage position. 3.12.1 Format From Maini menu->Setting->Storage->HDD Manager, you can go to HDD management interface.

  • Page 108: Hdd Information

    Figure 3-112 b) Select a HDD and then select format from the dropdown list. Click Execute button. c) Click OK button to complete the setup. You can see system needs to restart to activate current setup. 3.12.2 HDD Information From Main menu->Info ->System->HDD, here is to list hard disk type, total space, free space, and status. See Figure 3-113.
  • Page 109 In Figure 3-113, click one HDD item, the S.M.A.R.T interface is shown as in Figure 3-114. Figure 3-114 Parameter Function SATA 1 here means there is 1 HDD. For different series product, the max HDD amount may vary, When HDD is working properly, system is shown as O. . “_” means there is no HDD.

  • Page 110: Advanced

    3.12.3 Advanced From Main menu->Setting->Storage->Advanced, It is to set HDD group, and HDD group setup for main stream, sub stream and snapshot operation Click main stream/sub stream/snapshot button to set corresponding HDD group information. See Figure 3-115 through Figure 3-117. Figure 3-115 Figure 3-116...

  • Page 111: Raid Manager

    Figure 3-117 3.12.4 RAID Manager Important Please make sure your purchased product support the RAID function, otherwise you can not see the following interface. Right now, RAID supports Raid0, Raid1, Raid5, Raid6, and Raid10. Local hotspare supports Raid1, Raid5, Raid6, and Raid10. 3.12.4.1 RAID Config From Main menu->Setting->Storage->RAID->RAID Config, it is for you to manage RAID HDD.

  • Page 112: Raid Info

    Figure 3-118 3.12.4.2 RAID Info From Main menu->Setting->Storage->RAID->RAID info, it is to display RAID name, space, type, member HDD, hotspare HDD, status and etc. Here you can delete RAID. See Figure 3-119. Figure 3-119...

  • Page 113: Hotspare Disks

    3.12.4.3 Hotspare disks From Main menu->Setting->Storage->RAID->Hotspare HDD, you can add the hotspare HDD. See Figure 3-120. The type includes two options:  Global: It is global hotspare disk. When any RAID becomes degrading, it can replace and build the RAID. ...

  • Page 114: Data And Time

    HDD is no empty, then system stops recording, If the current HDD is full and then next HDD is not empty, then system overwrites the previous files.  Pack duration: Here is for you to specify record duration. The value ranges from 1 to 120 minutes. Default value is 60 minutes.

  • Page 115: Holiday

     Time format: There are two types: 24-hour mode or 12-hour mode.  NTP: It is to set NTP server, port and interval. Note: Since system time is very important, do not modify time casually unless there is a must! Before your time modification, please stop record operation first! After completing all the setups please click save button, system goes back to the previous menu.

  • Page 116: Device Maintenance And Manager

    Figure 3-123 Figure 3-124 3.14 Device Maintenance and Manager 3.14.1 System Info 3.14.1.1 Version From main menu->Info->System->Version, you can go to version interface. Here is for you to view some version information. See Figure 3-125. Please note the following figure for reference only.

  • Page 117: Bps

     Alarm in  Alarm out  System version  Build Date   Serial number Figure 3-125 3.14.1.2 BPS From main menu->Info->System->BPS, here is for you to view current video bit rate (kb/s) and resolution. See Figure 3-126. Figure 3-126...

  • Page 118: Online User

    3.14.1.3 Online User From main menu->Info->System->Online user, here is for you manage online users connected to your NVR. See Figure 3-127. You can click button to disconnect or block one user if you have proper system right. System detects there is any newly added or deleted user in each five seconds and refresh the list automatically.

  • Page 119: Remote

    3.14.1.5 Remote 3.14.1.5.1 Device Status From main menu->Setting->Remote->Status, here you can view the IPC status of the corresponding channel such as motion detect, video loss, tampering, alarm and etc. See Figure 3-129.  IPC status: : Front-end does not support. : Front-end supports.

  • Page 120: Log

    Figure 3-130 3.14.2 Log From Main menu->Info->Log, you can go to the following interface. See Figure 3-131.  Start time/end time: Pleased select start time and end time, then click search button. You can view the log files in a list. System max displays 100 logs in one page. It can save 500,000 logs on the HDD, and 16384 logs on the system.

  • Page 121: Account

    Figure 3-131 Figure 3-132 3.14.3 Account From main menu->Setting->System->Account, here is for you to implement account management. See Figure 3-133 and Figure 3-134. Here you can:  Add new user  Modify user...
  • Page 122  Add group  Modify group  Modify password. For account management please note:  For the user account name and the user group, the string max length is 6-byte. The backspace in front of or at the back of the string is invalid. There can be backspace in the middle. The string includes the valid character, letter, number, underline, subtraction sign, and dot.

  • Page 123: Add/Modify Group

    Figure 3-134 3.14.3.1 Add/Modify Group Click add group button, the interface is shown as below. See Figure 3-135. Here you can input group name and then input some memo information if necessary. There are many rights such as control panel, shut down, real-time monitor, playback, record, record file backup, PTZ, user account, system information view, alarm input/output setup, system setup, log view, clear log, upgrade system, control device and etc.

  • Page 124: Update

    Click add user button, the interface is shown as in Figure 3-136. Please input the user name, password, select the group it belongs to from the dropdown list. Then you can check the corresponding rights for current user. For convenient user management, usually we recommend the general user right is lower than the admin account.

  • Page 125: Default

    Figure 3-137 3.14.5 Default You can restore factory default setup to fix some problems when the device is running slowly. Configuration error occurred. From Main menu->Setting->System->Default, you can go to the default interface. See Figure 3-138. Click default icon, system pops up a dialogue box. You can highlight to restore factory default setup.

  • Page 126: Rs232

    Figure 3-138 3.14.6 RS232 From Main menu->Setting->System->RS232, RS232 interface is shown as below. There are five items. See Figure 3-139.  Function: There are various devices for you to select. Console is for you to use the COM or mini-end software to upgrade or debug the program.

  • Page 127: Auto Maintain

    Figure 3-139 3.14.7 Auto Maintain From Main menu->Setting->System->Autom maintain, here you can set auto-reboot time and auto-delete old files setup. You can set to delete the files for the specified days. See Figure 3-140. You can select proper setup from dropdown list. After all the setups please click save button, system goes back to the previous menu.

  • Page 128: Logout /Shutdown/Restart

    3.14.8 Logout /Shutdown/Restart From Main menu->Operation->Shutdown, you can see an interface shown as in Figure 3-141.  Shutdown: System shuts down and turns off power.  Logout: Log out menu. You need to input password when you login the next time. ...

  • Page 129: Web Operation

    4 Web Operation 4.1 General Introduction The device web provides channel monitor menu tree, search, alarm setup, system setup, PTZ control and monitor window and etc. 4.1.1 Preparation Before log in, please make sure:  PC and NVR connection is OK. ...

  • Page 130: Lan Mode

    Figure 4-2 After installation, the interface is shown as below. See Figure 4-3. Figure 4-3 Please input your user name and password. Default factory name is admin and password is admin. Note: For security reasons, please modify your password after you first login. 4.2 LAN Mode...
  • Page 131 For the LAN mode, after you logged in, you can see the main window. See Figure 4-4. Figure 4-4 This main window can be divided into the following sections.  Section 1: there are six function buttons: Live（chapter 4.3）, setup (chapter 4.8), info (Chapter 4.9), playback (chapter 4.10), alarm (chapter 4.11), and logout (chapter 4.12).

  • Page 132: Real-Time Monitor

    Figure 4-6  Section 4: Instant record button. Click it, the button becomes yellow and system begins manual record. See Figure 4-7. Click it again, system restores previous record mode. Figure 4-7  Section 5: Local play button. The Web can playback the saved (Extension name is dav) files in the PC-end. Click local play button, system pops up the following interface for you to select local play file.

  • Page 133: Ptz

    Figure 4-9 On the top right corner, there are six unction buttons. See Figure 4-10. 2 3 4 Figure 4-10  1: Digital zoom: Click this button and then left drag the mouse in the zone to zoom in. right click mouse system restores original status.

  • Page 134: Image/Alarm-Out

    Parameter Function  Select Tour from the dropdown list. Tour  Input preset value in the column. Click Add preset button, you have added one preset in the tour.  Repeat the above procedures you can add more presets in one tour.

  • Page 135: Image

    Select one monitor channel video and then click Image button in section 9, the interface is shown as Figure 4-12. 4.5.1 Image Here you can adjust its brightness, contrast, hue and saturation. (Current channel border becomes green). Or you can click Reset button to restore system default setup. Figure 4-12 4.5.2 Alarm output Here you can enable or disable the alarm signal of the corresponding port.

  • Page 136: Wan Login

    4.7 WAN Login In WAN mode, after you logged in, the interface is shown as below. See Figure 4-15. Figure 4-15 Please refer to the following contents for LAN and WAN login difference. 1) In the WAN mode, system opens the main stream of the first channel to monitor by default. The open/close button on the left pane is null.

  • Page 137: Setup

    icons at the left top corner of the channel number for you reference. M stands for main stream. S stands for sub stream (extra stream). 4) If you login via the WAN mode, system does not support alarm activation to open the video function in the Alarm setup interface.
  • Page 138 Figure 4-18 Please refer to the following sheet for log parameter information. Parameter Function Click Device search button, you can view the searched device Device search information on the list. It includes device IP address, port, device name, manufacturer and type. Select a device in the list and then click Add button, system can connect the device automatically and add it to the Added device list.

  • Page 139: Upgrade

    Parameter Function Click it, the interface is shown as in Figure 4-18. Here you can add Manual network camera manually. You can select a channel from the dropdown list (Here only shows disconnection channel.) Note:  System supports manufactures such as Panasonic, Sony, Dynacolor, Samsung, AXIS, Arecont and Onvif standard protocol.
  • Page 140 Figure 4-20 Please refer to the following sheet for detailed information. Parameter Function Channel Please select a channel from the dropdown list. The options includes: day/night/general/switch by period. Once Config file the mode is switch by period, you can set sunset and sunrise time.
  • Page 141 video color may become too strong if the value is too high. For the grey part of the video, the distortion may occur if the white balance is not accurate. Please note the video may not be attractive if the value is too low. The recommended value ranges from 40 to 60.

  • Page 142: Encode

    setup is auto.  Color: Device outputs the color video.  Auto: Device auto select to output the color or the B/W video according to the device feature (The general bright of the video or there is IR light or not.) ...

  • Page 143: Snapshot

    camera. Frame Rate PAL：1～25f/s；NTSC：1～30f/s.  Bit Rate Main stream: You can set bit rate here to change video quality. The large the bit rate is, the better the quality is. Please refer to recommend bit rate for the detailed information. ...

  • Page 144: Video Overlay

    It is to set the image quality. There are six levels. Quality It is to set snapshot frequency. The value ranges from 1s to 7s. Interval Or you can set customized value. The max setup is 3600s/picture. 4.8.1.3.3 Video Overlay From main window->Setup->Camera->Encode->Overlay, the video overlay interface is shown as in Figure 4-23.

  • Page 145: Camera Name

    Please click the Save button to save current setup. Figure 4-24 4.8.1.4 Camera Name From main window->Setup->Camera->Camera name, here you can set channel name. See Figure 4-25. Figure 4-25 4.8.2 Network 4.8.2.1 TCP/IP From main window->Setup->Network->TCP/IP, the TCP/IP interface is shown as in Figure 4-26.
  • Page 146 Figure 4-26 Please refer to the following sheet for detailed information. Parameter Function Network mode It includes: multiple-address, fault tolerance, load balance.  Multiple-address mode: Multiple-Ethernet port operates separately. You can use the services such as HTTP, RTP service via any Ethernet port. Usually you need to set one default card (default setup is etho) to request the auto network service form the device-end such as DHCP, email, FTP and etc.

  • Page 147: Connection

    Network card It is the card bind by default if the mode is multiple-address or fault tolerance. Mac Address It is to display host Mac address. IP Version It is to select IP version. IPV4 or IPV6. You can access the IP address of these two versions. Mode There are two modes: static mode and the DHCP mode.

  • Page 148: Pppoe

    Please refer to the following sheet for detailed information. Parameter Function Max connection It is the max Web connection for the same device. The value ranges from 1 to 120. The default setup is 120. TCP port The default value is 37777. You can input the actual port number if necessary.
  • Page 149 Figure 4-29 Please refer to the following sheet for detailed information. Parameter Function Server Type You can select DDNS protocol from the dropdown list and then enable DDNS function. Server IP DDNS server IP address Server Port DDNS server port. Domain Name Your self-defined domain name.

  • Page 150: Ip Filter

     Port number：80  Domain name：There are two modes: Default domain name and customized domain name. Except default domain name registration, you can also use customized domain name (You can input your self-defined domain name.) After successful registration, you can use domain name to login installed of the device IP.
  • Page 151 Figure 4-31 Please refer to the following sheet for detailed information. Parameter Function Please check the box here to enable email function. Enable Input server address and then enable this function. SMTP Server Port Default value is 25. You can modify it if necessary. Anonymity For the server supports the anonymity function.

  • Page 152: Ftp

    Parameter Function Please check the box here to enable this function. Health mail enable This function allows the system to send out the test email to Update period check the connection is OK or not. (interval) Please check the box to enable this function and then set the corresponding interval.

  • Page 153: Snmp

     Enable UPnP from the Web. If your UPnP is enabled in the Windows OS, the NVR can auto detect it via the “My Network Places” Figure 4-33 4.8.2.9 SNMP From main window->Setup->Network->SNMP, the SNMP interface is shown as in Figure 4-34. The SNMP allows the communication between the network management work station software and the proxy of the managed device.

  • Page 154: Multicast

    Parameter Function SNMP Port The listening port of the proxy program of the device. It is a UDP port not a TCP port. The value ranges from 1 to 65535. The default value is 161 It is a string. It is a command between the manage process Read Community and the proxy process.

  • Page 155: Alarm Centre

    Figure 4-36. This function allows the device to auto register to the proxy you specified. In this way, you can use the client-end to access the NVR and etc via the proxy. Here the proxy has a switch function. In the network service, device supports the server address of IPv4 or domain.

  • Page 156: Https

    4.8.2.13 HTTPS From main window->Setup->Network->HTTPS, you can see an interface shown as in Figure 4-38. In this interface, you can set to make sure the PC can successfully login via the HTTPS. It is to guarantee communication data security. The reliable and stable technology can secure the user information security and device safety.

  • Page 157: Download Root Certificate

    4.8.2.13.2 Download root certificate In Figure 4-38, click button, system pops up a dialogue box. See Figure 4-41. Figure 4-41 Click Open button, you can go to the following interface. See Figure 4-42. Figure 4-42 Click Install certificate button, you can go to certificate wizard. See Figure 4-43.
  • Page 158 Figure 4-43 Click Next button to continue. Now you can select a location for the certificate. See Figure 4-44. Figure 4-44 Click Next button, you can see the certificate import process is complete. See Figure 4-45.

  • Page 159: View And Set Https Port

    Figure 4-45 Click Finish button, you can see system pops up a security warning dialogue box. See Figure 4-46. Figure 4-46 Click Yes button, system pops up the following dialogue box, you can see the certificate download is complete. See Figure 4-47. Figure 4-47 4.8.2.13.3 View and set HTTPS port From Setup->Network->Connection, you can see the following interface.

  • Page 160: Login

    Figure 4-48 4.8.2.13.4 Login Open the browser and then input https://xx.xx.xx.xx:port. xx.xx.xx.xx: is your device IP or domain mane. Port is your HTTPS port. If you are using default HTTPS value 443, you do not need to add port information here. You can input https://xx.xx.xx.xx to access.
  • Page 161 Figure 4-49 Figure 4-50...
  • Page 162 Figure 4-51 Figure 4-52...
  • Page 163 Figure 4-53 Figure 4-54 Please refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable motion detection function. Please select a channel from the dropdown list. Period Motion detection function becomes activated in the specified periods.

  • Page 164: Video Loss

    Parameter Function period and go to Storage-> Schedule to set current channel as schedule record. Record Delay System can delay the record for specified time after alarm ended. The value ranges from 10s to 300s. Alarm out Enable alarm activation function. You need to select alarm output port so that system can activate corresponding alarm device when an alarm occurs.

  • Page 165: Tampering

    Figure 4-55 4.8.3.1.3 Tampering From main window->Setup->Event->Video detect->Tampering, the tampering interface is shown as in Figure 4-56. After analysis video, system can generate a tampering alarm when the detected moving signal reached the sensitivity you set here. For detailed setups, please refer to chapter 4.8.3.1.1 motion detect for detailed information. Figure 4-56 4.8.3.1.4 Video diagnosis Important...

  • Page 166: Face Detect

    Please make sure the network camera supports this function. From main window->Setup->Event->Video detect->Video diagnosis, the video diagnosis interface is shown as in Figure 4-57. Figure 4-57 Click Set button, the interface is shown as below. See Figure 4-58. System can generate an alarm once there is stripe, noise, or video is color cast, out of focus or over exposure.

  • Page 167: Audio Detect

    From main menu->Setup->Event->Face detect, the interface is shown as in Figure 4-59.  Enable face boost: Check the box here, system can enhance the human face display pane.  Sensitivity: System supports 6 levels. The sixth level has the highest sensitivity. For detailed setups, please refer to chapter 4.8.3.1.1 motion detect for detailed information.

  • Page 168: Alarm

    Figure 4-60 4.8.3.4 Alarm Before operation, please make sure you have properly connected alarm devices such as buzzer. The input mode includes local alarm, network alarm, and IPC external alarm and IPC offline alarm. 4.8.3.4.1 Local Alarm From main menu->Setup->Event->Alarm->Local alarm, the local alarm interface is shown as in Figure 4-61.
  • Page 169 Figure 4-61 Figure 4-62...
  • Page 170 Figure 4-63 Please refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable this function. Please select a channel from the dropdown list. Period This function becomes activated in the specified periods. There are six periods in one day.

  • Page 171: Net Alarm

    Parameter Function System can delay the record for specified time after alarm Record Delay ended. The value ranges from 10s to 300s. Alarm out Enable alarm activation function. You need to select alarm output port so that system can activate corresponding alarm device when an alarm occurs.

  • Page 172: Ipc External Alarm

    Figure 4-64 4.8.3.4.3 IPC external alarm From main menu->Setup->Event->Alarm->IPC external alarm, the IPC external alarm interface is shown as in Figure 4-65. Network alarm refers to the alarm signal from the network. System does not support anti-dither and sensor type setup. For setup information, please refer to chapter 4.8.3.4.1. Figure 4-65 4.8.3.4.4 IPC Offline Alarm From main menu->Setup->Event->Alarm->IPC offline alarm, the IPC offline alarm interface is shown as...

  • Page 173: Abnormality

    in Figure 4-66. System can generate an alarm once the network camera is offline. For setup information, please refer to chapter 4.8.3.4.1. Figure 4-66 4.8.3.5 Abnormality From main menu->Setup->Event->Abnormality, you can go to the abnormality interface. It includes three types: HDD/Network/Power fault. See Figure 4-67 through Figure 4-69. Figure 4-67...
  • Page 174 Figure 4-68 Figure 4-69 Please refer to the following sheet for detailed information. Parameter Function  The HDD event type includes: No HDD, HDD error, no space. See Event Type Figure 4-67. You can set one or more items here. Less than: You can set the minimum percentage value here (For HDD not space only).

  • Page 175: Alarm Output

    Parameter Function Alarm Out Please select corresponding alarm output channel when an alarm occurs. You need to check the box to enable this function. Latch The alarm output can delay for the specified time after an alarm stops. The value ranges from 1s to 300s. Show System can pop up a message to alarm you in the local host screen if message...
  • Page 176 Figure 4-71 Figure 4-72...

  • Page 177: Hdd Manager

    Figure 4-73 Please refer to the following sheet for detailed information. Parameter Function Channel Please select a channel from the dropdown list. Pre-record Please input pre-record time here. The value ranges from 0 to 30. Redundancy Check the box here to enable redundancy function. Please note this function is null if there is only one HDD.

  • Page 178: Record Control

    Figure 4-74 4.8.4.3 Record Control From main menu->Setup->Storage->Record, the interface is shown as in Figure 4-75. Figure 4-75 Please refer to the following sheet for detailed information. Parameter Function Here you can view channel number. Channel The number displayed here is the max channel amount of your device.

  • Page 179: Advanced

    Stop current channel record no matter what period applied in the Stop record setup. Check the corresponding All button, you can enable or disable all Start all/ stop all channels record. 4.8.4.4 Advanced 4.8.4.4.1 HDD From main menu->Setup->Storage->Advanced->HDD, the HDD interface is shown as below. See Figure 4-76.

  • Page 180: Snapshot

    Figure 4-78 4.8.4.4.4 Snapshot From main menu->Setup->Storage->Advanced->Snapshot, the snapshot interface is shown as in Figure 4-79 . Here you can set corresponding HDD group to save snapshot picture. Figure 4-79 4.8.4.5 RAID Manager Important Please make sure your purchased product support the RAID function, otherwise you can not see the following interface.

  • Page 181: Raid Info

    Figure 4-80 4.8.4.5.2 RAID Info From main menu->Setup->Storage->RAID->RAID info, you can go to the following interface. See Figure 4-80. Here you can vie corresponding RAID information. Figure 4-81 4.8.4.5.3 Hotspare disks From main menu->Setup->Storage->RAID->Hotspare, you can see an interface shown as in Figure 4-82. The type includes two options: ...

  • Page 182: Iscsi

    Figure 4-82 4.8.4.6 iSCSI From main menu->Setup->Storage->iSCSI, you can see an interface shown as in Figure 4-83. Here you can set corresponding HDD group to save main stream. Figure 4-83 Check the box to enable iSCSI function and then input iSCSI server IP address and port. The default port number is 3260.
  • Page 183 Figure 4-84 Input user name and password to set iSCSI path access right. There are two situations:  When you set the iSCSI server, you have set corresponding user name or password for a path. In this situation, you need to input user name or password to login. ...

  • Page 184: Setting

    4.8.5 Setting 4.8.5.1 General The general interface includes general, date/time and holiday setup. 4.8.5.1.1 General From main menu->Setup->System->General->General, the general interface is shown as in Figure 4-86. Figure 4-86 Please refer to the following sheet for detailed information. Parameter Function It is to set device name.

  • Page 185: Holiday Setup

    Figure 4-87 Please refer to the following sheet for detailed information. Parameter Function Here you can select date format from the dropdown list. Date format There are two options: 24-H and 12-H. Time Format The time zone of the device. Time zone It is to set system time.

  • Page 186: Display

    Figure 4-88 4.8.5.2 Display Display interface includes GUI, Tour. 4.8.5.2.1 Display From main menu->Setup->System->Display->Display, here you can set background color and transparency level. See Figure 4-89. Figure 4-89 Please refer to the following sheet for detailed information. Parameter Function There four options: Resolution...

  • Page 187: Tour

    enhance 4.8.5.2.2 Tour From main menu->Setup->System->Display->Tour, the tour interface is shown as in Figure 4-90. Here you can set tour interval, split mode, motion detect tour and alarm tour mode. Figure 4-90 Please refer to the following sheet for detailed information. Parameter Function Check the box here to enable tour function.

  • Page 188: Ptz

    Figure 4-91 Please refer to the following sheet for detailed information. Parameter Function Select the corresponding dome protocol. Protocol Default setup is console. Select the baud rate. Baud Rate Default setup is 115200. Data Bit The value ranges from 5 to 8. Default setup is 8.

  • Page 189: Account

    Figure 4-93 Please refer to the following sheet for detailed information. Parameter Function Select speed dome connected channel. Channel There are two options: local/remote. PTZ Type Please select remote type if you are connecting to the network PTZ. Select the corresponding dome protocol such as PELCOD. Protocol Set corresponding dome address.
  • Page 190 Figure 4-94 Add user: It is to add a name to group and set the user rights. See Figure 4-95. There are four default users: admin/888888/666666 and hidden user “default”. Except user 6666, other users have administrator right. The user 666666 can only have the monitor rights,. Hidden user “default”...

  • Page 191: Group

    It is to modify the user property, belonging group, password and rights. See Figure 4-96. Modify password It is to modify the user password. You need to input the old password and then input the new password twice to confirm the new setup. Please click the OK button to save. Please note, the password ranges from 1-digit to 6-digit.

  • Page 192: Auto Maintain

    Add group: It is to add group and set its corresponding rights. See Figure 4-98. Please input the group name and then check the box to select the corresponding rights. It includes: shutdown/reboot device, live view, record control, PTZ control and etc. Figure 4-98 Modify group Click the modify group button, you can see an interface is shown as in Figure 4-99.

  • Page 193: Import/Export

    From main menu->Setup->System->Auto maintain, the auto maintain interface is shown as in Figure 4-100. Here you can select auto reboot and auto delete old files interval from the dropdown list. If you want to use the auto delete old files function, you need to set the file period. Click Manual reboot button, you can restart device manually.

  • Page 194: Upgrade

    Figure 4-102 4.8.5.9 Upgrade From main menu->Setup->System->upgrade, the upgrade interface is shown as in Figure 4-103. Please select the upgrade file and then click the update button to begin update. Please note the file name shall be as *.bin. During the upgrade process, do not unplug the power cable, network cable, or shutdown the device.
  • Page 195 In this interface, you can add several master devices manually. After you enable the cluster function, you can view device IP, work status. Click operation button, you can view the connection log of the main device. See Figure 4-104. Figure 4-104 Click Manual add, the interface is shown as below.

  • Page 196: Slave Device

    Figure 4-106 4.8.6.2 Slave Device When you add the first slave device , the default IP is the device IP address that logins in the WEB. From main menu->Setup->Cluster service->Slave device, you can go to the following interface. See Figure 4-107. You can refer to Chapter 4.8.6.1 to set. Figure 4-107 After you added master device and slave device , you need to enable cluster function.

  • Page 197: Cluster Control

    is the resume button. Important If you want to switch the slave device to the main device, please click button manually to resume the main device. You can see the following prompt. See Figure 4-108. Figure 4-108 After the master device becomes active again, system can forward the record files on the slave device to the master device.

  • Page 198: Info

    Figure 4-110 Info From main menu->Info, you can go to the following interface. 4.9.1 Version From main menu->Info->Version, the version interface is shown as in Figure 4-111. Here you can view record channel, alarm input/output information, software version, release date and etc. Please note the following information for reference only.

  • Page 199: Online User

    Figure 4-112 Please refer to the following sheet for log parameter information. Parameter Function Log types include: system operation, configuration operation, data Type operation, event operation, record operation, user management, log clear. Set the start time of the requested log. Start time Set the end time of the requested log.

  • Page 200: Hdd

    Figure 4-113 4.9.4 HDD From main menu->Info->HDD, the HDD interface is shown as in Figure 4-114. Here you can view HDD information. Figure 4-114 4.10 Playback Click Playback button, you can see an interface is shown as in Figure 4-115. Please set record type, record date, window display mode and channel name.
  • Page 201 Figure 4-115 Then please click File list button, you can see the corresponding files in the list. See Figure 4-116. Figure 4-116 Select a file you want to play and then click Play button, system can begin playback. You can select to playback in full-screen.
  • Page 202 Figure 4-117 Select the file(s) you want to download and then click download button, you can see an interface shown as in Figure 4-118. The Download button becomes Stop button and there is a process bar for your reference. Please go to you default file saved path to view the files. Figure 4-118...
  • Page 203 Load more Click More button in Figure 4-118, you can see an interface shown as in Figure 4-119. It is for you to search record or picture. You can select record channel, record type and record time to download. There are two download types.

  • Page 204: Alarm

    Figure 4-121 4.11 Alarm Click alarm function, you can see an interface is shown as Figure 4-122. Here you can set device alarm type and alarm sound setup (Please make sure you have enabled audio function of corresponding alarm events.). Figure 4-122 Please refer to the following sheet for detailed information.

  • Page 205: Log Out

    Type Parameter Function external It refers to the on-off signal from the network alarm camera. It can activate the NVR local activation operation. IPC offline alarm System can generate an alarm when the network camera and the NVR are disconnected. Operation Prompt Check the box here, system can automatically pops up an alarm icon on the Alarm button in the main...

  • Page 206: Appendix A Hdd Capacity Calculation

    5 Appendix A HDD Capacity Calculation Calculate total capacity needed by each device according to video recording (video recording type and video file storage time). Step 1: According to Formula (1) to calculate storage capacity that is the capacity of each channel needed for each hour, unit Mbyte.

  • Page 207: Appendix B Toxic Or Hazardous Materials Or Elements

    Appendix B Toxic or Hazardous Materials or Elements Toxic or Hazardous Materials or Elements Component Name Cr VI PBDE Sheet ○ ○ ○ ○ ○ ○ Metal(Case) Plastic Parts ○ ○ ○ ○ ○ ○ （Panel） ○ ○ ○ ○ ○...
