HEAT & COOL MODEL
(REVERSE CYCLE)
ROOM AIR CONDITIONER
WALL MOUNTED TYPE
Indoor Unit
ASTA24LFC
ASTA30LFC
Outdoor Unit
AOTR24LFL
AOTR30LFT
KEEP THIS OPERATION MANUAL
FOR FUTURE REFERENCE
FUJITSU GENERAL LIMITED
9315345301_OM_EN_cover
1
OPERATING MANUAL
R410A
REFRIGERANT
This Air Conditioner contains and
operates with refrigerant R410A.
THIS PRODUCT MUST ONLY BE INSTALLED OR SERVICED
BY QUALIFIED PERSONNEL.
Refer to Commonwealth, State, Territory and local legislation,
regulations, codes, installation & operation manuals, before
the installation, maintenance and/or service of this product.
3/22/10, 10:42 AM
P/N9315345301
Advertisement
Table of Contents
Related Manuals for Fujitsu ASTA24LFC
Summary of Contents for Fujitsu ASTA24LFC
-
Page 1: Operating Manual
BY QUALIFIED PERSONNEL. Refer to Commonwealth, State, Territory and local legislation, regulations, codes, installation & operation manuals, before KEEP THIS OPERATION MANUAL the installation, maintenance and/or service of this product. FOR FUTURE REFERENCE FUJITSU GENERAL LIMITED P/N9315345301 9315345301_OM_EN_cover 3/22/10, 10:42 AM... -
Page 2: Table Of Contents
CONTENTS SAFETY PRECAUTIONS .......... 1 ADJUSTING THE DIRECTION OF FEATURES AND FUNCTIONS ......... 2 AIR CIRCULATION ..........10 NAME OF PARTS ............4 SWING OPERATION ..........11 PREPARATION ............5 COIL DRY OPERATION ........... 11 OPERATION .............. 6 CLEANING AND CARE ........... 12 TIMER OPERATION .......... -
Page 3: Features And Functions
FEATURES AND FUNCTIONS INVERTER OMNI-DIRECTIONAL AIR FLOW (SWING OPERATION) At the start of operation, a large power is used to bring the room quickly to the desired temperature. Afterwards, the Three-dimensional control over air direction swing is possi- unit automatically switches to a low power setting for eco- ble through dual use of both an UP/DOWN air direction swing nomic and comfortable operation. - Page 4 Fig. 1 MANUAL AUTO Fig. 2 OPERATION TIMER COIL DRY Fig. 3 Fig. 5 Fig. 4 Fig. 6 Fig. 7 To facilitate explanation, the accompanying illustra- tion has been drawn to show all possible indicators; in actral operation, however, the display will only show those indicators appropriate to the current op- eration.
-
Page 5: Name Of Parts
NAME OF PARTS Fig. 1 Indoor Unit Fig. 6 Remote Controller 1 Operating Control Panel (Fig. 2) J SLEEP button 2 MANUAL AUTO button K MASTER CONTROL button L SET TEMP. button ( When kept on pressing the MANUAL AUTO button for more than 10 seconds, M COIL DRY button the forced cooling operation will start. -
Page 6: Preparation
PREPARATION Load Batteries (R03/LR03 × × × × × 2) CAUTION! G Take care to prevent infants from accidentally swallowing batteries. Press and slide the battery compartment lid on the re- G When not using the Remote Controller verse side to open it. for an extended period, remove the batteries to avoid possible leakage and Slide in the direction of the arrow while pressing the... -
Page 7: Operation
OPERATION To Select Mode Operation Press the START/STOP button (Fig.6 R). The indoor unit’s OPERATION Indicator Lamp (red) (Fig. 3 5) will light. The air conditioner will start operating. Press the MASTER CONTROL button (Fig.6 K) to se- lect the desired mode. Each time the button is pressed, the mode will change in the following order. -
Page 8: Om_En_Body
To Stop Operation Press the START/STOP button (Fig. 6 R). The OPERATION Indicator Lamp (red) (Fig. 3 5) will go out. About AUTO CHANGEOVER Operation G When AUTO CHANGEOVER operation first selected, the fan will oper- AUTO: ate at very low speed for about one minute, during which time the unit detects the room conditions and selects the proper operating mode. -
Page 9: Timer Operation
TIMER OPERATION Before using the timer function, be sure that the Remote Controller is set to the correct current time ( P . 5). To Use the ON timer or OFF timer Press the START/STOP button (Fig. 6 R) To Cancel the Timer (if the unit is already operating, proceed to step 2). -
Page 10: Sleep Timer Operation
SLEEP TIMER OPERATION Unlike other timer functions, the SLEEP timer is used to set the length of time until air conditioner operate is stopped. To Use the SLEEP Timer To Cancel the Timer: While the air conditioner is operating or stopped, press the Use the TIMER MODE button to select SLEEP button (Fig. -
Page 11: Adjusting The Direction Of Air Circulation
ADJUSTING THE DIRECTION OF AIR CIRCULATION G Adjust the up, down, left, and right AIR directions with the AIR DIRECTION buttons on the Remote Controller. G Use the AIR DIRECTION buttons after the Indoor Unit has started operating and the airflow-direction louvers have stopped moving. -
Page 12: Swing Operation
SWING OPERATION Begin air conditioner operation before performing this procedure. To select SWING Operation Press the SWING button (Fig. 6 U). The SWING Display (Fig. 7 d) will light. Each time the SWING button is pressed, the swing operation will change in the following order. -
Page 13: Cleaning And Care
CLEANING AND CARE G Before cleaning the air conditioner, be sure to turn it off and disconnect the Power Supply Cord. CAUTION! G Be sure the Intake Grille (Fig. 1 8) is installed securely. G When removing and replacing the air filters, be sure not to touch the heat exchanger, as per- sonal injury may result. - Page 14 CLEANING AND CARE Air Cleaning Filter Installation Replacing dirty Air cleaning filters Replace filters with the following components (purchased 1. Open the Intake Grille and remove the Air separately). filters. G POLYPHENOL CATECHIN AIR CLEANING FILTER : UTR-FA13-1 G Negative air ions deodorizing filter: UTR-FA13-2 1.
-
Page 15: Troubleshooting
TROUBLESHOOTING In the event of a malfunction (burning smell, etc.), immediately stop operation, turn off the elec- WARNING! trical breaker or disconnect the power supply plug, and consult authorized service personnel. Merely turning off the unit’s power switch will not completely disconnect the unit from the power source. -
Page 16: Operating Tips
TROUBLESHOOTING Symptom Items to check See Page G Is the Power Supply Plug disconnected its outlet? CHECK ONCE Doesn’t operate at all: MORE G Has there been a power failure? — G Has a fuse blown out, or a circuit breaker been tripped? G Is the timer operating? 8 - 9 G Is the Air Filter dirty? - Page 17 OPERATING TIPS Temperature and Humidity Range Dry Mode Heating Mode Cooling Mode Outdoor temperature About -10 to 46 °C About –15 to 24 °C About -10 to 46 °C Indoor temperature About 18 to 32 °C About 30 °C or less About 18 to 32 °C G If the air conditioner is used under higher temperature conditioner than those listed, the built-in protection circuit may operate to prevent internal circuit damage.
