Xtim bionicbird Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTRUCTION MANUAL
(To read imperatively before use. Adjustments required during the first flight)
THANK YOU FOR PURCHASING BIONIC BIRD

Technical Specifications

Bird
- Ultra light bird, weight 9.2 g.
- Powerful main motor (1.2 watt output) with aluminum heat sink.
- Electronic protection against overheating.
- 1:36 Reducer (patented) ultra-compact and lightweight (0.3 g).
- Precise power control (128 steps).
- Adjustable tail angle for slow or fast flights (indoor/outdoor).
- Sharp and immediate steering control by wing distortion (patented) for aerial stunts.
- Impressive gliding due to its very low ratio weight/wing area (3.42 g/dm²).
- On-board hybrid lithium polymer battery, 50 mAh (1.6 g).
- Full battery protection against short circuit, overload and complete discharge, for a
longer life.
- Up to 6 min flight at full speed, 7.5 min max for normal flight, or a distance of 1.8 km.
Egg
– Stand-alone charger
- 36 grams, 57 x 45 mm.
- Hybrid lithium polymer battery (800 mAh) included.
- Total capacity of the egg: 10 full flights, or 75 minutes of flying time.
- Short charging time of the Bird, only 12 minutes thanks to a proprietary smart charging
cycle "Turbo Charge®".
- The bird charges on the egg on which it connects automatically by retractable magnetic
contacts.
- Charging time of the egg: 90 minutes.
- Egg auto power-off after 12 minutes (battery saving).
XTIM SARL - 10, Bd Maire 13008 MARSEILLE – FRANCE
email: contact @mybionicbird.com tel : +33 4 84 18 52 36
website:
www.mybionicbird.com
14+
The first Bionic Bird !
Page 1 sur 17

Advertisement

Table of Contents
loading

Summary of Contents for Xtim bionicbird

  • Page 1: Technical Specifications

    XTIM SARL - 10, Bd Maire 13008 MARSEILLE – FRANCE email: contact @mybionicbird.com tel : +33 4 84 18 52 36 website: www.mybionicbird.com INSTRUCTION MANUAL (To read imperatively before use. Adjustments required during the first flight) THANK YOU FOR PURCHASING BIONIC BIRD...
  • Page 2 Application The Flying App: - Compatibility: Check compatibility with systems and devices on www.mybionicbird.com, which will be updated continuously. - Range: 100m - Protocol: Bluetooth - Multiplayer system with Bluetooth connection, ability for several players in one place. No limitations. - User Interface: 2 modes easy/expert.

  • Page 3: Safety Precautions

    WARNING: This product complies with the following standard and complies with FCC part 15 (2008); R&TTE 2008 (EN300440-2. EN301489-1. EN301489-3); DEEE (WEEE) directive 2002/96/EC. FCC ID: 2ADQDBB1 This device complies with part 15 of the FCC rules. Operation is subject to the following conditions: 1- This device may not cause harmful interference, and 2- This device must accept any interference received, including interference that may...

  • Page 4: Battery Cautions

    BATTERY CAUTIONS: Works with 2 rechargeable LI-PO (lithium-polymer) battery (included). One inside the egg and one inside the bird.They cannot be extracted or replaced. Rechargeable batteries are only to be charged by an adult. Respect the correct polarity (-) or (+) The supply terminals are not to be short-circuited.
  • Page 5 INSTRUCTION MANUAL MANUFACTURER NOTES: *The suitcase packing must be kept and used to store and carry the product in good conditions. This will increase product lifespan a lot. Before to put the bird into the box, use the app to adjust wing position. NEVER TRY TO MOVE WINGS MANUALLY! *This product was tested for a lifespan of hundreds of cycles in flight;...

  • Page 6: Application Operation

    III –APPLICATION OPERATION Bird detection: You must launch the app first, the screen “Searching bird” above will appear, then quickly switch BIONIC BIRD ON. The bird will be detected immediately. If this is the first time you use it, another screen appears to name your BIONIC BIRD. Next time, it will be recognized automatically with its name, and this screen will be skipped.
  • Page 7 NB: The bird detection process lasts a maximum of 18 seconds. If your bird isn’t detected during this time, the “NEST” screen will appear. Make sure your bird is switched off before using the “connection” button to access the bird detection screen and restart the detection process.
  • Page 8 Name of the bird in use Strengh of the Bluetooth signal Choix du mode de vol Indicates the direction of the turn (tilting the smartphone) Throttle control cursor Choix du mode de vol Cruise control On/Off Choix du mode de vol Activate speakerphone Back to «...
  • Page 9 Throttle back to 100% Signal and battery Throttle cursor level indicators Choix du mode de vol Choix du mode Choix du mode de vol de vol Stop wings Left steering cursor Right steering cursor Choix du Choix du mode de vol Choix du mode de vol mode de EXPERT flight mode: Using this mode, hold your smartphone in the horizontal position...
  • Page 10 IV – FLYING YOUR BIONIC BIRD Conditions of use: Indoor use doesn’t require any conditions except a room big enough to fly around without obstacle. Outdoor use requires adapted weather conditions, ideally no wind at all (recommended for beginner, and compulsory to balance wings, see below), and no rain. For an experienced user, wind up to 8 mph is acceptable, if it’s steady.
  • Page 11 Flying BIONIC BIRD * Launching: Push the throttle stick ¾ of the way up. Always point BIONIC BIRD facing the wind, launch the bird from your hand with a gentle horizontal toss. Let it gain some altitude before trying any turns. If it flies downward, you can try with the tail one notch higher.
  • Page 12 Turning direction Ballast If the bird tends to turn to the right, add some weight to the left wing: Take one of the aluminium tape piece and stick it near the tip of the right wing, below the wing, as shown on the picture.
  • Page 13 V – CHARGING BIONIC BIRD The first thing to do is to switch the egg ON, with the button located under its bottom. The bottom of the egg will lit blue. NB: If the egg doesn’t lit, it may be discharged. You need to charge it again (see below).
  • Page 14 The upper part of the egg will start to blink when it starts to charge. Charging takes around 12 minutes. The egg will stop blinking and remain lit when BIONIC BIRD is fully charged and ready to fly again. Note: You don’t have to worry about leaving BIONIC BIRD on the egg after it’s finished charging.
  • Page 15 To charge it, simply plug it in as indicated above. The egg will blink until it’s fully charged in around 90 minutes. It’s not necessary to fully charge the egg before charging the bird, but it’s recommended to ensure the best amount of flight time. It’s also possible to charge the bird while charging the egg.

  • Page 16: Replacing Other Parts

    VII – WINGS REPLACEMENT If a wing is broken, you can replace it with the spare set of wings included in the box. Lift the tail to the maximum notch. Pinch one side of the wing, at the back of the wing where the wing is clipped to the round knob, and take it off the knob.
  • Page 17 IMPORTANT NOTES ABOUT THE USE OF BIONIC BIRD: - It is strongly recommended to charge the bird at least at 50% of the battery capacity before to store it after use. Or the battery life will be shortened a lot. - At cold temperature, the batteries are losing most of their power.
