corresponding permission can also get access to the view and the related live video.
Steps:
1. Open the Main View page.
2. In the view panel, select the View node and click the icon
box.
3. Input the view name and click Add. The new view is of 4-Screen mode by default.
4. Optionally, Click the
view.
5. Click
to save the screen layout mode for the new view.
6. Click-and-drag the camera to the display window,
or double-click the camera name in custom view mode to start the live view.
7. Click the icon
to save the new view. Optionally, you can click
another view.
After successfully settings the view, you can click to call the view.
Move the mouse onto the custom view, the following icons are available:
Edit View Name
Delete View
Instant Playback
Stopping the Live View
Steps:
1. Select the display window.
2. Click the icon
that appears in the upper-right corner when the mouse pointer is over the
display window,
or click Stop Live View on the right-click menu to stop the live view of the display window.
You can also click the button
2.2.2 Auto-switch in Live View
Camera Auto-switch
Purpose:
The video stream of the cameras from the same area will switch automatically in a selected display
window in camera auto-switch.
Steps:
1. Open the Main View page.
2. Select a display window for camera auto-switch.
3. Click the icon
in the toolbar and select the switching interval.
4. Select an area and click the icon
5. You can click the icon
User Manual of iVMS-5200 Control Client
icon in live view toolbar and select the screen layout mode for the new
Edit the name of the custom view.
Delete the custom view.
Start the instant playback of the cameras related to the view. Up
to 16 cameras can be switch to instant playback at the same
time.
in live view toolbar to stop all the live view.
on the area node.
/
to pause/resume the camera auto-switch.
activate the view adding dialog
to save the current view as
11
