Raider 40 Horsepower Operator's Manual

Two stroke - multi-fuel - submersible – air drop
Hide thumbs Also See for 40 Horsepower:
Table of Contents

Advertisement

Quick Links

Download this manual
1
RAIDER OUTBOARD MOTOR
'
'
O
w
n
e
r
s
M
a
n
u
a
l
-
4
0
H
o
r
s
e
p
o
w
e
r
O
w
n
e
r
s
M
a
n
u
a
l
-
4
0
H
o
r
s
e
p
o
w
e
r
Two stroke - Multi-Fuel - Submersible – Air Drop

Outboard Motor

Owner's Manual R40-ES-001-15-1
This manual has been prepared for the United States military for
Operator knowledge of the Multi-fuel, Submersible Outboard motor designed and manufactured
under Contract No. N61331•11•C-0008, dated 3/4/11. The data presented in this
manual was revised as of January 2015 representing the latest revision.
Raider Outboards are not sold to the public.
