1. Functional Button Area
There will be various functional button icons shown in this area. Left clicking on the selected function button will carry out the corresponding operation.
Internet: Connects to the Internet.
Short Message: Sending an SMS or reading the SMS Inbox.
Phonebook: Save and view the contact list.
Settings: Device related settings.
Statistics: Velocity waveform display and the traffic statistics.
Help
2. System Information Area
Shows system status and related information.
Shows network signal intensity, 5 stages from none
There are new SMS in your inbox.
Shows the current status of Internet connection. Red means you are currently disconnected from the Internet.
The green icon shows that the current internet status is connected.
Letter "P" means D-Link dongle is supporting packet-switch (P) or data services, while letter "C" means supporting circuit switch (C) services.
SIM/USIM card is roaming.
Indicates the connection status of D-Link dongle, "Green" it has been connected to the computer.
"Orange" indicates the PC and D-Link dongle are connected but D-Link dongle offline.
