Front panel (STR-DN850)

(on/standby)
1.
2. SPEAKERS
3. TUNING MODE, TUNING +/–
Press TUNING MODE to operate a tuner (FM/AM).
Press TUNING +/– to scan a station.
4. NFC sensor
5. A.F.D./2CH, MOVIE, MUSIC
6. Display panel
7. SOUND OPTIMIZER
8. CONNECTION PAIRING BLUETOOTH
Operates the BLUETOOTH function.
9. DISPLAY
10. DIMMER
Adjusts the brightness of the display panel in 3 levels.
11. Remote control sensor
Receives signals from remote control.
12. PURE DIRECT
The indicator above the button lights up when the Pure Direct function is activated.
13. MASTER VOLUME
14. INPUT SELECTOR
(USB) port
15.
16. AUTO CAL MIC jack
