Samsung UN24H4000AF User Manual

LED TV

user manual

Transportation to and from the Service Center is the responsibility of
Figures and illustrations in this User Manual are provided for reference
the purchaser. Conditions covered are limited only to manufacturing
only and may differ from actual product appearance. Product design and
specifications may be changed without notice.
defects in material or workmanship, and only those encountered
Important Warranty Information Regarding in normal use of the product. Excluded, but not limited to, are
any originally specified provisions for, in-home or on-site services,
Television Format Viewing
minimum or maximum repair times, exchanges or replacements,
accessories, options, upgrades, or consumables.
✎
See the warranty card for more information on warranty
For the location of a SAMSUNG Authorized Service Center, please
terms.
call toll-free:
Wide screen format LED Displays (16:9, the aspect ratio of the
–– In the United States : 1-800-SAMSUNG (1-800-726-7864)
screen width to height) are primarily designed to view wide screen
format full-motion video. The images displayed on them should –– In Canada : 1-800-SAMSUNG
primarily be in the wide screen 16:9 ratio format, or expanded to
Still image warning
fill the screen if your model offers this feature and the images are
constantly moving. Displaying stationary graphics and images on Avoid displaying still images (such as jpeg picture files) or still
screen, such as the dark sidebars on non- expanded standard image elements (such as TV channel logos, TV shows or movies
format television video and programming, should be limited to no in panorama or 4:3 format, stock or news scroll bars, etc.) on the
more than 5% of the total television viewing per week. Additionally, screen. The constant display of still pictures can cause ghosting or
viewing other stationary images and text such as stock market image burn-in (image retention) on the LED screen, which will affect
reports, video game displays, station logos, web sites or computer image quality. To reduce the risk of this effect, please follow the
graphics and patterns, should be limited as described above for recommendations below:
all televisions. Displaying stationary images that exceed the above
• Avoid displaying the same TV channel for long periods.
guidelines can cause uneven aging of LED Displays that leave
• Always try to display any image in full screen mode. Use the TV's
subtle, but permanent burned-in ghost images in the LED picture.
Picture Options menu to select the optimal screen size.
To avoid this, vary the programming and images, and primarily
• Reduce brightness and contrast values to the minimum required
display full screen moving images, not stationary patterns or dark
to achieve the desired picture quality. Values that exceed the
bars. On LED models that offer picture sizing features, use these
minimum may speed up the burn-in process.
controls to view different formats as a full screen picture. Be careful
• Frequently use all TV features designed to reduce image retention
in the selection and duration of television formats you use for
and screen burn-in. Refer to proper user manual section for
viewing. Uneven LED aging as a result of format selection and use,
details.
as well as burned-in images, are not covered by your Samsung
limited warranty.
Contact SAMSUNG WORLD WIDE
• SAMSUNG ELECTRONICS NORTH AMERICAN LIMITED If you have any questions or comments relating to Samsung products,
WARRANTY STATEMENT please contact the SAMSUNG customer care center.
Subject to the requirements, conditions, exclusions and limitations
Country CANADA
of the original Limited Warranty supplied with Samsung Electronics
(SAMSUNG) products, and the requirements, conditions, exclusions
Samsung Electronics
and limitations contained herein, SAMSUNG will additionally Canada Inc. 2050 Derry
Address
Road West, Mississauga,
provide Warranty Repair Service in the United States on SAMSUNG
Ontario L5N 0B9 Canada
products purchased in Canada, and in Canada on SAMSUNG
products purchased in the United States, for the warranty period Customer Care
1-800-SAMSUNG (726-7864)
Center 
originally specified, and to the Original Purchaser only.
The above described warranty repairs must be performed by a www.samsung.com/ca/
support (English)
SAMSUNG Authorized Service Center. Along with this Statement, Web Site
www.samsung.com/ca_fr/
the Original Limited Warranty Statement and a dated Bill of Sale
support (French)
as Proof of Purchase must be presented to the Service Center.
BN68-05829K-01 © 2014 Samsung Electronics Co., Ltd. All rights reserved.
- 1 -
To delete channels from the Favorites list, follow these steps: Programmed List (on the Channel List Screen)
1. Select one or more channels in the Favorite Channels list
The Programmed list displays the channels and programs you
using the ▲/▼ buttons and the Yellow Select button on your
have scheduled for viewing using the Time Viewing function. You
remote.
can view, modify, or delete a show you have scheduled using the
functions on the Programmed List screen Tools menu.
2. Press the TOOLS button on your remote. The Tools menu
appears.
Programmed List Screen Tools Menu
3. Select Delete from Favorite in the Tools menu, and then
press the ENTERE button.
■ Change Info: Change the scheduling information for a show or
channel you have scheduled.
■ Timer Viewing: You can schedule a channel to be displayed
automatically at a set time, even when you are watching another To change the information, follow these steps:
channel. You must set the current time first in the Time > Clock
1. Select the Programmed List icon on the left side of the
function to use Time Viewing.
Channel List screen, and then press the ENTERE button.
To schedule a channel, follow these steps:
2. On the Programmed List screen, select the show or channel
1. Select a channel in the Added Channels list using the ▲/▼
entry you want to change, and then press the
buttons and the Yellow Select button on your remote.
The Tools menu appears.
2. Press the TOOLS button on your remote. The Tools menu
3. Select Change Info, and then press the ENTERE button.
appears.
The Time Viewing screen appears.
3. Select Time Viewing in the Tools menu, and then press the
4. Use the ◄/► buttons to move from entry field to entry field
ENTERE button. The Time Viewing screen appears. and the ▲/▼ buttons to change the entries. Where numbers
are displayed, you can also enter numbers directly using the
Timer Viewing
number keypad on your remote.
Antenna Channel Repeat
5. Press the ENTERE button when done.
▲
DTV Air 6-1 Once
■ Cancel Schedules: Cancel a show or channel you have
▼
scheduled.
Date Start Time
To cancel a scheduled show or channel, follow these steps:
01-01-2014 12 : 01 am
1. Select the Programmed List icon on the left side of the
L Move U Adjust E Enter R Return
Channel List screen, and then press the ENTERE button.
4. Use the ◄/► buttons to move from entry field to entry field
2. On the Programmed List screen, select the show or channel
and the ▲/▼ buttons to change the entries. Where numbers
entry you want to cancel, and then press the
are displayed, you can also enter numbers directly using the
The Tools menu appears.
number keypad on your remote.
3. Select Cancel Schedules, and then press the ENTERE
✎ If you select Everyday or Every Week, the date you
button. The Cancel Schedule screen appears.
select in the Date field becomes the start date for your
4. Select OK, and then press the ENTERE button.
scheduled viewing. For Everyday, the TV will turn on
every day, at the time you selected, starting from that ■ Information: Display the information for a show or channel you
date. For Everyweek, the TV will turn on every week, have scheduled. You can also change the schedule Information.
on the same day of the week as the start date you 1. Select the Programmed List icon on the left side of the
selected, at the time you selected, from that day on. If
Channel List screen, and then press the ENTERE button.
you select Once, the TV will turn on once, on the date
2. On the Programmed List screen, select the show or channel
and time you selected.
entry you want information for, and then press the
5. Press the ENTERE button on your remote when done.
button. The Tools menu appears.
✎ Only Added Channels can be scheduled. 3. Select Information, and then press the ENTERE button.
The Time Viewing Information screen appears.
✎
Scheduled programs and channels are displayed in the
4. Select Change Info and press the ENTERE button to
Programmed List.
change information, or select Close and press the ENTERE
✎ When you select a digital channel, press the ► button to
button to close the Information screen.
view the digital program list. If you highlight a program in
■ Select All / Deselect All: You can select or deselect all channels
the list, and then press the ENTERE(Schedule) button,
in the channel list.
you set Timer Viewing for that program directly.
■ Channel Name Edit: Analog channels only. Lets you assign a
name of up to five characters to an analog channel. For example,
Hist, Food, Golf, etc. This makes it easier to find and select a
channel.
■ Select All: Select all the channels in the displayed channel list.
■ Deselect All: Deselect all the selected displayed channels.
✎ You can only select Deselect All when one or more
channels are selected.
■ Auto Program: See Auto Program under Memorizing Channels.
- 5 -
[UH4000-ZA]BN68-05829K-01ENG.indb 1
Picture Options
The On Screen Menus
✎ When the TV is connected to a PC, you can only make
changes to the Color Tone, Size and HDMI Black Level.
Your TV has two kinds of menus, the Main menu and the various
Tools menus. The Main menu gives you access to most or all of ■ Color Tone (Cool / Standard / Warm): Cool makes the picture
bluer (cooler). Warm make the picture redder (warmer).
the menu options available on your TV. The Tools menus display
a selected number of frequently used menu options that change ■ Size: Set the size and aspect ratio of the picture on the screen.
Your cable box or satellite receiver may have its own set of
depending on the screen you are viewing.
screen sizes as well. However, we highly recommend you use
The Main menu has seven primary categories:
the TVs 16:9 mode most of the time.
✎ The menu is deactivated, when the H. 264 (1080p) DTV is
y Picture y Input
being played.
y Sound y Application 16:9: Sets the picture to the 16:9 wide screen format.
Zoom1: Provides moderate magnification of the picture. Sides,
y Channel y Support
top, and bottom are cut off.
Zoom2: Provides larger magnification of the picture. Sides, top,
y Setup
and bottom are cut off.
To view the Main menu, press the MENU button on your remote. To Wide Fit: Enlarges the aspect ratio of the picture so the picture
view a Tools menu, press the TOOLS button on your remote. fits the entire screen.
4:3: Sets the picture to the old, 4:3 format and puts black or gray
✎ The menu options that appear in the Main menu depend
borders on the right and left of the picture.
on the Source you have selected. For example, if you have
✎
Do not watch your TV in the 4:3 format for a long time.
selected the HDMI source, the Channel category will not
Traces of borders displayed on the left, right and center of
appear. To see the Channel category, you must first select TV
the screen may cause image retention (screen burn) which
in the Source List. is not covered by the warranty.
Screen Fit: Displays the full image without any cut-off when
The Menu options are presented below, arranged by Main menu
your TV is inputting HDMI (720p / 1080i / 1080p) or Component
t )
categories. A Tools button symbol ( next to an option
(1080i / 1080p) HD signals.
name indicates the option is also available in one of the Tools
✎ HD (High Definition) has a 16:9 aspect ratio and 1080i/1080p
menus.
(1920x1080) or 720p (1280x720) resolution.
✎ You can adjust and store settings for each external device you
Picture Menu
have connected to an input on the TV. Picture Sizes available
by Input Source are listed below:
Mode t
Input Source
Select your preferred picture mode.
ATV, AV, Component (480i, 480p)
✎ When your TV is connected to a PC, you can only select
Entertain and Standard
. DTV (1080i), Component (1080i, 1080p), HDMI
■ Dynamic: Brightens the screen. Suitable for a bright room. (720p, 1080i, 1080p)
■ Standard: Suitable for a normal. ■ Digital Clean View (Off / Low / Medium / High / Auto) : If the
broadcast signal received by your TV is weak, you can activate
■ Movie: Darkens the screen, making it less glary. Suitable for
the Digital Clean View feature to reduce any static and ghosting
watching movies in a darkened room.
that may appear on the screen.
■ Entertain: Sharpens the picture. Suitable for games.
✎ When the signal is weak, try all the Digital Clean View
✎ Only available when the TV is connected to a PC.
options until the TV displays the best picture.
Backlight / Contrast / Brightness / Sharpness /
■ HDMI Black Level (Normal / Low) : For HDMI signals, select
the black level to adjust the screen depth. Low make blacks look
Color / Tint (G/R)
darker.
■ Backlight: Adjusts the brightness of the screen by adjusting the
✎ Available only in HDMI mode (RGB signals).
brightness of the individual pixels.
■ Film Mode (Off / Auto) : Sets the TV to automatically sense and
■ Contrast: Increases or decreases the contrast between dark and
process film signals from all sources and adjusts the picture for
light areas of the picture.
optimum quality.
U.S.A ■ Brightness: Adjusts the brightness of the screen. Not as
✎ Available in ATV, DTV (interlace), AV, COMPONENT (480i /
effective as Backlight.
1080i) and HDMI (480i / 1080i).
Samsung Electronics
■ Sharpness: Sharpens or dulls the edges of objects.
■ Motion Lighting (Off / On): Reduce power consumption by
America, Inc. 85
■ Color: Adjusts the color saturation. The higher the Color setting,
Challenger Road brightness control adapted motion.
the more intense the color. Low settings remove color and the
Ridgefield Park, NJ 07660
✎ Available in Standard mode only.
picture becomes black, white and gray.
Picture Reset
■ Tint (G/R): Adjusts the amount of green and red in the picture.
As you increase the amount of green, the amount of red
■ Picture Reset (Reset Picture Mode/Cancel): Resets the
decreases and vice versa.
picture settings to their factory defaults.
www.samsung.com/us/ ✎ When the TV is connected to a PC, you can only make
support
changes to Backlight, Contrast, Brightness, and
Sharpness.
- 2 -
If you selected Manual:
❑ Other Channel Menu Functions
The Clock Set screen appears. Use the ▲/▼ buttons to
Channel Mode (Added Channels/Favorite change the values in each field or use the number buttons to
enter the values directly. Use the ◄/► buttons to move from
Channels)
field to field. When done with all the fields, press ENTERE.
Lets you select the channel list displayed when you press the
✎ Available only when Clock Mode is set to Manual.
t <CH> (Channel) button on your remote. For example, if you
■ Sleep Timer t
select Favorite Channels, you will only see Favorite channels when
you press the <CH> button. Automatically shuts off the TV after a preset period of time. (30,
60, 90, 120, 150 and 180 minutes).
Fine Tune
✎
To cancel the Sleep Timer, select Off.
Analog channels only.
Timer 1 / Timer 2 / Timer 3
If the reception is clear, you do not have to fine tune the channel,
as this is done automatically during the search and store Turns the TV on and off automatically at times and days you
operation. If the signal is weak or distorted, fine tune the channel select. You can set three different on/off timer settings.
TOOLS button.
manually.
✎ You must set the clock first.
✎
Select the channel, and then select Fine Tune.
■ On Time / Off Time: Set the hour, minute, am/pm, and
✎
Fine tuned channels that have been saved are marked with Activate/Inactivate fields for the On Time and Off Time. Use the
an asterisk "*" on the right-hand side of the channel number ◄/► buttons to move from field to field. Use the ▲/▼ buttons
in the channel banner. to change the values in each field. To activate the timer with
the setting you have chosen, set the Activate/Inactivate field to
✎ To reset fine-tuning, select the channel, select Fine Tune, and
Activate.
then select Reset on the Fine Tune screen.
■ Volume: Set the desired loudness.
■ Contents: To select what will be turned on when the timer
Setup Menu
setting is activated. You can set the TV to turn on a specific
channel or play back contents such as photo or audio files.
Plug & Play
Use the ◄/► buttons to move to move to the Contents field,
and then press the ENTERE button. The Contents screen
Lets you re-run the Plug & Play initial setup procedure. For
appears. Use the ◄/► buttons to move from field to field. Use
instructions, see your Quick Start Guide.
the ▲/▼ buttons to change the values in each field.
Language
TOOLS button.
- TV/USB: Select TV or USB. The USB device must be
connected to your TV before you can select USB.
Set the menu language.
✎ - Antenna: Displays the current antenna source, Air or Cable.
Choose between English, Español, and Français.
- Channel: If you have selected TV, select the desired channel.
❑ Setting the Time
- Music/Photo: If you have selected USB, follow these steps to
select a folder containing MP3 (Music) or JPEG (Photo) files on
Time
the USB device:
✎ The time you set will appear when you press the INFO
✎
The maximum displayed number of files, including sub
button.
folders, in one folder of USB storage device is 2000.
■ Clock: Set the clock so you can use the various timer features
✎ The media may not be playing smoothly when using the
of the TV.
TOOLS device lower than USB 2.0.
✎ If you disconnect the power cord, you have to set the
1. Use the ◄/► buttons to move to the field under Music
clock again.
or the field under Photo, and then press the ENTERE
To set the clock, follow these steps: button. The TV displays a single folder (the Root folder)
and the type or name of the device.
1. Select Setup >Time > Clock.
2. Press the ENTERE button. A list of folders on the device
2. Press ENTERE and select Auto or Manual, and then press
appears.
ENTERE again.
✎
If you selected Auto:
The TV will automatically download the correct time from a
digital channel.
• Select Time Zone, and then press the ENTERE button.
3. Use the ▲/▼ buttons to highlight a folder that contains
Use the▲/▼ buttons to select your Time Zone, and then
music or photos, and then press the Yellow select button
press ENTERE.
to select the folder.
• Select DST (Daylight Savings Time), and then press
4. Press the
ENTERE. Select On if you want to turn the DST
■ Repeat: Select Once, Everyday, Mon~Fri, Mon~Sat,
adjustment on and off manually. Select Off to turn off the
Sat~Sun or Manual. If you select Manual, you can select the
DST adjustment. Select Auto if you want the TV to adjust
days you want to activate the timer by using the ◄/► buttons
to DST automatically. Press ENTERE when done.
to highlight the day, and then pressing the ENTERE button.
✎ DST and Time Zone function are only available when
To unselect a day, highlight it, and then press the ENTERE
the Clock Mode is set to Auto.
button.
When you finished making all your selections on the Timer screen,
press either the ENTERE or
- 6 -
Sound Menu
Mode t
■ Standard: Selects the normal sound mode.
■ Music: Emphasizes music over voices.
■ Movie: Provides the best sound for movies.
■ Clear Voice: Emphasizes voices over other sounds.
Equalizer
Available in Standard sound mode only.
■ Balance L/R: Adjusts the balance between the right and left
speaker.
■ 100Hz / 300Hz / 1KHz / 3KHz / 10KHz (Bandwidth
Adjustment): Adjusts the loudness of specific bandwidth
frequencies.
■ Reset: Resets the equalizer to its default settings.
DTS TruSurround
Available in Standard sound mode only.
DTS TruSurround is a patented DTS technology that solves
the problem of playing 5.1 multichannel content over two
speakers. TruSurround delivers a compelling, virtual surround
sound experience through any two-speaker playback system,
including internal television speakers. It is fully compatible with all
multichannel formats.
Preferred Language
Digital channels only.
Digital-TV broadcasts can transmit many audio tracks
simultaneously (for example, simultaneous translations of a program
Picture Size
into foreign languages).
16:9, Zoom1,
✎ You can only select a language from among the ones being
Zoom2, 4:3
broadcast.
16:9, Wide Fit,
4:3, Screen Fit
Multi-Track Sound (MTS)
Analog channels only.
■ Mono: Select for channels that are broadcasting in mono or if
you are having difficulty receiving a stereo signal.
■ Stereo: Select for channels that are broadcasting in stereo.
■ SAP: Select to listen to the Separate Audio Program, which is
usually a foreign-language translation.
✎ Depending on the program being broadcast, you can listen to
Mono, Stereo or SAP.
Auto Volume
Automatically adjusts the volume level when you change video
sources or content so the level remains the same.
SPDIF Output
The SPDIF (Sony Philips Digital InterFace) outputs an
uncompressed digital audio signal when you connect the digital
audio jack on the back of the TV to a digital audio in jack on a
receiver or home theater.
■ Audio Format (PCM/Dolby Digital): You can select the Digital
Audio output (SPDIF) format. The available Digital Audio output
format may differ depending on the input source.
✎ By connecting the TV to a receiver or home theater with
Dolby Digital and 5.1ch speakers and selecting Dolby
Digital, you can maximize your interactive 3D sound
experience.
❑ Other Features
Program Rating Lock
The Program Rating Lock feature lets you block programs
you've determined are inappropriate for your children based on
the program's ratings. To access the Program Rating Lock
feature and make any changes, you must enter a PIN (personal
identification number). To watch a blocked program, you must also
enter the same PIN.
✎
Program Rating Lock is not available in HDMI or
Component mode.
✎ The default PIN number of a new TV set is "0-0-0-0". You can
set your own PIN using the Change PIN function.
How It Works
When you access the Program Rating Lock Menu functions for
the first time, the PIN input screen appears. Enter 0-0-0-0. The PIN
screen closes and the Program Rating Lock Menu appears. Every
time you access the Program Rating Lock functions, the PIN
screen will appear and you must enter a PIN.
When the Rating Lock screen appears, select Program Rating
Lock, and then press ENTERE. Select On, and then press the
ENTERE key again. Depending on what type of programs or
movies you want to block, select one of the options on the screen,
and then press the ENTERE button. The options are listed below:
■ TV Parental Guidelines: You can block TV programs based
on their ratings. This function allows you to control what your
children are watching.
■ MPAA Rating: You can block movies based on their MPAA
ratings. The Motion Picture Association of America (MPAA) has
implemented a rating system that provides parents or guardians
with advanced information on which films are appropriate for
children.
■ Canadian English: You can block TV programs based on their
Anglophone Canadian ratings.
■ Canadian French: You can block TV programs based on their
French Canadian ratings.
■ Downloadable U.S. Rating: Parental restriction information can
be used while watching DTV channels.
Locking/Blocking Programs or Movies
You lock or block programs and/or movies in essentially the same
way for each option. Each option displays a grid or table. All the
tables have ratings listed on the left. The TV Parental Guidelines
option also has kinds of content listed across the top: ALL: Lock all
TV ratings. / FV: Fantasy violence / V: Violence / S: Sexual situation
/ L: Adult Language / D: Sexually Suggestive Dialog.
To lock/block movies or shows with certain ratings and/or kinds of
content, click the square next to the rating and/or under the kind of
If there are no folders on your device, press the
content. A lock appears. To unlock/unblock, click the square again.
Yellow select button to select the Root folder, and
When you click a low rating, all the ratings above it will also display
then press the RETURN button. The Timer screen
locks. You can also Allow All or Lock All. When done, press the
re-appears.
RETURN button on your remote.
■ Change PIN: The Change PIN screen will appear. Choose any
4 digits for your PIN and enter them in Enter New PIN fields.
Re-enter the same 4 digits in Confirm New PIN fields. When the
RETURN button. The Timer screen re-appears.
Change PIN screen disappears, press the OK button. The TV
has memorized your new PIN.
✎ If you forget the PIN, press the remote-control buttons in
the following sequence, which resets the pin to "0-0-0-0" :
POWER (off) → MUTE → 8 → 2 → 4 → POWER
RETURN button.
■ Audio Delay: Lets you correct timing mismatches between the Air
audio track and the video when you are watching the TV and If your TV is connected to an antenna choose Air, and then press
listening to digital audio output from the TV through an external
ENTERE. The TV will automatically start memorizing channels.
device such as an AV receiver. When you select Audio Delay, a
Cable
slider appears. Use the left and right arrow buttons to adjust the
slider. Press ENTERE when done (0ms ~ 250ms). If your TV is connected to a cable outlet, choose Cable, and then
press ENTERE. Go to Step 3.
Speaker Select
Auto
A sound echo may occur due to a difference in decoding speed
If you choose Auto, and then press ENTERE, the TV will
between the main speaker and the audio receiver. In this case, set
automatically select the correct Antenna source. Go to Step 3.
the TV to External Speaker.
3. On the Cable Type screen, use the ◄/►/▲/▼ buttons to select
✎ When Speaker Select is set to External Speaker, the
the type of digital and analog cable systems you have: STD, HRC,
volume and MUTE buttons will not operate and the sound
or IRC. Most systems are STD (Standard). When done, select
settings will be limited.
Start, and then press ENTERE. The TV will start memorizing
✎ When Speaker Select is set to External Speaker.
channels.
x
TV Speaker: Off, External Speaker: On
✎ Channel memorization can take up to 45 minutes, depending
✎
When Speaker Select is set to TV Speaker. on your cable system.
x
TV Speaker: On, External Speaker: On ✎
Memorized channels are added to the Added Channels
✎ If there is no video signal, both speakers will be mute. list. These are the channels you will see when you use the
Channel buttons on your remote.
Visual Impaired
Clear Scrambled Channel
Digital channels only.
This function filters out scrambled channels after Auto Program is
Adds verbal description to the main audio to help the visually
completed. This process may take up to 20~30 minutes.
impaired.
✎ Press the ENTERE button to stop the Clear Scrambled
Sound Reset
Channel.
✎ This function is only available in Cable mode.
■ Reset All: Resets all sound settings to the factory defaults.
❑ Managing Channels
Channel Menu
Channel List
❑ Memorizing Channels See your list of Added channels, Favorite channels, or channels
you've scheduled for viewing. Add or delete Favorite channels, add
When you first set up your TV using Plug & Play, the TV
or delete channels from the Added Channels list, schedule channels
memorized the channels that were available over the air or through
or programs for viewing. Watch a channel by selecting the channel
your cable system and added them to the Channel List. The
in the All Channels, Added Channels, or Favorite screen, pressing
Antenna and Auto program functions described below let you
the ▲ / ▼ buttons, and then pressing the ENTERE button.
re-run the channel memorization function without having to re-run
the Plug & Play procedure. 6 Air
6-1 ♥ TV #6
Antenna (Air / Cable)
7-1 ♥ TV #7
Before your television can memorize the available channels, you
8 Air
must select your TV's signal source, Air (using an antenna) or
9 Air
Cable. Select MENU >Channel > Antenna > Air or Cable. After
9-1 ♥ TV #9
you have selected the signal source, go on to the Auto Program 10 Air
function. 10-1 ♥ TV #10
11-1 ♥ TV #11
✎ Selecting the signal source using the Antenna function also
Air ' Zoom '
determines the signal source the TV is tuned to. For example,
if you receive your TV signal over the air, and you select
Channel List Screens icons are listed on the left side. Select an
Cable, you will see only snow. You must select Air to see a
icon using the ▲/▼ buttons to view each list.
picture.
■ All Channels: Shows all currently available channels including
Auto Program
those you deleted from the Added Channels list.
Added Channels: Shows all Added Channels. These are the
The Auto Program function memorizes all channels that are ■
available over the air or through your cable system and adds them channels that appear when you press the
to the Channel List. ■ * Favorite: Shows all favorite channels.
To start Auto Program, follow these steps:
1. Push MENUm → Channel → Auto Program → ENTERE
on your remote. The Antenna Source screen appears.
2. On the Antenna Source screen, select the source of your TV
signal.
- 3 -
Game Mode (On/Off) Boot Logo
When you connect a game console such as a PlayStation™ Enable/disable displaying the logo while the TV starts up.
or Xbox™ to your TV, you can enjoy a more realistic gaming
Eco Solution
experience by turning on the Game Mode function.
✎ Precautions and limitations for game mode: ■ Energy Saving (Off / Low / Medium / High / Picture Off) :
This adjust the brightness of the TV in order to reduce power
x
Before you disconnect the game console and connect another
consumption. If you select Picture Off, the screen is turned
external device, set Game Mode to Off in the setup menu.
off, but the sound remains on. Press any button except volume
x
If you display the TV menu in Game Mode, the screen shakes
button to turn on the screen.
slightly.
■ Eco Sensor (Off / On): To enhance your power savings; the
✎ Game Mode is not available when the input source is set to
picture settings will automatically adapt to the light in the room.
TV.
✎ If you adjust the Backlight, the Eco Sensor will be set to
✎
After connecting the game console, set Game Mode to On.
Off.
You may notice slightly reduced picture quality.
Min. Backlight: When Eco Sensor is On, the minimum screen
Caption
brightness can be adjusted manually.
(On-Screen Text Dialogue) ✎
If Eco Sensor is On, the display brightness may change
(become slightly darker in most cases) depending on the
■ Caption: You can switch the caption function on or off. If
surrounding light intensity.
captions are not available, they will not be displayed on the
■ No Signal Power Off (Off / 15 min. / 30 min. / 60 min.): Sets
screen.
how quickly the TV switches to standby mode, if no picture is
✎ The Caption feature does not work in Component or
being received.
HDMI mode.
✎ Disabled when the PC is in power saving mode.
■ Caption Mode: You can select the desired caption mode.
■ Auto Power Off (Off / On): The TV will be automatically turned
Default / CC1~CC4 / Text1~Text4: (analog channels only) The
off when no user operation is received for 4 hours.
Analog Caption function operates in either analog TV channel
Auto Protection Time
mode or when a signal is supplied from an external device to the
TV. (Depending on the broadcasting signal, the Analog Caption
■ Auto Protection Time (Off / 2 hours / 4 hours / 8 hours / 10
function may or may not work with digital channels.)
hours): If the screen remains idle with a still image for a certain
Default / Service1~Service6 / CC1~CC4 / Text1~Text4: period of time you define, the screen saver is activated to prevent
the formation of ghost images on the screen.
(Digital channels only) The Digital Captions function works with
digital channels.
Support Menu
✎ Service1~6 may not be available in digital caption mode
depending on the broadcast.
■ Digital Caption Options: (Digital channels only)
Self Diagnosis
Size: Options include Default, Small, Standard and Large. The
■ Picture Test: Use to check for picture problems. If the problem
default is Standard.
appears in the test picture, select Yes and follow the directions
Font Style: Options include Default and Styles 0 to 7. The
on the screen.
default is Style 0.
■ Sound Test: Use the built-in melody sound to check for sound
Foreground Color: Options include Default, White, Black, Red,
problems. If the problem occurs during the test, select Yes and
Green, Blue, Yellow, Magenta and Cyan. You can change the
follow the directions on the screen.
color of the letters. The default is White.
■ Signal Strength: (Digital channels only) An HD channel's
Background Color: Options include Default, White, Black,
reception quality is either perfect or the channels are unavailable.
Red, Green, Blue, Yellow, Magenta and Cyan. You can change
Adjust your antenna to increase signal strength.
the background color of the captions. The default is Black.
■ Reset: Reset all settings to the factory defaults.
Foreground Opacity: This adjusts the opacity of text. Options
✎ The PIN input screen appears before the setup screen.
include Default, Transparent, Translucent, Solid and Flashing.
✎ Enter your 4-digit PIN. Change the PIN using the Change
Background Opacity: This adjusts the opacity of the
caption background. Options include Default, Transparent, PIN option.
Translucent, Solid and Flashing.
Software Upgrade
Return to Default: This option sets each Size, Font Style,
Software Upgrade can be performed by downloading the latest
Foreground Color, Background Color, Foreground Opacity
firmware from samsung.com to a USB memory device.
and Background Opacity to its default.
✎ Digital Caption Options are available only when you can
HD Connection Guide
select Default and Service1 ~ Service6 in Caption Mode.
Refer to this information when connecting external devices to the
✎
The Foreground and Background cannot be set to the
TV.
same color.
Contact Samsung
View this information when your TV does not work properly or
when you want to upgrade the software. You can find information
(on)
regarding our call centers and how to download products and
software.
- 7 -
■ Programmed: Shows all channels and programs currently
scheduled using Timer Viewing.
✎
Remote control buttons active on the Channel List screen.
x Green (Zoom): Enlarges or shrinks a channel number.
x
Yellow (Select): Move the cursor to a channel. Press the Yellow
button to select the channel. A c mark appears. Repeat to select
additional channels. Then, open the Tools menu and apply a
function to the channels you selected.
x
T (Tools): Displays the Channel List Tools menu. (The Tools
menus may differ depending on the situation.)
Display Icons Used in the Channel List Screens
Icons Meaning
c A selected channel.
* A Favorite channel.
) A reserved program.
A program currently being broadcast.
(
❑ The Channel List Tools Menu t
The Channel List Tools menu contains most of the functions you
can use on the All Channel, Added Channels, and Favorite List
screens. To view, select a list screen, select a channel, and then
press the TOOLS button.
■ Add / Delete: Delete a channel from or add a channel to the
Added Channels list.
To delete channels from the Added Channels list, follow these steps:
1. Select one or more channels in the Added Channels list using
the ▲/▼ buttons and the Yellow Select button on your remote.
2. Press the TOOLS button on your remote. The Tools menu
appears.
3. Select Delete in the Tools menu, and then press the ENTERE
button.
To add channels to the Added Channels list, follow these steps:
1. Select one or more channels in the All Channels list using the
▲/▼ buttons and the Yellow Select button on your remote.
2. Press the TOOLS button on your remote. The Tools menu
appears.
3. Select Add in the Tools menu, and then press the ENTERE
button.
✎ All deleted channels will be shown on the All Channels list.
You add channels back to the Added Channels list on the
Select T Tools
All Channels list.
✎
A gray-colored channel indicates the channel has been
deleted from the Added Channels list.
✎
The Add menu option only appears for deleted channels.
■ Add to Favorite/Delete from Favorite: Lets you add channels to
and delete channels from your Favorites list.
CH LIST button.
To add channels to the Favorites list, follow these steps:
1. Select one or more channels in the All Channels list using the
▲/▼ buttons and the Yellow Select button on your remote.
2. Press the TOOLS button on your remote. The Tools menu
appears.
3. Select Add to Favorite in the Tools menu, and then press the
ENTERE button.
POWER
P
- 4 -
Media Play
Enjoy photos, music and/or movie files saved on a
USB Mass Storage Class (MSC) device.
MEDIA.P
❑ Connecting a USB Device
1. Turn on your TV.
2. Connect a USB device containing photo, music, and/or movie
files to the USB jack on the back of the TV. A pop up window
appears.
3. Press the MEDIA.P button on your remote. The Media Play
menu appears.
❑ Using the Media Play Menu
Media Play
Videos
■
SUM Change Device E Enter R Return
To open Media Play in the Menu, follow these steps:
1. Press the MENU button. Then, press the ▲ or ▼ button to
select Application on the left, and then press the ENTERE
button.
2. Press the ▲ or ▼ button to select Media Play (USB), and then
press the ENTERE button.
3. Press the ◄ or ► button to select an icon (Videos, Music,
Photos, Settings), and then press the ENTERE button.
✎ Media Play might not work properly with unlicensed
multimedia files.
✎ Need-to-Know List before using Media Play (USB)
x The file system supports FAT16, FAT32 and NTFS.
x
Certain types of USB Digital camera and audio devices may not
be compatible with this TV.
x
Media Play only supports USB Mass Storage Class (MSC)
devices. MSC is a Mass Storage Class Bulk-Only Transport
device. Examples of MSC are Thumb drives and Flash Card
Readers. Devices should be connected directly to the TV's USB
port. USB HDD is not supported.
x
Before connecting your device to the TV, please back up your
files to prevent them from damage or loss of data. SAMSUNG is
not responsible for any data file damage or data loss.
x A USB device that requires high power (more than 0.5A) may not
be supported.
x
Do not disconnect the USB device while it is loading.
x The higher the resolution of the image, the longer it takes to
display on the screen.
x
The maximum supported JPEG resolution is 15360 x 8640 pixels.
x
If a file is corrupted or the TV does not support the file type, the
"Not Supported File Format" message appears.
x
The TV cannot play MP3 files with DRM that have been
downloaded from a for-pay site. Digital Rights Management
(DRM) is a technology that supports the creation, distribution,
and management of digital content in an integrated and
comprehensive way, including protecting the rights and interests
of content providers, preventing illegal copying of contents, and
managing billing and settlements.
- 8 -
2014-06-25 3:04:48
