Page 1: Safety Instructions
WASCOMAT Installation And Safety Instructions Full Size Tumble Action Washer P/N 134837300 (0611) Printed in U.S.A. -
Page 2: Table Of Contents
Product Record TABLE OF CONTENTS For GE warranty information or to contact a Wascomat Service SUBJECT PAGE Center, call 1-516-371-0700. Important Safety Instructions....3 Pre-Installation Requirements....4 If you need SERVICE or PARTS for your Wascomat coin- Electrical Requirements......4 operated washer: be ready to give the model number, serial number and date of purchase. -
Page 3: Important Safety Instructions
THE INTERLOCK SYSTEM IS REPAIRED, AND OPERATES AS DESCRIBED ABOVE. If you have questions regarding operation of this machine, or proper testing of the door interlock system, contact Wascomat Service at 1-516-371-0700. Important Safety Instructions Read all instructions before using this washer. -
Page 4: Pre-Installation Requirements
PRE-INSTALLATION REQUIREMENTS DRAIN REQUIREMENTS Tools Required for Installation: Models equipped with drain pump: 1/4 in. nut driver 3/8 in. socket with ratchet. Drain MUST be capable of eliminating 17 gals (64.3 L) per minute. 3/8 in. open end wrench. 7/16 in. socket with ratchet. A standpipe diameter of 1-1/4 in. -
Page 5: Rough-In Dimensions
ROUGH-IN DIMENSIONS < > (43.2) POWER CORD SIDE inch (cm) (11.2) > < (20.4) WATER INLETS UNDER COUNTER BACK inch (cm) -
Page 6: Unpacking
UNPACKING 1. Cut the shipping carton along the dotted line along the base 7. Remove the service panel from the front of the of the unit. washer. 2. While in the carton carefully lay the washer on its back side. 8. -
Page 7: Installation
INSTALLATION 1. Run some water from the hot and cold faucets to flush the 6. Carefully move the washer to its final location. water lines and remove particles that might clog up the water valve screens. NOTE: Do not use the dispenser drawer or door to lift washer. 2. -
Page 8: Replacement Parts
If replacements parts are needed for your washer, contact the source where you purchased your washer or call 516-371-0700 for the Wascomat Authorized Parts Distributor nearest you. For coin box parts, call 1-800-221-0982, Greenwald Industries. Destroy the carton and plastic bags after the washer is unpacked. -
Page 9: Meter Case Instructions
Meter Case Instructions INSTRUCTIONS TO CHANGE THE NUMBER OF COIN SLIDE INSERTIONS TO START APPLIANCE. 1. Disconnect power from machine. 2. Turn Shaft & Cam Assembly in a clockwise direction until switch lever arm drops into cam notch (Fig. 1). 3. - Page 10 CHANGING THE VEND PRICE ON A GREENWALD V8 COIN CHUTE CHANGING THE PRICE OF A V8 COIN CHUTE ID# 20-3000 1. Remove slide return spring (#15). 2. Remove slide stop (#22). 3. Remove slide (#12) from chute. 4. Turn slide upside down and remove screw (#38).
