Installation Guide
Network Camera
WV-SP306, WV-SP305
Model No.
WV-SP302
WV-SP306E, WV-SP305E
WV-SP302E
3 0 6
- S P
W V
Lens: Option
(This illustration represents WV-SP306.)
Before attempting to connect or operate this product, please read these
instructions carefully and save this manual for future use.
The model number is abbreviated in some descriptions in this manual.
Advertisement
Table of Contents
Related Manuals for Panasonic WV-SP306
Summary of Contents for Panasonic WV-SP306
-
Page 1: Installation Guide
3 0 6 - S P Lens: Option (This illustration represents WV-SP306.) Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. The model number is abbreviated in some descriptions in this manual. - Page 2 UL listed model No. • The connections should comply with local WV-SP306, WV-SP305, WV-SP302 electrical code. For Canada This Class A digital apparatus complies with Canadian ICES-003.
- Page 3 We declare under our sole responsibility that the product to which this declaration relates is in conformity with the standards or other normative documents following the provisions of Directives 2006/95/EC and 2004/108/EC. Wir erklären in alleiniger Verantwortung, daß das Produkt, auf das sich diese Erklärung bezieht, mit den folgenden Normen oder normativen Dokumenten übereinstimmt.
-
Page 4: Table Of Contents
Contents Important safety instructions ...................... 5 Limitation of liability ........................6 Disclaimer of warranty ........................ 6 Preface ............................6 About notations ......................... 7 Main functions ..........................7 About the user manuals ......................8 System requirements for a PC ....................9 Trademarks and registered trademarks.................. -
Page 5: Important Safety Instructions
Important safety instructions 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with dry cloth. 7) Do not block any ventilation openings. Install in accordance with the manufacturer's instruc- tions. -
Page 6: Limitation Of Liability
IMPROVEMENTS OF THIS PUBLICATION AND/OR THE CORRESPONDING PRODUCT (S). Disclaimer of warranty IN NO EVENT SHALL Panasonic System Networks Co., Ltd. BE LIABLE TO ANY PARTY OR ANY PERSON, EXCEPT FOR REPLACEMENT OR REASONABLE MAINTENANCE OF THE PRODUCT, FOR THE CASES, INCLUDING BUT NOT LIMITED TO BELOW:... -
Page 7: About Notations
The following notations are used when describing the functions limited for specified models. The functions without the notations are supported by all models. The functions with this notation are available when using the model WV-SP306. SP306 The functions with this notation are available when using the model WV-SP305. -
Page 8: About The User Manuals
It is also possible to save JPEG images at a network failure occurrence. (Download is possible.) * Recommended SDHC/SD memory card (☞ page 34) About the user manuals There are 2 sets of operating instructions for the WV-SP306, WV-SP305, WV-SP302 (NTSC model), WV-SP306E, WV-SP305E, WV-SP302E (PAL model) as follows. • Installation Guide: Explains how to install and connect devices. -
Page 9: System Requirements For A Pc
System requirements for a PC ® CPU: Intel Core 2 Duo 2.4 GHz or faster recommended Memory: 512 MB or more (A minimum of 1 GB memory is required when using ® ® ® ® Microsoft Windows 7 or Microsoft Windows Vista Network Interface: 10BASE-T/100BASE-TX 1 port... -
Page 10: Trademarks And Registered Trademarks
Trademarks and registered trademarks • Microsoft, Windows, Windows Vista, Internet Explorer, ActiveX and DirectX are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. • Intel and Intel Core are trademarks or registered trademarks of Intel Corporation in the United States and other countries. • Adobe, the Adobe logo, and Reader are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries. • SDHC logo is a trademark. • Other names of companies and products contained in these operating instructions may be trademarks or registered trademarks of their respective owners. -
Page 11: Precautions
Precautions Refer installation work to the dealer. Avoid installing this bracket in the loca- Installation work requires technique and experi- tions where salt damage occurs or corro- ences. Failure to observe this may cause fire, sive gas is produced. electric shock, injury, or damage to the prod- Otherwise, the mounting portions will deterio- uct. - Page 12 Turn the power off when do wiring of this Product disposal/transfer product. Images saved on the SDHC/SD memory card Failure to observe this may cause electric may lead to personal information leakage. shock. When it is necessary to dispose or give this In addition, short circuit or wrong wiring may product to someone, even when for repair, cause fire.
- Page 13 AVC Patent Portfolio License • When some SDHC/SD memory cards are This product is licensed under the AVC Patent used with this product, the product may Portfolio License for the personal and non- not work properly or performance deterio- ration may be caused.Use the SDHC/SD commercial use of a consumer to (i) encode memory cards recommended in page 34.
-
Page 14: Precautions For Installation
Precautions for Installation This camera is designed to be used Before installation indoors. • The camera mount bracket described on This camera is not operable outdoors. page 23 shall be used to mount the cam- Do not expose this camera to direct sunlight for era. - Page 15 Angle adjustment Be sure to loosen the screw of this product mount bracket when the camera angle is adjusted. If the camera angle is changed when the screw is tight, excessive force is applied to the camera mount bracket and camera, and accordingly they may be damaged.
-
Page 16: Major Operating Controls
Major operating controls <Side view> ALC lens connector Lens (option) Slide cover F.A. SDCARD LOCK SDCARD LOCK Auto back focus button SP306 Tripod mount base Focus assist button SP305 SP302 Clamp for SDHC/SD memory card <Rear view> Network connector Audio output connector 10BASE T/100BASE-TX Microphone/line input connector Access indicator... -
Page 17: Lens Mounting
Lens mounting Slowly rotate the lens clockwise to mount the lens and connect the lens cable to the ALC lens con- nector of the camera. Important: SP305 SP302 • It is impossible to use lenses without the focus adjustment function or zoom lenses. ALC lens connector Protruded portion from mount face: ø20 mm {25/32"} Zoom lock knob or less CS-mount lens... - Page 18 Note: • The most common use of a varifocal lens and a zoom lens Note that the adjustment method is different depending on the type. For further information, refer to the operating instructions for the lens to be used. Adjust the back focus after positioning the zoom ring at the "T" end and positioning the focus ring at a step short of the "F"...
- Page 19 When the focus ring is positioned near the best focus position, the position will automatically be memorized as the "PEAK HOLD" position. When the focus ring is moved, the current focus position will be indicated on "INDICATOR" Adjust the focus position so that the indicator value goes close to the "PEAK HOLD" position. When the indicator value goes to the best focus position, "BEST FOCUS"...
-
Page 20: Insert/Remove An Sdhc/Sd Memory Card
A R D L O C L O C (This illustration represents WV-SP306.) Screw of the clamp for SDHC/SD memory card Close the slide cover on the side of the camera. To remove the SDHC/SD memory card, rotate the clamp for SDHC/SD memory card 90 degrees counterclockwise, push the memory card to unlock it, and remove the memory card from the SDHC/SD memory card slot. -
Page 21: Installation
Installation Connect the safety wire The following is an example of safety wire connection. Important: • Be sure to install the safety wire. Ask your dealer for installation. Mounting screws For mounting on ceiling Tripod mount base Remove the tripod mount base on the top of Wire engaging Safety wire plate hole (rear) the camera. - Page 22 For mounting on wall Put the tripod mount base on the bottom of the camera. Secure the safety wire lug for wall (accessory) to the camera mount screw hole with the wire lug fixing screw (accessory). Wire lug fixing Wire engaging Important: screw (accessory) hole...
-
Page 23: Camera Mounting
Camera mounting The camera is mounted on the camera mount bracket and the safety wire is secured. Important: • The installation area shall be strong enough to hold the camera and camera mount bracket. • The camera mount bracket shall be mounted on the foundation part of the construction or a part with adequate strength. • To prevent the mounting strength from becoming lower, do not use wooden screws to secure the camera mount bracket. Secure the camera mount bracket to an installation position, and mount the camera on the camera mount bracket. - Page 24 Put the connection hook of the safety wire on the safety wire plate or the safety wire lug secured on the foundation part of the construction or a part with adequate strength. Important: • The safety wire shall be adjusted to remove slack. <For mounting on ceiling> <Mounting sample> Foundation part of construction or part with adequate strength Safety wire...
-
Page 25: Connection
AUX OUT ALARM OUT no problem with adjustment since the angle field of view is not affected.) (This illustration represents WV-SP306.) • The video output on the monitor for adjust- ment does not guarantee the video perfor- mance or image quality. Connect the microphone to MIC/LINE IN (for use of the audio reception function). - Page 26 4 3 2 1 q ALARM IN / DAY/NIGHT IN* w ALARM OUT * DAY/NIGHT IN is only for WV-SP306. Important: • Do not connect 2 wires or more directly to a terminal. When it is necessary to connect 2 or more wires, use a splitter.
- Page 27 (This illustration represents Specification of cable (wire): 16 AWG - 24 AWG, WV-SP306.) Single core, twisted • Check whether the stripped part of the wire is not exposed and is securely connected. e Tighten the screw of the power cord plug.
- Page 28 Connection example when connecting to a network using a PoE hub Video monitor (for adjustment use only) Speaker with amplifier (option) PoE device (hub) LAN cable (category 5 or better, straight, STP*) Microphone (option) LAN cable (category 5 or better, straight, STP*) Speaker with amplifier (option) LAN cable (category 5 or better, straight, STP*)
-
Page 29: Configure The Network Settings
When using multiple cameras, it is necessary to configure the network settings of each camera independently. If the Panasonic IP setting software does not work, configure the network settings of the camera and the PC individually on the "Network" page of the setup menu. Refer to the Operating Instructions (PDF) for further information. - Page 30 Start the Panasonic IP setting software. Click the [IP setting] button after selecting the MAC address/IP address of the camera to be configured. Note: • When using a DHCP server, the IP address assigned to the camera can be displayed by clicking the [Refresh] button of the IP setting software.
-
Page 31: Troubleshooting
Troubleshooting Before asking for repairs, check the symptoms with the following table. Contact your dealer if a problem cannot be solved even after checking and trying the solution in the table or a problem is not described below. Reference Cause/solution Symptom pages When using DC power supply... -
Page 32: Specifications
External I/O terminals: ALARM IN / DAY/NIGHT IN* ALARM OUT AUX OUT x1 each * DAY/NIGHT IN is only for WV-SP306. Microphone/Line input: ø3.5 mm monaural mini jack Input impedance: Approx. 2 kΩ For microphone input: Applicable microphone: Plug-in power type Supply voltage: 2.5 V ±0.5 V... - Page 33 1/500, 1/1000, 1/2000, 1/4000, 1/10000 Auto slow shutter: Off, Max. 2/30s, Max. 4/30s, Max. 6/30s, Max. 10/30s, Max. 16/30s Black & white mode*: On/ Off/ AUTO1/ AUTO2 * Only for WV-SP306 Simple black & white mode*: Off/AUTO * Only for WV-SP305 and WV-SP302 White balance: ATW1/ ATW2/ AWC...
- Page 34 FTP transmission is failed, backup on an optional SDHC/SD memory card is available.) Multi-screen: Up to 16 camera images can be displayed simultaneously on a multi-screen. Compatible SDHC/SD memory card (option): Manufactured by Panasonic SDHC memory card: 4 GB, 8 GB, 16 GB, 32 GB...
-
Page 35: Standard Accessories
SD memory card: 256 MB, 512 MB, 1 GB, 2 GB (except miniSD card and microSD card) *1 Either H.264 or MPEG-4 is selectable. *2 Transmission for 2 streams can be individually set in the same compression method. ® ® *3 Refer to "Notes on Windows Vista / Windows 7"... - Page 36 Panasonic Marketing Europe GmbH Three Panasonic Way, Secaucus, Winsbergring 15, 22525 Hamburg F.R.Germany New Jersey 07094 U.S.A. Panasonic Canada Inc. 5770 Ambler Drive, Mississauga, Ontario, L4W 2T3 Canada (905)624-5010 www.panasonic.ca © Panasonic System Networks Co., Ltd. 2010 Ns0310-1040 3TR006448BZA Printed in China...
