D-Link ™ DGE-530T
32-bit Gigabit Network Adapter
Manual
Version B1 (December 2005)
6DGE530T..05G
Printed in China
RECYCLABLE

Advertisement

Table of Contents
loading

Related Manuals for D-Link DGE-530T

Summary of Contents for D-Link DGE-530T

  • Page 1 D-Link ™ DGE-530T 32-bit Gigabit Network Adapter Manual Version B1 (December 2005) 6DGE530T..05G Printed in China RECYCLABLE...

  • Page 2: Table Of Contents

    Connecting the Network Cable ..........................3 Software Installation ............................4 ADVANCED FEATURES ..........................5 Wake On LAN ..............................5 QoS ..................................5 Jumbo Frames ..............................5 The D-Link SNMP Agent Utility ..........................6 SNMP ................................10 D-Link Network Control ............................11 The Cable Diagnostic Feature....................11 IEEE802.1p Priority Tagging ....................12 IEEE802.1Q VLANs......................13 Configuring the VLAN Settings .....................14...

  • Page 3: Introduction

    DGE-530T Gigabit Ethernet Adapter Card Introduction Thank you for choosing the D-Link DGE-530T, the value leader among Gigabit adapters for PCI Bus personal computers. This introduction gives a general description of the newer networking technologies found on the DGE-530T. The DGE-530T provides the bandwidth capability to support high-end servers and workstations.
  • Page 4 DGE-530T Gigabit Ethernet Adapter Card • Full-duplex Gigabit Ethernet interface that delivers 2Gbps aggregate bandwidth • Supports half and full duplex at 10Mbps, half and full-duplex at 100Mbps, and full-duplex operation at 1000Mbps • Supports for full-duplex double network throughput •...

  • Page 5: Installation

    Unpack and Inspect CAUTION: Under ordinary circumstances, a DGE-530T card will not be affected by a static charge that may be received through your body during handling of the unit. In special circumstances, the user may carry an extraordinarily high static charge and it is good practice to reduce the charge by touching a ground before handling the adapter card.

  • Page 6: Software Installation

    DGE-530T Gigabit Ethernet Adapter Card Software Installation The CD included with your DGE-530T is designed to make installation of necessary software a painless and trouble-free process. Simply click on the “Install Driver” button, and an Installation Wizard will guide you through the process, no matter which operating system you’re running. The included Adobe Acrobat Reader, which is needed to read or print out your user manual, will also come in handy for many other applications.

  • Page 7: Advanced Features

    This function increases end-user productivity by avoiding disruptions during working hours. The QoS function allows the DGE-530T to transmit and receive tagged frames, such as 802.1p priority tagged frames and 802.1Q VLAN tagged frames. In order for QoS to function on the DGE- 530T, it must be connected to a switch that supports and is configured for QoS.

  • Page 8: The D-Link Snmp Agent Utility

    Included on the installation CD is a program for viewing and configuring the DGE-530T, known as the D-Link SNMP Agent Utility. This agent will allow the user to view error packets, set passwords and choose NIC card options on your computer. This tool is only for computers running Windows 2000 and Windows XP operating systems.
  • Page 9 Window will then prompt the user to choose an Ethernet card from a pull down list. After choosing the D-Link DGE-530T Gigabit Ethernet Adapter and clicking OK, the user will be prompted with another window to input some personal information. You may input this information now or to set this information later, simply click OK.
  • Page 10 Clicking the Error Log tab will open the following screen. The Error log will display packets received by the DGE-530T, which were discarded due to an error. The user may choose to save these messages or clear them, using the appropriate buttons.
  • Page 11 To adjust your personal settings, click the Personal button, which will open the following screen. The user may set the following fields. Name: A name chosen to identify the user when configuring the DGE-530T. • Location: The user may identify the physical location of the computer where the Ethernet •...

  • Page 12: Snmp

    Devices that comply with SNMP correspond with management applications by sending alerts and updates, as well as allowing configuration changes. The DGE-530T’s SNMP agent will take event notices from the adapter, translate and then forward them to specified SNMP management stations.

  • Page 13: D-Link Network Control

    The distance of the fault can be reported to within one meter. To view the VCT window, simply double click the icon for the D-Link Network Control and select the VCT folder heading at the top of the window as seen below.

  • Page 14: Ieee802.1P Priority Tagging

    To test the diagnostic, first disconnect the cable from the remote end node so there is just an open cable connected to the DGE-530T. Click the appropriate adapter from the tree view above and then click the Start VCT button. The results which will appear in the table below will display the cable pairs, the status of the corresponding cable, the distance to the fault, and the status of the test.

  • Page 15: Ieee802.1Q Vlans

    DGE-530T Gigabit Ethernet Adapter Card IEEE802.1Q VLANs The IEEE802.1Q VLAN can help improve network performance and security by segmenting the network into VLANs. IEEE802.1Q VLANs can limit broadcast and node-to-node (unicast) traffic to a single VLAN. This limits the effects of broadcast storms and provides additional security for your network.

  • Page 16: Configuring The Vlan Settings

    DGE-530T Gigabit Ethernet Adapter Card Configuring the VLAN Settings To configure the VLAN settings for your DGE-530T, first open the D-Link Network Control utility located in the control panel of your computer, as shown below. Once opened, click the Virtual LAN tab at the top of the page, which will display the following screen.
  • Page 17 DGE-530T Gigabit Ethernet Adapter Card To add a VLAN setting to this window, click the Add VLAN button at the bottom of this screen, which will open the following configuration window. To set the VLAN, first select a Virtual LAN ID using the scroll up and down buttons. Available VLAN IDs are usually between 1 and 4094 but be sure to select the correct one, depending on the device’s settings to which the NIC is connected.
  • Page 18 DGE-530T Gigabit Ethernet Adapter Card the Virtual LAN Name field. The user can then adjust the Transmit and Receive Buffers in the following two fields, but it is recommended that the user not adjust these two unless they are sure of the proper settings. Once completed, click OK.

  • Page 19: Troubleshooting

    • The DGE-530T Adapter features four LED indicators: • Link/Activity – Steady green indicates good linkage between the DGE-530T and its supporting server or switch. Flashing green indicates activity (transmitting or receiving) within the adapter. •...

  • Page 20: Specifications

    Specifications EMC And Safety Certifications: • FCC Class B • CE Class B • BSMI Class B • C-Tick Host interface: 32-bit PCI Bus (Bus Master) I/O base address assigned by Plug and Play system Interrupt Number Assigned by Plug and Play system Physical Dimensions: 4.88 inches(L) x 2.17 inches (W) [124mm(L) x 51mm(W)] Environment:...

  • Page 21: Limited Warranty

    Spare parts and pare kits Ninety (90) days D-Link’s sole obligation shall be to repair or replace the defective Hardware at no charge to the original owner. Such repair or replacement will be rendered by D-Link at an Authorized D-Link Service Office.
  • Page 22 Submitting A Claim. Any claim under this limited warranty must be submitted in writing before the end of the Warranty Period to an Authorized D-Link Service Office. The claim must include a written description of the Hardware defect or Software nonconformance in sufficient detail to allow D-Link to confirm the same.
  • Page 23 This limited warranty provides specific legal rights and the product owner may also have other rights which vary from state to state. Trademarks Copyright 2005. D-Link Corporation. Contents subject to change without prior notice. D-Link is registered trademark of D-Link Corporation/D-Link Systems, Inc. All other trademarks belong to their respective proprietors.

  • Page 24: Fcc Warning

    FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 25 Any repair or replacement will be rendered by D-Link at an Authorized D-Link Service Office. The replacement hardware need not be new or have an identical make, model or part. D-Link may, at its option, replace the defective Hardware or any part thereof with any reconditioned product that D-Link reasonably determines is substantially equivalent (or superior) in all material respects to the defective Hardware.
  • Page 26 Any hardware, software, firmware or other products or services provided by anyone other than D-Link; and Products that have been purchased from inventory clearance or liquidation sales or other sales in which D-Link, the sellers, or the liquidators expressly disclaim their warranty obligation pertaining to the product.

  • Page 27: Product Registration

    Product Registration Register your D-Link product online at http://support.dlink.com/register/ Product registration is entirely voluntary and failure to complete or return this form will not diminish your warranty rights.
  • Page 28 The Limited Product Warranty set forth below is given by D-LINK (Europe) Ltd. (herein referred to as "D-LINK"). This Limited Product Warranty is only effective upon presentation of the proof of purchase. Upon further request by D-LINK, this warranty card has to be presented, too.
  • Page 29 (e) improper use or storage; or (f) fire, water, acts of God or other catastrophic events. This warranty shall also not apply to any particular product if any D-LINK serial number has been removed or defaced in any way.
  • Page 30 The replacement product need not be new or of an identical make, model or part; D-LINK may in its discretion replace the defective product (or any part thereof) with any reconditioned equivalent (or superior) product in all material respects to the defective product.
  • Page 31 Verarbeitungs- und Materialfehlern sind. Voraussetzung hierfür ist jedoch, dass das Produkt entsprechend dem Benutzerhandbuch und den weiteren Dokumentationen, die der Benutzer beim Kauf (oder später) erhalten hat, genutzt und gewartet wird. D-LINK garantiert nicht, dass die Produkte störungs- oder fehlerfrei arbeiteten oder dass alle Mängel, Fehler, Defekte oder Kompatibilitätsstörungen beseitigt werden können.
  • Page 32 FÜR DAS D-LINK HARDWARE-PRODUKT NICHT BEFOLGT WIRD. Laufzeit der eingeschränkten Garantie Die Laufzeit der eingeschränkten Garantie beginnt mit dem Zeitpunkt, zu dem das Produkt von D-LINK gekauft wurde. Als Nachweis für den Zeitpunkt des Kaufs gilt der datierte Kauf- oder Lieferbeleg. kann...
  • Page 33 Garantiegeber D-Link (Europe) Ltd. Floor, Merit House Edgware Road Colindale London NW9 5 AB Vereinigtes Königreich Telefon: +44-020-8731-5555 Fax: +44-020-8731-5511 www.dlink.co.uk...
  • Page 34 » utilisé dans la présente Garantie Produit Limitée D-LINK englobe uniquement les pays figurant dans la liste en annexe. La Garantie Produit Limitée sera honorée dans tout pays où D-LINK ou ses prestataires agréés proposent le service de garantie, sous réserve des modalités énoncées dans la présente Garantie Produit Limitée.
  • Page 35 Période de Garantie Produit Limitée La Période de Garantie Produit Limitée court à compter de la date d’achat auprès de D-LINK. La date de votre reçu ou bon de livraison correspond à la date d’achat du produit et constitue la date de votre preuve d’achat.
  • Page 36 à un Centre de Service Agréé D-LINK pendant la période de garantie. D-LINK assure la réparation ou le remplacement dans un Centre de Service Agréé D- LINK.
  • Page 37 (c) manejo incorrecto; (d) errores en artículos o servicios ajenos a D-LINK o no sujetos a una garantía o un...
  • Page 38 El período de la garantía limitada del producto se inicia en la fecha en que se realizó la compra a D-LINK. Para el comprador, el comprobante de la fecha de la compra es el recibo de la venta o de la entrega, en el que figura la fecha de la compra del producto. Puede ser necesario tener que presentar el comprobante de la compra a fin de que se preste el servicio de garantía.
  • Page 39 Garante D-Link (Europe) Ltd. Floor, Merit House Edgware Road Colindale London NW9 5 AB United Kingdom Teléfono: +44-020-8731-5555 Fax: +44-020-8731-5511 www.dlink.co.uk...
  • Page 40 (c) movimentazione impropria; (d) guasto di prodotti o servizi non forniti da D-LINK o non soggetti a una garanzia successiva di D-LINK o a un accordo di manutenzione; (e) impiego o conservazione impropri; (f) incendio, inondazione, cause di forza maggiore o altro evento catastrofico accidentale.

  • Page 41: Periodo Di Garanzia

    D-LINK o da qualsiasi suo rivenditore o distributore autorizzato decorre dal 1° gennaio 2004. Tutti i prodotti venduti nei Paesi europei da D-LINK o da uno qualsiasi dei suoi rivenditori o distributori autorizzati prima del 1° gennaio 2004 sono coperti da una garanzia di 5 anni fatto salvo per alimentatori, ventole e accessori che hanno 2 anni di garanzia.

  • Page 42: Technical Support

    Technical Support You can find software updates and user documentation on the D- Link website. Tech Support for customers within Australia: D-Link Technical Support over the Telephone: 1300-766-868 Monday to Friday 8:00am to 8:00pm EST Saturday 9:00am to 1:00pm EST D-Link Technical Support over the Internet: http://www.dlink.com.au...
  • Page 43 You can find software updates and user documentation on the D-Link website. Tech Support for customers within South Eastern Asia and Korea: D-Link South Eastern Asia and Korea Technical Support over the Telephone: +65-6895-5355 Monday to Friday 9:00am to 12:30pm, 2:00pm-6:00pm...
  • Page 44 Technical Support You can find software updates and user documentation on the D-Link website. Tech Support for customers within India D-Link Technical Support over the Telephone: +91-22-26526741 +91-22-26526696 –ext 161 to 167 Monday to Friday 9:30AM to 7:00PM D-Link Technical Support over the Internet: http://ww.dlink.co.in...
  • Page 45 Technical Support You can find software updates and user documentation on the D-Link website. D-Link provides free technical support for customers for the duration of the warranty period on this product. Customers can contact D-Link technical support through our web site or by phone.
  • Page 46 Technical Support You can find software updates and user documentation on the D-Link website. Tech Support for customers within the U.A.E & North Africa: D-Link Technical Support over the Telephone: (971) 4-391-6480 (U.A.E) Sunday to Wednesday 9:00am to 6:00pm GMT+4 Thursday 9:00am to 1:00pm GMT+4 D-Link Middle East &...
  • Page 47 You can find software updates and user documentation on the D-Link website. Tech Support for customers within South Africa and Sub Sahara Region: D-Link South Africa and Sub Sahara Technical Support over the Telephone: +27-12-665-2165 08600 DLINK ( For South Africa only )
  • Page 48 Technical Support You can find updates and user documentation on the D-Link website Tech Support for Latin America customers: D-Link Technical Support over the followings Telephones: Argentina: 0800-666 1442 Monday to Friday 09:00am to 22:00pm Chile: 800-214 422 Monday to Friday 08:00am to 21:00pm...
  • Page 49 Техническая поддержка Обновления программного обеспечения и документация доступны на Интернет-сайте D-Link. D-Link предоставляет бесплатную поддержку для клиентов в течение гарантийного срока. Клиенты могут обратиться в группу технической поддержки D-Link по телефону или через Интернет. Техническая поддержка D-Link: (095) 744-00-99 Техническая поддержка через Интернет...
  • Page 50 El servicio de soporte técnico tiene presencia en numerosos países de la Región Latino América, y presta asistencia gratuita a todos los clientes de D-Link, en forma telefónica e internet, a través de la casilla soporte@dlinkla.com Soporte Técnico Help Desk Argentina: Teléfono: 0800-6661442 Lunes a Viernes 09:00 am a 22:00 pm...
  • Page 51 Você pode encontrar atualizações de software e documentação de usuário no site da D-Link Brasil www.dlinkbrasil.com.br. A D-Link fornece suporte técnico gratuito para clientes no Brasil durante o período de vigência da garantia deste produto. Suporte Técnico para clientes no Brasil: Telefone São Paulo (11) 2185-9301...
  • Page 53 Technical Support You can find software updates and user documentation on the D- Link website. D-Link provides free technical support for customers within the United States and within Canada for the duration of the warranty period on this product. U.S. and Canadian customers can contact D-Link Technical Support through our website, or by phone.
  • Page 54 Technical Support You can find software updates and user documentation on the D-Link websites.D-Link provides free technical support for customers within Canada, the United Kingdom, and Ireland.Customers can contact D- Link technical support through our websites, or by phone. For Customers within The United Kingdom &...
  • Page 55 Telefon: +49 (1805)2787 Telefonische technische Unterstützung erhalten Sie Montags bis Freitags von 09.00 bis 17.30 Uhr. Unterstützung erhalten Sie auch bei der Premiumhotline für D-Link Produkte unter der Rufnummer 09001-475767 Montag bis Freitag von 6-22 Uhr und am Wochenende von 11-18 Uhr.
  • Page 56 Vous trouverez la documentation et les logiciels les plus récents sur le site web D-Link. Vous pouvez contacter le service technique de D-Link par notre site internet ou par téléphone. Support technique destiné aux clients établis en France: Assistance technique D-Link par téléphone :...
  • Page 57 D-Link . D-Link ofrece asistencia técnica gratuita para clientes dentro de España durante el periodo de garantía del producto. Los clientes españoles pueden ponerse en contacto con la asistencia técnica de D-Link a través de nuestro sitio web o por teléfono. Asistencia Técnica de D-Link por teléfono:...
  • Page 58 Supporto tecnico Gli ultimi aggiornamenti e la documentazione sono disponibili sul sito D-Link. Supporto tecnico per i clienti residenti in Italia D-Link Mediterraneo S.r.L. Via N. Bonnet 6/B 20154 Milano Supporto Tecnico dal lunedì al venerdì dalle ore 9.00 alle ore 19.00 con orario continuato...
  • Page 59 Technical Support You can find software updates and user documentation on the D-Link website. D-Link provides free technical support for customers within Benelux for the duration of the warranty period on this product. Benelux customers can contact D-Link technical support through our website, or by phone.
  • Page 60 Najnowsze wersje oprogramowania i dokumentacji użytkownika można znaleźć w serwisie internetowym firmy D- Link. D-Link zapewnia bezpłatną pomoc techniczną klientom w Polsce w okresie gwarancyjnym produktu. Klienci z Polski mogą się kontaktować z działem pomocy technicznej firmy D-Link za pośrednictwem Internetu lub telefonicznie.
  • Page 61 Technická podpora Aktualizované verze software a uživatelských příruček najdete na webové stránce firmy D-Link. D-Link poskytuje svým zákazníkům bezplatnou technickou podporu Zákazníci mohou kontaktovat oddělení technické podpory přes webové stránky, mailem nebo telefonicky Web: http://www.dlink.cz/suppport/ E-mail: info@dlink.cz Telefon: 0224247500 Telefonická podpora je v provozu:...
  • Page 62 Technikai Támogatás Meghajtó programokat és frissítéseket a D-Link Magyarország weblapjáról tölthet le. Telefonon technikai segítséget munkanapokon hétfőtől- csütörtökig 9.00 – 16.00 óráig és pénteken 9.00 – 14.00 óráig kérhet a (1) 461-3001 telefonszámon vagy a support@dlink.hu emailcímen. Magyarországi technikai támogatás : D-Link Magyarország...
  • Page 63 Teknisk Support Du kan finne programvare oppdateringer og bruker dokumentasjon på D-Links web sider. D-Link tilbyr sine kunder gratis teknisk support under produktets garantitid. Kunder kan kontakte D-Links teknisk support via våre hjemmesider, eller på tlf. Teknisk Support: D-Link Teknisk telefon Support:...
  • Page 64 Teknisk Support Du finder software opdateringer og bruger- dokumentation på D-Link’s hjemmeside. D-Link tilbyder gratis teknisk support til kunder i Danmark i hele produktets garantiperiode. Danske kunder kan kontakte D-Link’s tekniske support via vores hjemmeside eller telefonisk. D-Link teknisk support over telefonen: Tlf.
  • Page 65 Teknistä tukea asiakkaille Suomessa: D-Link tarjoaa teknistä tukea asiakkailleen. Tuotteen takuun voimassaoloajan. Tekninen tuki palvelee seuraavasti: Arkisin klo. 9 - 21 numerosta 0800-114 677 Internetin kautta Ajurit ja lisätietoja tuotteista. http://www.dlink.fi Sähköpostin kautta voit myös tehdä kyselyitä.
  • Page 66 Teknisk Support På vår hemsida kan du hitta mer information om mjukvaru uppdateringar och annan användarinformation. D-Link tillhandahåller teknisk support till kunder i Sverige under hela garantitiden för denna produkt. Teknisk Support för kunder i Sverige: D-Link Teknisk Support via telefon: 0770-33 00 35 Vardagar 08.00-20.00...

  • Page 68: International Offices

    No.71, Jianguo Road, Chaoyang District, Beijing, URL:www.dlink.dk URL: www.dlink.com.au 100025, China. Norway India TEL +86-10-58635800 Karihaugveien 89 D-Link House, Kurla Bandra Complex Road, FAX: +86-10-58635799 Off CST Road, Santacruz (East), Mumbai - 400098. N-1086 Oslo URL: www.dlink.com.cn Norway India Taiwan...
  • Page 69 5. What network management program does your organization use ? 6. What network medium/media does your organization use ? 7. What applications are used on your network? 8. What category best describes your company? 9. Would you recommend your D-Link product to a friend? 10.Your comments on this product?
