INSTALL GUIDE
Key-5 Advanced Remote Vehicle
Keyless Entry System
www.ultrastarters.com
Technical Support 866-698-5872
websupport@ultrastarters.com
FCC/ID Notice
This device complies with Part 15 of the FCC rules. Operation is subject to the following conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
CAUTION: Changes or modifications not expressly approved by the part responsible for compliance
void the user's authority to operate this devise.
Advertisement
Table of Contents
Related Manuals for Ultra Start Key-5
Summary of Contents for Ultra Start Key-5
- Page 1 INSTALL GUIDE Key-5 Advanced Remote Vehicle Keyless Entry System www.ultrastarters.com Technical Support 866-698-5872 websupport@ultrastarters.com FCC/ID Notice This device complies with Part 15 of the FCC rules. Operation is subject to the following conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
- Page 2 INSTALL MANUAL REMOTE VEHICLE KEYLESS PAGE 2 Table of Contents Table Of Contents Page 2 Contents. Feature List. Pre-Installation. Installation Tips. Main Wiring Diagram Page 3 Quick Start Installation Page 4 Wiring Description. Transmitter Operation. Transmitter Programming Page 5 System Reset Quick View Programming System Programming Page 6-7...
-
Page 3: Wiring Diagram
INSTALL MANUAL REMOTE VEHICLE KEYLESS PAGE 3 Wiring Diagram Antenna - Do Not Ground the antenna wire. (-)250ma Output Lock Output Green 12volts For Door Lock Module Only Unlock Output Blue (-)250ma Output Orange 250ma Maximum Output (-) Starter Kill Output (-) Horn Honk Output Brown 250ma Maximum Output... - Page 4 INSTALL MANUAL REMOTE VEHICLE KEYLESS PAGE 4 Quick Start Installation STEP 1 - The following wires MUST be connected for proper operation. (+15amp) 12volt Input Connect to constant 12volt power source Yellow (+) Ignition Input Connect to switched 12volt power source White (+15amp) Park Light Output Connect to positive park light source Black...
-
Page 5: Transmitter Programming
INSTALL MANUAL REMOTE VEHICLE KEYLESS PAGE 5 TRANSMITTER PROGRAMMING METHOD 1 1) Turn the ignition On-Off-On-Off-On-Off-On-Off. The park lights will flash twice. 2) Press the Lock button on the transmitters to be programmed. 3) The park lights will flash once, each time a new transmitter is learned. NOTE: The system can store a maximum of 3 transmitter codes in memory. - Page 6 INSTALL MANUAL REMOTE VEHICLE KEYLESS PAGE 6 PROGRAMMING Enter Programming: 1. Make sure ignition is in the OFF position. 2. Turn the ignition key ON - leaving key in the ON position. 3. Press the transmitter button in the appropriate sequence. The parking lights and the horn (optional) will flash the appropriate option.
- Page 7 INSTALL MANUAL REMOTE VEHICLE KEYLESS PAGE 7 PROGRAMMING Setting 4 - Door Lock Pulse 1. 3 Seconds 1 Flash/Honk 3 second LOCK/UNLOCK pulse. *2. 3/4 Second 2 Flashes/Honks 0.75 second LOCK/UNLOCK pulse 1. Turn the ignition key to the “ON” position. 2.
-
Page 8: Relay Diagrams
INSTALL MANUAL REMOTE VEHICLE KEYLESS PAGE 8 Relay Diagrams POSITIVE TRUNK RELEASE Trunk Release Solenoid Trunk Release Switch Grey +12V NEGATIVE PARK LIGHTS Parking Lights Parking Light Switch White Ground STARTER KILL Start Start To Starter Motor or Relay Orange...
