LCD MONITOR

TOUCH DISPLAY DRIVER 2

OPERATION MANUAL

Applicable models
LL-P202V/LL-S242A
for Mac
Version 1.0

Advertisement

Table of Contents
loading

Related Manuals for Sharp LCD MONITOR

Summary of Contents for Sharp LCD MONITOR

  • Page 1: Lcd Monitor

    LCD MONITOR TOUCH DISPLAY DRIVER 2 for Mac Version 1.0 OPERATION MANUAL Applicable models LL-P202V/LL-S242A...

  • Page 2: Table Of Contents

    • Transcribing or duplicating part or all of this manual and/or this software without permission from our company is not permitted. • As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice.

  • Page 3: Introduction

    Introduction System Requirements The touch display driver 2 is a program that enables you to use the touch panel to operate the computer that is connected to the touch panel. To use the touch panel, the touch panel must be connected to a computer, and the touch display driver 2 must be installed on the computer.

  • Page 4: Setting Up The Computer

    Setting up the Computer Install Caution • To install, an administrator name (user name) and password are required. • If an older version of the touch display driver 2 is installed, remove (uninstall) the old version before installing the touch display driver 2.

  • Page 5: Touch Panel Settings

    Touch Panel Settings The touch display driver 2 starts automatically and the icon ( ) appears on the menu bar. Caution • If LL-P202V and LL-S242A are connected at the same time, a screen for selecting the model will appear each time you select a setting.
  • Page 6 Touch Panel Settings nSettings when two devices are connected at the same time • If two displays of the same model are connected, touch operation will only be enabled on one model. • If LL-P202V and LL-S242A are connected at the same time, select the model to apply the touch panel settings to. * Two models cannot be set at the same time.

  • Page 7: Calibration

    If the automatically adjusted touch position is not correct, enter the display resolution (Width, Height) and click “Apply”. To check the monitor resolution, touch “Input Select” in the menu screen of the touch display. The resolution will be shown in the screen that appears. For details, see the LCD MONITOR manual.

  • Page 8: Properties

    Touch Panel Settings Properties Settings for the touch action can be configured in the properties. nDouble Click Range Set the range over which the position can shift between the first touch and the second touch and still be recognized as a double- click (“Narrow”...
  • Page 9 Touch Panel Settings nSecondary click You can set press and hold to be recognized as a secondary click.* Enable press and hold for secondary click When the checkbox is selected, press and hold is recognized as a secondary click. Press and Hold Duration Set the time until press and hold is recognized as a secondary click (“Short”...

  • Page 10: Pen Settings (Ll-P202V Only)

    Pen Settings (LL-P202V Only) Digitizer pen Settings for the digitizer pen can be configured. nButton Settings Assign functions to the function buttons of the digitizer pen. The factory default settings are shown below. Button action Function Press and release button1 * Secondary click Function button 1 Press button1 and move *...
  • Page 11 Pen Settings (LL-P202V Only) nPressure Settings Configure the pressure settings of the digitizer pen. Pen pressure Set pen pressure mode of the digitizer pen to Valid/Invalid. Pen pressure level adjustment Set the pen pressure at which the touch panel recognizes the pen. Pen pressure level test Shows the pen pressure level.

  • Page 12: Uninstall

    Uninstall Caution • To uninstall, an administrator name (user name) and password are required. 1. Disconnect the USB cable. 2. Execute uninstall. (1) Double-click the “TouchDisplay” folder, and then double-click the “Mac” folder. (2) Double-click “SharpDisplayDriver2 Uninstaller.app”. (3) Click “Uninstall”. •...

  • Page 13: Touch Action

    Touch Action Touch modes are finger/pen mode, pen-only mode, and finger- nCommon finger and pen actions only mode. The default setting is finger/pen mode. Same action as left-clicking a mouse. TIPS Touch with your finger/pen. • To change the touch mode, see the manual for the LCD MONITOR (LL-P202V/LL-S242A).
  • Page 14 Touch Action nFinger actions Pinch with two fingers Use in a screen that is capable of reduction/enlargement. Touch the screen with two fingers and move your fingers TIPS closer together to reduce the view, or apart to enlarge the view. • The screen may not respond correctly in the following cases: Touching is too quick The distance between the two points is too short...
  • Page 15 Touch Action Scroll left or right with two fingers / Swipe with two or Swipe left or right with three or four fingers three fingers Move an application to the front. Use cross page swipe. Swipe up with three or four fingers Display Mission Control. Swipe left from the right edge with two fingers Swipe down with three or four fingers Display the notice center. Display Application Exposé. Pinch with thumb and three fingers Tap with three fingers Touch the screen with 4 fingers, and move your thumb and 3 Check the tapped text in a dictionary or other resource.
  • Page 16 Touch Action Spread with thumb and three fingers Touch the screen with 4 fingers, and move your thumb and 3 fingers apart to show the desktop.
  • Page 17 LL-P202V/LL-S242A V1.0 DM EN14F(1)
