ADVANCED INTEGRATION A/V CONTROLLER
KOS-V1000
INSTRUCTION MANUAL
Take the time to read through this instruction manual.
Familiarity with installation and operation procedures will help you obtain the best
performance from your new Advanced Integration A/V Controller system.
For your records
Record the serial number, found on the back of the unit, in the spaces designated on the
warranty card, and in the space provided below. Refer to the model and serial numbers
whenever you call upon your Kenwood dealer for information or service on the product.
Model KOS-V1000 Serial number
US Residence Only
Register your Kenwood product at
www.Kenwoodusa.com
© B64-3584-00/00 (KV)
Register Online

Advertisement

Table of Contents
loading

Related Manuals for Kenwood KOS-V1000

Summary of Contents for Kenwood KOS-V1000

  • Page 1 Record the serial number, found on the back of the unit, in the spaces designated on the warranty card, and in the space provided below. Refer to the model and serial numbers whenever you call upon your Kenwood dealer for information or service on the product. Model KOS-V1000 Serial number...

  • Page 2: Table Of Contents

    Control Connecting an iPod Functions When Displaying the Easy Control Panel Functions While Displaying the Control Screen iPod List KOS-V1000 Basic Operations TV Watching Functions During TV Screen Functions When Displaying the Easy Control Panel Functions While Displaying the Control...
  • Page 3 External Device Power Supply Control External Device Power Supply Control Muting Audio Volume upon Reception of Phone call Muting Audio Volume upon Reception of Phone Call Character Entry How To Use the Character Entry screen Setup Menu Setup Menu Audio Setup Crossover Network Setup iPod Setup Software Information...

  • Page 4: How To Read This Manual

    For this reason, they may be different from the actual displays or panels used, or some display patterns may be different. KOS-V1000 Seek mode Sets a station selection. TUNER 98.1...
  • Page 5 If the optional monitor, KOS-L702 is connected to this unit, you can operate this unit by simply touching the buttons on the screen. English...

  • Page 6: Safety Precautions

    KOS-V1000 About disc changers connected to this unit Kenwood disc changers released in 1998 or later can be connected to this unit. Refer to the catalog or consult your Kenwood dealer for connectable models of disc changers.

  • Page 7: Notes

    • If you experience problems during installation, consult your Kenwood dealer. • When you purchase optional accessories, check with your Kenwood dealer to make sure that they work with your model and in your area. • We recommend the use of <Security Code Setup>...
  • Page 8 KOS-V1000 • Playing order of the Audio file In the example of folder/file tree shown below, the files are played in the order from ① to ⑩.
  • Page 9 About Picture files Acceptable picture files • Format: JPEG • Baseline format: Up to a maximum of 8192(W) × 7680(H) pixels • Progressive format: Up to a maximum of 1600(W) × 1200(H) pixels ⁄ • Enlarges and reduces images up to the size shown above to fit to the screen.

  • Page 10: Basic Operations

    Enters options. Adjusts the volume Attenuates the volume Press it again to cancel muting. Switches AV OUT source Switches the source that is output at the AV OUTPUT terminal when it is pressed. KOS-V1000 DISP V.SEL ZOOM MENU POSITION •...

  • Page 11: Battery Installation

    ¤ • Put the Remote Controller in a place where it will not move during braking or other operations. A dangerous situation could result, if the Remote Controller falls down and gets wedged under the pedals while driving. • Do not place the battery near an open flame or heat source. This may cause the battery to explode. •...

  • Page 12: Playing A Usb Device

    Even if the USB is removed and connected again, the playback will start from the last stopped point unless the contents in the USB device is changed. • Make sure that the USB device is connected firmly. KOS-V1000 DISP V.SEL...
  • Page 13 Switches the video source The video source switches in the following order each time you press the button. Video iPod Rear Camera Navigation When you press the button again, the previous video display comes back on. ⁄ • The Rear view camera video is displayed when the vehicle's gear is in "Reverse". •...
  • Page 14 The function control screen switches in the following order each time you press the button. Picture & Easy Control Panel Source Control Screen Picture Panel (OFF) The following buttons are always displayed on the source control screen. KOS-V1000 DISP V.SEL ZOOM MENU POSITION •...
  • Page 15 Audio files (AUD mode) Folder search Selects the folder to be played. Radio (AUD mode) Band switching Switches to bands received by the unit. Direct tuning After pressing this key, use the numeric keypad to specify the broadcast station you wish to receive.
  • Page 16 Basic Operations NAVI (NAVI mode) Joystick Scrolls the map, or moves the cursor. ENTER Performs the selected function. ZOOM Zooms in or out the navigation map. MENU Displays Main menu. KOS-V1000 DISP V.SEL ZOOM MENU POSITION • • ENTER •...
  • Page 17 CANCEL Displays previous screen. POSITION Displays the current position. Hands-free communication Enters the dialing method selection mode. When a call comes in, it answers the call. English...

  • Page 18: Usb Device Control

    See <External Device Power Supply Control> (page 46). ⁄ • The Easy Control Panel display is hidden when you touch a central area of the monitor. KOS-V1000 Functions while displaying the Control Screen Switches to control screen to use various playback functions.

  • Page 19: Usb List

    3 Selects a folder. (Only in Folder Select Mode)* 4 Selects a file. 5 Plays or pauses. 6 Switches the button display. 7 Starts or stops Scan Play (that plays the beginning of each music one after the other). 8 Repeats to play (the present music). 9 Starts or stops Random Play (to play music in random order).

  • Page 20: Folder Select

    2 Lists folders and Audio files Folder opens when touched, and the Audio file is played. 3 Moves to the top hierarchy level. 4 Moves up a hierarchy level. 5 Displays the currently playing file. 6 Returns to the original screen. KOS-V1000...

  • Page 21: Music Disc Listening

    Music Disc Listening You can recall various control screens during Disc Changer playback. Functions When Displaying the Easy Control Panel Displays a floating control panel in the screen. MODE/TOP MENU FNC/MENU/PBC AUDIO RETURN ROUTEM VOICE CANCEL AV OUT OPEN SUBTITLE VIEW MAP DIR ANGLE...

  • Page 22: Functions While Displaying The Control Screen

    Starts or stops Magazine Random Play (to play songs of the disc changer in random order). KOS-V1000 y Sets a name to the disc being played. u Displays a list of discs in the Disc changer i Displays the external device control ⁄...

  • Page 23: Disc Select

    End Name set Disc Select Displays a list of discs in the Disc changer and allows you to select the disc to listen. Start Direct Select Select a Disc 1 Scrolls the list. 2 Lists the discs. Plays when touched. 3 Switches the list name to Disc name or Disc Text.

  • Page 24: Radio Listening

    See <External Device Power Supply Control> (page 46). ⁄ • The Easy Control Panel is hidden when you touch a central part of the monitor. KOS-V1000 Functions While Displaying the Control Screen Switch to control screen to use various functions. NAVI...

  • Page 25: Seek Mode

    6 Switches the button display. 7 Turns the CRSC function On or Off. (Only when receiving the FM broadcast) 8 Selects the Auto Memory mode. (Refer to page 26 for the <Auto Memory>) 9 Switches the Seek mode. (Refer to page 25 for the <Seek Mode>) p Switches the number of lines displayed in the Information Display.

  • Page 26: Auto Memory

    ⁄ • The operation ends automatically if you do not operate within 10 seconds. KOS-V1000 Manual Memory Stores the current receiving station in memory. Select a station you wish to store in...

  • Page 27: Preset Select

    Preset Select Lists and selects memorized station. Start Preset Select Selects a station 1 Scrolls the list. 2 Memorized stations are displayed. Touch to tune in. 3 Switches the list display name to Station name or Program Service Name. 4 Returns to the original screen. Radio Text You can display the radio text.

  • Page 28: Set Station Name

    End Name set ⁄ • You can enter characters only after you have applied the parking brake. KOS-V1000 Direct Search Tunes in a station when its frequency is entered. Select a band AV OUT...

  • Page 29: Traffic Information

    Traffic Information When a traffic bulletin starts, any source is switched to the traffic information and it is displayed automatically. Set the Traffice information mode When the traffic bulletin starts... The Traffic Information screen appears automatically. Traffic Information screen ⁄ •...

  • Page 30: Ipod Control

    (Resume Function). • If the played song is not a video content, "No iPod Video Signal" is displayed on the video screen. • While connecting an iPod, "KENWOOD" appears on the iPod and the iPod's control is disabled. KOS-V1000 Functions When Displaying the Easy Control Panel Displays a floating control panel in the screen.

  • Page 31: Functions While Displaying The Control Screen

    Functions While Displaying the Control Screen Switches to control screen to use various playback functions. NAVI MODE/TOP MENU FNC/MENU/PBC AUDIO RETURN ROUTEM VOICE CANCEL AV OUT OPEN SUBTITLE VIEW MAP DIR ANGLE FM + NAVI AUDIO RETURN MODE/TOP MENU FNC/MENU/PBC ROUTEM VOICE CANCEL...

  • Page 32: Ipod List

    If music title is displayed, the music is played by touching it. is touched, all the music in its category is played. 3 Returns to previous category. 4 Moves to the top category. 5 Displays the currently playing category. KOS-V1000...

  • Page 33: Tv Watching

    TV Watching Various control screens appear in the TV Source mode. (You can only operate TV with the optional accessory TV Tuner connected.) Functions During TV Screen Basic functions are available even when the TV screen is displayed. Display the TV screen DISP V.SEL ZOOM...

  • Page 34: Functions While Displaying The Control Screen

    4 Switches the button display. 5 Selects the Auto Memory mode. Refer to <Auto Memory> (page 35). 6 Switches the Seek mode. Refer to <Seek Mode> (page 34). KOS-V1000 7 Indicates current Seek mode. 8 Memory Number Display 9 Channel Number Display p When...

  • Page 35: Auto Memory

    Auto Memory Stores stations with good reception in memory automatically. Select a band you wish to store in memory Select the Auto Memory mode Start Auto Memory Auto Memory terminates when 6 stations are stored or when all stations are tuned in. ⁄...

  • Page 36: Set Station Name

    End Name set ⁄ • You can enter characters only after you have applied the parking brake. KOS-V1000 Direct Search Tunes in a station when its channel number is entered. Select a band...

  • Page 37: Video Watching

    Video Watching Functions When Displaying the Easy Control Panel Displays a floating control panel in the screen. 1 Video switch Area Switches to Video1/Video2. MODE/TOP MENU FNC/MENU/PBC AUDIO RETURN ROUTEM CANCEL VOICE AV OUT OPEN SUBTITLE VIEW MAP DIR ANGLE FM + 2 Switches the source.

  • Page 38: Satellite Radio Control

    • For system button operations, see <Basic operations> (page 10). • The Easy Control Panel display is hidden when you touch a central area of the monitor. KOS-V1000 Functions While Displaying the Control Screen Switches to control screen to use various functions.

  • Page 39: Channel Search

    6 Switches the Seek mode. SEEK 1: Tunes channels one after the other. SEEK 2: Selects channels in memory one after the other. 7 Switches the number of lines displayed in the Information Display. 8 Indicates current Seek mode 9 When buttons appear, you can recall the channel on memory.

  • Page 40: Channel Memory

    Select a channel you wish to store in memory Store in memory Continue to touch until the memory number appears. KOS-V1000 Direct Channel Search Tuning in by entering the desired channel number. Start Direct Channel Search Displays the Direct Search screen.
  • Page 41 : Press for # seconds. English...

  • Page 42: Hd Radio Control

    See <External Device Power Supply Control> (page 46). ⁄ • The Easy Control Panel display is hidden when you touch a central area of the monitor. KOS-V1000 Functions While Displaying the Control Screen Switches to control screen to use various functions.

  • Page 43: Seek Mode

    6 Selects the Auto Memory mode. Refer to <Auto Memory> (page 44). 7 Switches the Seek mode. Refer to <Seek Mode> (page 43). 8 Switches the number of lines displayed in the Information Display. Selects the channel on memory. p The Receive mode switches in the following order.

  • Page 44: Auto Memory

    Select the Auto Memory mode Start Auto Memory Auto Memory terminates when 6 stations are stored or when all stations are tuned in. KOS-V1000 : Press for # seconds. Manual Memory Stores the current receiving station in memory. Select a station you wish to store in...

  • Page 45: Source Select

    Source Select The source you wish to listen to can be selected quickly. Displaying the Control Screen Display control screen MODE/TOP MENU FNC/MENU/PBC AUDIO RETURN ROUTEM VOICE CANCEL AV OUT OPEN SUBTITLE VIEW MAP DIR ANGLE FM + Press several times until the Control Screen appears.

  • Page 46: External Device Power Supply Control

    • You must connect a commercially available relay unit in order to use this function. Connect the external device to be controlled to that relay unit. • Refer to <EXT SW Setup> (page 72) for information on setting the power on or off specification. KOS-V1000...

  • Page 47: Muting Audio Volume Upon Reception Of Phone Call

    Muting Audio Volume upon Reception of Phone call Muting Audio Volume upon Reception of Phone Call When the telephone is called, the system is paused automatically. When the telephone is called... The Phone Call ("CALL") screen appears, and system is paused. Phone Call ("CALL") screen If you want to continue to listen to the audio source during phone call...

  • Page 48: Character Entry

    3 Enters characters. 4 Scrolls up or down the character button display. 5 Exits the Character Entry mode and returns to the previous screen. ⁄ • You can enter characters only after you have applied the parking brake. KOS-V1000...

  • Page 49: Screen Control

    Screen Control Screen Control Setting the monitor screen. Display Easy control panel MODE/TOP MENU FNC/MENU/PBC AUDIO RETURN ROUTEM VOICE CANCEL AV OUT OPEN SUBTITLE VIEW MAP DIR ANGLE FM + Display the Screen Control screen Adjust the picture quality 1 Brightness Control Disabled if Auto Dimmer is On.

  • Page 50: Hands Free Unit Control

    White: The cell-phone is connected. Orange: The cell-phone is not connected, or it is outside the service range. Display the Hands-Free Control screen KOS-V1000 NAVI RETURN CANCEL 2 Displays the Search for Phone Book screen. 3 Displays the Out Going Calls screen.

  • Page 51: When Called

    ⁄ • While your car is moving, some functions are disabled for safety’s sake. The buttons associated with the disabled functions become ineffective if pressed. • When the Hands-Free Control screen appears, the name of the connected cell-phone is displayed for 5 seconds. •...

  • Page 52: Quick Dialing

    • Only the phone numbers can be registered for Quick Dialing. Therefore, the destination subscriber name and others are not displayed during dialing. KOS-V1000 Calling by Phone Book You can call a person using his/her phone number that you have registered in the Phone Book.
  • Page 53 Phone Book List screen Phone Book List Kenwood 0426465116 Kenwood name name name name 4 Scrolls the list. 5 Enters the destination name. 6 Cancels the operations. 7 Returns to the Hands-Free Control screen. Select a destination you wish to call...

  • Page 54: Redialing

    5 Returns to the Hands-Free Control screen. Select a destination you wish to call Redial Father 0123456789 Mother 0123456789 Brother 0123456789 Sister 0123456789 Kenwood 0123456789 KOS-V1000 Confirm the destination Redial Father 0123456789 Mother 0123456789 Brother 0123456789 Sister 0123456789 Kenwood 0123456789 The Hands-Free Control screen appears again.

  • Page 55: Setting Up The Hands-Free Phone

    Setting up the Hands-Free Phone The Hands-Free system can be set as follows. Hands-Free Set Up screen Hands Free SETUP Auto Response Phone Voice Front L Beep Select Remove 1 Sets an automatic response time after call termination. ( "8") "Off": This function can not use.

  • Page 56: Deleting The Hands-Free Phone

    2 Returns to the Hands-Free Set Up screen. Select a Hands-Free phone you wish to delete Remove Father Mother Brother1 Brother2 Sister KOS-V1000 ⁄ • The Phone Book, outgoing call list, and incoming call list are deleted together with the deleted Hands-Free phone. AUTO Remove AUTO AUTO...
  • Page 57 English...

  • Page 58: Setup Menu

    Display the setup Menu Select the setup item 1 The selected setup screen appears. 2 Scrolls the setup menu. KOS-V1000 Audio Setup You can setup a speaker network, etc. Display the Audio SETUP screen Touch [Audio SETUP] in the SETUP Menu...

  • Page 59: Crossover Network Setup

    Crossover Network Setup You can set a crossover frequency of speakers. Select the speaker to set the crossover 1 Sets the High Pass Filter of the front speaker. 2 Sets the High Pass Filter of the rear speaker. 3 Sets the Low Pass Filter of the sub woofer. 4 Switches to the crossover setup screen.

  • Page 60: System Setup

    "Off": Uses the tuner of your vehicle to receive a radio station. 7 Returns to the original screen. KOS-V1000 ⁄ • * In order to receive a radio station with the built-in tuner, you need to connect an antenna cord. Refer to <Connection>...
  • Page 61 4 Selects a navigation system connection. RGB) "RGB": Allows the Kenwood’s Navigation System to connect via its interface cable. "AV-IN": Allows a third-party navigation system to connect via the AV INPUT1 port. "Off": Must be used if no navigation system is connected. (The navigation display is cancelled when the AV source is switched.)

  • Page 62: User Interface

    <Background Delete> (page 64). 3 Sets whether to display the target when touching the panel. 4 Returns to the original screen. KOS-V1000 5 Sets an on-screen display of the iPod Playback screen. ( "Auto": "Manual": Information is displayed when 6 Sets an on-screen display of the navigation screen.

  • Page 63: Entering Background

    p Sets an on-screen display of the TV screen. Auto) (with the optional accessory TV tuner connected only) "Auto": Information is displayed for 5 seconds when updated. "Manual": Information is displayed when you touch on the screen. q Returns to the original screen. w Sets whether to display animation when switching screens.

  • Page 64: Background Delete

    Delete the image Background Delete Confirm Background Delete Would you like to delete Background? 2 Returns to the Pictrue Select screen. KOS-V1000 Background Select Selects a image for background. Select Background Select screen Select a image for background Background Change 10:10 Cancel 1 Returns to the initial background.

  • Page 65: Touch Panel Adjustment

    Touch panel Adjustment You can adjust the touch panel operations. Display the Touch panel Adjustment screen Touch [Touch] in the SETUP Menu (page 58). Starts Touch panel setup 1 Returns to the original screen. Adjusts the Touch panel Follow the instruction on the screen and touch the center of 2 Cancels the adjustment and returns to the Touch Panel Adjust screen.

  • Page 66: Monitor Setup

    7 Selects a screen mode of the VIDEO2 playback screen. You can select any of the following screen mode. "Full", "Just", "Zoom", "Normal" KOS-V1000 8 Selects a screen mode of the VIDEO2 playback screen. You can select any of the following screen mode.
  • Page 67 Full picture mode (Full) Zoom picture mode (Zoom) Justify picture mode (Just) Normal picture mode (Normal) English...

  • Page 68: Security Code Setup

    2 Returns to the original screen. Start Security Code setup ⁄ • If you have already completed the code registration, is displayed. KOS-V1000 Enter a security Code Input four-digit number. Register your security code Reenter the security code Reenter the same security code as that you have entered in Step 3 for confirmation.

  • Page 69: Deactivating Security Code

    If you have pressed the Reset button or if you have disconnected the Receiver from battery... Enter the correct security code You must enter the same security code as that you have entered in Step 3. Enter the security code Now, you can use your Receiver.

  • Page 70: Sat Esn Watch Setup

    2 Select a setup option. 3 Selects a set value. 4 Enters the set value. 5 Returns to the original screen. KOS-V1000 ⁄ • For the model name of amp you can control from the system, see the amp’s catalog.
  • Page 71 4 Recalls the memorized settings. 5 Memorizes the current Audio Set Up and AV Interface settings. 6 Clears the currently memorized settings. 7 Returns to SETUP Memory screen. Memorize or recall the settings When memorizing the Audio Set Up and AV Interface settings: If settings have already been memorized, a confirmation message appears.

  • Page 72: Ext Sw Setup

    200ms with each step. Up to 100 steps can be set. 4 Returns to the original screen. KOS-V1000 Setting EXT SW Control 2 (EXT SW2) The setup method is the same as "EXT SW1". Setting EXT SW Control 3 (EXT SW3) The setup method is the same as "EXT SW1".
  • Page 73 English...

  • Page 74: Audio Control

    Press several times until the control screen appears. Display the Audio Control menu Select the Audio Control item 1 Switches to the selected Audio Control screen. KOS-V1000 Audio Control You can adjust the front/rear and right/left audio balance. Display Audio Control NAVI...

  • Page 75: Equalizer Control

    6 Adjusts the bass boost of the B.M.S power amplifier (optional accessory). 7 Sets the center frequency of bass boost you have set for "AMP Bass". If you set the center frequency to "Low", it will be dropped approximately 20% to 30%. 8 Adjusts the subwoofer volume.

  • Page 76: Tone Setup

    7 Sets the level. 8 Sets the Q factor. (Only Bass and Middle can be set) 9 Returns to the original screen. KOS-V1000 Zone Control You can set the front and rear audio source. Display Zone Control Touch [Zone Control] in the Audio Control Menu (page 74).
  • Page 77 ⁄ • When the rear speaker sound is switched, the audio source that is output at the AV OUTPUT terminal is also switched to the same source. However, if you have set the "Area" to "Reverse", the audio source that is output at the AV OUTPUT terminal is switched depending on the front sound source.

  • Page 78: Help? Troubleshooting

    • Cannot set up the crossover network. The Dual zone function is enabled. Control> (page 76) KOS-V1000 What might seem to be a malfunction in your unit may just be the result of slight misoperation or miswiring. Before calling service, first check the following table for possible problems.
  • Page 79 HD Radio source No sound can be heard, or the volume is low. ✔ The preset broadcast station is not transmitting in the mode that was set with <HD Radio Control> (page 42). ☞ Please set <Receive mode Setting> to "Auto".

  • Page 80: Help? Error

    ➡ Push the unit's Reset button. If the "Error 07−67" message does not disappear, see your nearest Kenwood dealer. No Device (USB device)/Disconnected (iPod): The USB device/iPod is selected as a source although no USB device/iPod is connected.
  • Page 81 English...

  • Page 82: Accessories

    Accessories Accessories KOS-V1000 ...1 ...1 ...2 ...1 ...1 ...1 ...4 ...1 ...1 ...1 ...2 ...1...

  • Page 83: Installation Procedure

    Installation Procedure Installation Procedure 1. To prevent a short circuit, remove the key from the ignition and disconnect the - battery. 2. Make the proper input and output wire connections for each unit. 3. Connect the speaker wires of the wiring harness. 4.

  • Page 84: Connection

    When using the optional power amplifier, To "EXT.AMP.CONT. " terminal of the amplifier having the external amp control function. KOS-V1000 Accessory 4 FM/AM antenna input Battery wire (Yellow) Ground wire (Black) - (To car chassis) PRK SW For the sake of safety, be sure to connect the parking sensor.
  • Page 85 Accessory 8 USB device (commercially available) REVERSE ILLUMI REMO.CONT MUTE ANT CONT P. CONT EXT. CONT To Relay Box Accessory 9 Accessory 0 Accessory 3 Wiring harness (Accessory 1) White/Black White Gray/Black Gray Green/Black Green Purple/Black Purple If you connect the ignition wire (red) and the battery wire (yellow) to the car chassis (ground), you may cause a short circuit, that in turn may start a fire.

  • Page 86: System Connection

    System Connection KOS-V1000 ■ Rear View Camera Input • Visual input (Yellow) ■ Audio/Visual Output 2 • Visual output (Yellow) • Audio left output (White) • Audio right output (Red) ■ Audio/Visual Output 1 • Visual output (Yellow) • Audio left output (White) •...

  • Page 87: Optional Accessory Connection

    Optional Accessory Connection iPod (commercially available) KCA-iP300V (Optional Accessory) Audio Output (Black) Visual Output (Yellow) USB terminal TV Tuner (Optional Accessory) UNIT MONITOR Connection cable (Included in the TV tuner) Connection cable (Included in the Disc changer) Disc Changer etc. (Optional Accessory) Accessory 6 Accessory 3...
  • Page 88 Optional Accessory Connection Accessory 5 KOS-V1000 KOS-L702 (Optional Accessory) DVD Player etc. (Optional Accessory) Connection cable (Included in KOS-L702)

  • Page 89: Installation

    Installation Installation for Remote control sensor Wipe off the installation location with a cleaning cloth. Secure the Remote control sensor (Accessory 8) in the specified place with the double- sided adhesive tape. • Install the Remote control sensor on a flat surface. If it is installed on a curved surface, the tape adhesion may weaken and the controller may come off.

  • Page 90: Specifications

    Maximum Supply current : 500 mA D/A Converter : 24 bit Decoder : MP3/ WMA/AAC KOS-V1000 FM tuner section Frequency Range (200 kHz) : 87.9 MHz – 107.9 MHz Usable Sensitivity (S/N : 30 dB) : 9.3 dBf (0.8 μV/75 Ω) Quieting Sensitivity (S/N : 50 dB) : 15.2 dBf (1.6 μV/75 Ω)
  • Page 91 Video section Color system of external video input : NTSC External video input level (RCA jacks) : 1Vp-p/75Ω External audio max input level (RCA jacks) : 2V/25kΩ Analog RGB input (NAVI)(TV-SECAM) : 0.7Vp-p/75Ω Video output level (RCA jacks) : 1Vp-p/75Ω Audio output level (RCA jacks) : 1.2V/10kΩ...
  • Page 92 FCC WARNING This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made. NOTE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
