Page 1: Programming Manual
PROGRAMMING MANUAL CODE: 00ZERA570VPME ELECTRONIC CASH REGISTER ER-A570 MODEL (For "V" version) SRV KEY : LKGIM7113RCZZ PRINTER : M-820 CONTENTS CHAPTER 1. SERVICE (SRV) MODE ....... . 1 CHAPTER 2.
Page 2 [key setup procedure] CHAPTER 1. SERVICE (SRV) MODE The SRV key is used for operating in the SRV mode. MRS-2 executed Key position set Free key Free key setup complete. Disable 1. SRV. reset (Program Loop Reset) MASTER PRESET ∗ ∗ ∗ Used to return the machine back to its operational state after a lock- up has occurred.
Page 3 [JOB# 900] [JOB# 950] All parameters contained for the SRV mode as listed The Key layout report is printed in SRV mode Key operation. Key operation ⊗ ⊗ 900 → → TL 950 → → TL 01/ 01/ 00 0: 00 DATE (DD/MM/YY)/TIME 21 / 09 / 94 14 : 30 DATE (DD/MM/YY)/TIME...
Page 4 Σ [JOB#970] [JOB#990] Reading the Contents of the SRV-Mode Programming for SSP Files on the memory are listed. Key operation Key operation ⊗ ⊗ 990 → → TL 970 → → TL 01/ 01/ 00 0: 04 DATE (DD/MM/YY)/TIME 11/01/9412:34pm DATE (DD/MM/YY)/TIME 000000#0006 MACHINE NO./CC-NO.
Page 5: Service Mode Programming
#902-D: 1. EFT terminal (For Germany) 4. Service mode programming 2. Real clerk key system The following are the key operation required for programming. 1. EFT terminal 2. Clerk key 902-D 4 bit key [A] [B] [C] [D] 8 bit key 4 bit key (Job#) Numeric entry...
Page 6 #906-D: 1. Presetting of consecutive No. [JOB#905] MRS=0100 2. Fractional quantity #905-A: Not used (Fixed at "0") 1. Consecutive No. 2. Fractional quantity 906-D #905-B: 1. Tax printing when taxable subtotal is zero. 2. Tax printing when tax is zero. Yes (3-digit decimal 1.
Page 7 [JOB#908] MRS=0000 [JOB#909] MRS=0001 #908-A: GT print on Z report #909-A: 1. Printing of balance GT on the Z report 2. Printing of training GT on the X report GT1 (NET) GT2 (+) GT3 (–) 908-A 3. Printing of training GT on the Z report Print Print 1.
Page 8 [JOB#910] MRS=0003 [JOB#912] MRS=1141 #910-A: 1. Clerk name print on receipt under (When #909-D-1 is #912-A: 1. Date print format "Enable") Date format 912-A 2. Over laped clerk function Month/Day/Year 1. Clerk name print 2. Over laped clerk 910-A Day/Month/Year on receipt under function Year/Month/Day...
Page 9 #914-B: 1. No-sale after NON ADD code entry [JOB#913] MRS = 0002 1. No-sale after # entry 914-B #913-A: 1. Pinting of VAT3, 4, 5, 6 on receipt 2. VP format on Receipt/Journal Disable 3. Content of TOTAL VP amount Enable 1.
Page 10 #916-C: 1. Negative merchandise subtotal #918-C: 1. Printing Z1/Z2 counter in Z reports 2. Subtotal entry compulsory before tendering 2. Printing the DEPT/PLU text on KP in double-size char- 3. Subtotal entry before direct non-tendering finalization acter 1. Negative 2. Subtotal 3 .Subtotal 1.
Page 11 919-D: 1. Conversion SBTL printing of native SBTL [JOB#922] MRS = 0008: INLINE PROGRAMMING AREA 1. Conversion SBTL print 919-D #922-A, B: Not used (Fixed at "00") #922-C, D: 1. Transmission speed and Carrier-off waiting time Transmission speed Carrier-off waiting time (mSec) 922-CD [JOB#920] MSR = 0000: INLINE PROGRAMMING AREA 480K BPS...
Page 12 #924-D: Programming whether or not to lock REG-mode entries af- #925-D: 1. PLU stock control system ter individual periodic total resetting when the system has 2. Resetting in the open store state no save file. 1. PLU stock control 2. Resetting in the open 1.
Page 13 #927-C: 1. Difference memory (Difference between before-round- #928-D: 1. Printing of PB/NBAL on slip ing and after-rounding) 2. Compulsory bill print system 2. Limit on the least sighificant digit in entering the amount (The Slip printing at NBAL in GLU system isn’t compulsory on item always.) 1.
Page 14 PLU keys if PLU code is 1 to 7 = Channel number assigned in the PGM2 mode. FUNCTION KEY LIST (In the ER-A570, the shaded section [JOB#946] NOT USED: MRS = 0000 ) is not used.) Key No.
Page 15 CUST PRICE CHANGE PRCHNG ER-A570 KEY POSITION 28 38 48 58 68 78 88 98 108 118 128 138 148 158 18 27 37 47 57 67 77 87 97 107 117 127 137 147 157 17 26 36 46 56 66 76 86 96 106 116 126 136 146 156...
Page 16 XXXXX GLU/PBLU Rcv. buffer (IRC) File group No. Number of records Sign off Clerk (IRC) 106, 107 File_table (In the ER-A570, the shaded section ( ) is not used.) KP (IRC) 128, 129 ∗ File table No. Group File name...
Page 17 File table RECORD BLOCK Table Label Data File name size size Max. Max. Dept. Preset Price Text (8chra.) Text (16chara.) Daily Term Save daily Consolidation Receive Daily (deduct.) Term (deduct.) Save daily (deduct.) Consol. (deduct.) Receive (deduct.) ∗ ∗ ∗ Preset ∗...
Page 18 RECORD BLOCK Table Label Data File name size size Max. Max. ∗ ∗ ∗ Text (54) ∗ ∗ ∗ Sales Q’ty ∗ ∗ ∗ EAN PGM Pick up ∗ ∗ ∗ D-EAN PGM Pick up ∗ ∗ ∗ EAN X/Z Pick up Transaction Label Daily...
Page 19 RECORD BLOCK Table Label Data File name size size Max. Max. Consolidation (113) Daily net receive Label (113) Receive (113) Reg. buffer KP buffer (119) Over lapped clerk (119) (86) GLU/PBLU buffer (119) B.T./B.S. buffer (119) GLU/PBLU receive buffer (119) GLU/PBLU save buffer (119) <Label:Data>...
Page 20 [JOB#1200]: PLU reading CHAPTER 2. PROGRAM Key operation (PGM2/PGM1) MODE Single item 1.Reading of the PGM mode program XXXX XXXX 1200 Start No. End No. [JOB#1100]: DEPT reading Key operation Single item 01/ 06/ 95 12: 34πµ 1100 123456#1234 0001 Start No.
Page 21 [JOB#1221]: STOCK SUB PRESET [JOB#2221]: SET MENU PRESET OR READING Key operation Single item 2221 XXXXXX XXXXXX 01/ 06/ 95 12: 34πµ Start No. End No. 123456#1234 0001 / βεττψ___ #1221 ∗Π Γ Μ ′ ∗ JOB CODE/MODE TITLE Π 000001 1000.
Page 22 Σ [JOB#2600]: READING OF OTHER [JOB#1300]: FUNCTION PRESET READING Key operation Key operation 1300 2600 01/ 06/ 95 12: 34πµ 01/ 06/ 95 12: 34πµ 123456#1234 0001 123456#1234 0001 / βεττψ___ / βεττψ___ #1300 ∗Π Γ Μ ′ ∗ #2600 ∗Π Γ Μ ′ ∗ JOB CODE/MODE TITLE JOB CODE/MODE TITLE Φ...
Page 23 x: 1 x:10 MRS = 01000000 A: OP X/Z report Disable/Enable 1/0 A: (Not used) B: PO operation in REG mode Disable/Enable 1/0 B: Action shift key Caps Lock/Shift 1/0 C: (not used) C: (Not used) D: "RFND" key entry in REG mode Disable/Enable 1/0 D: (Not used) E: Direct void function in REG mode...
Page 24 [JOB#2640]: READING OF TEXT PROGRAMMING [JOB#2900]: AUTO KEY READING Key operation Key operation 2640 2900 01/ 06/ 95 12: 34πµ 01/ 06/ 95 12: 34πµ 123456#1234 0001 123456#1234 0001 / βεττψ___ / βεττψ___ #2640 ∗Π Γ Μ ′ ∗ #2900 ∗Π Γ Μ ≤ ∗ JOB CODE/MODE TITLE JOB CODE/MODE TITLE #2641...
Page 25 [JOB#2700]: TAX TABLE READING REP. 2. Programming Key operation [JOB#1110] 2700 PROGRAMMING OF DEPT. PRICE 0 price 1110 YYYYYY price DEPT. CODE 01/ 06/ 95 12: 34πµ For the next DEPT. 123456#1234 0001 / βεττψ____ XX: DEPT-CODE = 01 ∼ 99 YYYYYY: PRICE = 0 ∼...
Page 26 [JOB#2111] [JOB#2114] DEPT. TAX STATUS AND SIGN PROGRAMMING DEPT. TEXT PROGRAMMING Space "0" 2114 Character key 2111 ABCDEFG DEPT. CODE DEPT. CODE For the next DEPT. For the next DEPT. XXX: DEPT. CODE = 01 ∼ 99 XX: DEPT. CODE = 01 ∼ 99 A: Not used (Fixed at "0") Characters can be entered by using alphabetic keys or numeric keys.
Page 27 [JOB#2118] [JOB#2119] PRINT STATION PROGRAMMING LINK NUMBER PROGRAMMING FOR DIRECT DEPT. KEYS "0" Delete 2118 2119 DEPT. code KEY No. Next code Next DEPT. XX: DEPT. code = 01 ∼ 99 DEPT. code is assigned to the key no. Which has been programmed in JOB#951 programming.
Page 28 [JOB#1200] [JOB#1213] Creating/assigning PLUs and the associated departments. PLU pint Q’ty programming 1200 XXXXXX 1213 XXXXXX DEPT n PLU code PLU CODE For next code = 01 ∼ 999999 XXXXXX: PLU code = 01 ∼ 99 AB: DEPT. code XXXXXX: PLU code = 1~999999 Z.Z: Print quantity = 0.0~9.9 Amount entry type Any PLU code should already be defined when its unit price is pro-...
Page 29 [JOB#1223] Taxable 2 Non taxable Programming of PLU minimum stock Taxable Taxable 1 1223 XXXXXX YYYYYY Non taxable PLU CODE Taxable For next code Any PLU code should already be defined when its unit price is pro- XXXXXX: PLU code = 1~999999 grammed.
Page 30 [JOB#2218] [JOB#2221] PRINT STATION PROGRAMMING SET PLU PROGRAMMING 2221 XXXXXX YYYYYY 2218 XXXXXX PLU CODE PLU CODE Max. 10 times For next code = 1 ∼ 999999 = 1 ∼ 999999 XXXXXX: PLU code XXXXXX: PLU code = 1 ∼ 999999 YYYYYY: PLU code KP1 No.
Page 31 [JOB#2232] [JOB#2236] PLU TAX STATUS PROGRAMMING (RANGE) Group programming (RANGE) 1 RECORD 1 RECORD 2232 XXXXXX YYYYYY 2236 XXXXXX YYYYYY PLU CODE PLU CODE ABCDEFG = 1 ∼ 999999 XXXXXX: Start PLU code XXXXXX: Start PLU code = 1~999999 = 1 ∼ 999999 YYYYYY: End PLU code = 1~999999 YYYYYY: End PLU code A: Group No.
Page 32 [JOB#2200] LEAD THROUGH PROGRAMMING FOR PLU Step Guidance No. Key sequence Display Contents (JOB#2644) ENTER PLU# 2200 XXXXXX DEPT & TYPE PRICE JOB#1200 DEPT n PRICE JOB#1210 XXXXXX (Lamped P2) BASE Q’TY JOB#1210 XXXXXX PINT PRICE JOB#1211 PINT PRICE JOB#1212 XXXXXX (Lamped P2) pint q’ty...
Page 33 [JOB#1310] [JOB#2312, 2322] RATE PROGRAMMING HALO PROGRAMMING "0" 1310 YYYY.YYYY 2312 2322 Function No. Rate Function code XXX: Fanction No. XXX: Function No. YYYY. YYYY: Rate A: Mantissa (0 to 9) B: Exponent (0 to 8) Function Function Entry range Remarks Function (–)1...
Page 34 XXX: CHARACTER CODE (3DIGITS) σχµ ( −) SCM (–) Please refer to section 3 χα/ χηκ CHECK CASHING (In the ER-A570, the shaded section ( ) of the TEXT is not used.) δεποσι τ DEPOSIT (+) F-NO. FUNCTION DEFAULT TEXT δεπο.
Page 35 F-NO. FUNCTION DEFAULT TEXT F-NO. FUNCTION DEFAULT TEXT εξχη9 ∗∗∗τοταλ EXCHANGE9 TOTAL εξχη1 ι σ δι φφ στ EXCHANGE1 IS DIFFER ST εξχη2 ι σ νον−τυρν EXCHANGE2 IS NON-TURNOVER εξχη3 ι σ χηανγε EXCHANGE3 IS CHANGE εξχη4 ι σ χηεχκ πρ EXCHANGE4 IS CHECK PRINT εξχη5 ι...
Page 36 F-NO. FUNCTION DEFAULT TEXT F-NO. FUNCTION DEFAULT TEXT τρανσ. γρουπ23 TRANS. REPO. TITLE GROUP23 for PLU τλ−ι δ γρουπ24 CID REPO. TITLE GROUP24 for PLU σαλεσ γρουπ25 COM. SALES REPO. TITLE GROUP25 for PLU) ϖ ατ/ ταξ γρουπ26 VAT/TAX REPORT TITLE GROUP26 for PLU χηι...
Page 37 [JOB#2316] F-NO. FUNCTION DEFAULT TEXT γρουπ74 GROUP74 for PLU MISC KEY PROGRAMMING (∃ ) γρουπ75 GROUP75 for PLU "0" γρουπ76 GROUP76 for PLU 2316 γρουπ77 GROUP77 for PLU γρουπ78 GROUP78 for PLU γρουπ79 GROUP79 for PLU XXX: Function No. γρουπ80 GROUP80 for PLU ∃...
Page 38 [JOB#1400] Charge due Enable CLERK CODE DIFINITION Disable Validation print 1400 YYYY Non compulsory Compulsory Clerk No.= 1 ∼ 255 XXX: G, H, I, J: Not used (Fixed at "0000") Clerk code = 0000 ∼ 9999 YYYY: MRS = 0001;1, 0002;2, 0003;3, 0004;4, 0005;5, 0006, 6 Drawer opening [JOB#1414] CLERK NAME PROGRAMMING...
Page 39 [JOB#2610] MRS = DATE SETTING S H A R P 2610 XXYYZZ T H E B E S T Y O U R XXYYZZ: Date (Year-Month-Day/Day-Month-Year/Month-Day-Year) R E C I P T ∗ The date entry format complies with the applicable SRV-mode T H A N programming.
Page 40 Refund VP Zero skip in Daily net report Non compulsory Compulsory X: 2 MRS = 00000000 X: 4 MRS = 00000000 A, B: Not used (Fixed at "00") The first last item void Enable Vat/Tax amount printing on R/J Disable PLU level shift system Auto Taxable amount printing on R/J...
Page 41 [JOB#2618] Time printing on bill Scale table programming Bill printing on slip 2618 YYYY X: Table No. = 1~9 YYYY: Weight = 0~99.99 Bill printing on receipt MRS = 00.00 [JOB#2619] G, H: Not used (Fixed at "00") HOURLY REPORT (Starting time) X: 7 NOT USED MRS = 00000000...
Page 42 JOB#2621: STACK REPORT 2 2641 Character key 2620 Message No. 2621 All delete X: Message No. = 1~50 (In the ER-A570, the shaded section ( ) of the MESSAGE is not No range used.) SSSSSS EEEEEE Message Description Next JOB# (max.=20)
Page 43 [JOB#2642] Message Description VP TEXT PROGRAMMING Power-off duaring VP of Space Euro/French check and Slip P-OFF IN VP paper feed 2642 Character key KP buffer full BUFFER FULL Position code KP hard error HARD ERROR X: Position code = 1 to 3 Open store OPEN STORE Close store...
Page 44 [JOB#2900] Guidance No. ENTER PLU# <CAUTION> DEPT & TYPE BASE Q’TY (This JOB must be performed at X2/Z2 mode position.) SIGN AND TAX AUTO KEY SETTING STOCK Max.25 MIN. STOCK 2900 AUTO (Free key) AUTO PINT PRICE AUTO2 AUTO2 Delete PINT Q’TY AUTO3 AUTO3...
Page 45 ∼ Using alphabetic assignment method ∼ 3. Character assignment method The ER-A570 has two kinds of method at character assignment. Push alphabetic One is to use alphabetic assigned key and other one is to use ten keys. Repeat Programming key layout (ER-A570) 1 Normal character â...
Page 46 CODE TABLE FOR ALPHA DESCRIPTOR PROGRAMMING CODE CHARACTER CODE CHARACTER CODE CHARACTER CODE CHARACTER á Å â ê é î è ì ¡ ô Ñ ó Ò û £ ú < ¥ œ °  ü >  ú ö •...
Page 47 CHAPTER 3. OP X/Z, X1/Z1,X2/Z2 MODE The following categories of reports can be printed by the ECR. 1) OP X/Z reports (individual clerk reports) 2) X1/Z1 reports (Daily sales total X and Z reports) 3) X2/Z2 reports (Periodic total X and Z reports) To print reports, use the following key entry sequence Reading JOB#...
Page 48 Stop of printing reports: The printing of all reports can be stopped by the following operation. Changing of Receipt switch during printing reports. ON → OFF or OFF → ON Note) When the printing is stopped, the consecutive number or Z counter don’t return to the original value.
Page 49 Data communications between the ECR and the ER-02FD are always CHAPTER 4. FILE DATA started by the ECR. This means that performing a specified key TRANSMISSION (ER-02FD = 02FD operation at the ECR activates its ER-02FD function. The file type of each file name is fixed at "DAT" in the ER-02FD. MODE) This means that those files that are preset in a floppy disk placed in the ER-02FD are all data files.
Page 50 When disk formatting has been canceled: Error Status No. Floppy disk error (Formatting cannot be made #0893 ∗Π Γ Μ ≤ ∗ correctly.) Floppy disk error (File cannot be read ερρορ12 correctly.) Files that are the same in file name are present. the setting of the dip switch does not agree with disk format.
Page 51 PRINT FORMAT 4-4) Deletion of files from a floppy disk When the send operation has successfully terminated: This function causes the ECR to send a file delete command to the ER-02FD. #0896 ∗Π Γ Μ ≤ ∗ JOB CODE/MODE TITLE Procedure for PGM job #895 σενδ...
Page 52 3. File creation terminates successfully and a request for floppy When the send operation has been canceled: disk replacement is made. PRINT FORMAT #0898 ∗Π Γ Μ ≤ ∗ #0896 ∗Π Γ Μ ≤ ∗ JOB CODE/MODE TITLE ρεχει ϖε σενδ...
Page 53 Those files that have been preset by jobs #887 and #888 can be sent and received by using the following procedures: (In the ER-A570, the shaded section ( ) is not used.) Procedures for sending and receiving those files preset by presetting REAL FILE No.
Page 54 REAL FILE No. File No. Contents (SRV#971) EAN DAILY (PRICE1) 41, 42 EAN TERM (PRICE1) EAN DAILY (PRICE2) EAN TERM (PRICE2) DYNAMIC EAN DAILY (PRICE1) DYNAMIC EAN DAILY (PRICE2) DEPT DAILY DEPT TERM DEPT DEDUCT. DAILY DEPT DEDUCT. TERM PLU DAILY (PRICE1) 22, 23 PLU TERM (PRICE1) PLU DAILY (PRICE2)
