- Page 1 OI78Z INDUCTION HOB INSTALLATION AND OPERATING INSTRUCTIONS...
-
Page 2: Table Of Contents
CONTENTS: Safety Warnings ....................1- 3 Description of the appliance ................4 Cooking surface and control panel of heaters............ 5 Operation of the appliance ................6 Switching the appliance on and off..............6 Switching the cooking-zones on and off............. 7 Smart Pause ...................... -
Page 3: Safety Warnings
SAFETY WARNINGS READ THESE INSTRUCTIONS CAREFULLY AND COMPLETELY BEFORE USING YOUR APPLIANCE, AND KEEP IT IN A CONVENIENT PLACE FOR REFERENCE WHEN NECESSARY. General Safety Warnings The appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervised or instruction concerning use of the appliance by a responsible person for their safety. - Page 4 - Your appliance is produced in accordance with all applicable local and international standards and regulations. - Maintenance and repair work must be made only by authorised service technicians. Installation and repair work that is carried out by unauthorised technicians may endanger you. It is dangerous to alter or modify the specifications of the appliance in any way.
- Page 5 During usage - Do not put flammable or combustible materials, in or near the appliance when it is operating. - Do not leave the cooker while cooking with solid or liquid oils. They may catch fire on condition of extreme heating. Never pour water on to flames that are caused by oil. Cover the saucepan or fry pan with its cover in order to choke the flame that has occurred in this case and turn the cooker off.
-
Page 6: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE Dear Customer, Please read the instructions in this user guide before using the hob and keep it for future reference. Cooking Surface for 4 heaters: Induction heating element Control panel... -
Page 7: Cooking Surface And Control Panel Of Heaters
Control Panel for 4 heaters: Heater Display Upper left Timer Upper Right heater selection Display Heater selection Timer Key Lock Smart Lower left Lower Right Boost On/Off Indicator Pause heater selection heater selection Sliding Buttons... -
Page 8: Operation Of The Appliance
OPERATION OF THE APPLIANCE Use the induction cooking zones with suitable cookware. After mains voltage is applied, all displays are come on for a moment. When this time is over, the hob is in the stand-by mode and it is ready for operation. The hob is controlled with electronic sensors which are operated by touching the related sensors. -
Page 9: Smart Pause
Switching all cooking-zones off: To turn all the cooking zones off at once, touch the key. In the stand-by mode, an "H" appears on all cooking zones which are hot. Residual heat indicator: Residual heat indicator indicates that the glass ceramic has a dangerous touch temperature in the circumference of a cooking zone. -
Page 10: Safety Switch Off Function
Safety switch off function: Every cooking zone will be switched off after a defined maximum operation time if the heat setting is not modified. Every change in the cooking zone puts back the maximum operation time to the initial value of the operating time limitation. The maximum operation time depends on the selected temperature level. -
Page 11: Minute Minder
Minute minder timer (1 - 99 min): The minute minder timer can be operated if the cooking zones are switched off. The timer display shows "00" with a blinking dot. Use the Timer Sliding Buttons to increase/decrease the time. Adjustment range is between 0 and 99 minutes. -
Page 12: Buzzer
When the timer has run down, a signal sounds and the timer display shows "00" statically, the assigned cooking zone timer LED blinks. The programmed cooking zone will be switched off and the "H" will be displayed if the cooking zone is hot. The sound signal and the blinking of the timer LED will be stopped automatically after 30 second and/or by operating any key. -
Page 13: Hints And Tips
HINTS AND TIPS Cookware · Use thick, flat, smooth bottomed cookware that are the same diameter as the element. This will help reduce cooking times. · Cookware made of steel, enamelled steel, cast iron and stainless steel will give you the best results. -
Page 14: Examples Of Cooking Applications
Examples of cooking applications The information given in the following table is for guidance only. Use for Settings Element off 1 - 3 Delicate warming Gentle simmering, slow warming 4 - 5 Reheating and rapid simmering 6 -7 Boiling, saute and searing Maximum heat Boost function Cleaning tips... -
Page 15: Installation Of The Appliance
INSTALLATION OF THE APPLIANCE WARNING: The electrical connection of this hob should be carried out by a qualified electrician, according to the instructions in this guide and in compliance with the current regulations. In the event of any damage that occurs as a result of improper connection or installation, the warranty will not be valid. This appliance must be earthed. - Page 16 Screw the 4 worktop mounting brackets on the side walls of product. worktop mounting bracket · Secure the hob in place by putting it into cutout on the work surface. · Before inserting the oven, it is necessary to remove the rear kitchen element panel i n the area of the oven opening, in order to supply cooling.
-
Page 17: Making An Electrical Connection
Making an electrical connection Before making a connection, check that: · The mains voltage is the same as that quoted on the rating plate which is situated at the back of your hob. · The circuit can support the appliance load (see the rating plate). ·... -
Page 18: Electrical Connection Diagram
Electrical connection diagram 3x2.5mm² 220V~ 5x1.5mm² 380V,3N~ 4x2.5mm² 380V,2N~ 3x2.5mm² 230V~ 5x1.5mm² 400V,3N~ 4x2.5mm² 400V,2N~ 3x2.5mm² 240V~ 5x1.5mm² 415V,3N~ 4x2.5mm² 415V,2N~ * This appliance must be earthed. * For this connection a power lead of wire type H05V V -F should be used. For the induction hob, the cable must be H05VV-F 3X2,5 mm²/60227 IEC 53 ••. -
Page 19: Error Codes
ERROR CODES If there is an error, error code will be showed at heater displays. E1 : Cooling Fan is disabled, call authorized service agents. wait until “H” E3 : Supply voltage is over than rated values, turn the hob off by touching disappears for all zones, turn the hob on by touching and continue to use. - Page 20 Omega products are distributed in Australia by Shriro Australia Pty Ltd. Locked Bag 5002, Kingsgrove NSW 2208 Phone: (02) 9415 5000 Fax: (02) 9415 5525 Email: service@shriro.com.au Web: www.omegaappliances.com.au The symbol on the product or on its packaging indicates that this product may not be treated as household waste.
