If the IP is 0.0.0.0, your ATA does not have a valid IP address. In this case you need to:
1. Hang up the phone, unplug and re-plug your ATA power cord.
2. Wait 2 minutes, and check the IP again.
3. If you still get 0.0.0.0, there can be three reasons for this:
a. Your DHCP Server is not assigning an IP address to the ATA (in which case you should
contact your network administrator or ISP for assistance).
b. Your network does not have a DHCP server (in which case you should proceed to
configuring your IP manually using a Static IP configuration).
For instruction how to manually configure your static IP click here.
c. You have bought a Static IP (in which case you should proceed to configuring your IP
manually using a Static IP configuration).
For instruction how to manually configure your static IP click here.
Step 3: Prepare you device to work with phone network
If you have purchased your Linksys ATA adaptor from KONTACT+ phone network you should
skip this step and proceed to
1. Open your configuration page. To do so, type the following into your web browser:
http://aaa.bbb.ccc.ddd/admin/advanced where "aaa.bbb.ccc.ddd" represents the IP address of your
ATA.
2. Then, on your ATA configuration page, make the necessary changes to the following fields so
they contain the values indicated below. (Please note that your configuration page may not contain
all of the fields that are listed. Make sure to update the fields that you do have on your
configuration page as outlined.)
3. Under the "line 1" tab:
1-
2-
3-
4-
5-
Appendix 1. IVR menu
Please use the table below for options and responses to the information you may use to configure your
LINKSYS ATA:
Action
Step 4.
Type the Sip proxy IP (208.89.105.21) address and proxy port (5060 and 7060)
Display Name, UserID, AuthID should be your Account ID on Portasip
Password should be your password on portasip
Use AuthID should be set to YES
Click on Save Settings
Menu Choice
User Input
Notes
