JVC 0409WMKMDWJMM Instructions

Warnings, Cautions and Others
CAUTION
The button in any position does not disconnect the
mains line.
Disconnect the mains plug to shut the power off completely
COMPACT COMPONENT (the STANDBY lamp goes off).
The MAINS plug or an appliance coupler is used as the
SYSTEM
disconnect device, the disconnect device shall remain readily
operable.
NX-D7 • When the System is on standby, the STANDBY lamp lights
— Consists of CA-NXD7,
red.
SP-NXD7F, and SP-NXD7W • When the System is turned on, the STANDBY lamp goes
off.
NX-D5
— Consists of CA-NXD5, The power can be remote controlled.
SP-NXD7F, and SP-NXD7W
CAUTION:
NX-D3 To reduce the risk of electrical shocks, fire, etc.:
— Consists of CA-NXD3 and
1. Do not remove screws, covers or cabinet.
SP-NXD3
2. Do not expose this appliance to rain or moisture.
NX-DC3
— Consists of CA-NXDC3
and SP-NXD3
CAUTION:
• Do not block the ventilation openings or holes. (If
Thank you for purchasing a JVC product. the ventilation openings or holes are blocked by a
newspaper or cloth, etc., the heat may not be able to get
out.)
INSTRUCTIONS
• Do not place any naked flame sources, such as lighted
candles, on the apparatus.
GVT0276-002A[US/UN/UG/UX/A/UW]
• When discarding batteries, environmental problems
0409WMKMDWJMM
must be considered and local rules or laws governing
the disposal of these batteries must be followed strictly.
• Do not expose this apparatus to rain, moisture, dripping
or splashing and that no objects filled with liquids, such
©2009 Victor Company of Japan, Limited
as vases, shall be placed on the apparatus.
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover or cabinet. There
are no user serviceable parts inside the unit; leave all
servicing to qualified service personnel.
3. CAUTION: Visible and/or invisible class 1M laser
radiation when open. Do not view directly with optical
instruments.
(for NX-D7) (for NX-D7/NX-D5)
4. REPRODUCTION OF LABEL: CAUTION LABEL,
PLACED INSIDE THE UNIT.
1
Precautions Introduction
Notes on the power cord
Playable Disc/File Types
• When you are away on travel or otherwise for an extended
period of time, remove the plug from the wall outlet.
• When unplugging the System from the wall outlet, always
pull the plug, not the power cord.
• Do not handle the power cord with wet hands.
• Disconnect the power cord before cleaning the System or
moving the System.
• Do not alter, twist or pull the power cord, or put anything
heavy on it, which may cause fire, electric shock, or other
accidents.
• CD-R/-RW: Recorded in the Audio CD, Video CD, and
• If the cord is damaged, consult a dealer and have the
SVCD formats. MP3, WMA, WAV, JPEG, MPEG-1,
power cord replaced with a new one.
MPEG-2, ASF, and DivX files written in accordance with
Avoid moisture, water, dust, and high temperatures the "ISO 9660" format can also be played.
• Do not place the System in moist or dusty places.
• DVD-R/-RW, +R/+RW: MP3, WMA, WAV, JPEG,
• If water gets inside the System, turn off the power and
MPEG-1, MPEG-2, ASF, and DivX files written in the
remove the plug from the wall outlet, then consult your
UDF-Bridge format can be played.
dealer. Using the System in this state may cause a fire or
electrical shock. • DVD-R/-RW: Recorded in the DVD Video format and
• Do not expose the System to direct sunlight or place it the DVD Video Recording (VR) format.
near a heating device.
• DVD+R: Recorded in the DVD Video format.
Notes on installation
• Select a place which is level, dry and neither too hot nor • USB device: MP3, WMA, WAV, JPEG, MPEG-1,
too cold—between 5˚C and 35˚C.
MPEG-2, ASF, and DivX* files.
• Do not install the System in a place subject to vibrations.
• Do not put heavy objects on the System.
In addition to the above discs/files, this System can play back
• Do not drag or push the speakers on the floor or table;
audio data recorded on CD-Extra and CD-G (CD-Graphics).
otherwise, the four feet at the bottom side of each speaker
• The following discs cannot be played back:
may peel off or drop from the speaker.
DVD-RAM, CD-I (CD-I Ready), and Photo CD.
To prevent malfunction or damage of the System
Playing back these discs will generate noise and damage the
• Do not insert any metallic objects, such as wires, hairpins,
speakers.
coins, etc. into the System.
• CD Text and DVD Text can be played, but text information
• Do not block the vents.
will not be shown on the display.
• This System can play back Everio file with the extension
code <.mod> recorded on DVD, CD*, and USB device*.
There are no user-serviceable parts inside. If anything
goes wrong, unplug the power cord and consult your
dealer. * Only when the maximum bit rate is less than 2 Mbps.
Caution for DualDisc playback
The Non-DVD side of a "DualDisc" does not comply with the
"Compact Disc Digital Audio" standard. Therefore, the use of
the Non-DVD side of a DualDisc in this product may not be
recommended.
3
CAUTION: Proper Ventilation
To avoid risk of electric shock and fire, and to prevent damage, locate the apparatus as follows:
1. Front: No obstructions and open spacing.
2. Sides/Top/Back: No obstructions should be placed in the areas shown by the dimensions below.
3. Bottom: Place on the level surface. Maintain an adequate air path for ventilation by placing on a stand with a height of
10 cm or more.
Front view
Speaker Speaker
system system
CA-NXD7/CA-NXD5/
CA-NXD3/CA-NXDC3
CAUTION:
Excessive sound pressure from earphones or headphones
can cause hearing loss.
[European Union only]
CAUTION:
Battery shall not be exposed to excessive heat such as
sunshine, fire, or the like.
Mains (AC) Line Instruction
(Excluding Australian models)
CAUTION for mains (AC) line
BEFORE PLUGGING IN, do check that your mains (AC)
line voltage corresponds with the position of the voltage
selector switch provided on the outside of this equipment
and, if different, reset the voltage selector switch, to prevent
from a damage or risk of fire/electric shock.
• Use a screwdriver to slide the voltage selector to the
correct voltage in the area you are plugging in the unit.
The illustration above is for NX-D7.
GVT0276-002A
2
• DivX® is a registered trademark of DivX, Inc., and is used
IMPORTANT: Before playing a disc/file, make sure of the
under license.
following...
• ABOUT DIVX VIDEO: DivX® is a digital video format
• Turn on the TV and select an appropriate input mode on
created by DivX, Inc. This is an official DivX Certified or
the TV to view the pictures or on-screen displays.
DivX Ultra Certified device that plays DivX video.
• For disc/file playback, you can change the initial setting
• ABOUT DIVX VIDEO-ON-DEMAND: This DivX®
to your preference. Refer to "Setup Menu" in "Operating
Certified device must be registered in order to play DivX
Guide. "
Video-on-Demand (VOD) content. First generate the DivX
If " " appears on the TV screen when you press a button, VOD registration code for your device and submit it during
the disc/file cannot perform the operation you have tried the registration process. [Important: DivX VOD content
to do. is protected by a DivX DRM (Digital Rights Management)
system that restricts playback to registered DivX Certified
• When playing a multi-channel encoded software, the
devices. If you try to play DivX VOD content not
System properly converts the multi-channel signals into
authorized for your device, the message "Authorization
2 channels, and emits the downmixed sound from the Error" will be displayed and your content will not play.]
speakers. To enjoy the powerful sound of these multi-
Learn more at www.divx.com/vod.
channel encoded software, connect a proper decoder or an
• Plays DivX® video
amplifier with a proper built-in decoder to the OPTICAL
• Microsoft and Windows Media are either registered
DIGITAL OUTPUT terminal on the rear.
trademarks or trademarks of Microsoft Corporation in the
United States and/or other countries.
• This product incorporates copyright protection technology
About color system
that is protected by U.S. patents and other intellectual
This System accommodates both NTSC and PAL system and
property rights. Use of this copyright protection technology
can play back discs/files recorded in either system.
must be authorized by Macrovision, and is intended for
To change the color system, see "Preparations. "
home and other limited viewing uses only unless otherwise
authorized by Macrovision. Reverse engineering or
Note on Region Code disassembly is prohibited.
• "CONSUMERS SHOULD NOTE THAT NOT ALL
DVD players and DVDs have their own Region Code
HIGH DEFINITION TELEVISION SETS ARE FULLY
numbers. This System can play back only DVDs with an
COMPATIBLE WITH THIS PRODUCT AND MAY
appropriate Region Code number.
CAUSE ARTIFACTS TO BE DISPLAYED IN THE
• For details, see "Specifications. "
PICTURE. IN CASE OF 525 OR 625 PROGRESSIVE
• "REGION ERR" appears if DVD with a wrong Region Code
SCAN PICTURE PROBLEMS, IT IS RECOMMENDED
is loaded.
THAT THE USER SWITCH THE CONNECTION
Ex.: For Southeast Asia
TO THE 'STANDARD DEFINITION' OUTPUT. IF
THERE ARE QUESTIONS REGARDING OUR TV SET
COMPATIBILITY WITH THIS MODEL 525p AND 625p
DVD PLAYER, PLEASE CONTACT OUR CUSTOMER
SERVICE CENTER. "
• USE OF THIS PRODUCT IN ANY MANNER THAT
7 License and Trademark
COMPLIES WITH THE MPEG-4 VISUAL STANDARD
IS PROHIBITED, EXCEPT FOR USE BY A CONSUMER
• "DVD Logo" is a trademark of DVD Format/Logo
ENGAGING IN PERSONAL AND NON-COMMERCIAL
Licensing Corporation.
ACTIVITIES.
• Manufactured under license from Dolby Laboratories.
• HDMI, the HDMI logo and High-Definition Multimedia
"Dolby" and the double-D symbol are trademarks of Dolby
Interface are trademarks or registered trademarks of HDMI
Laboratories.
Licensing LLC.
• Manufactured under license under U.S. Patent numbers:
• HDCP is the abbreviation of "High-bandwidth Digital
5,451,942; 5,956,674; 5,974,380; 5,978,762; 6,487,535 and
Content Protection, " and is the high-reliable copy control
other U.S. and worldwide patents issued & pending. DTS
technology licensed by Digital Content Protection, LLC.
and DTS 2.0 + Digital Out are registered trademarks and
the DTS logos and Symbol are trademarks of DTS, Inc.
© 1996-2007 DTS, Inc. All Rights Reserved.
4
Learning More about This System
Connections
• Make sure the antenna conductors do not touch any other
terminals, connecting cords or the power cord. Also, keep
the antennas away from metallic parts of the System,
Side view connecting cords, and the power cord. These could cause
poor reception.
• Use only speakers with the same speaker impedance as
indicated by the speaker terminals on the rear of the
System.
• The speakers are magnetically shielded to avoid color
distortions on TVs. However, if not installed properly,
it may cause color distortions. So, pay attention to the
following when installing the speakers.
– When placing the speakers near a TV set, turn off the
TV's main power switch or unplug it before installing the
speakers.
CA-NXD7/CA-NXD5/
CA-NXD3/CA-NXDC3 Then wait at least 30 minutes before turning on the TV's
main power switch again.
– Some TVs may still be affected even though you have
followed the above instructions. If this happens, move
the speakers away from the TV.
• You cannot connect a computer and JVC Everio camcorder
to the USB terminals of the System.
• Noise and static electricity may stop the USB device sound.
In this case, disconnect and connect the USB device again
after turning off the System.
Preparations
To change the color system and scanning mode:
• You cannot change the scanning mode to progressive in the
following cases:
– When your TV does not support the progressive video
input.
– When you have not connected your TV to the System
using a component video cord or an HDMI cable.
Basic Operations
Setting the ECO (Ecology) Mode:
• If you turn on the Daily Timer or the Recording Timer (for
NX-D7) while the ECO mode is activated, the ECO mode
is canceled.
Troubleshooting
General
Adjustments or settings are suddenly canceled before
you finish.
] There is a time limit. Repeat procedure again.
Operations are disabled.
] The built-in microprocessor may malfunction due to
external electrical interference. Unplug the power cord and
then plug it back in.
Unable to operate the System from the remote control.
] The path between the remote control and the remote
sensor on the System is blocked.
] The batteries are exhausted.
No sound is heard.
] Speaker connections are incorrect or loose.
] Headphones are connected.
No picture appears on the TV screen.
] The video cord connections are incorrect or loose.
No picture is displayed on the TV screen, the picture is
blurred, or the picture is divided into two parts.
] The System is connected to a TV which does not support
progressive video input.
] Incorrect scanning mode is selected (see "Preparations").
] When you unplug the power cord and plug it back again,
the scanning mode may change back to the initial setting
(see "Preparations").
The left and right edges of the picture are missing on
the screen.
] Select "4:3 LB, " "4:3 MULTI LB" for "MONITOR TYPE"
(refer to "Setup Menu" on page 20).
Radio Operations
Hard to hear broadcasts because of noise.
] Antenna connections are incorrect or loose.
] The AM loop antenna is too close to the System.
] The FM antenna is not properly extended and positioned.
Disc/USB Device Playback Operations
The disc does not play.
] You have inserted a disc whose Region Code is not correct.
("REGION ERR" appears on the display.)
] The disc is placed upside down. Place the disc with the
label side facing up.
ID3 Tag on an MP3 file cannot be shown.
] Two types of ID3 Tag exist—Version 1 and Version 2. This
System can only show ID3 Tag Version 1.
Groups and tracks are not played back as you expect.
] The playing order is determined when the groups
and tracks were recorded. It depends on the writing
application.
Listening to a Disc/USB Device Setup Menu
General:
JVC bears no responsibility for any loss of data in the USB
mass storage class device while using this System. • If the upper and lower parts of the menu are cut off, adjust
the picture size control of the TV.
• When connecting with a USB cable, use the USB 2.0 cable
whose length is less than 1 m. LANGUAGE menu:
• You can connect a USB device such as a USB flash memory
• When the language you have selected for "MENU
device, hard disk drive, multimedia card reader, etc. to this LANGUAGE, " "AUDIO LANGUAGE, " or "SUBTITLE" is
System.
not recorded, the original language is used as the initial
• When you change the source to "DVD/CD" or "USB, " it
language.
may take a while to activate the source.
PICTURE menu—MONITOR TYPE:
• While the System is reading a disc, the source may not
change to "USB1" or "USB2" properly. In this case, press 7, • Even if "4:3 PS, " "4:3 MULTI PS" is selected, the screen
size may become 4:3 letter box while playing a disc/file.
then change the source to "USB1" or "USB2. "
This depends on how the discs are recorded.
• On some discs, the actual operations may be different from
• When you select "16:9 NORMAL, " "16:9 MULTI
what is explained in this manual due to the programming
and disc structure; such differences are not a malfunction NORMAL" or "16:9 AUTO, " "16:9 MULTI AUTO" for
of this System. a picture whose aspect ratio is 4:3, the picture changes
• The total number of tracks (files) that the System can detect slightly due to the process of converting the picture width.
is 4 000 for "DVD/CD" and "USB1, " and 2 000 for "USB2".
OTHERS menu—ON SCREEN GUIDE:
• The System recognizes up to...
• The setup menu and on-screen bar will be displayed (and
– 999 tracks (files) per group.
recorded) even if this function is set to "OFF. " Subtitles
– 99 groups per disc, "USB 1" (for NX-D7), and "USB" (for
and the information for zoom-in always appear on the
NX-D5/NX-D3/NX-DC3).
display regardless of this setting.
– 999 groups per "USB 2. "
Unplayable files are also counted in the total file number.
Timer Operations
Playable files which do not belong to any groups are
recognized as files of group 1. General:
Program Play/Random Play/Group Play: • When the System is on standby, you cannot set Daily
Timer or Recording Timer (for NX-D7).
• Program is cleared in the following cases:
– When the System is turned off (standby). Setting the Clock:
– For USB2 (NX-D7), when the source is changed to USB1.
• "0:00" will flash on the display until you set the clock.
• While programming steps...
• The clock may gain or lose 1 to 2 minutes per month. If
– Your entry will be ignored if you have tried to program
this happens, reset the clock.
an item number that does not exist (for example,
Setting the Daily Timer:
selecting track 14 on a disc that only has 12 tracks).
– For MP3/WMA/WAV files, you can program up to 99 • If you do not specify the preset station or track number
files.
correctly while setting a timer, the currently selected
– You cannot select the 151st or later tracks. station or the first track will be played when the timer is
activated.
Playing Repeatedly:
• When you unplug the power cord or if a power failure
• A-B Repeat cannot be used for MP3/WMA/WAV/JPEG/
occurs, the timer will be canceled. You need to set the
MPEG-1/MPEG-2/ASF/DivX files and some DVDs.
clock first, then the timer again.
To select the audio track: • If you set DVD Video as the source, Daily Timer will not
work correctly.
• On some discs/files, you cannot change audio language
• If you set the Sleep Timer after Daily Timer starts playing
during playback.
the selected source, Daily Timer is canceled.
Zoom:
Listening to the Radio
• While zoomed in, the picture may look coarse.
• If you store a new station into an occupied preset number,
On-screen Operations
the previously stored station in that number will be erased.
• When you unplug the power cord or if a power failure
Operating the On-screen Bar:
occurs, the preset stations will be erased in a few days. If
• A-B Repeat is available only within the same title/original
this happens, preset the stations again.
program/track.
5
MP3, WMA, WAV, JPEG, MPEG-1, MPEG-2, ASF or DivX
Bluetooth Operations (NX-D7)
files are not played back.
Sound of a Bluetooth audio player does not come out
] The disc or the USB device may contain different types of
of the speakers.
files (ex. MP3/WMA/WAV/JPEG). In this case, you can
• The Bluetooth indicator is on.
only play back the files selected by pressing FILE TYPE.
] Another player than the one you want to listen to is
] You have changed the "FILE TYPE" setting after the
connected to the System. Change the device to be
System read the disc or the USB device. In this case, reload
connected to the System (refer to "Using the Bluetooth
the disc or disconnect the USB device and connect it again.
Device (for NX-D7)" on page 30).
The disc sound is discontinuous.
• The Bluetooth indicator is flashing.
] The disc is scratched or dirty.
] Connection is not established. Try pairing again (refer to
No subtitle appears on the display though you have
"Using the Bluetooth Device (for NX-D7)" on page 30).
selected the initial subtitle language. • The Bluetooth indicator is off.
] Some DVDs are programmed not to display any subtitle ] The Bluetooth adapter is not connected properly.
] "Bluetooth" is not selected as the source.
initially. If this happens, press SUBTITLE after starting
playback.
Sound of the System does not come out of Bluetooth
Audio language is different from the one you have
headphones.
selected as the initial audio language. • The Bluetooth indicator is on.
] Some DVDs are programmed to always use the original ] Another pair of headphones than the one you want to use
language initially. If this happens, press AUDIO/MPX after is connected to the System. Change the headphones to be
starting playback. connected to the System (refer to "Using the Bluetooth
Device (for NX-D7)" on page 30).
The disc tray does not open or close.
] The power cord is not plugged in. • The Bluetooth indicator is flashing.
] Connection is not established. Try searching for the
] Child Lock is in use. "LOCKED" appears on the display
device ("SEARCH DV?") again (refer to "Using the
(refer to "Listening to a Disc/USB Device" on page 17).
Bluetooth Device (for NX-D7)" on page 30).
Recording Operations
• The Bluetooth indicator is off.
] The Bluetooth adapter is not connected properly.
Unable to record into the USB device.
] The Bluetooth transmitter is not activated.
] The capacity of the USB device is full. Erase some tracks.
] You have recorded 999 tracks or group on the USB device
A Bluetooth device cannot be paired with the System.
] Set the System ready to be paired.
you want to record into. Erase unwanted tracks.
] For NX-D5/NX-D3/NX-DC3: You cannot record tracks ] Input the right PIN code.
] Refer to the manual of the Bluetooth device for pairing.
while Mic Mixing is activated.
] The USB device is write-protected.
The sound quality is not good.
] The connected USB device is incompatible to this System.
] Change the SOUND QLTY setting to "HIGH" (refer to
"Using the Bluetooth Device (for NX-D7)" on page 30).
Editing Operations
The sound is discontinuous.
Unable to assign title to tracks on the USB device.
] A wireless LAN or a microwave oven is interfering.
] For NX-D5/NX-D3/NX-DC3: You cannot edit files while
] Change the SOUND QLTY setting to "NORMAL" (refer
Mic Mixing is activated.
to "Using the Bluetooth Device (for NX-D7)" on page 30).
] When a track is damaged, you cannot edit that track. In
this case, turn off the System and turn on again.
] The USB device is write-protected.
Timer Operations
Daily Timer does not work.
] The System has been turned on when the on-time comes.
Timer starts working only when the System is turned off.
Daily Timer does not start playback.
] The loaded disc is a DVD Video. Change the disc.
7
Listening to a Tape (for NX-DC3)
• If you open the slide door on the top of the main unit
during playback, the playback stops.
• You cannot pause tape playback.
Sound & Picture Adjustments
Adjusting the Sound:
• This function also affects the sound through the
headphones.
Setting My Sound (for DVD/CD and USB1):
• My Sound setup is prohibited for certain file format.
• My Sound setup is prohibited during recording/editing or
while Mic Mixing is activated.
Enjoying Karaoke
General:
• You cannot enjoy all the Karaoke functions with DVD-
VR, video files and picture files.
• While the System is turned on, connecting a microphone
automatically activates Mic Mixing and all the Karaoke
related functions.
• While the System is turned off, connecting a microphone
does not activate Mic Mixing and any other Karaoke
related function. In this case, press MIC MIX after turning
the System on.
• You cannot activate Mic Mixing during My Sound setup.
• While recording, connecting microphones does not
automatically activate Mic Mixing.
Adjusting the Sound Track for Karaoke:
• Vocal Masking is not applied to the optical digital output
signals through the OPTICAL DIGITAL OUTPUT
terminal.
• For some music files, Vocal Masking does not provide the
correct effect.
Recording Operations
Recording from a Disc (for NX-D7):
• When you press USB REC, "×1 ONLY" appears on the
display in the following cases:
– While Program Play or Random Play is selected.
– When "HQ REC" is selected for the transfer rate.
Editing Operations
Editing Titles to Tracks or Groups:
• When a track is recorded, a title is automatically given to
the track. When you want to give a new title to the track,
delete the old title, then enter your desired title.
• For NX-D5/NX-D3/NX-DC3, you cannot edit files while
using Karaoke function.
6
Maintenance
To get the best performance of the System, keep your discs
and cassette tapes, and mechanism clean.
Handling Discs
• Remove the disc from its case by holding it at the edge
while pressing the center hole lightly.
• Do not touch the shiny surface of the disc, or bend the
disc.
• Put the disc back in its case after use to prevent warping.
• Be careful not to scratch the surface of the disc when
placing it back in its case.
• Avoid exposure to direct sunlight, extreme temperature,
and moisture.
To clean the disc:
Wipe the disc with a soft cloth in a straight line from center
to edge.
Handling Cassette Tapes
• If the tape is loose in its cassette, take up the slack by
inserting a pencil in one of the reels and rotate it.
– If the tape is loose, it may get stretched, cut, or caught in
the cassette.
• Be careful not to touch the tape surface.
• Avoid the following places to store the tape—in dusty
places, in direct sunlight or heat, in moist areas, on a TV
or speaker, or near a magnet.
Cleaning the System
• Stains should be wiped off with a soft cloth. If the System
is heavily stained, wipe it with a cloth soaked in water-
diluted neutral detergent and wrung well, then wipe clean
with a dry cloth.
• Since the System may deteriorate in quality, become
damaged or get its paint peeled off, be careful about the
following:
– DO NOT wipe it with a hard cloth.
– DO NOT wipe it forcefully.
– DO NOT wipe it with thinner or benzine.
– DO NOT apply any volatile substance such as
insecticides to it.
– DO NOT allow any rubber or plastic to remain in
contact for a long time.
8
