REVISION HISTORY

MODEL
KLV-26S200A
KLV-26S200A
KLV-26S200A
KLV-32S200A
KLV-32S200A
KLV-32S200A
KLV-40S200A
KLV-40S200A
KLV-40S200A
KLV-46S200A
KLV-46S200A
KLV-46S200A
NO.
SUFFIX
DATE
1
-01
2006/6
2
-02
2006/7
3
-03
SUPPL. / CORR
--
Corr-1
2006/9
Supp-1
WAX2
9-872-898-03
PART NO. :
DESCRIPTION
1st. Issue
Section 4: Exploded View
1) Ref No. change & Delete illustration(Page 84)
2) Battery Cover Part number change
(Page 88) (Page 89)
3) Screw part number change(Page 83)
Section 4: Exploded View
Stand and Bezel Assy new and different color
information (Page 108)
CHASSIS

Advertisement

Table of Contents
loading

Related Manuals for Sony KLV-26S200A

Summary of Contents for Sony KLV-26S200A

  • Page 1: Revision History

    REVISION HISTORY WAX2 CHASSIS MODEL 9-872-898-03 PART NO. : KLV-26S200A KLV-26S200A KLV-26S200A KLV-32S200A KLV-32S200A KLV-32S200A KLV-40S200A KLV-40S200A KLV-40S200A KLV-46S200A KLV-46S200A KLV-46S200A SUFFIX DATE SUPPL. / CORR DESCRIPTION 2006/6 1st. Issue Section 4: Exploded View 2006/7 Corr-1 1) Ref No. change & Delete illustration(Page 84)

  • Page 2: Service Manual

    SERVICE MANUAL WAX2 CHASSIS MODEL COMMANDER DEST. MODEL COMMANDER DEST. KLV-26S200A KLV-46S200A RM-GA005 RM-GA005 KLV-26S200A KLV-46S200A RM-GA005 Oceania RM-GA005 Oceania KLV-26S200A KLV-46S200A RM-GA005 Middle East RM-GA005 Middle East KLV-32S200A RM-GA005 KLV-32S200A RM-GA005 Oceania KLV-32S200A RM-GA005 Middle East KLV-40S200A RM-GA005 KLV-40S200A...

  • Page 3: Table Of Contents

    OR CARBON PAINTED ON THE CRT, AFTER REMOVING THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE ANODE. THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. – 2 –...

  • Page 4: Safety Check Out/Leakage Test

    Point them out to the customer and recommend OPERATION. REPLACE THESE COMPONENTS WITH their replacement. SONY PARTS WHOSE PART NUMBERS APPEAR AS 6. Check the line cords for cracks and abrasion. Recommend the SHOWN IN THIS MANUAL OR IN SUPPLEMENTS replacement of any such line cord to the customer.
  • Page 5 Due to the higher melting point of Lead Free Solder the soldering iron tip temperature needs to be set to 370 degrees centigrade. This requires soldering equipment capable of accurate temperature control coupled with a good heat recovery characteristics. For more information on the use of Lead Free Solder, please refer to http://www.sony-training.com – 4 –...

  • Page 6: Self Diagnostic

    KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 SELF DIAGNOSTIC FUNCTION Control Buttons MENU POWER TV/VIDEO VOLUME CHANNEL PIC OFF/TIMER STANDBY POWER Description of LED Indictors LED Type Description * Light is green when the TV set is on POWER LED Red/Green LED * Functions as failure indicator...
  • Page 7 KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 LED Control TIMER LED/ STANDBY STATUS POWER LED REMARKS PICTURE OFF LED Power off using the power switch or remote control. NOTE: Standby Power Off state does not exist in this model; however, the microcomputer does enter into sleep mode.

  • Page 8: Disassembly

    SECTION 1 DISASSEMBLY 1-1. REAR COVER REMOVAL Two Screws, 3 x 12 Type2 IT-3 Two Screws +PSW M4 X 16 (KLV-26S200A) +PSW M6 X 16 (Except KLV-26S200A) Sixteen Screws Lift to remove Rear Cover +BVTP2 4 X 16 – 7 –...

  • Page 9: Vesa Bracket Assembly Removal

    KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 1-2. VESA BRACKET ASSEMBLY REMOVAL 1 Three screws 4 Vesa assy bracket (L) 3 Two screws (+PSW M4X16) (+PSW M5X16) 5 Two screws (+PSW M5X16) 2 Stand assy 6 Vesa assy bracket (R) KLV-40S200A/46S200A 1 Three screws 3 One screw...

  • Page 10: H1 Board Removal

    Two screws (+BVTP 3 X 12 TYPE2 IT-3 4 H2 board (Except KLV-46S200A) (Except KLV-40S200A)) H46 board (KLV-46S200A) Side jack holder (L) KLV-40S200A/46S200A) 1 One Connector CN201 (KLV-46S200A) Side jack holder (M) KLV-26S200A/32S200A) 6 Side terminal assy – 9 –...

  • Page 11: G1 And G2 Boards Removal

    KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 1-5. G1 AND G2 BOARDS REMOVAL 2 Two screws KLV-26S200A/32S200A 1 Four screws (+BVTP 3X12) (+PSW 3SG) (3X14) 1 Two screws (+PSW M3X5) 5 G1 assy bracket 3 G1 board 2 G2 board 4 Two screws (+PSW M3X5)

  • Page 12: Tug Board Removal

    KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 1-7. TUG BOARD REMOVAL 3 One screw + PSW 3SG 2 Three screws + BVTP 3 X 12 TYPE2 IT-2 4 TUG board 1 3 Connectors CN3802, CN3903, CN3904 1-8. DTT SHIELD REMOVAL 2 One screw 1 Two screws...

  • Page 13: B Board Removal

    KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 1-9. B BOARD REMOVAL 2 One screw (+PSW M3X5) 3 Lead wire with connector (LVDS) 5 Two screws (+PSW 3SG) 4 Two screws 1 Connectors (+BVST 3 X 8) CN1004, CN1003, CN1007, CN7009, CN1002, CN1700, CN5000, CN1001, CN7008,...

  • Page 14: Ac Inlet Removal

    KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 1-10. AC INLET REMOVAL 5 Cover under 4 Two screws 1 One screw (+BVTP2 4 X 16) (+PSW M4X8) 6 Two screws (+BVTP2 4 X 16) 2 Two screws (+KTT 3X10) 7 Four screws (+PSW M5X8) 3 AC Inlet...

  • Page 15: 1-12-2.Lcd Panel Removal (Klv-46S200A/46S200A)

    KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 1-12-1. LCD PANEL REMOVAL (KLV-26S200A/32S200A) 1 Two screws (+PSW M4X8) 2 Frame top assy 3 One screw 4 Harness (+BVTP2 4 X 16) with connector (LVDS) 5 LCD panel Bezel assy – 14 –...
  • Page 16 KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 1-12-2. LCD PANEL REMOVAL (KLV-40S200A/46S200A) 71 screw (+BVTP2 4 X 16) 8 Harness with connector (LVDS) 9 LCD panel 1 One screw (+PSW M5X8) 2 Two screws (+BVTP2 4 X 12) 3 Frame top 4 One screw (+PSW M5X8)

  • Page 17: Service Adjustments

    KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 SECTION 2 SERVICE ADJUSTMENTS 2-1. How to enter Service Mode 2-2. Signal Level Adjustment 2-2-1. Set up of AD calibration 1 adjustment for Service adjustments to this model can be performed using the supplied remote Commander RM-GA005. terrestrial analog.
  • Page 18 KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 2-2-4. C signal calibration1 adjustment for 2-2-7. Set up of C signal calibration1 adjustment terrestrial analog. for video. 1. Send ECS_ADJUST_TCD3_HUE_RF command. 1. Input PAL colour bar 75%Y, 75%C via AV1 input. 2. Read S-REG: READ_BACK_B00 via ECS. (READ_AREA=0).

  • Page 19: Gamma Adjustment

    KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 2. Send ECS_ADJUST_TCD3_CONT_V command. 2-3-2. Set up Trident internal SG and brightness measurement 3. Read the value of S-REG:APL_LUMA via ECS. Confirming that the value is within spec of the table below. 1. Ensure TEST_PATTEN_ON=1. 2. Ensure TEST_G_LEVEL=204.
  • Page 20 KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 6. Adjust R_GAMMA_OFST_01 and B_GAMMA_OFST_01 10. Adjust R_GAMMA_OFST_03 and B_GAMMA_OFST_03 chroma values so that they are within tolerance in the table below. chroma values so that they are within tolerance in the table below. TOLERANCE TOLERANCE 26" 20IRE 0.2804...

  • Page 21: Panel Replacement

    KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 19. Set up DYNAMIC_EN=0xffff 2-5. Panel Replacement 20. Set up COLOR_TEMP=1. When replacing the panel please reset the gamma and white balance 21. Write the correct values for R_DRV, B_DRV, R_BKG and B_BKG before performing W/B (See page 18) for new panel.

  • Page 22: Diagrams

    KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 SECTION 3 DIAGRAMS 3-1-1. TUG BLOCK DIAGRAM TU3900 CN3903 SCL (TU) TU_I2C_SCL SCL (IF) TU_I2C_SDA B BOARD SDA (TU) TV_AFT CN1700 SDA (IF) AFT OUT Q3901 CN3802 IC3802 +10.5V 10.5V POWER UNIT 9,10 5V,6V CN3904 DET OUT TV_V...

  • Page 23: G2 Block Diagram

    KLV-26S200A/32S200A/40S200A/46S200A KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 RM-GA005 3-1-2. G2 BLOCK DIAGRAM (KLV-40S200A/46S200A) D6000 RECT AC INLET CN6001 L6000,6001 L6502 D6506 AC IN(N) AC IN(L) F6000 RY6003 Q6051 RLYON RELAY DRIVE IC6502 IC6100 D6551 D6552 CONVERTER DRIVE PH6000 Q6501,6502 Q6405 RELAY CONVERTER Q6500 CONVERTER...

  • Page 24: B,H1 And H3 Block Diagrams

    KLV-26S200A/32S200A/40S200A/46S200A KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 RM-GA005 3-1-3. B, H1 AND H3 BLOCK DIAGRAM IC5000 VIDEO PROCESSOR CN1001 D1_IN_Y Y1/G1(NC) Y_G2 D1_IN_CB CB1/B1(NC) PB_B2 D1_IN_CR CR1/R1(NC) PR_R2 D1_IN_L3/MODE L3_1/MODE_1(NC) D1_IN_SW/FB FB_1(NC) Q5001 CN5000 Y/CV,C Q5000 Y/CV SEL2_Y/CV BUFFER CVBS1 TA1P SEL2_C BUFFER TA1M...

  • Page 25: Ag And H2 Block Diagrams

    KLV-26S200A/32S200A/40S200A/46S200A KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 RM-GA005 3-1-4. AG AND H2 BLOCK DIAGRAMS Q6011-Q6013,6001 Q6004,6005,6007,6008 SYNC SEP. IC2001 Q6002 Q6009 AV SW Q2001,2002 CN9702 BUFFER BUFFER CN9501 VIDEO VIDEO Y/CV Y/CV V/YOUT2 SEL2_Y/CV AUDIO L BUFFER COUT2 SEL2_C AUDIO R TV_V V_DET FM/AM...

  • Page 26: Circuit Boards Location

    KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 3-2. CIRCUIT BOARDS LOCATION H1 Board B Board H2 Board (KLV-26S200A/32S200A/40S200A) H46 Board (KLV-46S200A) TUG Board G1 Board (KLV-26S200A/32S200A) G2 Board (KLV-40S200A/46S200A) AG Board H3 Board 3-3. SCHEMATIC DIAGRAM INFORMATION Note: Circuit Device Printed symbol Terminal name •...

  • Page 27: Ag Board - (001)

    KLV-26S200A/32S200A/40S200A/46S200A KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 RM-GA005 3-3-1. AG Board – (001) R6001 R6004 R6010 2.2k 2.2k C6001 C6013 RN-CP RN-CP RN-CP C9019 R9041 V1_IN_C,V1_IN_S2SW,V1_IN_SSW,V1_IN_V,V1_IN_Y R9062 R9032 J9003 Q6009 R9057 R6003 001:11E D9013 1-819-358-11 R6006 2SC1623-L5L6 RN-CP RN-CP RN-CP DTZ10B RN-CP V1_IN_Y PHONO JACK...

  • Page 28: Ag Board - (002)

    KLV-26S200A/32S200A/40S200A/46S200A KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 RM-GA005 3-3-2. AG Board – (002) C7062 PS7001 0.001 L7008 FB9100 L7012 22uH AU_15V C7061 L9606 L7011 0.001 FB9101 002:11E;002:15A C7044 10uH R7061 R7062 R7067 AU_15V_M 0.0022 C7113 C7024 8.2k CHIP R7134 TO FE RN-CP RN-CP TO DETECT 1/10W 002:11E;002:12A...

  • Page 29: B Board - (001)

    KLV-26S200A/32S200A/40S200A/46S200A KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 RM-GA005 3-3-3. B Board — (001) NOTE PAGES WAX2 B BOARD INFORMATION FUNCTION COVER MAIN ICON TRIDENT DDP&CPU IF POWER, VIDEO PROCESSOR DDR SDRAM 006 AUTO WIDE 007 PC Connector 008 HDMI & D/A 009 POWER 010 DC_ALERT...

  • Page 30: B Board - (002)

    KLV-26S200A/32S200A/40S200A/46S200A KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 RM-GA005 3-3-4. B Board — (002) << STBY3.3V >> Y1/G1 D1_IN_Y R1021 1/10W RN-CP 003:2B IC1005 R1022 1/10W RN-CP R1044 D1_IN_CB FROM A PWB X1009 CB1/B1 IC1003 R1167 M24256-BWMN6T R1040 32.768kHz RESET 181378421 C1065 R1023 22 1/10W RN-CP...

  • Page 31: B Board - (003)

    KLV-26S200A/32S200A/40S200A/46S200A KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 RM-GA005 3-3-5. B Board — (003) Mount Mecha 267488101 IC5000 A5000 R 5027 R5026 CHIP CHIP Mount Mecha A5001 169497421 003:6D DCLK_AEP DCLK_AEP DY1_AEP TA1M B14 DPA_0 DY2_AEP TA1P A14 RB5000 DPA_1 DY3_AEP DPA_2 DY0_AEP TB1M B15...

  • Page 32: B Board - (004)

    KLV-26S200A/32S200A/40S200A/46S200A KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 RM-GA005 3-3-6. B Board — (004) FL5201 D3.3V IC5203 VDDH VDDH VDDMQ TC7SH86FU(T5RSOYJF) D3.3V R5223 IC5202 D3.3V C5239 C5255 C5245 SN74CBTLV3245APWR R5209 R5211 C5229 1/16W CHIP L5201 VDDM B4 C5273 CHIP C5281 C5278 VDDH C5220 C5205 0.001...

  • Page 33: B Board - (005)

    KLV-26S200A/32S200A/40S200A/46S200A KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 RM-GA005 3-3-7. B Board — (005) R5502 MD[19] VDDMQO MD[16] C5504 C5502 0.01 0.01 MD[18] R5500 FL5501 L5501 MD[17] RB5504 C5501 C5506 MD[20] 6.3V C5512 0.1 25V B R5503 1K RN-CP MD[21] MD[22] MD[23] MVREF RB5505 004:5G...

  • Page 34: B Board - (006)

    KLV-26S200A/32S200A/40S200A/46S200A KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 RM-GA005 3-3-8. B Board — (006) D5 V L5701 10uH C5709 IC5700 FB5702 C5704 1000p OAW1 OLBX R5709 O169 OAW2 RN-CP FB5700 X5700 FB5701 OWSS R5710 C5705 0.01 ADIN AVSS C5706 C5710 AVDD 0.01 C5707 0.01 AVDD...

  • Page 35: B Board - (007)

    KLV-26S200A/32S200A/40S200A/46S200A KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 RM-GA005 3-3-9. B Board — (007) CN6000 TO Trident 007:6B;007:6B; R6021 007:6B;007:6B FB6001 PC-R RN-CP PC_R R6001 PC_R 003:3C R6014 R6015 PC-G GND 007:6B;007:6B; RN-CP FB6002 007:6B;007:6B RN-CP RN-CP PC_G PC-B PC_G 003:3C FB6000 R6022 GND 007:6B;007:6B;...

  • Page 36: B Board - 008)

    KLV-26S200A/32S200A/40S200A/46S200A KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 RM-GA005 3-3-10. B Board — (008) L9005 10uH R9062 150k PC_AU_9V 1/10W 007:5F RN-CP C9034 D3.3V-2 HDMI3.3V C9033 FL9000 J9000 R9068 R9016 C9007 VD9001 EM I PHONO JACK R9054 180207811 1/10W Q9004 R9047 RN-CP VARISTOR(SMD) 2SC1623-L5L6 C9010...

  • Page 37: B Board - (009)

    KLV-26S200A/32S200A/40S200A/46S200A KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 RM-GA005 3-3-11. B Board — (009) D7000 MMDL914T1 IC7001 SI8008TM-TL FB7011 R7051 D3.3V-2 RN-CP R7031 F7000 R7048 DIMMER L7002 R7040 C7050 D7010 L7000 2.2k 002:3D 3.15A 47uH 3.15A R7053 10uH D3.3V UDZ-TE-17-6.8B RN-CP CHIP CHIP 3.3k FB7001 C7029 REG17.5V...

  • Page 38: B Board - (010)

    KLV-26S200A/32S200A/40S200A/46S200A KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 RM-GA005 3-3-12. B Board — (010) STBY3.3V D7508 R7542 MMDL914T1 CHIP DCALERT1 D3.3V R7545 D7509 100k C7501 Q7504 1/16W MMDL914T1 RT1N141M-TP-1 CHIP D3.3V R7546 DC_ALERT1 R7544 R7543 004:4E D2.5V(=VDDMQO) CHIP R7541 D7505 VDDMQO CHIP D1.8V CHIP Q7505...

  • Page 39: B Board - (011)

    KLV-26S200A/32S200A/40S200A/46S200A KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 RM-GA005 3-3-13. B Board — (011) TO F/E POWER(J&U/C) CN4701 C4701 C4700 0.01 UNREG10.5V 10.5V R4701 10.5V FE5/6.2/10.5V R4715 C4702 100p FROM F/E HD VIDEO(DIGITAL) SYSTEM(J)/SD_VIDEO(UK) INPUT TO Trident R4702 CHIP BUSMOSI DTT_BUS_MOSI U_DIN/DCLK R4703 XX RN-CP...

  • Page 40: B Board - (012)

    KLV-26S200A/32S200A/40S200A/46S200A KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 RM-GA005 3-3-14. B Board — (012) POWER TO TUNER TUNER_CONTROL Q1700 SSM6N16FU R1723 Q1701 2SC1623-L5L6 UNREG33V R1708 R1721 3.3K R1722 RN-CP C1703 FB1711 470K C1704 C1708 D1701 R1705 C1712 0.001 R1706 HZU16B2TRF-E CHIP D1702 SDA_TUNER 17.5V CHIP...

  • Page 41: G1 Board Schematic Diagram

    KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 3-3-15. G1 Board Schematic Diagram Due to complexity of the board, performing componet level field repairs is not recommended. If service is required, complete board replacement is required, therefore schematic are not included. For part number information refer to the Exploded view or Electrical Parts lists section of this manual.

  • Page 42: G2 Board Schematic Diagram

    KLV-26S200A/32S200A/40S200A/46S200A KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 RM-GA005 3-3-16. G2 Board Schematic Diagram (KLV-40S200/46S200A) Mount Mecha Mount Mecha A6007 263406601 D6000 Mount Mecha A6008 403694821 D6200 A6005 234990061 Q6500,Q6504,D6506 Mount Mecha A6001 214976661 D6201,D6207 T6102 144398311 GND_1 R6208 Mount Mecha 90mm A6014 214976671 D6000 0.47...

  • Page 43: H1 Board Schematic Diagram

    KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 3-3-17. H1 Board Schematic Diagram POWER TOP SWITCH S106 157259511 SWITCH CN101 C102 D101 TO B BOARD CN1007 HOME INPUT SEL VOL+ MENU VOL- POWER INT WEGAGATE KEY1 C101 D102 R101 S103 S101 S102 R102 S104 C103 S105 S107 1.1k...

  • Page 44: H2 Board Schematic Diagram

    KLV-26S200A/32S200A/40S200A/46S200A KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 RM-GA005 3-3-18. H2 Board Schematic Diagram (Except-KLV-46S200A) R228 GND_3 GND_1 GND_2 R229 GND_4 J202 VD203 VD202 R220 156826711 180208211 180208211 CHIP JACK VARISTOR VARISTOR C215 R212 0.001 CHIP C210 GND_2 VD201 C209 C211 C212 180208211 R215 VARISTOR...

  • Page 45: H3 Board Schematic Diagram

    KLV-26S200A/32S200A/40S200A/46S200A KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 RM-GA005 3-3-19. H3 Board Schematic Diagram STBY3.3V STBY3.3V C301 REC/RESERVE STBY_LED ON_TIMER PWR/RESERVE PICTURE_OFF R303 R305 VD3.3V R301 BL_IN 1.5k 1/10W R302 RN-CP VD3.3V 1/10W R304 RN-CP RN-CP SIRCS 1/10W RN-CP RN-CP CN301 D308 TO B BOARD...

  • Page 46: H46 Board Schematic Diagram

    KLV-26S200A/32S200A/40S200A/46S200A KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 RM-GA005 3-3-20. H46 Board Schematic Diagram (KLV-46S200A) R228 GND_3 GND_1 GND_4 GND_2 R229 J202 181532511 R212 JACK VD203 R220 VD201 180208211 CHIP 180208211 CHIP VD202 VARISTOR VARISTOR 180208211 VARISTOR C210 C211 C212 C209 C215 GND_2 0.001 R225...

  • Page 47: Tug Board Schematic Diagram

    KLV-26S200A/32S200A/40S200A/46S200A KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 RM-GA005 3-3-21. TUG Board Schematic Diagram CN3903 TU3900 BTF-BG413Z TU_I2C_SCL CN3905 R3807 R3909 R3908 TU_I2C_SDA FB3904 C3904 CHIP CHIP 1/10W C3808 RN-CP TV_AFT CN3906 R3904 EARTH TERMINAL 3806 R3804 D3904 TV_AGC_M FB3903 FB3802 R3910 CN3907 L3802 CHIP...

  • Page 48: Voltage Measurement And Waveforms

    KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 3-4. VOLTAGE MEASUREMENT AND WAVEFORMS AG BOARD VOLTAGE LIST AND WAVEFORM Pin No. Voltage[v] Pin No. Voltage[v] Pin No. Voltage[v] IC2001 IC7001 1.200Vp-p NTSC 960.0mVp-p 2.400Vp-p NTSC 1.920Vp-p – 69 –...

  • Page 49: Printed Wiring Boards

    KLV-26S200A/32S200A/40S200A/46S200A KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 RM-GA005 3-5. PRINTED WIRING BOARDS NOTE: [AV SW/INPUT TERMINAL, AUDIO/FE CONNECTION] The circuit indicated at left contains high voltage of over 1220 Vp-p. Please pay attention when inspecting or repairing it to prevent an electric shock. – AG Board – (Component Side)
  • Page 50 KLV-26S200A/32S200A/40S200A/46S200A KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 RM-GA005 [POWER UNIT] (KLV-26S200A/32S200A) [SIDE AV INPUT] (KLV-46S200A) [TUNER] – G1 Board – – TUG Board – (Component Side) C3822 R3909 C3903 R3903 1-870-900-11 D3904 R3904 L3803 R3908 L3903 FB3903 (172767011) L3905 R3910 C3906 L3804 L3802 R3902...
  • Page 51 KLV-26S200A/32S200A/40S200A/46S200A KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 RM-GA005 [POWER SUPPLY] (KLV-40S200A/46S200A) – G2 Board – (KLV-40S200A/46S200A) PF LP 1-869-027-12 JL6401 IC6200 D6201 D6207 R6554 R6443 R6417 R6555 JR6009 R6441 R6529 PH6400 R6552 R6527 R6545 R6546 R6547 R6548 R6560 R6402 R6549 R6444 Q6400 C6201 C6200...
  • Page 52 KLV-26S200A/32S200A/40S200A/46S200A KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 RM-GA005 [MAIN IC, TRIDENT, DDR SDRAM, AUTO WIDE, PC CONNECTON, [TOP SWITCH] HDMIP D/A, POWER, DC ALERT, B TO F/E, TUNER] – B Board – (Component Side) – B Board – (Conductor Side) JL1045 JL1043 JL7010 Q7008...
  • Page 53 KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 [SIDE AV INPUT] (Except KLV-46S200A) [LED/SIGNAL DETECTION] – H2 Board – (Except KLV-46S200A) (Component Side) D203 (1-727-469-11) R219 VD203 R205 C206 A-1151- Video IN 2 – H2 Board – (Except KLV-46S200A) (Conductor Side) (000000003) R207 0-000-000-03 R202 (1-727-469-11) –...

  • Page 54: Semiconductors

    KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 3-6. SEMICONDUCTORS DIODE ñ MM3Z6V8ST1 BAT54HT1 D10SBS4 D10SC6M D1NL40-TA2 BAS316-115 MM3Z8V2ST1 DTZ10B D10SBS4F D1NL40-TR2 EP05FA20 HZU5.6GTRF D2SB60A-F04 ERA22-08 MM3Z10VT1 MA113-(TX) D4SB60L MM3Z11VT1 MMDL914T1 MM3Z13VT1 MM3Z18VST1 RD5.6SB-T1 MM3Z22VT1 UDZ-TE-17-18B MM3Z2V4T1 UDZ-TE-17-6.2B MM3Z5V6ST1 UDZ-TE-17-6.8B MM3Z6V2ST1 D1NS6 EC10QS-04 EC21QS03L-TE12L FSF05A60 HN1D03FU-TE85L...
  • Page 55 KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 TRANSISTOR FDS6690A HN1B01FU-TE85R SSM6N15FU(TE85R) 2SB1122-S 2SD2114KT146 2SK2158-T2B 2SB1122-ST-TD-E 2SD1621-ST 2SD1621ST-TD-E BA00AST-V5 BA05FP-E2 BA18BC0FP-E2 BR24L02F-WE2 NJM3414AV(TE2) CD4052BNSR BA09FP-E2 BA25BC0FP-E2 CS4335-KSZR RC4558DR FMS6418AM16X S-1111B33MC-NYSTFG FA5501N-TE1 RC4558PWR TC7SZ125FU(TE85R) LM75CIMX-3 M24128-BWMN6T(A) M24C02-WMN6T(B) NJM2521V(TE2) CXA2188Q-T4 EM6A9320BI-5MG HD6433692A39FXV HD64F2378-12681-01 L88M05T-FA-TL M5234FP-TE HD64F369FXV-DA4 TPA3004D2PHPR MM1431ATT...
  • Page 56 KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 SN74LV132APWR STR-A6169 TK11819MTL SN74LV14APWR – 81 –...

  • Page 57: Exploded Views

    ▼ : SCREW, (B) 5X301 KLV-26S200A/32S200A KLV-40S200A/46S200A REF. NO. PART NO. DESCRIPTION MARK REF. NO. PART NO. DESCRIPTION MARK X-2109-586-2 COVER(26SJ), REAR ASSY (KLV-26S200A) X-2109-791-2 COVER(32SJ), REAR ASSY (KLV-32S200A) X-2109-456-3 COVER(40S); REAR ASSY (KLV-40S200A) X-2148-059-1 COVER(46SJ), REAR ASSY (KLV-46S200A) 2-682-212-01 COVER, ECS X-2103-365-3...

  • Page 58: Frame And Cover

    KLV-40S200A/46S200A REF. NO. PART NO. DESCRIPTION MARK REF. NO. PART NO. DESCRIPTION MARK X-2148-005-1 SIDE, TERMINAL (M) ASSY (Except KLV-26S200A) 2-660-802-01 COVER, UNDER (M) (KLV-26S200A/32S200A) X-2148-002-1 SIDE, TERMINAL(S) ASSY (KLV-26S200A) 2-660-801-02 COVER, UNDER (L) (KLV-40S200A/46S200A) 2-663-985-11 HOLDER, SIDE JACK (M)

  • Page 59: Chassis

    1-832-469-12 HARNESS WITH CONNECTOR (LVDS) A-1169-213-A TUG MOUNT (KLV-32S200A/46S200A) A-1182-675-A AG MOUNT 1-832-470-11 HARNESS WITH CONNECTOR (LVDS) A-1203-526-B B MOUNT (SERVICE) (KLV-26S200A) (KLV-40S200A) A-1203-525-B B MOUNT (SERVICE) (KLV-32S200A) 2-580-591-01 SCREW, +PSW M3X5 A-1189-884-B B MOUNT (SERVICE) (KLV-40S200A) 2-674-965-21 SCREW, +PSW 3SG...
  • Page 60 +KTT 3X10 (S TYPE) X-2109-168-3 FRAME, BOTTOM(L) ASSY (KLV-40S200A/46S200A) 155 ! 1-819-729-13 INLET, AC(WITH NOISE FILTER) 2-650-770-21 SLIDE, CLAMP (KLV-40S200A/46S200A) 2-580-606-01 SCREW, +PSW M5X8 (KLV-40S200A/46S200A) 2-580-591-01 SCREW, +PSW M3X5 2-580-639-01 SCREW, +BVTP2 4X12 (Except KLV-46S200A) X-2109-589-1 BRACKET, G1 ASSY(A) (KLV-26S200A/32S200A) – 85 –...
  • Page 61 KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 4-5. H3 BOARD AND SPEAKER KLV-26/32S200A KLV-40/46S200A REF. No. PART No. DESCRIPTION MARK REF. No. PART No. DESCRIPTION MARK 2-580-591-01 SCREW, +PWS M3X5 1-826-363-11 LOUDSPEAKER (4.2X15CM) (KLV-26200A/32S200A) A-1183-739-A H3 MOUNT 1-826-362-11 LOUDSPEAKER (5.5X15.5CM) (KLV-40S200A) 1-826-435-11 LOUDSPEAKER(13X7CM) (KLV-46S200A) -86-...

  • Page 62: Bezel Assy And Lcd Panel

    : 2-580-640-01 SCREW, +BVTP2 4 × 16 REF. NO. PART NO. DESCRIPTION [ASSEMBLY INCLUDES] REF. NO. PART NO. DESCRIPTION [ASSEMBLY INCLUDES] X-2148-000-1 BEZEL(26SG) ASSY (KLV-26S200A) 1-802-060-13 LCD PANEL (32WXGA+TFT) (KLV-32S200A) X-2148-003-1 BEZEL(32SG) ASSY (KLV-32S200A) 1-802-059-11 LCD PANEL (40WXGA+TFT) (KLV-40S200A) X-2148-006-1...
  • Page 63 KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 4-7. ACCESSORIES AND PACKING MATERIALS (KLV-26S200A/32S200A) REF. NO. PART NO. DESCRIPTION [ASSEMBLY INCLUDES] REF. NO. PART NO. DESCRIPTION [ASSEMBLY INCLUDES] 1-833-117-11 POWER SUPPLY CORD SET 308 * 2-676-368-01 CUSHION (UPPER) (KLV-26S200A) (KLV-26S200A/32S200A(OCE)) * 2-676-371-01 CUSHION (UPPER) (KLV-32S200A) 1-833-118-11...
  • Page 64 KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 4-8. ACCESSORIES AND PACKING MATERIALS (KLV-40S200A/46S200A) 352 353 354 REF. NO. PART NO. DESCRIPTION [ASSEMBLY INCLUDES] REF. NO. PART NO. DESCRIPTION [ASSEMBLY INCLUDES] 1-479-841-11 REMOTE COMMANDER (RM-GA005) 2-685-864-13 MANUAL, INSTRUCTION 9-885-099-05 REMOTE COMMANDER BATTERY COVER X-2102-511-1 BAG ASSY, RUDDER LOCK...

  • Page 65: Electrical Parts List

    KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 The components identified by shading and mark ! are critical for safety. SECTION 5 Replace only with part number specified. ELECTRICAL PARTS LIST REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK NOTE: • Items marked " ∗ " are not stocked since •...
  • Page 66 KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK C9022 1-125-889-91 CERAMIC CHIP 2.2UF C7095 1-162-965-11 CERAMIC CHIP 0.0015UF 10.00%...
  • Page 67 KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK <FERRITE BEAD> Q6007 8-729-120-28 TRANSISTOR 2SC1623-L5L6 Q6008 8-729-120-28...
  • Page 68 KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK R7066 1-218-867-11 METAL CHIP 6.8K 0.50% 1/10W R6007...
  • Page 69 KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK R7626 1-216-845-11 METAL CHIP 100K 1/10W R9031 1-216-864-11...
  • Page 70 C1080 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% A-1189-884-B B, MOUNTED (SERVICE) (KLV-40S200A) C1081 1-126-391-11 ELECT CHIP 47UF 20.00% 6.3V A-1203-526-B B, MOUNTED (SERVICE) (KLV-26S200A) C1082 1-126-394-11 ELECT CHIP 10UF 20.00% A-1203-525-B B, MOUNTED (SERVICE) (KLV-32S200A) C1083 1-100-566-91 CERAMIC CHIP 0.1UF 10.00%...
  • Page 71 KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK C5255 1-100-566-91 CERAMIC CHIP 0.1UF 10.00% C1710 1-100-831-91 CERAMIC CHIP 0.001UF...
  • Page 72 KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK C7032 1-165-673-21 ELECT CHIP 56UF D1007 8-719-077-59 DIODE 1PS302...
  • Page 73 KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK <FILTER> L7002 1-481-081-11 INDUCTOR 47UH L7003 1-481-080-11 INDUCTOR...
  • Page 74 KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK R1007 1-216-864-11 SHORT CHIP R1119 1-218-941-81 RES-CHIP 1/16W...
  • Page 75 KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK R1266 1-216-864-11 SHORT CHIP R5510 1-218-933-11 RES-CHIP 1/16W...
  • Page 76 KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK R7024 1-216-837-11 METAL CHIP 1/10W R9017 1-218-941-81 RES-CHIP...
  • Page 77 KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK <VARISTOR> C6102 1-107-910-11 ELECT 100UF C6103 1-162-970-11 CERAMIC CHIP 0.01UF...
  • Page 78 KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK D6003 8-719-081-97 DIODE MMDL914T1 IC6402 6-709-368-01 IC MM1431ATT (CN)
  • Page 79 KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK R6051 1-216-821-11 METAL CHIP 1/10W R6451 1-216-833-11 METAL CHIP...
  • Page 80 KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK <VARISTOR> <RESISTOR> R202 1-216-864-11 SHORT CHIP VD6000! 1-804-996-21...
  • Page 81 KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK Q303 8-729-028-96 TRANSISTOR DTC114EUA-T106 <RESISTOR> Q304 8-729-028-96 TRANSISTOR DTC114EUA-T106...
  • Page 82 KLV-26S200A/32S200A/40S200A/46S200A RM-GA005 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK FB3901 1-414-760-21 FERRITE FB3902 1-414-760-21 FERRITE FB3903 1-469-324-21...
  • Page 83 SECTION 4: EXPLODED VIEWS 4-1: Rear Cabinet and Stand Assembly KLV-26S200A/32S200A KLV-40S200A/46S200A REF. NO. PART NO. DESCRIPTION MARK X-2148-630-1 ASSY, STAND(M) (KLV-26S200A/32S200A) (SILVER) X-2148-637-1 ASSY,STAND (L) (KLV-40S200A/46S200A) (SILVER) X-2149-442-1 ASSY, STAND(M)(B) (KLV-26S200A/32S200A) (BLACK) X-2149-470-1 ASSY, STAND(L)(B) (KLV-40S200A/46S200A) (BLACK) – 108 –...
  • Page 84 4-6. BEZEL ASSY AND LCD PANEL REF. NO. PART NO. DESCRIPTION [ASSEMBLY INCLUDES] REF. NO. PART NO. DESCRIPTION [ASSEMBLY INCLUDES] X-2148-000-1 BEZEL(26SG) ASSY (KLV-26S200A) (SILVER) X-2148-646-2 BEZEL(32SG) ASSY (KLV-32S200A) (SILVER) X-2148-640-2 BEZEL(40SG) ASSY (KLV-40S200A) (SILVER) X-2148-009-4 BEZEL(46SG) ASSY (KLV-46S200A) (SILVER) X-2176-007-1...

  • Page 85: Operating Instructions

    2-685-864-13(1) LCD Color TV Operating Instructions Before operating the TV, please read the “Safety information” section of this manual. Retain this manual for future reference. KLV-46S200A KLV-40S200A KLV-32S200A KLV-26S200A © 2006 Sony Corporation...

  • Page 86: Trademark Information

    Introduction • To prevent the risk of electric shock, if the AC power cord Thank you for choosing this Sony product. or plug is damaged, do not insert the plug into the AC Before operating the TV, please read this manual power outlet.
  • Page 87 Table of Contents Start-up Guide Start-up Guide 4 Safety information ........................7 Overview of the remote ......................12 Overview of the TV buttons and indicators ................13 Watching TV Watching TV..........................14 Viewing pictures from connected equipment ................16 Using MENU Functions Navigating through menus ......................17 Picture menu ...........................18 Sound menu..........................20 Screen menu...........................22...

  • Page 88: Start-Up Guide

    Start-up Guide Connecting an antenna and VCR 1: Inserting batteries AC power cord (supplied) into the remote AC IN Notes To 8 VHF/UHF (antenna) • Observe the correct polarity when inserting batteries. • Dispose of batteries in an environmentally friendly way. Certain regions may regulate disposal of the battery.
  • Page 89 3: Bundling the cables 5: Selecting the language 4: Preventing the TV from toppling over Connect the TV to the AC power outlet (110-240V AC, 50/60Hz). Press 1 on the TV (top side). When you switch on the TV for the first time, the Language menu appears on the screen.

  • Page 90: Auto Tuning The Tv

    To change the order in which the channels 6: Auto Tuning the TV are stored on the TV See page 26. After selecting the language, a message confirming the TV start Auto Tuning appears on the screen. To allow this menu to appear again when You must tune the TV to receive channels (TV you turn on the TV, press to select...

  • Page 91: Safety Information

    • Do not install the LCD TV on a shelf or in a closet. • Do not place the LCD TV on a rug or bed. Safety information • Do not cover the LCD TV with cloth, such as curtains, or items such as newspapers, etc.
  • Page 92 Ventilation Power Sources Leave space around the LCD TV. Otherwise, adequate air- Overloading circulation may be blocked causing overheating and cause This LCD TV is designed to fire or damage the LCD TV. operate on a 110-240V AC supply for the LCD TV. Take When installing the LCD TV on the wall care not to connect too many appliances to the same AC...

  • Page 93: Additional Safety Information

    Additional Safety Information Damage requiring service Electric shock If the surface of the LCD TV cracks, do not touch it until you Do not touch the LCD TV with a wet hand. Doing so may unplug the AC power cord. Otherwise electric shock may cause electric shock or damage the LCD TV.
  • Page 94 If the AC power cord is damaged, stop using it and ask your air conditioning. If the display unit is installed in such a dealer or Sony service center to exchange it. location, moisture may condense on the panel inside the Not in use display unit.
  • Page 95 On cleaning the screen surface/cabinet • Be sure to unplug the AC power cord connected to the LCD TV from the AC power outlet before cleaning. • To remove dust from the screen surface/cabinet, wipe gently with a soft cloth. If dust is persistent, wipe with a soft cloth slightly moistened with a diluted mild detergent solution.

  • Page 96: Overview Of The Remote

    Overview of the remote 1 "/1 – TV standby Switches off the TV temporarily. The 1 (standby) indicator on the front of the TV lights up. Press again to switch on the TV from the standby mode. 2 A/B – Dual Sound (page 21) 3 Colored buttons In Text mode (page 14): Used for Fastext.

  • Page 97: Overview Of The Tv Buttons And Indicators

    Overview of the TV buttons and indicators 1 MENU (page 17) – Input select/OK • In TV mode (page 16): Selects the input source from equipment connected to the TV jacks. • In TV menu: Selects the menu or option, and confirm the setting.

  • Page 98: Watching Tv

    Watching TV Watching TV Additional operations Do this Turn off the TV Press "/1. temporarily (Standby mode) Press %. Press 2 +/- to set the Turn on the TV from Standby mode volume level. without sound Turn off the TV Press 1 on the TV (top side).
  • Page 99 Picture Freeze For PC Input Freezes the TV picture (e.g. to make a note of a Normal telephone number or recipe). Press on the remote control. Press to adjust the position of the window. Press to remove the window. Displays the picture in its original pixel size. Bars are shown at the top, bottom, and both sides for small Press again to return to normal TV...

  • Page 100: Viewing Pictures From Connected Equipment

    Using the Tools menu Viewing pictures from Press TOOLS to display the following options when viewing pictures from connected equipment other connected equipment than PC. Options Description Switch on the connected equipment, then Close Close the Tools Menu. press repeatedly until the correct Power Saving See page 24.

  • Page 101: Using Menu Functions

    Using MENU Functions Navigating through menus “MENU” allows you to enjoy various convenient features of this TV. You can easily select channels or external inputs with the remote. Also, settings for your TV can be changed easily using “MENU”. Press MENU to display the menu. Press to select an option.

  • Page 102: Picture Menu

    Picture menu You can select the options listed below on the Picture menu. To select options in “Settings”, see “Navigating through menus” (page 17). Target Inputs Selects whether to apply settings made in the Picture menu to all inputs, or only to the input currently being watched.
  • Page 103 Sharpness Sharpens or softens the picture. Noise Reduction Reduces the picture noise (snowy picture) in a weak broadcast signal. “Auto”: Automatically reduces the picture noise. “High”/“Medium”/“Low”: Modifies the effect of the noise reduction. “Off”: Turns off the Noise Reduction feature. Advanced Settings Customizes the Picture function in more detail.

  • Page 104: Sound Menu

    Sound menu You can select the options listed below on the Sound menu. To select options in “Settings”, see “Navigating through menus” (page 17). Target Inputs Selects whether to apply settings made in the Sound menu to all inputs, or only to the input currently being watched.
  • Page 105 Dual Sound Selects the sound from the speaker for a stereo or bilingual broadcast. The selection varies, depending on the Broadcasting. Broadcasting Selection NICAM stereo NICAM (stereo sound) Mono (regular sound) NICAM bilingual NICAM Main (main sound) NICAM Sub (sub sound) Mono (regular sound) NICAM monaural NICAM Main (main sound)

  • Page 106: Screen Menu

    Screen menu You can select the options listed below on the Screen menu. To select options in “Settings”, see “Navigating through menus” (page 17). Target Inputs Selects whether to apply settings made in the Screen menu to all inputs, or only to the input currently being watched.

  • Page 107: Setup Menu

    Setup menu You can select the options listed below on the Setup menu. To select options in “Settings”, see “Navigating through menus” (page 17). Auto Startup Starts the “first time operation menu” to tune in all the available channels. Usually you do not need to do this operation because the channels are already tuned when the TV was first installed (page 5, 6).
  • Page 108 Timer Settings Sets the timer to turn on/off the TV Sleep Timer Sets a period of time after which the TV automatically switches itself into standby mode. When the “Sleep Timer” is activated, the (Timer) indicator on the TV (front) lights up in amber.

  • Page 109: Pc Settings Menu

    PC Settings menu You can select the options listed below on the PC Settings menu. To select options in “Settings”, see “Navigating through menus” (page 17). Wide Mode Selects a screen mode for displaying input from your PC. “Normal”: Displays the picture in its original size. “Full1”: Enlarges the picture to fill the display area, keeping its original horizontal- to-vertical aspect ratio.

  • Page 110: Channel Setup Menu

    Channel Setup menu You can change/set the Channel settings using the Channel Setup menu. To select options in “Settings”, see “Navigating through menus” (page 17). 1 Digit Direct When “1 Digit Direct” is set to “On”, you can select a channel using one preset number button (0 - 9) on the remote.
  • Page 111 Manual Program Before selecting “Label”/“AFT”/“Audio Filter”/“Skip”, press PROG +/- to select the program number with the channel. You cannot select a program number that is Preset set to skip. Program TV System /VHF or UHF Presets program channels manually. Select “Program”, then press Press to select the program number you want to manually tune (if tuning a VCR, select channel 00), then press RETURN.

  • Page 112: Using Optional Equipment

    DVD recorder *1Use an HDMI cable (recommended Sony HDMI cable), HDMI-to-DVI cable, or adaptor (not supplied). *2When using an HDMI cable, it is not necessary to connect the audio cable. When using an HDMI-to-DVI cable or an adaptor, it is necessary to connect the audio cable.
  • Page 113 To connect Do this To connect Do this Hi-Fi audio Connect to the audio output jacks S VHS/Hi8/DVC Connect to the S video jack equipment H to listen to the sound from the camcorder or video or the video jack 2, and the TV on the Hi-Fi audio equipment.

  • Page 114: Additional Information

    KLV-40S200A: 40 inches KLV-32S200A: 32 inches UHF: B21 to B68 / CATV: S01 to S03, S1 to S41 KLV-26S200A: 26 inches Display Resolution: VHF: C1 to C12, R1 to R12 / UHF: C13 to C57, R21 to 1,366 pixels (horizontal) × 768 lines (vertical)
  • Page 115 Sound Output 10 W + 10 W Optional Accessories Wall-Mount bracket SU-WL51 (for KLV-46S200A/KLV-40S200A) SU-WL31 (for KLV-32S200A/KLV-26S200A) Design and specifications are subject to change without notice. PC input signal Reference chart Horizontal Horizontal Vertical Signals Vertical (Line) Standard (Pixel) frequency (kHz) frequency (Hz) 31.5...

  • Page 116: Troubleshooting

    Double images or ghosting • Check antenna/cable connections. • Check the antenna location and direction. Contact a Sony dealer for advice. • Broadcast signals are reflected by nearby mountains or building. Use the fine tuning (“AFT”) function (page 27). Otherwise, use a highly direction antenna.
  • Page 117 • Keep the antenna cable away from other connecting cables. • Do not use a 300-ohm twin lead cable as interference may occur. • Adjust the antenna direction for the minimum interference. Contact a Sony dealer for advice. Picture noise when viewing a •...
  • Page 118 TV, VCR, and on the wall (page 4). distorted; • Adjust the antenna direction for the minimum interference. Contact a Sony The sound switches between dealer for advice. stereo and monaural frequently •...

  • Page 119: Index

    Index Numerics 1 Digit Direct 26 HDMI 28 Screen Format 22 4:3 Default 22 Headphones Screen menu 22 connecting 29 Setup menu 23 Horizontal Shift 22 Sharpness 19 A/B button 12 Hue 18 Skip 23 Advanced Settings 19 Sleep Timer 24 AFT 27 Sound menu 20 All Reset 24...
  • Page 120 Printed in Malaysia...

This manual is also suitable for:

Klv-32s200aKlv-40s200aKlv-32s200Klv-46s200a

Table of Contents
