- Page 1 BOOM BOX KS-SB200 INSTRUCTIONS For Customer Use: Enter below the Model No. and Serial No. which are located either on the rear, bot- tom or side of the cabinet. Retain this information for future reference. Model No. Serial No. LVT1307-001B...
- Page 2 Warnings, Cautions and Others CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage”...
- Page 3 CAUTION—POWER button! Disconnect the mains plug and remove all the batteries to shut the power off completely (all lamps and indications go off). The POWER button in any position does not disconnect the mains line. • When the unit is turned off, the power-on lamp goes off. •...
- Page 4 We would like to thank you for purchasing Boom Box. This product is designed to enjoy JVC PnP easily either inside or outside of your house. Before operating this unit, read this manual carefully and thoroughly to obtain the best possible performance from your unit, and retain this manual for future reference.
-
Page 5: Preparations
Preparations Connecting the Antenna Connect the supplied antenna by referring to the illustration. • Refer also to the manual supplied to the JVC PnP (KT- SR2000) for details. For indoor use, place the antenna closer to the window. For outdoor use, place the antenna at a location from obstructions. - Page 6 JVC PnP when attaching/removing JVC PnP. Press PUSH on the top of the unit to open the dock holder. Attach JVC PnP by sliding it down to the dock. • Press in JVC PnP firmly to the dock.
- Page 7 Putting the Batteries into the Unit Push and pull up tabs to open the battery compartment cover on the bottom of the unit to the direction of Insert 8 batteries by matching the polarity as marked on the compartment. • Insert batteries in order of number as shown in the illustration.
-
Page 8: Operations
Turning on the Power Press POWER on the unit. Turn on JVC PnP. • The sound does not come out when JVC PnP is turned off. The power-on lamp lights green. • When the power-on lamp lights red, the batteries are almost exhausted. - Page 9 • The unit changes the listening source to auxiliary equipment automatically. Note: Turn JVC PnP’s power off while listening to the auxiliary equipment to save the battery power. To listen to JVC PnP, unplug the cord from the AUX jack. AUX jack (3.5 mm stereo mini jack)
-
Page 10: Troubleshooting
Battery operation is not active if the AC adaptor is connected to the unit. The batteries are exhausted. • Antenna is not connected to the unit. • JVC PnP is not attached correctly to the dock. There are obstacles over or around the antenna. -
Page 11: Specifications
Output Level (Variable) (PHONES): 20 mV (Maximum) Connector Type (PHONES, AUX): 3.5 mm Stereo Jack Signal-to-noise ratio: 86 dB (Maximum) Speakers Speaker Type: Bass-reflex type 12.6 cm (5 inches) Tweeter 28 mm (1 - 1/8 inches) 8 Ω Speaker Impedance: Frequency Response:... - Page 12 Having TROUBLE with operation? USA ONLY Call 1-800-252-5722 http://www.jvc.com We can help you! © 2004 Victor Company of Japan, Limited © 2004 SIRIUS Satellite Radio Inc. “SIRIUS” and the SIRIUS dog logo 1004MNMMDWZAC are registered trademarks of SIRIUS Satellite Radio Inc.
