- Page 1 ® LAMP REPLACEMENT INSTRUCTIONS Replacement Lamp Kit PK-CL200U WARNING: This Lamp Kit is for use only with JVC model AV-61S902. LCT0811-001A...
- Page 2 Because the lamp contains a small amount of mercury, it cannot be disposed of with normal trash in the U.S. Packaging, with a pre-paid shipping label for returning the lamp to a JVC-authorized recycling center for recycling, is included with the replacement lamp. See the included sheet and page 63 in the AV-61S902 User’s Guide for...
-
Page 3: Check The Accessories
Check the accessories Check that nothing is missing. The kit will include: • High-Pressure Mercury Lamp • Hex Wrench • Replacement Instructions • Recycling Information Sheet • Pre-paid shipping label Replacing the Lamp 1) Turn the television off. Press the Power button on the remote control or television’s front panel to turn the television off. - Page 4 3) Remove the left speaker panel. The next step is to remove the left speaker panel locat- ed at the bottom of the front 1. Pull of the television cabinet. Make sure the television is unplugged (see steps 1 and 2) before removing the 2.
- Page 5 5) Removing the filter assembly. Next you will need to remove the filter Interlock switch assembly. To remove the assembly, use a coin to loosen the three large- slotted screws fastening the filter assembly. When the screws have been Coin etc. loosened, slide the filter assembly out to remove it.
- Page 6 The lamp assembly in this product contains mercury. Disposal of the lamp assembly may be regulated due to environmental considerations. For information on replacement, disposal or recycling procedures, please contact JVC Customer Relations at 1-800-252-5722. Handle Hex wrench Light-source lamp unit...
- Page 7 8) Install the filter unit. Position the filter assembly back into its place, being careful not to touch the surface of the filter. Position the three screws and tighten using an correct-sized coin. 9) Reinstall the filter cover. Place the filter cover over the filter. Insert the four screws and tighten them using the screwdriver.
- Page 8 Warning Messages If the lamp replacement was successful, the television will operate normally. If there was a problem with the installation, one of several messages may display on the front panel LED lights. Lamp installed on a slant or not fully inside the television. If the lamp assembly has been installed into the unit slanted (not flat) or is not fully inserted into the lamp housing inside the television, when the television is turned on the ON TIMER and POWER light...
-
Page 9: Warranty
THE DISTRICT OF COLUMBIA AND COMMONWEALTH OF PUERTO RICO. WHAT WE WILL DO: If this product is found to be defective within the warranty period, JVC will repair or replace defective parts at no charge to the original owner. Such repair and replacement services shall be rendered during regular business hours by JVC authorized service centers. - Page 10 WARRANTY OF MERCHANTABILTY, IS LIMITED TO THE DURATION OF THE EXPRESS WARRANTY HEREIN. JVC SHALL NOT BE LIABLE FOR THE LOSS OF USE OF THE PRODUCT, INCON- VENIENCE, OR ANY OTHER DAMAGES, WHETHER DIRECT, INCIDENTAL OR CONSEQUENTIAL (INCLUDING, WITHOUT LIMITATION, DAMAGE TO TAPES,...
-
Page 11: Authorized Service Centers
Please refer to qualified service personnel for repairs. Accessories To purchase accessories for your JVC product, please call toll free: 1 (800) 882-2345 or on the web at www.JVC.com To locate your local JVC service center or dealer in Canada please call:... - Page 12 JVC COMPANY OF AMERICA JVC CANADA, INC. Division of JVC Americas Corp. 21 Finchdene Square 1700 Valley Road Scarborough, Ontario Wayne, New Jersey, 07470 Canada, M1X 1A7...
