SERVICE MANUAL

TECHNICAL INFORMATION

FOR SERVICE PERSONNEL ONLY
NOTE:
This manual describes only points that differ from
PM No. 0322E, PM No. 0355E and PM No. 0366E
for items not described in this manual.
TYPE
MODEL
POWER SOURCE
TOTAL INPUT
TOTAL AMPERES
COOLING CAPACITY
HEATING CAPACITY
DIMENSIONS
NET WEIGHT
SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT

ROOM AIR CONDITIONER

APRIL 2007
RAM-90QH5
(W)
(A)
(kW)
(B.T.U.)
W
(mm)
H
D
(kg)
OUTDOOR UNIT
Refrigeration & Air-Conditioning Division
NO. 0371E
PM
RAM-90QH5
REFER TO THE FOUNDATION MANUAL
SPECIFICATIONS ------------------------------------------------------------------- 5
Installation --------------------------------------------------------------------- 16
Construction And Dimensional Diagram --------------------- 20
Wiring Diagram ---------------------------------------------------------------- 21
Main Parts Component --------------------------------------------------- 24
CIRCUIT DIAGRAM --------------------------------------------------------------- 25
Block Diagram ----------------------------------------------------------------- 29
Basic Mode ----------------------------------------------------------------------- 31
Refrigerating Cycle Diagram --------------------------------------- 51
Description Of Main Circuit Operation ----------------------- 52
Trouble Shooting ----------------------------------------------------------- 88
Parts List And Diagram -------------------------------------------------- 94
DC INVERTER FIVE SYSTEM MULTI
OUTDOOR UNIT
RAM-90QH5
1ø, 220 - 240V, 50/60Hz
REFER TO THE SPECIFICATIONS PAGE
950
800
370
71
CONTENTS
